Nautilus Hyosung MONiMAX7600 User manual

Installation Manual
MONiMAX7600 System
V01.00.02(2015.05.11)
© 2011 Nautilus Hyosung, Inc. All Rights Reserved.

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
I
Revision History
No. Version Date Description of Change Chapter
1
V1.0
2011/11
New Publication
All
2 V01.00.01 2012/08/29 Added “Height and Depth Main Fascia Items” Chapter 3
3 V01.00.02 2015/05/11 Added the approximate weight of MX7600 Chapter 3
© 2011 Nautilus Hyosung All Rights Reserved.
The content of this specification is protected bycopyright laws.
2015. 5. 11. 3rd Release
Installation Manual – MX7600 System

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
II
Contents
Chapter1. Preface...........................................................................................................................1-1
Purpose.........................................................................................................................................................1-1
Audience .......................................................................................................................................................1-1
Support Information............................................................................................................................................. 1-1
What is in This Manual........................................................................................................................................ 1-1
Conventions......................................................................................................................................................... 1-2
Abbreviations of ATM.........................................................................................................................................................1-2
Safety Precautions.............................................................................................................................................. 1-4
Related Document .............................................................................................................................................. 1-6
Chapter2. Introduction ...................................................................................................................2-1
About the MX7600 ........................................................................................................................................2-1
System Identification Label...........................................................................................................................2-2
Chapter3. Installation Information.................................................................................................3-1
Installation Condition and Space ....................................................................................................................... 3-1
Packing Dimensions......................................................................................................................................3-1
Weight & Dimensions....................................................................................................................................3-2
Height and Depth Main Fascia Items............................................................................................................3-4
Fascia Item Locations for Voice Guidance....................................................................................................3-5
Recommended Installation and Service Clearance......................................................................................3-6
Chapter4. System Installation........................................................................................................4-1
Unpacking the ATM............................................................................................................................................................4-1
Bolting Down the MX7600.............................................................................................................................4-2
Appendix.........................................................................................................….............................. A-1
Precaution ........................................................................................................................................................ A-1
Cash & Check in Module (CCIM) in the Safety Body.....................................................................................A-1
Removing the Protective Material from the main body of Cash & Check In Module ................................A-1
Removing the locking section from the main body of Cash & Check In Module.......................................A-2
SeparatingtheCassetteSection................................................................................................................A-3
Installing Section............................................................................................................................................... A-4
Notes.......................................................................................................................................Notes-1

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
1-1
InstallationManual Chapter1.Preface
Chapter 1. Preface
Purpose
►This manual provides guidelines for preparing and installing the MX7600 ATM.
Audience
►This manual is written for bank branch personnel who are installing the MX7600.
Additional audiences include designers and construction workers involved in this
installation.
Support Information
►For questions or if errors occur while preparing and installing the MX7600, please
contact the Nautilus Hyosung maintenance team.
For contact information, see the
email addresses
and telephone numbers provided to you separately.
What is in This Manual
►In addition to installation guidelines for the MX7600, this manual includes important
warnings you must take into consideration during installation.
►All measurements in this manual are in metric with inches provided in braces
( ).
►All informationdescribed in this manual is a licensed product of Nautilus
Hyosung.
Some of the information in this manual may differ according to the network processor
to be connected and may be subsequently updated for the bank’s needs or from
improvements byNautilus Hyosung.
It is the policy of Nautilus Hyosung to improve products as new technology,
components, software, and firmware become available. Therefore Nautilus Hyosung
reserves the right to change specifications without notice.

