MSA CONTENTS
AirMaXX SL 3
Contents
1. Safety Regulations ..................................................................................................5
1.1. Correct Use.....................................................................................................5
1.2. Liability Information .........................................................................................5
2. Description............................................................................................................... 6
2.1. Standard Model (AirMaXX SL)........................................................................6
2.1.1. Pressure Reducer...............................................................................7
2.1.2. Manifold ..............................................................................................7
2.1.3. SingleLine SCOUT .............................................................................8
2.2. Model AirMaXX SL-CLICK .............................................................................. 8
2.2.1. alphaCLICK 2 Coupling 300 bar.........................................................9
2.2.2. alphaCLICK 2 Cylinder Adaptor 300 bar ............................................9
2.2.3. Model AirMaXX SL-M ....................................................................... 10
2.3. Models AirMaXX SL-3C and AirMaXX SL-3N ...............................................11
2.4. Model AirMaXX SL-Q....................................................................................12
2.5. Model AirMaXX eXXtreme SL.......................................................................12
2.6. Technical Data ..............................................................................................13
3. Using the Compressed Air Breathing Apparatus ...............................................14
3.1. Prior to the First Use ..................................................................................... 14
3.2. Connecting One Compressed Air Cylinder ...................................................14
3.2.1.Pressure Reducer with Screw Coupling ...........................................14
3.2.1.1. Preparing the Apparatus for Use with One Compressed Air
Cylinder.........................................................................................14
3.2.1.2. Connecting One Compressed Air Cylinder ................................... 15
3.2.2. Pressure Reducer with alphaCLICK 2 .............................................. 16
3.2.2.1. Installing Quick Connect Adaptor to Cylinder................................16
3.2.2.2. Connecting One Compressed Air Cylinder ................................... 17
3.3. Connecting Two Compressed Air Cylinders.................................................. 19
3.3.1. Pressure Reducer with Screw Coupling ...........................................19
3.3.1.1. Preparing the Apparatus for Use with Two Compressed Air
Cylinders....................................................................................... 19
3.3.1.2. Connecting Two Compressed Air Cylinders..................................19
3.3.2. Pressure Reducer with alphaCLICK 2 ..............................................20
3.4. Adjusting the Back Plate ...............................................................................21
3.5. Donning the Compressed Air Breathing Apparatus ......................................21
3.6. Condensed Check Prior to Use.....................................................................22
3.7. Donning the Full Face Mask ......................................................................... 22
3.8. During Use ....................................................................................................22
3.9. Use of the Second Connection .....................................................................23
3.10. Handling the Warning Device........................................................................23
3.11. Filling with Quick-Fill ..................................................................................... 24

CONTENTS MSA
4 AirMaXX SL
3.12. Removing the Compressed Air Breathing Apparatus.................................... 24
3.13. Removing the Compressed Air Cylinders ..................................................... 25
3.13.1. Pressure Reducer with Screw Coupling ........................................... 25
3.13.2. Pressure Reducer with alphaCLICK 2 .............................................. 25
4. Maintenance and Care of the SCBA..................................................................... 27
4.1. Maintenance Instructions .............................................................................. 27
4.2. Maintenance Intervals................................................................................... 28
4.2.1. Test Intervals for all Countries (except Germany) ............................ 28
4.3. Cleaning........................................................................................................ 29
4.3.1. Pre-cleaning ..................................................................................... 29
4.3.2. Cleaning, Light Soiling...................................................................... 29
4.3.3. Cleaning, Heavy Soiling ................................................................... 29
4.4. Instructions for Assembling the Pressure Reducer ....................................... 31
4.5. Visual, Function and Tightness Check.......................................................... 31
4.6. Warning Device Check ................................................................................. 32
4.7. High pressure Gaskets Check ...................................................................... 32
4.8. Overhaul ....................................................................................................... 32
4.9. Storage ......................................................................................................... 32
4.10. Malfunctions.................................................................................................. 32
5. Changing/Filling of Compressed Air Cylinders to alphaCLICK 2 ............................... 33
5.1. Changing of Compressed Air Cylinders to alphaCLICK 2............................. 33
5.2. Filling of Compressed Air Cylinders with alphaCLICK 2 ............................... 34
6. Accessories ........................................................................................................... 36
6.1. Compressed Air Cylinders ............................................................................ 36
6.1.1. Compressed Air Cylinders................................................................ 36
6.1.2. Valves............................................................................................... 36
6.1.3. T-Pieces ........................................................................................... 36
6.2. Lung Governed Demand Valve / Full Face Mask.......................................... 36
7. Ordering Information............................................................................................. 37
7.1. Compressed Air Cylinders ............................................................................ 37
7.2. Lung Governed Demand Valve..................................................................... 37
7.3. Compressed Air Cylinders ............................................................................ 38
7.4. Accessories................................................................................................... 39
7.5. Upgrading Options ........................................................................................ 40
7.6. Work Shop Accessories................................................................................ 41

