PROAIM Tango P-TNGO-01 User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Tango 360° Camera Rotang Dutch Angle Rig (P-TNGO-01)
Assembly Manual
Camera Plaorm
Tango 360° Camera Rotang Dutch Angle Rig
Camera Plaorm Rods with Stopper
1.5mm L
Type Allen Key

2
 Loosen and remove the stopper of the camera
plaorm rods, as shown in the picture.
 Loosen and remove the stoppers from the
camera plaorm rods, as shown in the
picture.
Tango 360° Rig Setup
 Insert the rods into the camera plaorm and
then secure them properly using a 1.5mm
Allen key. Follow the same process on the
other side as well.
 Loosen the red knob of the Tango 360°
camera rotang Dutch angle rig and then
insert it into the rods.
 Follow the same process on other side.
 Aer inserng the rods into the camera
plaorm hole, insert the stoppers from the
boom and ghten them to secure properly.

3
 Aer inserng it into the rods, secure it
properly with the help of the red knob and
then secure the rods properly from the top
with the help of stoppers.
 Properly aach the Ball Head (Not Included)
to the tripod, by matching it with the 3/8”
thread of the Tripod.
NOTE: Tripod comes with a (1/4” & 3/8”) quick
tripod mounng threads.
 Remove the camera plate as shown.
Camera Setup
 To give the Ball Head a 360° rotaon, loosen
the knob a lile and then rotate the knob to
ghten it again. To remove the Camera Plate,
loosen the knob.
 Aach the camera plate to the boom
mounng 1/4” thread of tango dutch angle rig
and secure it with the help of an Allen key.
 Rods are properly secured via stopper.

4
 Then mount it on the Ball Head (Not Included)
and properly secure it with the help of the
knob.
 To move the camera platform’s position up
and down, loosen the red knob, then
according to your requirement, set the height
at a position where you want your camera
and then properly tighten its knob.
NOTE: Height-adjustable camera plaorm, lets
you posion the camera at an accurate level
where the shot requires.
 Fix your setup on the Tango 360° Camera
Rotang Dutch Angle Rig at a specic angle
and secure it properly using the rotaon lock.
It facilitates a camera rotaon lock so that
you keep it to a specic angle for a stac shot.
NOTE: Tango 360° Camera Rotang Dutch Angle
Rig has a 360° rotaon feature, It oers full 360°
rotaon around its lens and also, allows you to
set the rotaon angle
NOTE: Reproduce the shot without trouble, has
angular ring and stopper to set rotaon.
 Mount the camera (Not Included) on the
camera plaorm plate. It is provided with a
(1/4”-20) Screw, properly secure it with the
help of the Allen key.
NOTE: Camera plaorm adapts DSLR cameras
with ¼” screw.

5
 Now your Setup is ready to use.
 Aer aaching the uid head’s top plate,
mount it on the top of the uid head
(Not Included) and then push the red knob, as
shown in the picture.
 Aach the uid head (Not Included) by
matching its top plate thread with boom
side of tango and secure them properly using
an Allen key.
 To mount the tango angle rig on the uid
head (Not Included) release the top plate of
the uid head by pulling the red knob.
YOUR PROAIM TANGO 360° CAMERA ROTATING DUTCH ANGLE RIG
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)

6
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
