Nautilus Hyosung MONiMAX7800I User manual

Operator Manual
MONiMAX7800I System
V01.00.00 (2016. 11. 17)
© 2016 Nautilus Hyosung Inc. All Rights Reserved.

© 2016 Nautilus Hyosung Inc. All Rights Reserved. I
Revision History
Operator Manual - MX7800I System
No.
Version
Date
Description of Change
Chapter
1
V01.00.00
2016/11/17
New Publication
All
© 2016 Nautilus Hyosung All Rights Reserved.
The content of this specification is protected by copyright laws.
2016. 11. 17. 1st Release

II © 2016 Nautilus Hyosung Inc. All Rights Reserved.
Contents
Chapter1. Preface...........................................................................................................................1-1
Purpose ........................................................................................................................................................1-1
Audience.......................................................................................................................................................1-1
Support Information......................................................................................................................................1-1
What is in This Manual .................................................................................................................................1-1
Terminologies ...............................................................................................................................................1-2
Abbreviations................................................................................................................................................1-2
Safety Precautions .......................................................................................................................................1-4
Related Document ........................................................................................................................................1-6
Chapter2. Introduction ...................................................................................................................2-1
About the MX7800I.......................................................................................................................................2-1
The Exterior Overview..................................................................................................................................2-2
Basic Features..............................................................................................................................................2-3
Devices of MX7800I .....................................................................................................................................2-7
Control Electronics (CE, PC)······························································································2-7
Customer Display & Keypad·······························································································2-8
Advertisement Display······································································································2-9
Teller Display················································································································ 2-10
Cash Dispenser Unit (CDU) ····························································································· 2-11
Card Reader················································································································· 2-12
Receipt Printer (SPR) ····································································································· 2-13
Cash & Check In Module (CCIM) ······················································································ 2-14
Power Supply ··············································································································· 2-15
Coin Dispenser ············································································································· 2-16
RF Reader ··················································································································· 2-17
ID Scan ······················································································································· 2-18
Video Banking··············································································································· 2-19
Safety & Security··········································································································· 2-20
Additional Function ········································································································ 2-22
Chapter3. For the beginning operator...........................................................................................3-1
Opening the Exterior Door............................................................................................................................3-1
Opening the Security Enclosure...................................................................................................................3-2
Accessing the Teller Display.........................................................................................................................3-3
Switching Power On/Off ...............................................................................................................................3-4
Switching Power On·········································································································3-4
Switching Power Off·········································································································3-5
Power Supply Status ········································································································3-6
Opening/Closing the Security Enclosure (Security Door) ............................................................................3-7
Environment ...............................................................................................................................................3-12
General Guidelines to Environmental Exposure···································································· 3-12
Heater························································································································· 3-13
Chapter4. Cash & Check In Module (CCIM) ..................................................................................4-1
Basic Specification of Cash & Check In Module ..........................................................................................4-3
Specification of External Appearance ..........................................................................................................4-4
Cash & Check Conditions ............................................................................................................................4-5
How to remove jam from each section.........................................................................................................4-6
Remove jam from Bundle Module························································································4-8
Remove jam from the First Transport Path ············································································4-9
Remove jam from BC ····································································································· 4-10
Remove jam from ALG···································································································· 4-11
Remove jam from Recog Transport Section········································································· 4-12
Remove jam from the B2 Upper Transport Path of BM2 ························································· 4-13