MSA SAFETY REGULATIONS
AirMaXX SL 5
1. Safety Regulations
1.1. Correct Use
The MSA AirMaXX SL (hereinafter referred to as compressed air breathing
apparatus) is a self-contained breathing apparatus operating independently of the
ambient air.
In combination with a certified facepiece (full face mask) the device protects the
wearer against inhalation of hazardous substances and mixtures, harmful
biological agents and oxygen deficiency.
Breathable air is supplied to the user from (a) compressed air cylinder(s) via a
pressure reducer, a demand controlled dosage assembly (see Instruction Manual
for the Lung Governed Demand Valve) and a facepiece (see Instruction Manual
for the Facepiece). The exhalation air is released directly into the ambient
atmosphere.
It is imperative that this operating manual be read and observed when using the
compressed air breathing apparatus. In particular, the safety instructions, as well
as the information for the use and operation of the apparatus, must be carefully
read and observed. Furthermore, the national regulations applicable in the user's
country must be taken into account for a safe use.
Alternative use, or use outside this specifications will be considered as non-
compliance. This also applies especially to unauthorised alterations to the
apparatus and to commissioning work that has not been carried out by MSA or
authorised persons.
Danger!
This product supports life and health. Inappropriate use, maintenance
or servicing may affect the function of the device and thereby seriously
compromise the user’s life.
Before use, the product operability must be verified. The product must
not be used if the function test is unsuccessful, it is damaged, a
competent servicing/maintenance has not been made, genuine MSA
spare parts have not been used.
Danger!
This compressed air breathing apparatus is a pure gas protection
device. It is not suitable for underwater diving.
1.2. Liability Information
MSA accepts no liability in cases where the product has been used
inappropriately or not as intended. The selection and use of the product are the
exclusive responsibility of the individual operator.
Product liability claims, warranties also as guarantees made by MSA with respect
to the product are voided, if it is not used, serviced or maintained in accordance
with the instructions in this manual.

DESCRIPTION MSA
6 AirMaXX SL
2. Description
Fig.
1 AirMaxx SL compressed air breathing apparatus
1
Manifold
8
Handle
2
Cylinder separator
9
Catch clip
3
Cylinder retaining strap
10
Push lock
4
Cylinder support
11
Quick-Fill coupling (Option)
5
Tension clamp
12
Pressure reducer
6
Shoulder strap
13
Single line
7
Back plate
14
Hip belt
2.1. Standard Model (AirMaXX SL)
The two-piece back plate of the compressed air breathing apparatus is adjustable
to three different lengths and should be adjusted to the user's height. The single
line passes through the sliding upper part from the pressure reducer to the
manifold.
The carrying belts and the hip belt are adjustable in length. The hip belt is fixed to
the back plate elastically. It will automatically return to the horizontal position on
installation.
One or two compressed air cylinders can be placed in the cylinder support. The
cylinder retaining strap is freely adjustable and after inserting the compressed air
cylinder(s), it is tightened and secured using the tension clamp.
5
6
1
2
7
8
10
11
12
13
14
9
3
4

MSA DESCRIPTION
AirMaXX SL 7
2.1.1. Pressure Reducer
Fig. 2 Pressure reducer
1
Single line connection
2
Compressed air cylinder connection
3
Quick-Fill coupling (not for standard model)
4
Lead seal
The pressure reducer is mounted in the lower area of the back plate (Fig. 2).
On the pressure reducer, there is a relief valve and the single line for connecting
the manifold. The pressure reducer reduces the cylinder pressure to
approx. 7 bar and the relief valve activates on non-permitted pressure rise to
prevent damage insuring the continued supply of breathable air.
2.1.2. Manifold
Fig. 3 Manifold
1
Pressure gauge
2
Lung governed demand valve coupling
3
Warning device (signal whistle)
4
Second connection
The manifold (Fig. 3) is connected at the end of the single line. It consists of
the pressure gauge (1), the coupling for the lung governed demand valve (2) as
well as an acoustic warning device (3) (signal whistle). It triggers a continuous
warning signal when the cylinder pressure drops below 55±5 bar. The second
connection (4) connects a second lung governed demand valve (e.g. rescue kit).
3
1
2
3
1
2
4
4