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
1-2
InstallationManual Chapter1.Preface
Conventions
►Terminology
The terminology listed below is used in this manual:
▪ Customer and consumer refer to anyperson who transacts business through the
ATM.
▪ Device and unit refer to the standard and optional ATM equipment, such as monitor,
card reader, printer and dispenser.
▪ Fascia refers to the entire front portion of the unit, including the portion where the
customer transacts business.
▪ Module refers to a plug-in device that can be serviced or replaced.
▪ Note(s) and bill(s) refer to the individual documents loaded into and dispensed from
the dispenser.
▪ Servicing and maintenance refer to the supervisor, operator and technician’s tasks
performed to keep theATM operational.
▪ Screen refers to the text appearing on the customer display.
Abbreviations of ATM
►The abbreviations listed below are used in tis manual:
#
Abbreviations
Description
1
AD board
Analog to Digital conversion board
2
ADA
TheAmerican DisabilitiesAct
3
ALG
AlignmentModule
4 AP ApplicationProgram
5 Assy Assembly
6 BATT S/W BatterySwitch
7 BC Bill Checker
8
BM1
BodyModule1
9
BM2
BodyModule2
10
BM3
BodyModule3
11
BUNDLE
Bulk Note Separation Module
12 CAM Camera Unit
13 CASSETTE Cash & Check Cassette
14 CCIM Cash & Check In Module
15 CCR Contactless Card Reader
16 CDU Cash Dispenser Unit
17 CE ControlElectronics
18
Earphone Jack
Voice Converter for Visually Disabled Persons (ADA)
19
EMV
Europay, Mastercard, Visa
20
EP
ElementaryProgram
21
EPP
Encryption PIN Pad

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
1-3
InstallationManual Chapter1.Preface
#
Abbreviations
Description
22 ESCROW EscrowModule
23 FELT Ink Head Cleaner Felt
24 H/W Hardware
25
I/F
Interface
26
ISO
InternationalStandard Organization
27
JPR
Journal Printer
28
LCD
Liquid Crystal Display
29
MCU
Magnetic Card Unit
30 OPL Operation Panel for Customers to Operate
31 OSD board On Screen Display Board
32 P/S Power Supply
33 PIN PersonalIdentification Number
34 PNC Panel Control Board
35 PRT EndorsementModule
36
PTR
Printer (mainly Receipt Printer)
37
RECOG
RecognitionModule
38
REJECT
Reject Module
39
RT/A6
Retract & A6 Cassette
40 S/W Switch
41 SCM Separator Control Module
42 SIU Sensor and Indications Unit
43 SP Service Provider
44 SPR Slip Printer (Receipt Printer)
45 TTU Text Terminal Unit (OPL or SPL)
46
VFD
Vacuum Fluorescent Display

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
1-4
InstallationManual Chapter1.Preface
Safety Precautions
►Common Safety Precaution
▪ Safety Precautions in outlined this manual provide information on safe and proper
handling of the product. Non-compliance of the safety precautions may result in injury
or damage to the product.
▪ This precaution symbol with sample term tells you safety warnings during equipment
handlings.
►Please read the following instructions before operating equipment.
▪ Operate equipment in the order outlined in this manual.
▪ Follow precautions indicated in this manual, as well as the equipment itself.
Failure to properly address these precautions may lead to injury or damage to the
product.
▪ Avoid operations not addressed in this manual.
▪ If you cannot remedy system problems using the methods outlined in this manual,
please refer to contact information listed in the manual.
▪ Any change or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
<Note!>
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, maycause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
►CAUTION
1. To reduce the risk of fire, use only No. 26 AWG OR LARGER Telecommunication
cord
2. Risk of explosion if battery is replaced byan incorrect type.
Dispose used batteries according to the instructions.
3. For pluggable equipment, the socket-outlet shall be installed near the equipment and
shall be easily accessible.
4. The equipment is to be secured to he building structure before operation
5. Asecurity container shall be permitted to optionally be provided with a secondary
lock, but improper use of the secondary lock feature will reduce the security level of
theATM.

