Qlight SH1S User manual

Model number Voltage Current %XOEVSHFL¿FDWLRQV &HUWL¿FDWH Color
Volts/
Watts
&RQ¿JXUDWLRQ Part#
• SH1S Standard type
• SH1SP Protection cage type
• SH1TS Terminal box type
• SH1TSP Protection cage and
terminal box type
DC12
-24V Max. 1.000A
200V
-550V
EUB0641
-1A(G)
U type
48
R-Red
A-Amber
G-Green
B-Blue
AC110V 0.135A
AC220V 0.105A
• SH2S Standard type
• SH2SP Protection cage type
• SH2TS Terminal box type
• SH2TSP Protection cage and
terminal box type
DC12
-24V Max. 1.000A
AC110V 0.135A
AC220V 0.106A
66
5030
1
SH1S/ SH2S
Heavy-Duty Xenon Lamp Strobe Signal Lights for Vessels and Heavy Industry Applications
• Protection rating : IP66
• Ambient operating temperature : -30°C to +50°C
Ordering Specications Product Specications
Please scan the QR code for more
detailed product information.
www.qlight.com
SH1S - 220 - R
[Model
number] [Voltage] [Color]
| | |
• SH1S
• SH1SP
• SH1TS
• SH1TSP
• SH2S
• SH2SP
• SH2TS
• SH2TSP
• 12/24
- DC12V-24V
• 110 -AC110V
• 220 -AC220V
R-Red
A-Amber
G-Green
B-Blue
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
3OHDVHWXUQRWKHSRZHURIWKHSURGXFWLPPHGLDWHO\LILWIDLOVWRRSHUDWHSURSHUO\
&DUHIXOO\ZLUHWKHSURGXFWDFFRUGLQJWRHDFKSURGXFW¶VVSHFL¿FDWLRQ
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
)DLOXUHWRIROORZDQ\RIWKHLQVWUXFWLRQVDERYHPD\FDXVHPDOIXQFWLRQRUGDPDJHWRWKHSURGXFW¿UHDQGHOHFWULFVKRFN
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product
that would void the warranty.
’XULQJZLULQJRUPDLQWHQDQFHSOHDVHFRPSOHWHO\WXUQRWKHSRZHURIWKHSURGXFW)DLOXUHWRIROORZWKLVPD\OHDGWRDQHOHFWULFVKRFN
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
UDWLQJVLQGLFDWHGIRUHDFKSURGXFW)DLOXUHWRIROORZWKHVHLQVWUXFWLRQVPD\FDXVHD¿UHWRWKHSURGXFWHOHFWULFVKRFNSK\VLFDOLQMXU\
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
IROORZWKHVHLQVWUXFWLRQVPD\OHDGWR¿UHHOHFWULFVKRFNRUSURGXFWGDPDJH
3OHDVHDSSO\WKHFRUUHFWYROWDJHWRWKHSURGXFW)DLOXUHWRIROORZWKHVHLQVWUXFWLRQVPD\OHDGWR¿UHHOHFWULFVKRFNRUSURGXFWGDPDJH
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
IROORZWKLVPD\FDXVHGDPDJHWRSURSHUW\¿UHHOHFWULFVKRFNDQGORVVRIOLIH
※CE compliant : DC12V-24V

22
Ø135
178
* (167)
12012
Ø136
149
PCD 155 CABLE ENTRY PF 1/2″
360˚/3-Ø8
FITTING HOLES
TERMINAL BOX
PROTECTION CAGE
Ø135
178
* (167)
12012
Ø136
234
PCD 155
360˚/3-Ø8
CABLE ENTRY PF 1/2″
70
FITTING HOLES
Ø158
Ø154
164
212
146
12
CABLE ENTRY PF 1/2″
PCD 155
360˚/3-Ø8
FITTING HOLES
* (198)
Ø158
Ø154
212
146
12
* (198)
250
TERMINAL BOX
PROTECTION CAGE
CABLE ENTRY PF 1/2″
PCD 155
360˚/3-Ø8
FITTING HOLES
70
Ø135
Ø136
210
178
120
12
TERMINAL BOX
PROTECTION CAGE
CABLE ENTRY PF 1/2″
PCD 155
360˚/3-Ø8
FITTING HOLES
* (167)
CABLE ENTRY PF 1/2″
PCD 155
360 ˚/3-Ø8
FITTING HOLES
TERMINAL BOX
PROTECTION CAGE
223
Ø158
Ø154
212
* (198)
146
12
SH1SP
SH2SP
SH1S-2TP
SH1TSP
SH2TSP
SH2S-2TP
Dimensions
(Units : mm)
■ Dimensions for 2T type has 2 cable entries
※*(167)size without protection cage.
※*(198)size without protection cage.