DESCRIPTION MSA
8 AirMaXX SL
2.1.3. SingleLine SCOUT
See additional manual SingleLine SCOUT.
2.2. Model AirMaXX SL-CLICK
The difference between this model and the standard model is the modified
pressure reducer, the constituent part of the alphaCLICK 2 coupling system.
It is also available as the standard model and in the SL-M, SL-Q and
eXXtreme SL versions.
Fig. 4 Pressure reducer
1
alphaCLICK 2 coupling
alphaCLICK 2 permits the easy, quick and safe connection of the compressed air
cylinders to the pressure reducer. Time-consuming screwing-on of the cylinder is
no longer required since the cylinder is simply slotted into the pressure reducer.
alphaCLICK 2 is safer than the usual standard connection:
•alphaCLICK 2 cannot be disconnected when the system is pressurised.
•Two steps are required to disconnect it: the cylinder can only be removed
when the safety ring has been turned through 20 degrees and pushed
back.
•alphaCLICK 2 has no built-in flow restrictor.
•Moreover, alphaCLICK 2 has a flat face design which keeps the
components clean and operative.
alphaCLICK 2 fits all standard breathable air valve threads [EN 144-2].
alphaCLICK 2 is only available for 300 bar.
1

MSA DESCRIPTION
AirMaXX SL 9
2.2.1. alphaCLICK 2 Coupling 300 bar
Fig. 5 alphaCLICK 2 coupling 300 bar
1
alphaCLICK 2 coupling 300 bar
2
Indicator ring with arrow
2.2.2. alphaCLICK 2 Cylinder Adaptor 300 bar
Fig. 6 alphaCLICK 2 cylinder adaptor 300 bar
1
alphaCLICK 2 cylinder adaptor 300 bar
The cylinder adaptor has to be screwed into a cylinder valve with a
specific torque of 20-30 Nm.
1
2
1

DESCRIPTION MSA
10 AirMaXX SL
2.2.3. Model AirMaXX SL-M
Besides the standard unit fittings, this model also comes with a built-in short
range transmitter (alphaMITTER). This is assembled on the back plate of the
compressed air breathing apparatus and connected via an additional line to the
pressure reducer.
It is also available as the standard model and in the SL-Q and eXXtreme SL
versions.
Fig. 7 Model AirMaxx SL-M
1
Manifold
8
Back plate
2
Handle
9
alphaMITTER (Option)
3
Cylinder separator
10
Catch clip
4
Cylinder retaining strap
11
High pressure line
5
Cylinder support
12
Pressure reducer
6
Tension clamp
13
Single line
7
Shoulder strap
14
Hip belt
As soon as the system is pressurised it automatically starts to search for a
partner to transfer data to.
The alphaMITTER measures the high pressure of the compressed air cylinder(s)
and transmits this every 2 seconds via short range radio to the alphaSCOUT /
alphaSCOUT TM.
For detailed information on the alphaMITTER see the operating manual for the
"alpha personal network".
8
9
10
11
12
13
3
4
5
7
1
2
6
14

MSA DESCRIPTION
AirMaXX SL 11
2.3. Models AirMaXX SL-3C and AirMaXX SL-3N
The versions AirMaXX SL-3C and AirMaXX SL-3N differ from the standard
version in that they have an additional medium pressure connection.
They are available as the standard model and in the SL-Q and eXXtreme SL
versions.
Fig. 8 SCBA Basic Apparatus AirMaXX SL with additional medium pressure
connection
1
Additional medium pressure connection
2
Coupling/Nipple
The version AirMaXX SL-3C is equipped with a coupling and the version
AirMaXX SL-3N is equipped with a nipple and an integrated non-return valve.
The version AirMaXX SL-3C is prepared for the connection of the following
equipment:
•Rescue set (mask with lung governed demand valve)
•Rescue equipment e.g. Respihood
•Compressed air tubing equipment with or without automatic change-over
valve
and for use in a protective overall including decontamination process.
The version AirMaXX SL-3N is prepared for the connection of the following
equipment:
•Compressed air tubing equipment without automatic change-over valve
and for use in a protective overall including decontamination process.
2
1

