MoniMax 5100T Operator Manual
CopyrightⓒNautilus Hyosung Inc. 2005·2006·2007·2008·2009 All right reserved

MoniMax 5100T
Revision Record
Date Page Version Description of Change
November 2005 All 1.0 New Publication
October 2006 Chapter 5 1.1 Change of display screens and addition of operator
function with NDC
November 2007 All 1.2 Changing Model Name
(NH-5040 →MoniMax 5100T)
January 2008 Chapter 5 1.3
Updating “Chapter 5. Operator Function”
- Host Setup (page 5-8)
- Host IP Setup (page 5-9)
- Remote Monitor (page 5-11)
- RMS IP Setup (page 5-12)
- RMS Call Back Option (page 5-15)
- Customer Setup (page 5-19)
- Select Host (page 5-23)
- Communication (page 5-24)
- Message Format (page 5-26)
- EOT Option (page 5-27)
- TCPIP Type (page 5-28)
- STANDARD 3 Option (page 5-29)
- Advertisement Setup (page 5-31)
- Advertisement X Setup (page 5-31)
- Coupon (page 5-33)
- Coupon X Setup (page 5-34)
- System Setup (page 5-36)
- ATM IP Setup (page 5-43)
- ATM Static IP Setup (page 5-44)
- RCOPY (page 5-49)
- Log RCOPY (page 5-50)
Adding “Option B. MoniMax 5100T H-SPL QUICK
USER GUIDE” (page 5-61)

MoniMax 5100T
Date Page Version Description of Change
February 2008 Chapter 5 1.4 Updating “Option A. Operator Functions with NDC”
(page 5-51)
March 2008 Chapter 5
Chapter 6 1.5
Adding NDC Supervisor Screen Map
Modifying screen and description of Chapter 5.
- 22.1 of 5-61 page
- 22.2 and 22.3 of 5-62 page
Deleting NDC S/W Setup menu
April 2008 Chapter 6 1.6 - Updating “Error Code Table” in Chapter 6.
(Addition of error code : D00C100, D00C200,
D410000, D410100)
May 2008 Chapter 6 1.7 - Adding “I. Software Installation Guide for Dial-up” in
the Chapter 6.
- Updating “Error Code Table” in Chapter6.”
(Addition of error code : 7000100, 7000200,
7000300)
June 2008 All 1.8 Changing the specification
- Control Electronics, Receipt printer, Power Supply,
Rear operator panel
June 2008 Chapter 3, 6 1.9 Adding dimensions for adjustor type in Chapter 3, 6.
July 2008 Chapter 5,6 2.0 - Updating description and images for each menu in
Chapter 5.
- Adding “Option A. New Operator Function for NDC
Emulation.” in Chapter 6.
- Adding “Option A. Diagnostics_STD”
(This chapter is to explain “5.6 Diagnostics” in
Chapter 5 particularly)
- F. Key Management in Chapter 6 ⇒Option B.
Key Management.
- Adding “Option C. Operator Function of H-SPL”
- Updating “Error Code Table” in Chapter 7.
January 2009 Chapter 5,
Option D.
2.1 -Modifying Chapter 5. (See 5-2, 5-15 pages)
- Adding “Option D. T-SPL”

MoniMax 5100T
Table of Contents
1. Introduction
1.1 About the MoniMax 5100T ················································································1-2
1.2 Basic Features ·····································································································1-2
1.3 What is in this Manual ·························································································1-4
1.4 Terminologies ······································································································1-5
2. Precautions for Safety
2.1 Overview ··············································································································2-2
2.2 Description of Precaution Symbols ···································································2-3
3. Hardware Specifications
3.1 Dimensions ············································································································3-2
3.2 Component Locations ························································································3-4
3.3 LCD & Customer Keypad ····················································································3-6
3.4 CDU (Cash Dispensing Unit) ················································································3-7
3.5 SPR (Slip Printer/Receipt Printer) ······································································3-8
3.6 MCU (Magnetic Card Unit) ····················································································3-9
3.7 Control Electronics ·····························································································3-10
3.8 Power Supply ······································································································3-11
3.9 Rear Operator Panel ···························································································3-13
3.10 Operating Environment ·····················································································3-14
4. Operating Instructions
4.1 Opening and Closing the Doors ·········································································4-2
4.2 Replenishing the Cash Cassette ········································································4-4
4.3 Emptying the Cash in the Reject Box ································································4-7
4.4 Removing Jammed Bills ························································································4-8
4.5 Loading the Receipt Paper ·················································································4-10
4.6 Removing Receipt(Slip) Paper Jammed ···························································4-13

