Qlight QTG-WIZ User manual

PB 1
Wireless LED Steady/ Flashing Tower Light
QTG-WIZ
54 65
85dB
5030
QTG60L-WIZ
-3-24 -RAG -LW18
[Model number] [Layer count] [Voltage] [Color] [Mounting option]
| | | | |
• QTG60L-WIZ
• QTG60L-WIZ-BZ
• QTG60LF-WIZ
• QTG60LF-WIZ-BZ
• QTGA60L-WIZ
• QTGA60L-WIZ-BZ
• QTGA60LF-WIZ
• QTGA60LF-WIZ-BZ
• 1 Layer
• 2 Layers
• 3 Layers
• 4 Layers
• 5 Layers
• 12-DC12V
• 24-DC24V
• 110/220
- AC110V~220V
R-Red
A-Amber
G-Green
B-Blue
W-White
• (Blank)
- Standard type
• Mounting type
- LB18 - L W 18
- QZ18 - SZ18
- QL18 - SL18
- QLA18
QTG70L-WIZ
-3-110/220 -RAG -LW24
[Model number] [Layer count] [Voltage] [Color] [Mounting option]
| | | | |
• QTG70L-WIZ
• QTG70L-WIZ-BZ
• QTG70LF-WIZ
• QTG70LF-WIZ-BZ
• QTGA70L-WIZ
• QTGA70L-WIZ-BZ
• QTGA70LF-WIZ
• QTGA70LF-WIZ-BZ
• 1 Layer
• 2 Layers
• 3 Layers
• 4 Layers
• 5 Layers
• 12-DC12V
• 24-DC24V
• 110/220
- AC110V~220V
R-Red
A-Amber
G-Green
B-Blue
W-White
• (Blank)
- Standard type
• Mounting type
- LB24 - L W 24
- QZ24 - SZ24
- QL24 - SL24
- QLA24
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn off the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s specication.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product
that would void the warranty.
1. During wiring or maintenance, please completely turn off the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
ratings indicated for each product. (Failure to follow these instructions may cause a re to the product, electric shock, physical injury,
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
follow these instructions may lead to re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
follow this may cause damage to property, re, electric shock and loss of life.)
Ordering Specications
Please scan the QR code for more
detailed product information.
www.qlight.com

2 3
Application Software USB DONGLE GATEWAY ROUTER
(wireless signaling device)
• Wireless LED Steady/Flashing Tower light has monitoring and controlling feature via PC that consists of USB DONGLE and GATEWAY.
■ Description
No. Item Description
1PC and mobile
Application
PC Application would be a comprehensive control system by enabling the setting, monitoring, control
and log analysis of the wireless signaling device.
C# based application and software developer’s API are provided.
Mobile application can help to expand utility manager’s coverage.
2USB DONGLE
(WIZ32)
USB DONGLE (WIZ32) can connect up to 32 wireless signaling device and is connected to the PC
through a USB port in serial communication. It does not require a separate installation but simply inser-
tion into a USB port for use.
Note : USB DONGLE does NOT support Mobile application.
3GATEWAY
(GW768)
GATEWAY (GW768) can connect up to 32 wireless signaling device. Since it is possible to extend up to
24 GATEWAYs with a LAN ROUTER, they can connect up to 768 wireless signaling device.
Note : GATEWAY supports Mobile application.
4
ROUTER
(A wireless signal
information device)
A wireless signaling device replaces an existing signaling device and converts the status data of produc-
tion into wireless one so the control tower can control the status information of production equipment
more easily and quickly.
It functions to transmit (send) the status information of production equipment wirelessly and help the
control tower control the wireless signaling device and send specied information to a worker.
QTG60ML-WIZ
-3-110/220 -RAG
[Model number] [Layer
count] [Voltage] [Color]
| | | |
• QTG60ML-WIZ
• QTG60ML-WIZ-BZ
• QTG60MLF-WIZ
• QTG60MLF-WIZ-BZ
• QTGA60ML-WIZ
• QTGA60ML-WIZ-BZ
• QTGA60MLF-WIZ
• QTGA60MLF-WIZ-BZ
• 1 Layer
• 2 Layers
• 3 Layers
• 4 Layers
• 5 Layers
• 12-DC12V
• 24-DC24V
• 110/220
- AC110V~220V
R-Red
A-Amber
G-Green
B-Blue
W-White
QTG70ML-WIZ
-3-12 -RAG
[Model number] [Layer
count] [Voltage] [Color]
| | | |
• QTG70ML-WIZ
• QTG70ML-WIZ-BZ
• QTG70MLF-WIZ
• QTG70MLF-WIZ-BZ
• QTGA70ML-WIZ
• QTGA70ML-WIZ-BZ
• QTGA70MLF-WIZ
• QTGA70MLF-WIZ-BZ
• 1 Layer
• 2 Layers
• 3 Layers
• 4 Layers
• 5 Layers
• 12-DC12V
• 24-DC24V
• 110/220
- AC110V~220V
R-Red
A-Amber
G-Green
B-Blue
W-White
Ordering Specications
• QTG60ML-WIZ • QTG70ML-WIZ

