Nuna Pipa lite User manual

pipa™lite

Designed
around your life

2PIPA lite instructions
IMPORTANT!
KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE:
READ CAREFULLY

3PIPA lite instructions
Contents
Product Information
Product Registration 4
Recall Information 4
Warranty 5
Contact 5
Child Usage Requirements 5
Warnings 6
Vehicle Compatibility 10
Infant Car Seat Parts List 14
Base Parts List 16
Product Overview 18
Product Use 28
Installation 32
Accessories 40
PIPA organic cotton insert 40
PIPA adapters 40
Cleaning and Maintenance 42

4PIPA lite instructions
Product Information
Model Number: __________________________________
Manufactured (date): ___________________________
Product Registration
Please fill in the above information. The model
number and the manufactured date are located
on a label on the bottom of your child restraint.
Fill out the prepaid registration postcard attached
to the seat pad and mail it today.
Child restraints could be recalled for safety reasons.
You must register this restraint to be reached in a
recall. Send your name, address, e-mail address if
available and the Child Restraint’s model number
and manufacturing date to:
Nuna Canada
4500 Thimens Blvd., Suite 100
St-Laurent, QC, H4R 2P2
or call 1.800.667.4111
or register online at:
www.nuna.eu/caen
Recall Information
For recall information, call the Transport Canada at:
1.800.333.0371 or
go to www.tc.gc.ca

5PIPA lite instructions
Warranty
We have purposely designed our high-quality
products so that they can grow with both your child
and your family. Because we stand by our product,
our gear is covered by a custom warranty per product,
starting from the day it was purchased. Please
have the proof of purchase, model number and
manufactured in date available when you contact us.
For warranty information please visit:
www.nuna.eu/caen
Contact
For replacement parts, service, or additional
warranty questions, please contact our customer
service department.
[e-mail]
1.800.667.4111
Child Usage Requirements
PIPA lite and PIPA lite lx are suitable for use with
children who meet the following requirements:
Weight: 1.8 to 10 kg (4 to 22 lbs)
Height: less than 81 cm (32 inches)
It is recommended to keep your child rear facing as
long as possible.

6PIPA lite instructions
WARNING
Failure to follow these warnings, instructions
and labels on the child restraint could result
in serious injury or death.
A child’s safety is your responsibility. NEVER
leave your child unattended.
Read all instructions before use of this
child restraint or installation in a vehicle. In
addition, read the vehicle owner’s manual
for information on child restraint installation.
Use the bottom of the base for storage of
the instruction manual.
This child restraint can ONLY be used
in a rear facing position when used in a
vehicle and MUST be installed in a vehicle
with the base. This child restraint cannot
be properly secured in a forward facing
position or without a base. Use only with
children who weigh between 1.8 and 10 kg
(4 and 22 lbs) and whose height is 81 cm
(32 inches) or less. Exceeding these height
and weight limits is unsafe.
Snugly adjust the belts provided with this
child restraint aroundyourchild. Ifstraps are
not snugly adjusted, child may be ejected
from seat in the event of an accident.

7PIPA lite instructions
A snug strap should not allow any slack.
It lies in a relatively straight line without
sagging. It does not press on the child’s
flesh or push the child’s body into an
unnatural position.
Register your child restraint with the
manufacturer.
Cover the child restraint when your vehicle
is parked in sunlight. Parts of a child restraint
can become very hot if left in the sun, and
can burn a child’s skin. Check for hot parts
before putting your child in the child
restraint.
Replace this child restraint if it has been
involved in a crash, even if it was minor and
there appears to be no damage to the child
restraint.
EXPIRATION DATE
Do not use this infant restraint system more
than 7 years after date of purchase (proof of
purchase required) or date of manufacture
otherwise. Please keep a copy of the receipt
with this user guide for future reference.
Check the label on the underside of the
base or child restraint for expiration date
information.

8PIPA lite instructions
FALL HAZARD Child’s activity can move
carrier. NEVER place carrier on counter
tops, tables, or any other elevated surface.
Always stay within arms reach whenever
carrier is not on floor/ground. Be sure
handle locks into position before lifting
carrier.
STRANGULATION HAZARD Children have
strangled in loose or partially buckled
harness straps. Fully restrain the child even
when carrier is used outside the vehicle.
SUFFOCATION HAZARD Infant carrier can
roll over on soft surfaces and suffocate
child. Never place carrier on beds, sofas, or
other soft surfaces.
ALWAYS check child restraint to base
connection.
THIS INFANT RESTRAINT SYSTEM
CONFORMS to Canada Motor Vehicle
Safety Standard 213.1
DO NOT allow anyone who has not read
the instruction manual to install or use this
child restraint.
DO NOT allow child restraint or handle to
contact the vehicle interior (side of car door
or seat in front) when installed on base.

