Nautilus Hyosung MX7600DR User manual

Installation Manual
MX7600DR System
V01.01.00 (2014.01)
2011 © Nautilus Hyosung Inc. All Rights Reserved.

© Nautilus Hyosung, Inc. All Rights Reserved. I
Revision History
Installation Manual–MX7600DR System
No.
Version
Date
Description of Change
Chapter
1
V01.00.00
2011/10
New Publication
All
2
V01.01.00
2014/02
Update to standard format and replace EDU-P to CCIM
All
© Nautilus Hyosung Inc. All Rights Reserved.
The content of this specification is protected by copyright laws.
2014. 02. 2nd Release

© Nautilus Hyosung, Inc. All Rights Reserved. II
Contents
Chapter1. Preface...........................................................................................................................1-1
Purpose.................................................................................................................................................. 1-1
Audience ................................................................................................................................................ 1-1
Support Information................................................................................................................................. 1-1
What is in This Manual............................................................................................................................. 1-1
Conventions............................................................................................................................................ 1-2
Abbreviations of ATM............................................................................................................................... 1-2
Safety Precautions (English).................................................................................................................... 1-4
Précautions pour la sécurité (French)....................................................................................................... 1-6
Related Document................................................................................................................................... 1-8
Chapter2. Introduction ...................................................................................................................2-2
About the MX7600DR.............................................................................................................................. 2-2
System Identification Label ...................................................................................................................... 2-1
Chapter3. Installation Information.................................................................................................3-2
Installation Condition and Space.............................................................................................................. 3-2
Environmental Specification (temperature & humidity)............................................................................... 3-2
Tools required for installation.................................................................................................................... 3-2
Packing Dimensions................................................................................................................................ 3-3
ATM Dimensions..................................................................................................................................... 3-3
Dimension for tilt angle ............................................................................................................................ 3-6
Fascia Item Locations for Voice Guidance................................................................................................ 3-8
Recommended Installation and Service Clearance ................................................................................... 3-9
Minimum Installation and Service Clearance........................................................................................... 3-10
Wall Cut Plan .........................................................................................................................................3-11
Sensor Installation................................................................................................................................. 3-13
Chapter4. System Installation........................................................................................................4-1
Unpacking theATM ................................................................................................................................. 4-1
Removing equipment from the Palette...................................................................................................... 4-2
System Positing....................................................................................................................................... 4-3
Adjusting the Height ................................................................................................................................ 4-4
Inserting the Collar Wing.......................................................................................................................... 4-5
Hole LocationforAC Cord & LAN Cable................................................................................................... 4-7
Power Requirements............................................................................................................................... 4-7
Terminal Block Interface........................................................................................................................... 4-8
Precaution............................................................................................................................................... 4-8
This is basic requirements before turn on the system................................................................................ 4-9
Index........................................................................................................................................ Index-1
Memo...................................................................................................................................... Memo-1

Installation Manual Chapter1.Preface
© Nautilus Hyosung, Inc. All Rights Reserved. 1-1
Chapter1. Preface
Purpose
►This manual is produced to provide the guidelines for installers to comply with while
installing it.
►This manual describes how to prepare for and to proceed the installation of MX7600DR
in advance.
Audience
►This manual is for persons related to installing MX7600DR in branches of banks, such
as designers and construction workers of the branches and ATM installers, to work
efficiently and conveniently.
Support Information
►If any question or installation error occurs while preparing for and installing MX7600DR
in compliance with this manual, please contact maintenance staffs of Nautilus Hyosung
Inc. For the contact of maintenance staffs of Nautilus Hyosung Inc, see the E-mail
addresses and telephone numbers provided separately.
What is in This Manual
►This manual is designed to provide the installation guide for the MX7600DR and the
detailed description of the following:
▪Important Warnings
▪Information for installation
►All measurements in this manual are in metric and U.S. standards. Metric
measurements are first, and U.S. measurements are second in parentheses
►All information describedin this manual is a licensed product of Nautilus
Hyosung Inc.
Some of the information in this manual may differ according to the network processor
to be connected and may be subsequently updated by the bank’s needs or the
improvement by Nautilus Hyosung Inc.
It is the policy of Nautilus Hyosung Inc. to improve products as new technology,
components, software, and firmware become available. Therefore Nautilus Hyosung
Inc. reserves the right to change specificationswithout notice.