DESCRIPTION MSA
12 AirMaXX SL
2.4. Model AirMaXX SL-Q
Besides the standard unit fittings, this model also comes with a high pressure
safety coupling (Pos. 3 in Fig. 2). It is then possible to fill 300 bar compressed
air cylinder(s) whilst the compressed air breathing apparatus is in use.
Warning!
On compressed air breathing apparatus with Quick-Fill couplings, the
use of 200 bar compressed air cylinders is not possible.
2.5. Model AirMaXX eXXtreme SL
This model is essentially distinguished from the standard model by a heatproof
harness, chrome-plated buckles and protecting channels for the lines on the
shoulder straps.
It is also available as the standard model and in the SL-Q and SL-M versions.

MSA DESCRIPTION
AirMaXX SL 13
2.6. Technical Data
High pressure : 200 bar resp. 300 bar
Medium pressure : 5 bar to 9 bar
Operating : -30°C to +60°C
Weight (approx.) : 3.7 kg
Dimensions
:
Length
575 mm
Width 300 mm
Height 135 mm
Approvals : The compressed air breathing apparatus
conforms to Directive 89/686 EEC or
Regulation (EU) 2016/425, respectively, and
Directive 2014/34/EU. It is a container unit with
compressed air in accordance with EN 137.
DEKRA EXAM GmbH, Dinnendahlstr. 9,
44809 Bochum (Germany), Notified
Body Number: 0158.
ATEX
BVS 05 ATEX H 027 X
IM1
II 1 G IIC T6 -30 °C ≤Ta ≤+60 °C
II 1 D
The product complies with "Technical Regulation
on Safety of Maritime Transport" (TP 620) of the
Russian Federation.
OKP code: 641830 "Fire fighter Equipment -
self-contained breathing apparatus operated on
compressed air."
Dispose in accordance with the recommendations
of the ship manufacturer together with the vessel,
in accordance with a unique technological
process, taking into consideration
MANUFACTURER PRODUCT DECLARATION,
see appendix.
Type Approval Certificate of Russian
Maritime Register of Shipping
The Declaration of Conformity can be found under the following link:
https://MSAsafety.com/DoC

USING THE COMPRESSED AIR BREATHING APPARATUS MSA
14 AirMaXX SL
3. Using the Compressed Air Breathing Apparatus
Warning!
The compressed air breathing apparatus may only be put into use in
a fully maintained and tested condition. If malfunctions or defects
are noticed prior to use, do not use the compressed air breathing
apparatus under any circumstances.
Get the apparatus checked and repaired by an authorised service
centre.
3.1. Prior to the First Use
Prior to the first use, the apparatus must be prepared for the number and types of
compressed air cylinders. Afterwards, when changing compressed air cylinders
(without attached bumpers) that have the same diameter, the closed loop of the
tension strap is increased or again tightened by opening or closing the tension
clamp. A re-adjustment of the length of the tension strap and a loosening of the
Velcro closure then is no longer required.
(1) Before installing the threaded handwheel, check that the O-ring inside the
handwheel high pressure socket is present and free of damage. If the O-ring
is damaged, it must be replaced before the SCBA is used.
(2) Thread the handwheel into the cylinder thread. The handwheel should be
hand-tight (no tools should be used).
3.2. Connecting One Compressed Air Cylinder
Fig. 9 SCBA apparatus with one compressed air cylinder
3.2.1. Pressure Reducer with Screw Coupling
3.2.1.1. Preparing the Apparatus for Use with One Compressed Air Cylinder
(1) Hinge down the cylinder separator that is in the middle of the cylinder
support into a horizontal position until it catches.
(2) If necessary, disconnect T-piece from high pressure socket of pressure
reducer.

MSA USING THE COMPRESSED AIR BREATHING APPARATUS
AirMaXX SL 15
Fig. 10 Compressed air breathing apparatus – details
1
Cylinder separator
3
Cylinder support
2
Cylinder retaining strap
4
Tension clamp
3.2.1.2. Connecting One Compressed Air Cylinder
(1) Place compressed air breathing apparatus horizontally so that the back face
is uppermost (Fig. 10).
(2) Bring cylinder separator (1) into a horizontal position opposite the tension
clamp (4) until it catches.
(3) Check gasket on pressure reducer high pressure socket for proper condition.
(4) Open tension clamp on cylinder strap eliminating any tension by extending
the strap to full length pulling the small bar at the tension clamp (Fig. 11).
Fig. 11 Opening the tension clamp
(5) Push compressed air cylinder through the cylinder strap (2) with the cylinder
valve toward the pressure reducer, so that it lies on the central support (3).
(6) Screw cylinder valve onto pressure reducer, if necessary, bring the
compressed air breathing apparatus with valve up into a vertical position.