© 2016 Nautilus Hyosung Inc. All Rights Reserved. III
Remove jam from the B2 Upper Transport Path of BM2··························································4-14
Remove jam from B2 Reject Transport Section·····································································4-15
Remove jam from B3 Transport Section ··············································································4-16
Remove jam from Reject Section·······················································································4-17
Remove jam from B3 Escrow Transport Section····································································4-18
Remove jam from B4 Transport Section ··············································································4-19
Remove jam from Escrow ································································································4-20
Remove jam from RT/A6 Cassette ·····················································································4-21
Remove jam from Cassette ······························································································4-23
How to change PRT Maintenance Module.................................................................................................4-25
How to replace Ink cartridge ·····························································································4-25
How to reset PRT Cartridge Count ·····················································································4-26
How to replace Ink Head Cleaner Felt·················································································4-28
Chapter5. Cash Dispenser.............................................................................................................5-1
Bill Conditions...............................................................................................................................................5-1
Acceptable condition········································································································ 5-1
Unacceptable condition····································································································· 5-2
How to Replenish the Cash Cassette...........................................................................................................5-6
How to Empty the Reject/Retract Box........................................................................................................5-10
How to Clear Jamming in cash dispenser..................................................................................................5-13
Remove jam from the upper horizontal transport path·····························································5-14
Remove jam from the vertical transport path·········································································5-16
Remove jam from the carriage ··························································································5-17
Remove jam from the transport path of the main body····························································5-18
Remove jam from the transport path of RJ/RT box·································································5-19
Remove jam from the separation part ·················································································5-20
Remove jam from the transport path of reject ·······································································5-21
How to Reset Main Board...........................................................................................................................5-22
How to set the Cassette for Each Denomination .......................................................................................5-23
Cassette Base Guide Setting for the Horizontal Size of Each Denomination································5-23
Cassette Cover Guide Setting for the Vertical Size of Each Denomination ··································5-27
Change Note Index·········································································································5-29
Chapter6. Receipt Printer...............................................................................................................6-1
Receipt Paper...............................................................................................................................................6-1
How to load the receipt paper.......................................................................................................................6-2
How to clear jamming in receipt printer........................................................................................................6-4
Chapter7. Coin Dispenser..............................................................................................................7-1
Replenishing the Coin Dispenser.................................................................................................................7-1
Clearing a coin jam.......................................................................................................................................7-3
Chapter8. ID Scanner.....................................................................................................................8-1

Operator Manual Chapter1. Preface
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 1-1
Chapter1. Preface
Purpose
▶This manual is produced to describe how the customers operate Nautilus Hyosung’s
MX7800I.
This manual details how the customers replenish the notes, paper and coins and how
they remove the jam at the MX7800I.
Audience
▶Customers and staffs of Nautilus Hyosung who use and operate the MX7800I in each
branches of bank.
Support Information
▶If any question or error occurs while operating MX7800I in compliance with this
manual, please contact maintenance staffs of Nautilus Hyosung.
For the contact of maintenance staffs of Nautilus Hyosung, see the E-mail addresses
and telephone numbers provided separately.
What is in This Manual
▶MONiMAX referred to as “MX”
▶This manual is designed to provide the operation guide for the MX7800I and the
detailed description of the following:
▪Replenishing the notes and the receipt paper
▪Emptying the notes and the checks
▪Removing the jam like the notes, the check and the receipt paper
▶All information described in this manual is a licensed product of Nautilus Hyosung.
Some of the information in this manual may differ according to the network processor
to be connected and may be subsequently updated by the bank’s needs or the
improvement by Nautilus Hyosung.
It is the policy of Nautilus Hyosung to improve products as new technology,

Chapter1. Preface Operator Manual
1-2 © 2016 Nautilus Hyosung Inc. All Rights Reserved.
components, software, and firmware become available. Therefore Nautilus Hyosung
reserves the right to change specifications without notice.
Other company names and product names described in this document are trademarks
or reigstered trademarks of each company. For the section of that product, the whole
section or a necessary part of relevant document is quoted.
Terminologies
▶In this document the terminology listed below is used as follows:
▪Customer and consumer refer to any person who transacts business through the
ATM.
▪Device and unit refer to the standard and optional ATM equipment, such as monitor,
card reader, printer and dispenser.
▪Fascia refers to the entire front portion of the unit, including the portion where the
customer transacts business.
▪Module refers to a plug-in device that can be serviced or replaced.
▪Note(s) and bill(s) refer to the individual documents loaded into and dispensed from
the dispenser.
▪Servicing and maintenance refer to the supervisor, operator and technician’s tasks
performed to keep the ATM operational.
▪Screen refers to the text appearing on the customer display.
Abbreviations
▶In this document the abbreviations listed below is used as follows:
#
Abbreviations
Description
1
AD board
Analog to Digital conversion board
2
ADA
The American Disabilities Act
3
ALG
Alignment Module
4
AP
Application Program
5
Assy
Assembly
6
BATT S/W
Battery Switch
7
BC
Bill Checker
8
BM1
Body Module1
9
BM2
Body Module2
10
BM3
Body Module3