Installation Manual Chapter1.Preface
© Nautilus Hyosung, Inc. All Rights Reserved. 1-2
Conventions
►Terminologies
In this document the terminology listed below is used as follows:
▪Customer and consumer refer to any person who transacts business through the
ATM.
▪Device and unit refer to the standard and optional ATM equipment, such as monitor,
card reader, printer and dispenser.
▪Fascia refers to the entire front portion of the unit, including the portion where the
customer transacts business.
▪Module refers to a plug-in device that can be serviced or replaced.
▪Note(s) and bill(s) refer to the individual documents loaded into and dispensed from
the dispenser.
▪Servicing and maintenance refer to the supervisor, operator and technician’s tasks
performed to keep the ATM operational.
▪Screen refers to the text appearing on the customer display.
Abbreviations of ATM
►In this document the abbreviations listed below is used as follows:
#
Abbreviations
Description
1
AD board
Analog to Digital conversion board
2
ADA
The American Disabilities Act
3
ALG
Alignment Module
4
AP
Application Program
5
Assy
Assembly
6
BATT S/W
Battery Switch
7
BC
Bill Checker
8
BM1
Body Module1
9
BM2
Body Module2
10
BM3
Body Module3
11
BUNDLE
Bulk Note Separation Module
12
CAM
Camera Unit
13
CASSETTE
Cash & Check Cassette
14
CCIM
Cash & Check In Module
15
CCR
Contactless Card Reader
16
CDU
Cash Dispenser Unit
17
CE
Control Electronics
18
Earphone Jack
Voice Converter for Visually Disabled Persons (ADA)
19
EMV
Europay, Mastercard, Visa

Installation Manual Chapter1.Preface
© Nautilus Hyosung, Inc. All Rights Reserved. 1-3
#
Abbreviations
Description
20
EP
Elementary Program
21
EPP
Encryption PIN Pad
22
ESCROW
Escrow Module
23
FELT
Ink Head Cleaner Felt
24
H/W
Hardware
25
I/F
Interface
26
ISO
International Standard Organization
27
ISO 1
IATA(International Air Transaction Association)
28
ISO 2
ABA (American Banks Association)
29
ISO 3
MINTS(Mutual Institutions National Transfer Systems)
30
JPR
Journal Printer
31
LCD
Liquid Crystal Display
32
MCU
Magnetic Card Unit
33
OPL
Operation Panel for Customers to Operate
34
OSD board
On Screen Display Board
35
P/S
Power Supply
36
PIN
Personal Identification Number
37
PNC
Panel Control Board
38
PRT
Endorsement Module
39
PTR
Printer (mainly Receipt Printer)
40
RECOG
Recognition Module
41
REJECT
Reject Module
42
RT/A6
Retract & A6 Cassette
43
S/W
Switch
44
SCM
Separator Control Module
45
SIU
Sensor and Indications Unit
46
SP
Service Provider
47
SPR
Slip Printer (Receipt Printer)
48
TTU
Text Terminal Unit (OPL or SPL)
49
VFD
Vacuum Fluorescent Display

Installation Manual Chapter1.Preface
© Nautilus Hyosung, Inc. All Rights Reserved. 1-4
Safety Precautions (English)
▶Common Safety Precaution
Precautions outlined this manual provide information on safe
and proper handling of the product. Non-compliance of the
precautions may result in injury or damage to the product.
This precaution symbol with sample term tells you safety
warnings during equipment handlings.
▶Please read the following instructions before operating equipment.
▪Operate equipment in the order outlined in this manual.
▪Follow precautions indicated in this manual, as well as the equipment itself.
Failure to properly address these precautions may lead to injury or damage to the
product.
▪Avoid operations not addressed in this manual.
▪If you cannot remedy system problems using the methods outlined in this manual,
please refer to contact information listed in the manual.
▪Any change or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
<Note!>
This equipment has been tested and found to comply with the limits for a ClassA
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
▶Description of Precaution Symbols
Symbol
Description
Electrical Shock Warning
▪Do not remove cover. Only a maintenance engineer is
allowed to open the cover.
▪Do not touch. You may receive electric shock.
▪Make sure to turn off the power when servicing the
equipment.