MoniMax 5100T
5. Operator Functions
5.1 Password for Entering Supervisor Mode ·······················································5-2
5.2 Supervisor Menu·····································································································5-3
5.3 Replenish ······································································································5-5
5.4 Configure ······································································································5-7
5.5 Journal ······································································································5-39
5.6 Diagnostics ·······························································································5-42
5.7 Report ······································································································5-42
5.8 Rcopy ·······································································································5-45
6. Operator Function with NDC
6.1 Entering OP Mode (NDC Machine) ······································································6-2
6.2 Main Screen ····································································· 6-3
Option A. New Operator Function for NDC Emulation ········································· 6-15
Option A. Diagnostics
A.1 Diagnostics of Front Supervisor ···································································A-2
A.2 Diagnostics of T-SPL Supervisor ································································A-10
Option B. Key Management
B.1 Start Screen ··························································································B-2
B.2 Main Screen ·························································································B-3
B.3 Setting the Key Mode ·················································································B-4
B.4 Key Injection ····························································································B-5
B.5 Confirmation of the injected keys ···························································B-6
B.6 Change Password for execution program ··············································B-7
Option C. Operator Function of H-SPL
C.1 Operator Function of H-SPL ··········································································C-4
C.2 MoniMax 5100T H-SPL Quick User Guide·························································C-12
Option D. Operator Function of T-SPL
D.1 Supervisor Menu ··························································································D-4
D.2 Replenish ········································································································D-6
D.3 Configure ··························································································D-9

MoniMax 5100T
D.4 Journal ·······································································································D-12
D.5 Diagnostic ·························································································D-14
D.6 Report ······································································································D-14
D.7 RCOPY ·······················································································D-16
7. Appendix
A. Summary of Specification for MoniMax 5100T ···················································7-2
B. Bill Conditions ····································································································· 7-4
C. Receipt Paper Specifications ···············································································7-9
D. Magnetic Card Specifications ··············································································7-13
E. Error Codes Table ··························································································7-14
F. Electronics Combination Lock ···············································································7-44
G. Installation Guide ·································································································7-49
H. Demonstration Screen ··························································································7-57
I. Software Installation Guide for Dial-up···································································7-62

MoniMax 5100T 1. Introduction
1
1-
Chapter 1. Introduction

MoniMax 5100T 1. Introduction
2
1-
1. Introduction
1.1 About the MoniMax 5100T
The MoniMax 5100T (Through-The-Wall Type) is designed to meet higher transaction as
well as low maintenance components. Whether installed as a walk-up or drive-through,
MoniMax 5100T offers solid, weatherized construction while its compact architecture allows
flexibility in mounting. The MoniMax 5100T is easy to use, easy to service and is able to
support customer’s needs.
1.2 Basic Features
Important features of the MoniMax 5100T ATM is highlighted in the following list:
zUL 291 Business hour listed or complied with safe
zUL 291 Level 1 listed or complied with safe (optional)
zKABA MAS Cencon lock
zElectronic combination lock or mechanical combination lock (optional)
zNormal bright 10.4” TFT LCD (400cd/㎡)
zSunlight visible 10.4” TFT LCD (1,500cd/㎡) (optional)
zUser-friendly keypad and display interface
zOperating system with Windows XP Professional
z256 Memory, 80GB HDD, high speed CD-ROM
zSupport PCI 3 expansion slot, USB 4 ports
zPCI certified Encryption PIN Pad
zSupporting LAN communications, using TCP/IP
zComplying with Americans with Disabilities Act (ADA) for height and access
zSupporting multiple serial interface up to 8 ports

MoniMax 5100T 1. Introduction
3
1-
zFunction key compatible with NDC
zSupporting enormous bill capacity up to 8,000 notes in cash dispenser (Optional)
zSupporting U.S. and international currency types
zDip card reader
zSemi-automated receipt paper loading for operator’s convenience
zSupport a rear operator panel for operator’s convenience
zModular design for easy maintenance
zQuick setup feature
zAdvertisement feature for bank promotion
zRear access cabinet and rear access available for easy service

MoniMax 5100T 1. Introduction
4
1-
1.3 What is in this manual
This MoniMax 5100T Manual contains all information needed for normal operational use.
This manual contains Unit Specifications, Opening & Closing Procedures, Operator
Functions(Supervisor Screen), Error Recovery, etc.
Some of the information in this manual may be subsequently updated based on the
customer’s needs or the improvement by Nautilus Hyosung.