9PIPA lite instructions
DO NOT use child restraint if it has frayed
or cut harness straps, or is damaged in
any way. To find out if damaged parts are
replaceable, call 1-800-667-4111.
DO NOT use any products or accessories
with this child restraint unless they are
approved by Nuna for use with this child
restraint. Doing so may be unsafe and may
void the warranty.
NEVER leave child restraint and base
in vehicle when uninstalled, even when
unoccupied. In a crash, it could become
a projectile and injure other vehicle
occupants.
NEVER modify any part of the child
restraint.
NEVER use clothing or blankets that
interfere with providing a properly
tightened harness. An unsecured or
improperly harnessed child can come
out of the restraint during a crash. Place
blankets over child AFTER harness has
been properly tightened.
NEVER place carrier on top of a shopping
cart. Carrier will not be properly secured
and could fall.
Only use with Nuna strollers or appropriate
Nuna adapters designed for use with other
strollers.

10 PIPA lite instructions
Vehicle Compatibility
You MUST read and understand ALL child restraint
related instructions and warnings in your vehicle
owner’s manual to correctly and safely use this
child restraint in your vehicle.
This child restraint can ONLY be installed on
vehicle seats that face forward and MUST be
installed in a vehicle with the base. DO NOT install
in seats that face to the sides or rear of the vehicle.
NEVER install this child restraint rear facing in
a vehicle seating position with a frontal air bag
unless it is turned off. Airbags inflate with great
force and can cause severe injury to a child’s neck
and spine.

11PIPA lite instructions
If your vehicle is equipped with passenger side air
bags, check your vehicle owner’s manual for child
restraint installation instructions.
According to accident statistics, children are
safer when properly restrained in the rear seating
positions than in the front seating positions.
Refer to your vehicle owner’s manual to determine
if the belts in your vehicle lock by switching the
seat belt’s retractor OR if they have a locking latch
plate that locks the vehicle’s seat belt so they will
hold the child restraint tightly without loosening.

12 PIPA lite instructions
This child restraint MUST be installed in a
vehicle with the base.
The following vehicle belts CANNOT BE USED with
your child restraint:
1 - Motorized Belts (Automatic)
These should not be used unless the shoulder
belt can be removed, the lap belt is locked and
use is allowed by the vehicle manufacturer.
2 - Dual Retractor Lap/Shoulder Belts
If allowed by the manufacturer, the lap belt
only may be used to secure the child restraint in
accordance with this manual and the vehicle’s
manual.
3 - Non-Locking (ELR) Lap Belts
This belt locks in a crash or sudden stop and
should only be used with a belt shortening clip.
Contact your vehicle manufacturer if needed.
4 - Airbag/Inflatable Belts
This belt can not be used to install this child
restraint.
5 - Door Mounted Belts
This belt can not be used to install this child restraint.
6 -Lap Belts forward of Seat Bight
This belt (where the seat bottom and back
meet) should not be used to install this child
restraint.
This infant restraint system is not to be used in
vehicles that do not have seat belts or UAS.
This restraint system can only be used in these
classes of vehicles: passenger cars, multipurpose
passenger vehicles and trucks that have vehicle
lap/shoulder belts and UAS.

13PIPA lite instructions
6
5
4
3
2
1

14 PIPA lite instructions
Infant Car Seat Parts List
Make sure all parts are available before assembly.
If any part is missing, please contact Nuna (see
page 4 for information). No tools are required
for assembly.
1 Canopy
2 Seat Pad
3 Body Support (x2)
4 Chest Clip
5 Buckle and
Crotch Pad
6 Harness
Adjustment Button
7 Harness
Adjustment Strap
8 Buckle Holder
9 Handle Adjustment
Button
10 Stroller Release
Button*
11 Canopy Release
Button
12 Shoulder Harness
Pads
13 Head Support (x2)
14 Handle
15 Stroller Release
Button**
16 Harness Slots
17 Base Attachment
Bar
18 Harness Straps
19 Shoulder Harness
Loops
20 Splitter Plate
21 Base Attachment
Bar
*only used with infant car seat post adapters
**only used with infant car seat ring adapters

15PIPA lite instructions
5
3
4
6
9
214
1
12
10
11
13
8
7
13
3
15
18
16
17
19
20
21

16 PIPA lite instructions
Base Parts List
Make sure all parts are available before assembly.
If any part is missing, please contact Nuna (see
page 4 for information). No tools are required for
assembly.
1 Vehicle Belt Lock Off
2 Rigid UAS
(lower attachments)
3 Primary Rigid UAS
Release Button
4 Secondary Rigid UAS
Release Button
5 Rigid UAS Guides
6 Carrier Release
Button
7 Instruction Manual
Storage

17PIPA lite instructions
7
1
2
3
4
5
6

Product Overview
Canopy
1 - To attach the canopy, snap the canopy to the
canopy mount on both sides. To open the
canopy, pull the canopy toward the front of the
seat, and to close the canopy, push it back.
2 - To remove the canopy, reverse step 1. Then
unsnap the seat pad from the shell and lift
fabric up.
3 - Press the canopy release button (1) and pull
canopy through the fabric slot (2).
Repeat on opposite side.
Dream Drape™
Included on PIPA lite lx models.
4 - Unzip the zipper behind the front canopy bow.
5 - Pull the dream drape™out of the compartment.
Attach the dream drape™to the magnets on
each corner to the front of the carrier.
Shoulder Harness Pads
6 - Shoulder harness pads are removable.
Unfasten the hook and loop to remove the
shoulder harness pads.
18 PIPA lite instructions

1
2
1
2
3
4
5
6
19PIPA lite instructions
