Assembly Instructions
Eloquence™ Series
Ganging Center and
Corner Tables
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent. If you
have any questions concerning these instructions, please call National Customer Service.
SEATING
1Figure A
Telephone [phone]
Fax [phone]
www.nationalonline.com
Part #2064345
Printed in U.S.A
© 2007 Kimball International, Inc.
Ganging Center Table:
Position chairs to be ganged evenly
apart (approximately two feet) so that the
table will be able to rest on side rails of each
chair (Figure A).
2With angled shims on table toward rear,
position table so it rests on the side rails
of each chair. Squeeze chairs inward
toward table for tight fit. Observe that
table top is level to floor. If not, check
that angled shims are toward rear of
chairs (Figure B).
Recommended Tools
• Cordless Drill
Figure B
Package Contents Qty.
• Center/Corner Ganging Table 1
• U-Brackets 4
• #10 x 3/4” Screws 16
3Figure C
On one side, place two (2) U-brackets over
the side rails of both chair and table.
Note: U-brackets are NOT symmetrical.
When placing U-brackets, make sure
holes line up on center of both table
and chair rails.
Repeat for other side (Figure C).
4Using a cordless drill, insert four (4)
#10 x 3/4” screws in the U-bracket
(Figure D).
Figure D
5Repeat Step 4 to fasten remaining
U-brackets.
6Figure E
After U-brackets are installed, inspect
that table top is tightly secured and
level with floor (Figure E).

1Figure A
Ganging Corner Table:
Carefully uncarton and place worksurface
face down on a smooth, clean, soft surface
(Figure A).
2Remove legs from packaging and
insert threaded end of one leg into
the hole on the bottom of table.
Turn leg clockwise until tightened
(Figure B).
Figure B
3Figure C
Repeat Step 2 to fasten remaining leg
(Figure C).
4Position chairs (to be ganged perpendicular
to one another) facing inward and spaced
apart so that the table will be able to rest
on side rails of each chair (Figure D).
Figure D
5With legs of table aligned with back
legs of chairs, position table so it rests
on the side rails of each chair. Squeeze
chairs inward toward table for tight fit
(Figure E).
Figure E