2 3
1st
2nd
24th
1st
2nd
24th
Components of wireless system
1. Connection through USB DONGLE
• USB DONGLE can be easily inserted in the PC and this is a method suitable for building a small-sized single wireless network
(up to 32 wireless control display lamps can be connected).
2. Connection through GATEWAY
• Up to 768 wireless control indicators can be connected by adopting multiple GATEWAYs. This is suitable for large-scale business sites.
• Smart phone can monitor or control the status of signaling devices.
USB DONGLE
PC
Wireless signaling devices
LAN ROUTER
Smartphone
HOST PC

4 5
1. ROUTER(Wireless Signaling Device)
• The status information of the production equipment can be recognized by using an external contact and the status information are
transmitted to USB DONGLE or GATEWAY. ROUTER can receive control signal from USB DONGLE or GATEWAY.
• Please refer to wireless information table on the label of the product.
2. USB DONGLE
• USB DONGE is a wireless transmitter & receiver that is suitable for a small network with less than 32 wireless signaling devices.
• Please refer to wireless information table on the label of the product.
Wireless Signaling Device
<ROUTER Wireless information table>
• ROUTER Wireless information table reference
USB DONGLE
ROUTER
NAME QTG60L-WIZ
GROUP ID 1
NODE ID 1101
CHANNEL 11
PAN ID 01
ROUTER
NAME Model name
GROUP ID
• Designated GROUP ID by customer. Possible to set 1 to 24 GROUPS.
• It must be set as same as receiver(USB DONGLE, GATEWAY).
NODE ID
• Designated NODE ID(Product ID) by customer. 32 ID’s are available.
• Referring 1101, 11 represents channel number. NODE ID conguration is related to the channel number.
(recommended)
CHANNEL
• Can select up-to 16 channels from 11 to 26. It must be congured same as receivers(GATEWAY and
USB DONGLE).
PAN ID
• PAN ID can be set from 0 to 65535. It is wireless network identier as an unique customer’s number and
designated by manufacturer.
<USB DONGLE Wireless information table>
USB
DONGLE
NAME WIZ32
GROUP ID 1
CHANNEL 11
PAN ID 01
Information of wireless system

4 5
GATEWAY
NAME GW768
MAC ADDR. 0.35.183.XXX.XXX.XXX
GROUP ID 1
CHANNEL 11
PAN ID 01
• GATEWAY Wireless information table reference
GATEWAY
NAME Model name
MAC ADDR.
• MAC ADDRESS designated by manufacturer.
• MAC ADDRESS is used to set IP address and network information by searching GATEWAY in the
network.
GROUP ID
• Designated GROUP ID by customer. Possible to set 1 to 24 GROUPS.
• GROUP ID must NOT be same as USB DONGLE.
• It must be set as same as ROUTER(Wireless Signaling Device).
CHANNEL
• Can select up-to 16 channels from 11 to 26. It must be congured same as ROUTER(Wireless Signaling
Device).
PAN ID
• Pan ID can be set from 0 to 65535. It is wireless network identier as an unique customer’s number
and designated by manufacturer.
3. GATEWAY
• Suitable for large-scaled network over 32 wireless networks. One GATEWAY unit is a single group, can connect up to 24 groups.
• Support Smartphone Application
• Please refer to wireless information table on the label of the product.
• USB DONGLE Wireless information table reference
GATEWAY
USB
DONGLE
NAME Model name
GROUP ID
• Designated GROUP ID by customer. Possible to set 1 to 24 GROUPS.
• Possible to use single unit per PC. GROUP ID must NOT be same as GATEWAY.
• It must be set as same as ROUTER(Wireless Signaling Device).
CHANNEL
• Can select up-to 16 channels from 11 to 26. It must be congured same as ROUTER(Wireless Signaling
Device).
PAN ID
• PAN ID can be set from 0 to 65535. It is wireless network identier as an unique customer’s number and
designated by manufacturer.
<GATEWAY wireless information table>
Information of wireless system

6 7
(2) Installation of PC Application
• The PC application is used to monitor, set, and control the status information of a wireless signaling device.
• In case of using C# Library, please refer to the Library User Manual which is provided separately.
• Please download the PC Application from our website and install it.
Information of wireless system
4. Installation of PC Application
(1) SERIAL TO USB DRIVER installation
• There are two options of receiving & controlling the wireless signaling device such as USB DONGLE and USB interface with the
GATEWAY. In both cases, `USB to serial device driver’ should be installed (download it from Qlight website or http://blog.qlight.com).
• Select x64 or x86 EXE. le depending on your OS type.
• Silicon Labs’ drivers are provided as a device driver.
• After the installation completes, check if COM# Port is displayed in the Device Manager of PC before connecting the USB DONGLE or the
GATEWAY through a USB PORT.
• COM# can vary depending on the PC environment.
<= Please run .exe le. Software VERSION may be upgraded without notice.
**For the installation instruction and usage, please refer to manual.
(3) For the usage of API using DLL, please refer to manual.