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
1-5
InstallationManual Chapter1.Preface
►Description of Precaution Symbols
#
Symbol
Description
1
Electrical Shock Warning
▪ Do not remove cover. Only a maintenance engineer is
allowed to open the cover.
▪ Do not touch. You mayreceive electric shock.
▪ Make sure to turn off the power when servicing the
equipment.
2
High Temperature Warning
▪ Do not touch the equipment when it is running.
▪ The equipment can get extremely hot and may cause a
burn.
▪ Make sure to close the cover before running the
equipment.
3
Use Precaution when Moving
▪ The equipment is heavy. Make sure at least 2 people lift or
move the equipment.
▪ Do not attempt to move the equipment alone. You may be
injured from dropping the heavy equipment.
4
Fire Hazard
▪ Place the equipment in an area away from any
combustiblematerials.
▪ The equipment maycatch on fire from overheating or
short circuit of the power supply unit.
5
DisassemblyWarnings
▪ Do not disassemble or modify the equipment unless you
are a certified engineer.
▪ Contact the service center for maintenance, adjustments
and repairs.
▪ Improper disassembly may cause fire or electrical shock.
6
CollapsePrecautions
▪ Do not place the equipment where the floor cannot sustain
the weight of the equipment, or on slanted or unstable
surface.
▪ Equipment mayfall and cause injury or damage.
7
Unplug the Equipment
▪ Stop using the equipment immediately if it smokes, emits
an unusual smell, makes abnormal sounds, or if liquids or
other foreign materials enter the equipment.
▪ If the above-mentioned abnormalities occur, immediately
turn off the power, unplug the equipment and contact the
servicecenter.
▪ If you ignore these symptoms, the equipment may catch
on fire or cause electric shock.

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
1-6
InstallationManual Chapter1.Preface
Related Document
►Related documents are listed as follows. If needed, please contact the Nautilus Hyosung
technical support team or maintenance team for copies.
▪ Operator Manual
▪ MaintenanceManual
►To contact the Nautilus Hyosung maintenance staff, see the email addresses
and
telephone numbers provided separately.

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
2-1
InstallationManual Chapter2.Introduction
Chapter 2. Introduction
About the MX7600
►The MX7600 is a full serviceATM. Consumers can deposit mixed cash/check in one
slot
a nd receive dispensed cash and transaction records through openings in the
fascia.
The MX7600 is a versatile, easily maintained delivery system that can be modified to
keep pace with the bank's changing needs.
►The benefits that the new concept MX7600 provides are as follows.
1. Removes inconvenience which occurs when bank tellers directly handle cash and
checks with customers and relieves workload upon tellers byprocessing
deposit/withdrawal of cash/check automatically.
2. Relieves risks and burden of directly handling cash/check bydirectly keeping
cash/check deposited in a safe.
3. Allows tellers to calculate and close amount on hand faster than the existing manual
calculation.
4. Abank customer and a teller can easily interact on a touch screen, just like talking,
through Nautilus Hyosung’s intuitive and easy UI.
5. Supports expanded options as well as basic functions of deposit/withdrawal of
cash/check.
6. Allows easy and quick installation and maintenance.

© 2011 Nautilus Hyosung Inc. All Rights Reserved.
2-2
InstallationManual Chapter2.Introduction
System Identification Label
▶The System Label below shows the layout of the product identification label which is
fixed inside the side box of theATM

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
3-1
InstallationManual Chapter3. Installation Information
Chapter 3. Installation Information
Installation Condition and Space
►When you determine the location of your MX7600 ATM, ensure that the physical
environment, including the temperature and humidity, meets the requirements.
Following conditions should be met before installing equipment.
1. Avoid locations where intense direct light is reflected off the LCD screen.
2. Avoid locations where strong static electricity can occur.
3. The floor must allow easy wheelchair access from the front or the side.
4. Space required for servicing the machine should be considered before installation.
►Temperature & Humidity
Temperature
In Storage
-5°C ~ 50°C (23°F ~ 122°F)
Operating
-10°C ~ 40°C (14°F ~ 104°F)
Humidity
In Storage
10% ~ 90%
Operating
25% ~ 86%
Packing Dimensions
►Packaging Dimensions
In some cases it may be necessary to store the ATM (in its box) before it is installed.
See figure below for information on the dimensions of a boxed Monimax7600 ATM.

