PROAIM P-12-JS-JRPP User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
12FT Camera Crane Jib, Stand & Jr. Pan-Tilt
(P-12-JS-JRPP)
Assembly Manual
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
1
Jib Stand
Middle Secon
Front Secon
2 x Spanner - 17
1 x Spanner - 13
End Secon
Central Post
6mm Allen Keys
Weight Shank
2 x Flower
Knob
1 x Knob
Central Pool
Adapter
Weight Closers
3 x Velcro
Tool Pouch

2
 Loosen the lower knob of the Jib Stand, as
shown in the image.
Jib Stand Setup
Jr. Pan-Tilt Head
12V Joysck Controller
with Safety cap
12V AC Adapter
15 mtr XLR Cable, 3 mtr Cable
4 x Wings Nuts
MS Check nut
(Size:-1/4)
3 x L-Type
Allen key
2 x Fuse
Storage Bag
Universal
Adapter
Jib Secon Storage Bag
Jib Stand Bag
Index
Sr. No Parculars Page No.
1Jib Arm Assembly 2-3
2Integrating the Section Jib Section 3-6
3Pan-Tilt Head Setup 6-7
4Joystick Controller Attachment 7-8
5Joystick Operation 8
6Final Setup 8-9

3
 Extend the legs along the Center Post to their
widest posion and re-ghten the lower knob
for added stability.
 Insert the Center Post of the Jib onto the
Stand, as shown in the image.
 Aer inserng the Center Post, secure it with
pins.
 Loosen the bolt from the Center post using a
spanner and remove the washers to further
remove the bolt.
 Insert the end of the 2nd secon in the
Center Post and align the holes of the secon
with the Post to screw in the shank.
 Secure the aachment with the help of the
knobs, as shown in the image.
Assembling The Jib Arm
Connect The 2nd Jib Secon To The Center Post

4
 Re-insert the black washers and push the
shank to ghten the aachment with the
dome nut.
 Tighten the dome nut from both sides using a
wrench and secure the Jib secon using a pin,
as shown in the image.
 The jib secon is securely aached to the
middle secon.
 Use the spanner and Allen key to remove the
bolt for seng the posion of the Central
Pool Adapter.
 Set the posion of the Central Pool Adapter
and insert the bolt to properly secure it, as
shown in the image.
 Tighten the bolt using the spanner and Allen
key.

5
 Remove the bolts in the front of the Middle
secon using the spanner and Allen key, as
shown in the image.
 Align the middle and end secons together to
insert the bolt and nuts.
 Tighten the bolt using the spanner and Allen
key to secure it.
 Remove the bolts of the middle secon using
the spanner and Allen key.
 Align the middle and front secons to insert
the bolts to secure them.
 Now, ghten the bolts using the spanner and
Allen key, as shown in the image.

6
 Remove the bolts of the Center pool Adapter
by loosening them.
 Then, align the central pool adapter in the
center of the wire puller and insert the bolt,
as shown in the image.
 Aer inserng the bolt in the Central pool
adapter, ghten it using the Allen key.
 Loosen the wing nuts and detach them.
 Aach the Jr. Pan-Tilt Head to the Front
Secon head plate and insert the screw in the
threaded hole.
 Similarly, insert the remaining screws to
securely aach the Pan-Tilt Head.
Pan Tilt Head Setup

7
 Jr. Pan-Tilt Head is properly Aached to the
Jib.
 Unwrap the Velcro strap around the 12V
joysck controller and safely remove the cap,
as shown in the image.
 Connect the 4-pin male connector of the
cable to the 4-pin female connector on the
head for panning and lng.
 Loosen the knob at the back of the 12V
joysck controller and insert it into the weight
rod.
 Aer properly inserng the Joysck
controller, ghten both the knobs to secure it.
 Now, aach the 4-pin Power Cable with the
Joysck Controller.
Aaching Joysck Controller

8
 Aach one end of the 12v adapter cable to
the adapter.
 Connect the electric plug of the 12v adapter
wire to the universal adapter.
 Aach the 4-pin Power Cable with the
Joysck Controller.
 Loosen the bolt of the Jr. Pan-Tilt Head using
the Allen key and reghten it aer properly
posioning the head.
 Speed Controller- Adjusts the speed of pan &
lt based on the requirement of the shot.
 Damping Control- Prevents the Head from
stopping with a jerk, enabling you to achieve
smooth endings.
 Pan-Tilt Direcon- You can reverse the
panning & lng direcon as & when
required.
Joysck Controlled Movement Funcons

9
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
YOUR PROAIM 12FT CAMERA CRANE JIB WITH STAND
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
 Aach your camera to the Head’s camera
plate using the provided check nut.
NOTE: If the Joysck Control is opposite, undo
the connectors of motors, rotate 180° and
re-install.
 Your Camera is Properly aached with the Jr.
Pan Tilt Head.
NOTE: Proaim Jr. Pan lt oers complete
360° pan & lt inaudible movements while
keeping your camera safe and secure.