USING THE COMPRESSED AIR BREATHING APPARATUS MSA
16 AirMaXX SL
(7) Put the SCBA back into the horizontal position. Check that the cylinder is
laying on the central support (3).
(8) Tighten cylinder strap (2) gently by pulling the free end.
Attention!
Do not overtighten the cylinder strap! Damage can occur when using
excessive force to close the tension clamp and the SCBA might not be
ready for use.
The final fastening tension will be achieved when closing the tension
clamp.
(9) Check position of compressed air cylinder, retighten if necessary.
(10) Hinge tension clamp gently and completely down over the centre until it
catches.
(11) If push force/tension is too high during hinging of the tension clamp,
re-adjust the strap length at the tension clamp. If the strap tension is too low,
re-adjust the strap length at the tension clamp (Fig. 12).
Fig. 12 Readjusting the strap length at the tension clamp
(12) Fasten end of the cylinder retaining strap onto Velco strip.
(13) Briefly open cylinder valve and check for escaping air, retighten if necessary.
3.2.2. Pressure Reducer with alphaCLICK 2
3.2.2.1. Installing Quick Connect Adaptor to Cylinder
(1) Use only a fully charged cylinder and inspect the internal coupling of the
cylinder valve to ensure it is not damaged and free of dirt and debris.
•The screw coupling of the cylinder valve must be undamaged and free
from dirt and debris.
•If the cylinder valve is damaged, remove from service and return it to a
MSA trained or certified repair technician.
1
2

MSA USING THE COMPRESSED AIR BREATHING APPARATUS
AirMaXX SL 17
(2) Inspect the external couplings of the cylinder adaptor and the nipple of the
male connector on the pressure reducer to ensure they are not damaged
and free of dirt and debris.
•Ensure that the O-ring is installed on the cylinder adaptor and it is
undamaged and free of dirt and debris.
(3) Thread the adaptor with a specific torque of 20-30 Nm into the cylinder
valve.
(4) Before installing, ensure there is no dirt or debris on either the male or
female end of the coupling. Ensure the adaptor on the cylinder valve is tight.
(5) Push the quick connect coupling (using light force) onto the male adaptor of
the pressure reducer until an audible snap is heard. The handwheel will
rapidly rotate approx. 45° counter-clockwise indicating that the valve is
connected to the pressure reducer.
(6) Grasp the handwheel firmly and pull on it to ensure the handwheel is fully
attached.
Fig. 13 Compressed air cylinder with alphaCLICK 2
1
Compressed air cylinder with alphaCLICK 2 cylinder adaptor
2
alphaCLICK 2 coupling
3
Pressure reducer
3.2.2.2. Connecting One Compressed Air Cylinder
(1) If necessary, screw the alphaCLICK 2 cylinder adaptor with a specific torque
of 20-30 Nm into the cylinder valve.
(2) Place compressed air breathing apparatus horizontally so that the back face
is uppermost (Fig. 10).
(3) Bring cylinder separator (1) into a horizontal position opposite the tension
clamp (4) until it catches.
When fitting the compressed air cylinder on the coupling of the pressure
reducer, it may tip down. In this case, support the pressure reducer with
your hand.
2
3
1

USING THE COMPRESSED AIR BREATHING APPARATUS MSA
18 AirMaXX SL
(4) Open tension clamp on the cylinder strap eliminating any tension by
extending the strap to full length pulling the small bar at the tension clamp
(Fig. 11).
(5) Push compressed air cylinder through the cylinder strap (2) with the cylinder
valve toward the pressure reducer so that it lies on the central support (3).
(6) Align the compressed air cylinder with the alphaCLICK 2 axially to the
coupling and fit on the alphaCLICK 2 coupling.
Attention!
Never push the coupling system together using excessive force.
(7) Close the coupling by pushing together using a "small amount" of force and
checking that the arrow of the indicator ring is vertically aligned with the back
plate.
(8) Tighten cylinder strap gently by pulling the free end.
Attention!
Do not overtighten the cylinder strap! Damage can occur when using
excessive force to close the tension clamp and the SCBA might not be
ready for use.
The final fastening tension will be achieved when closing the tension
clamp.
(9) Check position of compressed air cylinder, re-position if necessary.
(10) Hinge tension clamp (4) gently and completely down over the centre until it
catches.
(11) If push force/tension is too high during hinging of the tension clamp,
re-adjust the strap length at the tension clamp. If the strap tension is too low,
re-adjust the strap length at the tension clamp (Fig. 12).
(12) Fasten end of the cylinder retaining strap onto Velcro strip.
(13) Briefly open cylinder valve and check for escaping air, retighten if necessary.