Operator Manual Chapter1. Preface
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 1-3
#
Abbreviations
Description
11
BUNDLE
Bulk Note Separation Module
12
CAM
Camera Unit
13
CASSETTE
Cash & Check Cassette
14
CCIM
Cash & Check In Module
15
CCR
Contactless Card Reader
16
CDU
Cash Dispenser Unit
17
CE
Control Electronics
18
Earphone Jack
Voice Converter for Visually Disabled Persons (ADA)
19
EMV
Europay, Mastercard, Visa
20
EP
Elementary Program
21
EPP
Encryption PIN Pad
22
Escrow
Escrow Module
23
FELT
Ink Head Cleaner Felt
24
H/W
Hardware
25
I/F
Interface
26
ISO
International Standard Organization
27
JPR
Journal Printer
28
LCD
Liquid Crystal Display
29
MCU
Magnetic Card Unit
30
OPL
Operation Panel for Customers to Operate
31
OSD board
On Screen Display Board
32
P/S
Power Supply
33
PIN
Personal Identification Number
34
PNC
Panel Control Board
35
PRT
Endorsement Module
36
PTR
Printer (mainly Receipt Printer)
37
RECOG
Recognition Module
38
REJECT
Reject Module
39
RT/A6
Retract & A6 Cassette
40
S/W
Switch
41
SCM
Separator Control Module
42
SIU
Sensor and Indications Unit
43
SP
Service Provider
44
SPR
Slip Printer (Receipt Printer)
45
TTU
Text Terminal Unit (OPL or SPL)
46
VFD
Vacuum Fluorescent Display

Chapter1. Preface Operator Manual
1-4 © 2016 Nautilus Hyosung Inc. All Rights Reserved.
Safety Precautions
▶Common Safety Precaution
Safety Precautions in outlined this manual provide information
on safe and proper handling of the product. Non-compliance of
the safety precautions may result in injury or damage to the
product.
This precaution symbol with sample term tells you safety
warnings during equipment handlings.
▶Please read the following instructions before operating equipment.
▪Operate equipment in the order outlined in this manual.
▪Follow precautions indicated in this manual, as well as the equipment itself.
Failure to properly address these precautions may lead to injury or damage to the
product.
▪Avoid operations not addressed in this manual.
▪If you cannot remedy system problems using the methods outlined in this manual,
please refer to contact information listed in the manual.
▪Any change or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
<Note!>
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
▶CAUTION
1. To reduce the risk of fire, use only No. 26 AWG OR LARGER Telecommunication
cord
2. Risk of explosion if battery is replaced by an incorrect type.
Dispose used batteries according to the instructions.
3. For pluggable equipment, the socket-outlet shall be installed near the equipment and
shall be easily accessible.
4. The equipment is to be secured to the building structure before operation
5. A security container shall be permitted to optionally be provided with a secondary
lock, but improper use of the secondary lock feature will reduce the security level of
the ATM.

Operator Manual Chapter1. Preface
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 1-5
▶Description of Precaution Symbols
Symbol
Description
Electrical Shock Warning
▪Do not remove cover. Only a maintenance engineer is allowed
to open the cover.
▪Do not touch. You may receive electric shock.
▪Make sure to turn off the power when servicing the equipment.
High Temperature Warning
▪Do not touch the equipment when it is running.
▪The equipment can get extremely hot and may cause a burn.
▪Make sure to close the cover beore running the equipment.
Use Precaution when Moving
▪The equipment is heavy. Make sure at least 2 people lift or
move the equipment.
▪Do not attempt to move the equipment alone. You may be
injured from dropping the heavy equipment.
Fire Hazard
▪Place the equipment in an area away from any combustible
materials.
▪The equipment may catch on fire from overheating or short
circuit of the power supply unit.
Disassembly Warnings
▪Do not disassemble or modify the equipment unless you are a
certified engineer.
▪Contact the service center for maintenance, adjustments and
repairs.
▪Improper disassembly may cause fire or electrical shock.
Collapse Precautions
▪Do not place the equipment where the floor cannot sustain the
weight of the equipment, or on slanted or unstable surface.
▪Equipment may fall and cause injury or damage.
Unplug the Equipment
▪Stop using the equipment immediately if it smokes, emits an
unusual smell, makes abnormal sounds, or if liquids or other
foreign materials enter the equipment.
▪If the above-mentioned abnormalities occur, immediately turn
off the power, unplug the equipment and contact the service
center.
▪If you ignore these symptoms, the equipment may catch on fire
or cause electric shock.