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
3-2
InstallationManual Chapter3. Installation Information
Weight & Dimensions
►ApproximateWeight: 820kg (1,807.79Ibs.).
►The figure below shows the dimensions of MX7600 ATM viewed from front.

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
3-3
InstallationManual Chapter3. Installation Information
►The figure below shows the dimensions of the MX7600 ATM viewed from the side.

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
3-4
InstallationManual Chapter3. Installation Information
Height and Depth Main Fascia Items
►The following pictures and tables give the height and depth to the main fascia items
located on the fascia. The height dimensions are calculated from the base of the ATM.
That satisfies theADAstandard and allows good accessibility and convenience for
both of unhandicapped and handicapped people.
The height and depth of main fascia items
Symbol
Height /Depth
Remarks
A
1217mm[47.91inch]
Top of the touch screen
B
1155.5mm [45.49inch]
Top of the function key
C
958.1mm [37.72inch]
Receipt Printer
D
951.7mm [37.46inch]
Card Reader
E
922.3mm [36.31inch]
EPP
F 788.5mm [31.04inch]
Cash Dispenser, Cash&Check
Input Module
G
770mm [30.31inch]
H
1574.9mm [62inch]
I
1220.0mm [48.03inch]
J
295mm [11.61inch]
Touch Screen
K
232mm [9.14inch]
Function Key
L
1549.0mm [60.98inch]

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
3-5
InstallationManual Chapter3. Installation Information
Fascia Item Locations for Voice Guidance
Unit
MCU
SPR
CDU
CCIM
Symbol
A B C D
Distance
From
No.5Key
193.7mm
(7.6 In)
153.5mm
(6.0 In)
140.8mm
(5.5 In)
376.2mm
(14.8 In)
Clock
Face
Position
3 10 6 4

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
3-6
InstallationManual Chapter3. Installation Information
Recommended Installation and Service Clearance
►The following diagrams describe the recommended areas required for installing and servicing
the MX7600. (Plan View)
<Note!> Hyosung highly recommends that your service personnel have
enough maintenance
space as described below to service thisATM machine

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
3-7
InstallationManual Chapter3. Installation Information
▶The following diagram describes the recommended area required for installing and
servicing the MX7600. (Side View)

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
4-1
InstallationManual Chapter4. System Installation
Chapter 4. System Installation
Unpacking the ATM
▶Unpack the machine on top of the palette.
1. Cut the straps that are fastened around the box with a knife.
(Be careful when cutting the straps. Refer to figure below.)
2. Use an appropriate tool to remove the nails from the palette. (Refer to figure below)
3. Remove the lid, then box from the top. Do not discard the packaging materials until you have
verified any shipping damage claim. Contact your distributor immediately if you see any
shipping damage. Store the box in a safe place to re-use or discard of appropriately.
4. Verify the contents carefully with the packing list to be sure all items listed are included. Notify
your distributor of any shortages.
5. If only the palette needs to be removed, lift the whole machine from the bottom and set it
aside.

© 2011 Nautilus Hyosung, Inc. All Rights Reserved.
4-2
InstallationManual Chapter4. System Installation
▶Removing equipment from the palette
1. Removing bolts from equipment locking bracket.
2. Removing the Adjustor with a spanner.
3. Lifting equipment using a lifting device.
4. Moving this ATM machine to the installation site.
PRECAUTION:
MX7600 ATM machine is very heavy equipment and can cause injuries if not handled with
caution. Read the following carefully.
▪ Firmlyclose the vault door and lock the door by turning the knob completely.
▪ Only experienced staff members should move the heavymachine.
▪ Do not tilt the ATM when moving.
Equipment
LockingBracket