MSA USING THE COMPRESSED AIR BREATHING APPARATUS
AirMaXX SL 19
3.3. Connecting Two Compressed Air Cylinders
3.3.1. Pressure Reducer with Screw Coupling
Fig. 14 SCBA apparatus with twin compressed air cylinders
3.3.1.1. Preparing the Apparatus for Use with Two Compressed Air Cylinders
(1) Hinge up the cylinder separator to a vertical position in the middle of the
cylinder support until it catches.
(2) Connect T-piece to high pressure socket of pressure reducer.
3.3.1.2. Connecting Two Compressed Air Cylinders
(1) Place compressed air breathing apparatus horizontally so that the back face
is uppermost (Fig. 10).
(2) Hinge cylinder separator (1) into a vertical position until it catches.
(3) If there is no T-piece connected to the pressure reducer, check gaskets on
pressure reducer and T-piece and screw in T-piece loosely.
(4) Open tension clamp on cylinder strap eliminating any tension by extending
the strap to full length pulling the small bar at the tension clamp (Fig. 12).
(5) Push one compressed air cylinder through the cylinder retaining strap so
that the cylinder valve points to the T-piece, and lies on one of the outer
supports.
(6) Loosely screw the cylinder valve onto the T-piece.
(7) Push a second compressed air cylinder through the cylinder retaining strap so
that the cylinder valve points to the T-piece and lies on the outer support.
(8) Loosely screw the second cylinder valve onto the T-piece.
With right-angled T-piece, align the compressed air cylinders by hinging
the pressure reducer and pulling the cylinders together (see Operating
Manual for T-pieces).
(9) Tighten all three high pressure connection handwheels.

USING THE COMPRESSED AIR BREATHING APPARATUS MSA
20 AirMaXX SL
(10) Briefly open cylinder valves and check for escaping air, retighten if
necessary.
(11) Tighten cylinder strap gently by pulling the free end.
Attention!
Do not overtighten the cylinder strap! Damage can occur when using
excessive force to close the tension clamp and the SCBA might not be
ready for use.
The final fastening tension will be achieved when closing the tension
clamp.
(12) Hinge tension clamp down until it catches.
(13) If push force/tension is too high during hinging of the tension clamp,
re-adjust the strap length at the tension clamp. If the strap tension is too low,
re-adjust the strap length at the tension clamp (Fig. 12).
(14) Fasten end of the cylinder retaining strap onto Velco strip.
(15) Check that compressed air cylinders are held securely, retighten if
necessary.
3.3.2. Pressure Reducer with alphaCLICK 2
(1) If necessary, screw the alphaCLICK 2 cylinder adaptor with a specific torque
of 20-30 Nm into in the T-piece.
(2) Place compressed air breathing apparatus horizontally so that the back face
is uppermost (Fig. 10).
(3) Hinge cylinder separator (2) into a vertical position until it catches.
(4) Open tension clamp on cylinder strap eliminating any tension by extending
the strap to full length pulling the small bar at the tension clamp (Fig. 12).
(5) Push one compressed air cylinder through the cylinder retaining strap so
that the cylinder valve points to the T-piece, and lies on one of the outer
supports.
(6) Screw the cylinder valve onto the T-piece.
(7) Push a second compressed air cylinder through the cylinder retaining strap
so that the cylinder valve points to the T-piece, and lies on the outer support.
(8) Screw the second cylinder valve onto the T-piece.
When fitting the T-piece with alphaCLICK 2 on the coupling of the
pressure reducer it may tip down.
In this case, support the pressure reducer with your hand.
(9) Align the T-piece with the alphaCLICK 2 axially to the coupling and fit on the
alphaCLICK 2 coupling.
Attention!
Never push the coupling system together using excessive force.