Installation Manual Chapter1.Preface
© Nautilus Hyosung, Inc. All Rights Reserved. 1-5
High Temperature Warning
▪Do not touch the equipment when it is running.
▪The equipment can get extremely hot and may cause a
burn.
▪Make sure to close the cover before running the
equipment.
Use Precaution when Moving
▪The equipment is heavy. Make sure at least 2 people lift or
move the equipment.
▪Do not attempt to move the equipment alone. You may be
injured from dropping the heavy equipment.
Fire Hazard
▪Place the equipment in an area away from any
combustible materials.
▪The equipment may catch onfire from overheating or short
circuit of the power supply unit.
Disassembly Warnings
▪Do not disassemble or modify the equipment unless you
are a certified engineer.
▪Contact the service center for maintenance, adjustments
and repairs.
▪Improper disassembly may cause fire or electrical shock.
Collapse Precautions
▪Do not place the equipment where the floor cannot sustain
the weight of the equipment, or on slanted or unstable
surface.
▪Equipment may fall and cause injury or damage.
Unplug the Equipment
▪Stop using the equipment immediately if it smokes, emits
an unusual smell, makes abnormal sounds, or if liquids or
other foreign materials enter the equipment.
▪If the above-mentioned abnormalities occur, immediately
turn off the power, unplug the equipment and contact the
service center.
▪If you ignore these symptoms, the equipment may catch on
fire or cause electric shock.
<Caution !>
1. TO REDUCE THE RISK OF FIRE, USE ONLY No. 26 AWG OR LARGER
TELECOMMUNICATION LINE CORD
2. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSED OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
3. FOR PLUGGABLE EQUIPMENT, THE SOCKET-OUTLET SHALL BE INSTALLED
NEAR THE EQUIPMENT AN SHALL BE EASILY ACCESSIBLE
4. THE EQUIPMENT IS TO BE SECURED TO THE BUILDING STRUCTURE BEFORE
OPERATION

Installation Manual Chapter1.Preface
© Nautilus Hyosung, Inc. All Rights Reserved. 1-6
Précautions pour la sécurité (French)
►Précaution générale pour la sécurité
Précautions décrits de ce manuel fournissent des informations
sur une manipulation sûre et appropriée du produit. Le non-
respect des précautions peut causer des blessures ou
endommager le produit.
Ce symbole de précaution avec le terme d’example vous
indique des consignes de sécurité lors de la manipulation de
l'équipement.
►Veuillez lire des instructions suivantes avant d'utiliser l'équipement
▪Fonctionner l'équipement dans l'ordre indiqué dans ce manuel.
▪Suivre les précautions indiquées dans ce manuel, ainsi que l'équipement lui-même.
Le défaut de traiter correctement de ces précautions peut entraîner des blessures ou
endommager le produit.
▪Évitez des opérations non traitées dans ce manuel.
▪Si vous ne pouvez pas résoudre des problèmes du système en utilisant des méthodes
décrites dans ce manuel, veuillez se référer aux informations de contact figurant dans
le manuel, s’il vous plaît.
▪Certain changement ou des modifications dans la construction de ce dispositif qui ne
sont pas expressément approuvés par la partie responsable de la conformité
pourraient annuler l'autorité de l'utilisateur de faire fonctionner l'équipement.
<REMAQUE!>
Cet équipement a été testé et fondé pour se conformer aux limites pour un
équipement numérique de classe A, conformément à la partie 15 des règles FCC. Ces
limites sont conçues pour fournir une protection raisonnable contre des interférences
nuisibles lorsque l'équipement est utilisé dans un environnement commercial. Cet
équipement génère, utilise et peut émettre des fréquences radios et, s'il n'est pas
installé et utilisé conformément aux instructions de ce manuel, peut causer des
interférences nuisibles aux communications radios.
Le fonctionnement de cet équipement dans une zone résidentielle est susceptible de
provoquer des interférences nuisibles dans le cas, l'utilisateur devra corriger ces
interférences à ses propres frais.
►Description des symboles de précaution
Symbole
Description
Choc électrique
• Ne pas retirer le couvercle. Seul le technicien d'entretien est
autorisé à ouvrir le couvercle.
• Ne pas toucher. Vous pouvez avoir un choc électrique.
• Assurez-vous d'éteindre l'appareil lors de l'entretien de
l'équipement.