Chapter1. Preface Operator Manual
1-6 © 2016 Nautilus Hyosung Inc. All Rights Reserved.
Related Document
▶The related documents are listed as follows. If needed, please contact staffs of our
technical support team and maintenance team.
▪Installation Manual
▪Service Manual
For the contact of maintenance staffs of Nautilus Hyosung, see the E-mail addresses
and telephone numbers provided separately.

Operator Manual Chapter2. Introduction
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 2-1
Chapter2. Introduction
About the MX7800I
►The MX7800I is a full service ATM. Consumers deposit the cash/check in one slot with
mixing, make the withdrawal and receive the transaction records through openings in
the fascia with MX7800I ATM.
The MX7800I is a versatile, easily maintained delivery system that can be modified to
keep pace with the bank's changing needs.
►The benefits that the new concept MX7800I provides are as follows.
Removes inconvenience which occurs when bank clerks directly handle cash and
checks with customers and relieves workload upon tellers by processing deposit/
withdrawal of cash/check automatically.
Relieves risks and burden of directly handling cash/check by directly keeping cash/
check deposited in a safe.
Allows tellers to calculate and close amount on hand faster than the existing manual
calculation.
Abank customer and a teller can easily interact on a touch screen, just like talking,
through Nautilus Hyosung’s intuitive and easy UI.
Supports expanded options such as coin dispenser, RF (NFC), and ID scan, as well as
basic functions of deposit/withdrawal of cash/check.
Allows easy and quick installation and maintenance.

Chapter2. Introduction Operator Manual
2-2 © 2016 Nautilus Hyosung Inc. All Rights Reserved.
The Exterior Overview
▶The following picture shows the front of MX7800I and key units.
The fascia provides the interface between the customer and MX7800I.
The customer selects transactions and requests information at the fascia.
Advertisement
Display
Cash
Dispenser Slot
(Cash Out)
EPP
(Encryption
PIN Pad)
RF Reader
(Contactless
Card Reader)
Cash & Check
In Module Slot
(Cash/Check
Deposit)
Earphone
Jack
Card Reader
Slot
Receipt
Printer Slot
Customer
Display (with
touch screen)
ID Card Scan
Coin Dispenser
(Coin Out)

Operator Manual Chapter2. Introduction
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 2-3
Basic Features
▶Important features of the MX7800I is highlighted in the following list:
<Note!>
1. Your MX7800I may not contain all the devices described in this section. Some devices are optional
and some devices cannot be used in combination with other devices (mutually exclusive
combinations).
2. Option :
Item
Specification
Remarks (Option)
Main
Controller
(ASROCK Q87)
CPU
I5-4590 (3.3GHz)
Memory
DDR Memory
4GB
DDR-III
Storage
Device
HDD
500 GB
SATATYPE
FDD
None
3.5”, 1.44MB
ODD
DVD-RW
SATATYPE
Operating System
Windows 7
with Service Pack 1
(Eng)
Expansion Slots
2-PCI, 1-PCI-Express
x16,
1-PCI-Express x4
Q41 Main B/D
Serial Ports
3 Port
Use for Coin
USB Ports
12 Ports
Main Board 12 Ports
USB2.0 7Port HUB
VGA
Onboard
On-Board Dual VGA
(DVI, HDMI)
Intel Q61 express
chipset
VGA CARD
GT520 (nVIDIA)
LAN
10/100/1000Mbps On-
Board
Customer
Display
Display
Type
21.5” TFT LCD
Brightness
1,500 cd/m²(SunLight
Viewable)
Auto
Brightness
Day & Night (2 Step)
(Day : 1500cd, Night :
800cd)
Sensing External
Bright
Privacy Filter
None
Option
Guide Light
Flicker
White :
SPR/CDU/CCIM/MCU
/COIN/A4/EPP
Open/Close
Top Indicator :
White/OFF
Side Indicator :
Green/Red
Customer
Input Method
Pin-Pad
PCI 3.0 EPP (PCI
Compliant)
Poly-Carbonate
Button
Function Key
Touch Screen
IR Touchscreen
Supervisor
Operation
Display Module
10.1” TFT LCD,
200cd/m2
Input Method
Touch Screen
Res Touchscreen

