Roger MCT12M User manual

MCT12M Installation Manual.doc 2018-10-05
1/2
Roger Access Control System
MCT12M Installation Manual
Firmware version: 1.1.6 and newer
Document version: Rev. A
This document contains minimum information that is necessary for initial setup
and installation of the device. The detailed description of configuration
parameters and functionalities is specified in respective Operating Manual
available at www.roger.pl.
INTRODUCTION
The MCT reader is designed to operate in RACS 5 system as peripheral device
connected to RS485 bus of MC16 access controller. Factory new reader is
configured with default settings including ID=100 address. Before connecting to
controller, the reader should be assigned with unoccupied address in range of
100-115. Programming of other parameters depends on the individual
requirements and is not obligatory. Addressing of the reader can be done from
computer by means of RogerVDM program or manually. Configuration of the
reader with RogerVDM requires RUD-1 interface.
CONFIGURATION WITH ROGERVDM PROGRAM
Fig. 1 Connection of MCT reader to RUD-1 interface for configuration
Programming procedure:
1. Connect the reader to RUD-1 interface (fig. 1) and connect the RUD-1 to
computer’s USB port.
2. Place jumper on MEM contacts (fig. 3).
3. Restart the reader (switch power supply off and on or short RST contacts for
a moment) and orange LED SYSTEM will pulsate.
4. Start RogerVDM program, select MCT device, firmware version, RS485
communication channel and serial port with RUD-1 interface.
5. Click Connect, the program will establish connection and will automatically
display Configuration tab.
6. Enter unoccupied RS485 address in range of 100-115 and other settings
according to requirements of specific installation.
7. Click Send to Device to update the configuration of reader.
8. Optionally make a backup by clicking Send to File… and saving settings to
file on disk.
9. Remove jumper from MEM contacts and disconnect reader from RUD-1
interface.
Note: Do not read any cards nor press reader keypad when reader is configured
with RogerVDM.
MANUAL ADDRESSING
Manual addressing procedure enables configuration of new RS485 address with
all other settings unchanged.
Manual addressing procedure:
1. Remove all connections from A and B lines.
2. Place jumper on MEM contacts (fig. 3).
3. Restart the reader (switch power supply off and on or short RST contacts for
a moment) and orange LED SYSTEM will pulsate.
4. Enter 3 digits of RS485 address in range of 100-115 with reader keypad or
with any MIFARE card.
5. Remove jumper from MEM contacts and restart the reader.
Readers without keypad can be addressed with multiple card readings where the
N number of readings emulates digit of the address. Three series of readings
with any MIFARE proximity card are necessary to set the address. After each
series wait for two beeps and proceed with the next digit. Zero digit is emulated
with 10 readings.
Example:
Programming of ID=101 address with card readings:
1. Read card 1 time and wait for two beeps.
2. Read card 10 times and wait for two beeps.
3. Read card 1 time and wait for two beeps.
4. Wait till reader is restarted with the new address and other default settings.
MEMORY RESET PROCEDURE
Memory reset procedure resets all settings to factory default ones including
ID=100 address.
Memory reset procedure:
1. Remove all connections from A and B lines.
2. Place jumper on MEM contacts (fig. 3).
3. Restart the reader (switch power supply off and on or short RST contacts for
a moment) and orange LED SYSTEM will pulsate.
4. Press [*] or read any MIFARE card 11 times.
5. Wait till reader confirms reset with long acoustic signal.
6. Remove jumper from MEM contacts and restart the reader.
FIRMWARE UPDATE
The update requires connection of reader to computer with RUD-1 interface
(fig. 2) and starting RogerVDM software. The latest firmware file is available at
www.roger.pl.
Firmware update procedure:
1. Connect the reader to RUD-1 interface (fig. 1) and connect the RUD-1 to
computer’s USB port.
2. Place jumper on FDM contacts (fig. 3).
3. Restart the reader (switch power supply off and on or short RST contacts for
a moment).
4. Start RogerVDM program and in the top menu select Tools and then Update
firmware.
5. In the opened window select device type, serial port with RUD-1 interface
and path to firmware file (*.hex).
6. Click Update to start firmware upload with progress bar in the bottom.
7. When the update is finished, remove jumper from FDM contacts and restart
the reader.
Fig. 2 Connection of MCT reader to RUD-1 interface for firmware update

MCT12M Installation Manual.doc 2018-10-05
2/2
APPENDIX
Fig. 3 Service contacts
Table 1. Wires
Name
Wire colour
(MCT12M-IO)
Wire colour
(MCT12M)
Description
12V
Red
Red
Supply plus
GND
Black
Black
Ground
A
Yellow
Yellow
RS485 bus, line A
B
Green
Green
RS485 bus, line B
IN1
Brown
IN1 input line
IN2
Blue
IN2 input line
IN3
Grey
IN3 input line
IO1
White
IO1 output line
IO2
Violet
IO2 output line
NC
Grey-pink
REL1 relay output (NC)
COM
Red-blue
REL1 relay common
terminal
NO
Pink
REL1 relay output (NO)
Fig. 4 Connection of readers and expanders to MC16 access controller
Table 2. Specification
Supply voltage
Nominal 12VDC, min./max. range 10-15VDC
Current consumption
(average)
MCT12M-BK/MCT12M-BK-IO/
MCT12M-BK-DES-IO: ~65 mA
MCT12M/MCT12M-IO/
MCT12M-DES-IO:: ~85 mA
Inputs
Three parametric inputs (IN1..IN3) internally
connected to the power supply plus through a
5.6kΩ resistor. Approx. 3.5V triggering level for
NO and NC inputs.
Relay output
Relay output (REL1) with single NO/NC contact,
30V/1.5A DC/AC max. load
Transistor outputs
Two (IO1, IO2) open collector outputs, 15VDC/1A
max. load
Tamper protection
Enclosure opening reported to access controller
Proximity cards
MCT12M-DES-IO/MCT12M-BK-DES-IO:
13.56MHz MIFARE Ultralight, Classic,
DESFire EV1 and Plus
Remaining MCT12M readers:
13.56MHz MIFARE Ultralight, Classic
Reading range
Up to 7 cm for MIFARE Ultralight, Classic
Up to 4 cm for MIFARE DESFire EV1, Plus
Distance
1200m maximal cable length for RS485 bus
between controller and reader
IP Code
IP65
Environmental class
(according to EN 50133-1)
MCT12M series:
Class IV, outdoor general conditions,
temperature: -25°C to +60°C, relative humidity:
10 to 95% (no condensation)
Dimensions H x W x D
152,5 x 46 x 23(35) mm
Weight
~150g
Certificates
CE
Fig. 5 Connection of door lock, door contact and exit button to MCTxx-IO reader
This symbol placed on a product or packaging indicates that the
product should not be disposed of with other wastes as this may
have a negative impact on the environment and health. The user is
obliged to deliver equipment to the designated collection points of
electric and electronic waste. For detailed information on recycling,
contact your local authorities, waste disposal company or point of
purchase. Separate collection and recycling of this type of waste
contributes to the protection of the natural resources and is safe to
health and the environment. Weight of the equipment is specified in
the document.