Installation Manual Chapter1.Preface
© Nautilus Hyosung, Inc. All Rights Reserved. 1-7
À haute temperature
• Ne pas toucher l’équipement quand il est en marche.
• L’équipement peut devenir extrêmement chaud et peut
provoquer une brûlure.
• Assurez-vous de fermer le couvercle avant de lancer
l'équipement.
Soyez prudent lors du déplacement
• L'équipement est lourd. Assurez-vous d'au moins 2
personnes pour soulever ou déplacer l'équipement
• N'essayez pas de déplacer l’équipement seul. Vous pouvez
être blessés par la chute de l'équipement lourd.
Risque d'incendie
• Placer l’équipement dans une zone éloignée de tous les
matériaux combustibles.
• L'équipement peut s'enflammer de surchauffe ou de court-
circuit de l'unité d'alimentation.
Démontage
• Ne pas démonter ou de modifier l'équipement, sauf si vous
êtes ingénieur certifié.
• Contacter le centre de service pour l'entretien, le réglage et
la réparation.
• Le mauvais démontage peut provoquer un incendie ou un
choc électrique.
Tomber
• Ne pas placer l'équipement dont le sol ne peut pas supporter
le poids de l'équipement, ou sur une surface inclinée ou
instable.
• L'équipement peut tomber et provoquer des blessures ou
des dommages.
Débrancher l'équipement
• Cessez d'utiliser l’équipement immédiatement si il fume,
émet une odeur inhabituelle, fait des bruits anormaux ou si
des liquides ou d'autres matériaux étrangers dans
l'équipement.
• Si les anomalies mentionnées ci-dessus se produisent,
éteignez immédiatement la puissance, débranchez l'appareil
et contactez le centre de service.
• Si vous ignorez ces symptômes, l’équipement peut prendre
feu ou provoquer un choc électrique.
AVERTISSEMENT :
1. POUR RÉDUIRE LES RISQUES D'INCENDIE, UTILISEZ UNIQUEMENT AWG No. 26
OU LA LIGNES DE TELECOMMUNICATION PLUS GROSSE
2. RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN TYPE
INCORRECT. DISPOSER POUR UTILISATION DES BATTRIES SELON LES
INSTRUCTIONS
3. POUR LES APPAREILS RACCORDES, LA PRISE DOIT ETRE INSTALLEE PRES
D’EQUIPEMENT POUR ÊTRE FACILEMENT ACCESSIBLE
4. L’EQUIPEMENT DOIT ETRE SECURISE A LA STRUCTURE DU BATIMENT AVANT
D'UTILISER

Installation Manual Chapter1.Preface
© Nautilus Hyosung, Inc. All Rights Reserved. 1-8
Related Document
►The related documents are listed as follows. If needed, please contact staffs of our
technical support team and maintenance team.
▪Operator Manual
▪Service Manual
▪Error Code Manual
►For the contact of maintenance staffs of Nautilus Hyosung Inc., see the E-mail
addresses and telephone numbers provided separately.