Chapter2. Introduction Operator Manual
2-4 © 2016 Nautilus Hyosung Inc. All Rights Reserved.
Item
Specification
Remarks (Option)
Advertisement
Display Module
32” TFT LCD, 300c d/m2
Cash Dispenser
(CDU10)
Sutter type
Automatic Shutter
Denomination
US $20,20,20,20,20(ID
1,2,3,4,5)
-
Maximum Dispense
50 Notes/1 transaction
-
Number of cassettes
5 Cassettes
-
Cassette Capacity
3,000 notes/1 cassette
-
Cassette Key
Non Locking Key
Reject Type
Note by Note Reject
(300 bills Max)
Reject / Retract
BOX
Retract
Bundle Retract (100 bills
Max)
Number of Near-End Sensing
500 Notes Max
100 to 500, 5 Step
Card Reader
(SANKYO)
Type
Sankyo MCR (DYP
TYPE)
Magnetic Stripe
ISO 1,2 Read
-
IC card Support
Support
-
Receipt Printer
(K-SPR11)
Printing Type
Thermal Line Printing
Printing Width
80mm Max
-
Paper
Specification
Type
Thermal Roll Paper
Width
Max. 80mm
-
Outer
Diameter
Max. 210Φ
-
Paper Roll Capacity
5,000 Transaction/Roll
Depends on Format
Black Mark Paper Support
None
Black Mark Paper
Option
Cash & Check
In Module
(CCIM2.0)
Media Size
Width
Min : 60 mm (2.36 inch)
Max : 102 mm (4.01
inch)
Length
Min : 110 mm (4.33 inch)
Max : 230 mm (9.055
inch)
Thickness
Min : 0.0762 mm (0.003
inch)
Max : 0.203 mm (0.0079
inch)
Bundle Capacity
50 Mixed Notes and
Checks
/1 transaction
One Single Deposit
Slot
Deposit Direction
4 way
Capacity
Deposit
Cassettes
2,000 notes/1 cassette
2,000 checks/1 cassette
Criteria for Deposit
New Notes &
Checks
Reject
Cassettes
50 Mixed Notes and
Checks
Article6
Cassettes
10 Mixed Notes and
Checks
Escrow
50 Mixed Notes and
Checks
/1 transaction

Operator Manual Chapter2. Introduction
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 2-5
Item
Specification
Remarks (Option)
Capacity
Deposit
Reject
50 Mixed Notes and
Checks
/1 transaction
Processing
Time
Deposit
Time
1 Note : - Seconds,
1 Check : - Seconds
Deposit
Time
5 Notes & 2 Checks
: Less than 30 Seconds
25 Notes & 25 Checks :
: Less than 30 Seconds
Storage
Time
1 Sheet : - Seconds
7 Sheets : - Seconds
50 Sheets : - Seconds
Image scanning
Double side scanning
200 dpi
MICR
CMC-7, E13-B
Endorsement Print
Double side printing, Ink
jet
Shutter Type
Automatic Shutter
JPR
Journal Printer
Electronic Journal
Dot JPR/ T-JPR
Option
Safety
&
Security
Safety
UL 291 Level-1
(Front Access)
-
Body Cover
Steel
Locking device
Cencon Lock
Dual Lock (Dual
Combo Lock),
Single Combo Lock
Option
Key Lock
Lever Key
Alarm
Seismic + Heat Sensor
-
Security
Terminal Block (External
I/F)
-
Camera
CCD 2EA (FACE,HAND)
Panorama(180°) 1EA
Camera I/F
Video Port /w Pig Tail for
internal Cam
Video Power /w Pig Tail
for Cam
-
Anti-Skimming Device
Option
Mirror
Awareness Mirror
Coin Hopper
(SCH2)
Denomination
4 sorts
1, 5,10, 25 cents
Dispensing Capacity
1cent 658ea, 5cent
449ea,
10cent 847ea, 25cent
355ea
-
Contactless
Card Reader
(VivoPay)
Audio guidance
Beeper
Transaction Interface
13.56MHz ISO14443
Type A,B,
NFC and MiFare