MoniMax 5100T 1. Introduction
5
1-
1.4 Terminologies
zCE : Control Electronics
zLCD : Liquid Crystal Display
zPNC : Panel Control Board
zAD board : Analog Digital Board
zOSD board : On Screen Display Board
zOPL : Operation Panel and Handling Screen for Customer
zSPL : Service Panel and Handling Screen for Operator (= Rear Operator Panel)
zEPP : Encryption PIN Pad
zMCU : Magnetic Card Reader Unit
zMS Head : Magnetic Stripe Head
zB/D : Control Board
zI/F : Interface
zH/W : Hardware
zS/W : Software, Switch
zP/N : Part Number
zD/L : Download
zTM : Test mode (= Diagnostic Program)
zSPR : Slip Printer (=Receipt Printer)
zTPH : Thermal Printer Head
zCDU : Cash Dispensing Unit
zF/M : Feed Module in Cash Dispenser
zAssy : Assembly
zCST : Cassette
zRj/Rt : Reject/Retract
zP/S : Power Supply
zADA : The Americans with Disabilities Act
zBATT : Battery
zEarphone Jack : Voice Converter for Visually Disabled Persons
zAP : Application Program
zSP : Service Provider
zEP : Elementary Program

MoniMax5100T 2.PrecautionsforSafety
1
2-
Chapter 2. Precautions for Safety

MoniMax5100T 2.PrecautionsforSafety
2
2-
2. Precautions for Safety
2.1 Overview
Common Precaution for Safety
Please read the following instructions before operating equipment.
zOperate equipment in the order outlined in this manual.
zFollow precautions indicated in this manual, as well as the equipment itself.
Failure to properly address these precautions may lead to injury or damage to
the product.
zAvoid operations not addressed in this manual.
zIf you cannot remedy system problems using the methods outlined in this manual,
please refer to contact information listed in the manual.
Precautions outlined this manual provide information on
safe and proper handling of the product. Non-compliance
of the precautions may result in injury or damage to the
product.
This precaution symbol with sample term tells you safety
warnings during equipment handlings.

MoniMax5100T 2.PrecautionsforSafety
3
2-
2.2 Description of Precaution Symbols
Symbol Description
Electrical Shock
• Do not remove cover. Only a maintenance engineer is allowed to
open the cover.
• Do not touch. You may receive electric shock.
• Make sure to turn off the power when servicing the equipment.
High Temperature
• Do not touch the equipment when it is running.
• The equipment can get extremely hot and may cause a burn.
• Make sure to close the cover before running the equipment.
Be Careful when Moving
• The equipment is heavy. Make sure at least 2 people to lift or move
the equipment.
• Do not attempt to move the equipment alone. You may be injured by
dropping the heavy equipment.
Fire Hazard
• Place the equipment in an area away from any combustible materials.
• The equipment may catch on fire from overheating or short circuit of
the power supply unit.
Disassembly
• Do not disassemble or modify the equipment unless you are a
certified engineer.
• Contact the service center for maintenance, adjustments and repairs.
• Improper disassembly may cause fire or electrical shock.
Fall down
• Do not place the equipment where the floor cannot sustain the weight
of the equipment, or on slanted or unstable surface.
• Equipment may fall down and cause injury or damage.

MoniMax5100T 2.PrecautionsforSafety
4
2-
Symbol Description
Unplug the Equipment
• Stop using the equipment immediately if it smokes, emits an unusual
smell, makes abnormal sounds, or if liquids or other foreign materials
enter the equipment.
• If the above-mentioned abnormalities occur, immediately turn off the
power, unplug the equipment and contact the service center.
• If you ignore these symptoms, the equipment may catch on fire or
cause electric shock.

MoniMax 5100T 3. Hardware Specifications
3- 1
Chapter 3. Hardware Specifications

MoniMax 5100T 3. Hardware Specifications
3- 2
3. Hardware Specifications
3.1 Dimensions
(1) Adjustor Type
※Note 1) The unit is millimeter and inch with [ ] .
2) 1 inch equals 25.4mm
Fig. 3.1(a) Dimensions for Adjustor Type

MoniMax 5100T 3. Hardware Specifications
3- 3
(2) Non Adjustor Type
Fig. 3.1(b) Dimensions for Non Adjustor Type

MoniMax 5100T 3. Hardware Specifications
3- 4
3.2 Component Locations
Front view
Fig. 3.2 Component Location (Front)
1. Lighted Top Panel 5. Flicker
2. LCD & Customer Keypad 6. Card Reader Slot
3. Cash Tray 7. Earphone Jack
4. Slip Printer Slot 8. Encrypted PIN Pad
1
2
3
45
6
7
8

MoniMax 5100T 3. Hardware Specifications
3- 5
Rear view
Fig. 3.3 Component Location (Back)
1. Rear Operator Panel 5. Power Supply
2. Receipt Printer 6. Control Electronics
3. Vault Door 7. Cash Dispenser
4. Battery 8. Cash Cassette
1
3
4
5
26
7
8