3
• SH1TS/ SH1TSP/ SH2TS/ SH2TSP
①
SH1S/ SH1SP/ SH2S/ SH2SP SH1TS/ SH1TSP/ SH2TS/ SH2TSP
①
Protection cage
(STS316L)
Lens(PC)
Terminal Box
Housing
(Al)
• Terminal block is located inside of the product. Unscrew the 4 bolts located in the
upper body to get rid of the upper lighting element of the unit.
• Please apply fork (U-type) or ring (O-type) locking spade terminal at naked tip of the
wire for secure connection.
• Please wire the power line to terminal ①
Terminal Box Wiring Instructions
Wiring Instructions
• External power line - UL1015 AWG18(0.75sq) × 2C 400mm
• DC type product can be wired regardless of polarity.
Red
Black
White
Black
Power Power
Fuse Fuse
DC AC
Parts Denition/ Installation
•
First, machine holes on the mounting surface①
•
The mounting hole of this product is 8mm in diameter.
•
When machining taps, fasten the bolt through the mounting hole of the bracket.
• When machining holes, insert the bolt through the hole of the product, and tighten the nut from the opposite side of the mounting
VXUIDFH:KHQDVVHPEOLQJXVLQJEROWDQGQXWSOHDVHPDNHVXUHWRXVHDWZDVKHUDQGVSULQJZDVKHU
■ Parts Denition
v
Installation
※Applicable cable range : AWG16-AWG22
Mounting bracket
(STS316L)

3-Ø9 HOLES
PCD 155
4
Installation Environment and Protection Rating
• This product is designed for use with protection rating of IP66.
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating
indicated(IP66), it may cause malfunction or damage to the product.
• For further information, please visit our website (www.qlight.com).
• Machine holes on the mounting surface referring to the
diagram below.
v
Xenon Bulb Replacement instructions
v
Mounting Hole Specications
Mounting Hole Specications/ Xenon Bulb Replacement lnstructions
3OHDVHZDLWDWOHDVWPLQXWHDIWHUWXUQLQJRWKHSRZHUEHIRUH
replacing the xenon bulb.
• Please pull out the entire xenon bulb structure ① to disassemble
while pushing the hook down.
• For xenon bulb assembly, please push down the connector portion
of the xenon bulb structure to the connector pin location ②until it
makes “clark” sound.
①
②
Disassemble bulb Assemble bulb

Product installation direction
■ Install the product in accordance with the manual. Otherwise rainwater or moisture may penetrate into the product.
ㆍELECTRONIC SOUNDER/SIGNAL HORN
Sounder part shall not be facing the sky.
Sounder part shall not be facing the sky.
ㆍBEACON/SIGNALING LIGHT
Power cord inlet part shall not be facing the sky.
Power cord inlet part shall not be facing the sky.
ㆍSIGNAL TOWER LIGHTS
ㆍHEAVY-DUTY & EXPLOSION PROOF SIGNALINGS
※For products with a protection rating of less than IPX4, please install it vertically.
※For products with a protection rating of less than IPX4, please install it vertically.

MEMO

MEMO

Qlight Co., Ltd. www.qlight.com | [email protected]
+HDG2FH_6XLWH67;97RZHU*DVDQGLJLWDOUR*HXPFKHRQJX6HRXO.RUHD
Tel. [phone](Toll free. [phone]) Fax. [phone]
)DFWRU\_0XNEDQJUR6DQJGRQJP\HRQ*LPKDHVL*\HRQJVDQJQDPGR.RUHD7HO7ROOIUHH
4OLJKW2YHU6($V6DOHV’HSW_ 1DNGRQJGDHUR6DVDQJJX%XVDQ.RUHD(RPJXQJ’RQJ7HO
4OLJKW3XEOLF5HODWLRQV0DUNHWLQJ7HDP2FH_1DNGRQJGDHUR6DVDQJJX%XVDQ.RUHD(RPJXQJ’RQJ7HO
Qlight USA, Inc. www.qlight.com www.qlightusa.com | [email protected]
3003 North First Street, Suite #341, San Jose, CA95134 USA Tel. [phone] Fax. [phone]
SHANGHAI Qlight Electronic Co., Ltd. www.qlight.com www.qlightcn.com | [email protected]
&KLQD)DFWRU\6KDQJKDL6DOHV2FH_1DQGD5RDG%DRVKDQ$UHD6KDQJKDL&KLQD7HO - 21 - 6651 - 7100 Fax. +86 - 21 - 6315 - 3929
&KLQD)DFWRU\6LWH4LGRQJ_+DL\DQ5RDG4LGRQJ+LJKWHFK,QGXVWULDO’HYHORSPHQW=RQH4LGRQJ-LDQJVX3URYLQFH&KLQD
Tel +86 - 513 - 8384 - 9999 Fax +86 - 513 - 8384 - 9910
Product Operation Inquiry / Customer Support [phone]
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.