Chapter2. Introduction Operator Manual
2-6 © 2016 Nautilus Hyosung Inc. All Rights Reserved.
Item
Specification
Remarks (Option)
Payment Applications
American Express-
Express Pay
Discover Zip, JCB
J/speedy
Mastercard PayPass
Mstripe
Visa payWave MSD
ID Scan
ID Scanner
ID Card
2D Barcode
Video Banking
Web Cam
Logitech C615
1920X1080P(30Hz)
Use External mic
Additional
function
Audio guidance
Sound Card On-Board
-
ADAAudio guidance
Available(/w Earphone
jack cover/plug)
Dimension
&
Environment
Battery
System Battery
Alarm Battery
Option
Heater
3 Heater
(Upper/Bottom
Left/Bottom Right)

Operator Manual Chapter2. Introduction
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 2-7
Devices of MX7800I
Control Electronics (CE, PC)
▶The Control Electronics mainly consist of a motherboard, HDD, DVD-RW, multiple serial card,
and so on.
Basic functions of the control electronics used in this ATM is similar to that of a personal
computer you may have in your office or home with exception of a multiple USB HUB used to
communicate with several devices such as a cash dispenser, card reader, receipt printer and
EPP.
►Basic Specification
Item
Specification
Remarks (Option)
CPU
I5-4590 (3.3GHz)
Memory
DDR
Memory
4GB
DDR-III
Storage
Device
HDD
500 GB
SATATYPE
FDD
None
3.5”, 1.44MB
ODD
DVD-RW
SATATYPE
Operating System
Windows 7
with Service Pack 1 (Eng)
Expansion Slots
2-PCI, 1-PCI-Express x16,
1-PCI-Express x4
Q41 Main B/D
Serial Ports
3 Port
Use for Coin
USB Ports
12 Ports
Main Board 12 Ports
USB2.0 7Port HUB
VGA
Onboard
On-Board Dual VGA (DVI,
HDMI)
Intel Q61 express chipset
VGA CARD
GT520 (nVIDIA)
LAN
10/100/1000Mbps On-Board

Chapter2. Introduction Operator Manual
2-8 © 2016 Nautilus Hyosung Inc. All Rights Reserved.
Customer Display & Keypad
▶The Customer Display welcomes the customer and provides instructions for performing
transactions at the ATM.
During the transaction, the ATM prompts the customer to use the customer keypad to enter
transaction information. The 16-key keypad uses an Encryption PIN Pad technology to secure
the information entered by the customer at the keypad. The customer touch screen is used
with the customer display. The customer selects functions or enters information by touching the
screen.
►Basic Specification of PIN-Pad
Item
Specifications
Remarks
Pin-Pad
PCI 3.0 EPP
(PCI Compliant)
Poly-Carbonate Button
►Basic Specification of Customer Display
Item
Specifications
Remarks
Display
Type
21.5” TFT LCD
Brightness
1,500 cd/m²(Sun Light
Viewable)
Auto
Brightness
Day & Night (2 Step)
(Day : 1500cd, Night : 800cd)
Sensing External
Bright
Input Method
Touch Screen
IR Touchscreen
EPP
(Encryption
PIN Pad)
Customer
Display (with
touch screen)

Operator Manual Chapter2. Introduction
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 2-9
Advertisement Display
►Basic Specification
Item
Specification
Remarks (Option)
Display Module
32” TFT LCD, 300c d/m2

Chapter2. Introduction Operator Manual
2-10 © 2016 Nautilus Hyosung Inc. All Rights Reserved.
Teller Display
►Basic Specification
Item
Specification
Remarks (Option)
Display Module
10.1” TFT LCD,
200cd/m2
Input Method
Touch Screen
Res Touchscreen
