PROAIM CINEMA DL-CLBS-01 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Assembly Manual
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Push Bar Handel
What’s In The Box
Columbus Video Camera Plaorm Dolly (DL-CLBS-01)
T-Type Allen Key
(Size: 6mm)
Columbus Plaorm Dolly

2
Columbus Dolly Setup
 Place the Columbus Dolly on the Velvet Steel
Track (Not Included), as shown in the image.
 Now place the Columbus Dolly onto the
Velvet Steel Track (Not Included). Make sure
all wheels are aligned correctly on the track
and dolly runs smoothly.
NOTE: It smoothly maneuvers on a curved or
convenonal track with equipped 4 x 4
skateboard wheels that assure awless and
smooth mobility without dri, noise, or
excessive rolling resistance.
 Now, attach the push Bar Handle to the side
corner of the Columbus Dolly by tightening
both the knobs to properly secure it.
 The push bar handle is properly attached to
the Columbus Dolly.
NOTE: The push-bar handle oers smooth dolly
operaons; it can be aached to any four
corners of the plaorm of the dolly.
Assembling Push Bar Handel
NOTE: Adding to that, the wheel has a push and pull mechanism that allows the wheels to be readily
aached and removed from the dolly at any given moment.

3
 Place the Adapter Plate by matching it
(Not Included) with the center thread hole of
the Dolly, and then insert the bolts.
 After inserting the bolts in the Euro Adapter
Plate (Not Included), tighten the bolts with
the help of the Allen Key.
 Loosen the Knob of the Flexino Bazooka
(Not Included) and mount it on the Euro
Adapter Plate (Not Included), as shown in the
image.
 After properly mounting the Flexino Bazooka
(Not Included) onto the Euro Adapter Plate
(Not Included), securely re-tighten the
assembly with the ratchet knob.
 Loosen the ratchet knob of Bowl Riser
Adapter (Not Included), and then attach it to
the top of the Flexino Bazooka (Not Included).
 Then secure the assembly using the ratchet
knob.
Assembling Euro Adapter Plate
Assembling Flexino Bazooka Set

4
 Remove the knob of 75mm Bowl Fluid Head
(Not Included) and mount it onto the Bowl
Riser Adapter (Not Included).
 Then, properly tighten the knob of the Fluid
Head (Not Included) from bottom.
 Pull & release the knob of the Fluid Head, and
then remove the plate. Now, attach the plate
to the bottom of the camera (Not Included).
 Secure the assembly using the screw driver
and mount the camera (Not Included) on the
Fluid Head, as shown in the image.
 Now, pull the knob of the Fluid Head and
properly tighten it to secure the camera
(Not Included).
 Loosen the knob of the Cranked Bazooka
(Not Included) and mount it on the Euro
Adapter Plate (Not Included), as shown in the
image.
NOTE: Mulple 3/8”-16 threaded holes on the
dolly plaorm oer incredible mounng
exibility for compable gear and accessories.
That's why you can change the posion of euro
adapter and put it on the side.
Assembling 75mm Fluid Head
Cranked Telescopic Bazooka Setup

5
 After properly mounting the Cranked Bazooka
(Not Included) on the Euro Adapter Plate
(Not Included), secure the Bazooka with the
ratchet knob by tightening it.
 Loosen the ratchet knob of the offset
(100mm Bowl Adapter) (Not Included) and
mount it on the Cranked Bazooka
(Not Included), as shown in the image.
 After properly mounting the offset
(Not Included) on the cranked Bazooka
(Not Included), secure it by tightening the
ratchet knob.
 Mount the 100mm bowl Fluid Head
(Not Included) on the offset (Not Included).
 Place the Turnstile at the center of the
Columbus Dolly by matching the threads
(Not Included).
 Then, properly secure the Turnstile
(Not Included) on the Columbus Dolly with
the help of bolts.
Assembling Oset Euro (100mm Bowl Adapter)
Assembling of Turnsle mount

6
 Properly lock the assembly with the help of
the provided locking brake of the Turnstile
(Not Included).
 Loosen the knob of the seat arm
(Not Included), and then place it on the baby
pin of the Turnstile (Not Included).
 Properly secure it by tightening the knob of
the seat arm (Not Included).
 Loosen the second knob (top seat mounting)
of seat arm (Not Included) and insert the seat
(Not Included) into the seat hole by matching
the threads.
 Now, properly secure the seat by tightening
the seat arm (Not Included) knob.
Compability :
Compable with a Euro-adapter or turnsle
mount, it lets you aach a bazooka, risers,
seats, other compable gears, and accessories.
Assembling of Seat arm

7
YOUR PROAIM COLUMBUS VIDEO CAMERA PLATFORM DOLLY
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