Installation Manual Chapter2. Introduction
© Nautilus Hyosung, Inc. All Rights Reserved.2-1
Chapter2. Introduction
About the MX7600DR
▶The MX7600DR ATM gives a new look for your customer as a drive-up-rear-access wall
type ATM solution. This compact, convenient ATM can still be easily installed and
operated with an economic cost. As well as offering traditional cash dispense
functionality, both cash and checks can be deposited directly into the ATM. This manual
is designed to provide installation guide for the MX7600DR ATM and provide detailed
description of the following:
This manual is designed to provide installation guide for the MX7600DR ATM and
provide detailed description of the following:
- Information for installation
- Environmental Specification
- Power Specification
►The benefits that the new concept MX7600DR provides are as follows.
1. Removes inconvenience which occurs when bank tellers directly handle cash and
checks with customers and relieves workload upon tellers by processing
deposit/withdrawal of cash/check automatically.
2. Relieves risks and burden of directly handling cash/check by directly keeping
cash/check deposited in a safe.
3. Allows tellers to calculate and close amount on hand faster than the existing
manual calculation.
4. Abank customer and a teller can easily interact on a touch screen, just like talking,
through Nautilus Hyosung Inc.’s intuitive and easy UI.
5. Supports expanded options as well as basic functions of deposit/withdrawal of
cash/check.
6. Allows easy and quick installation and maintenance.

Installation Manual Chapter3. Installation Information
© Nautilus Hyosung, Inc. All Rights Reserved.3-1
System Identification Label
▶The System Label below shows the layout of the product identification label which is
fixed inside the side box of theATM

Installation Manual Chapter3. Installation Information
© Nautilus Hyosung, Inc. All Rights Reserved.3-2
Chapter3. Installation Information
Installation Condition and Space
►Installation Condition and Space
When you determine the location of your MX7600DR ATM, ensure that the physical
environment, including the temperature and humidity, meets the requirements.
Following conditions should be met before installing equipment.
▪Avoid locations where intense direct light is reflected off the LCD screen.
▪Avoid locations where strong static electricity can occur.
▪The floor must allow easy wheelchair access from the front or the side.
▪Space required for servicing the machine should be considered before installation.
Environmental Specification (temperature & humidity)
▶Environmental Specification (temperature & humidity)
Operating
Temperature Range
-10°C ~ 40°C [14°F ~ 104°F]
Relative Humidity
25% ~ 86%
Storage
Temperature Range
-5°C ~ 50°C [23°F ~ 122°F]
Relative Humidity
10% ~ 90%
Tools required for installation
▶Tools required for installation
In order to move the machine and place it in a proper location, you should seek the help
of professionals trained in moving heavy equipment. Following tools are needed to
install the machine
1
Wire cutter
5
Leveling tool
2
Lifter
6
Silicone
3
Screw driver (Flat, Phillips)
7
Silicone gun
4
Wrench (Spanner)

Installation Manual Chapter3. Installation Information
© Nautilus Hyosung, Inc. All Rights Reserved.3-3
Packing Dimensions
►Packaging Dimensions
The design of packing used on below picture is structured for shipping of MX-7600DR
by load or air/sea freight.
<Note !>
Approximate weight of a boxed MX7600DR ATM is 700.0Kg [1543.23Ib].
Actual weight will vary depending on ATM component configuration.
ATM Dimensions
▶ATM Dimensions
The following diagrams show the dimensions of MX-7600DRATM.

Installation Manual Chapter3. Installation Information
© Nautilus Hyosung, Inc. All Rights Reserved.3-4

Installation Manual Chapter3. Installation Information
© Nautilus Hyosung, Inc. All Rights Reserved.3-5
< Dimension of Outline >

Installation Manual Chapter3. Installation Information
© Nautilus Hyosung, Inc. All Rights Reserved.3-6
Dimension for tilt angle
►Dimension for tilt angle
The following diagrams show the dimensions for tilt angle of MX-7600DR ATM.
< Default :10˚ >

Installation Manual Chapter3. Installation Information
© Nautilus Hyosung, Inc. All Rights Reserved.3-7
< 1Step 22°>
< 2Step 35°>

Installation Manual Chapter3. Installation Information
© Nautilus Hyosung, Inc. All Rights Reserved.3-8
Fascia Item Locations for Voice Guidance
►Fascia Item Locations for Voice Guidance.
Unit
MCU
CCIM
CDU
SPR
Symbol
A
B
C
D
Distance
167.5mm
[6.59inch]
347.3mm
[13.67inch]
134.0mm
[5.28inch]
145.6mm
[5.73inch]
From
No.5 Key
Clock
Face
3
4
6
10
Postion
A
B
C
D
