Barcode Printer

Quick Guide

Introduction

This manual is intended to help you become familiar with the

basic operation of MB200i/MB201i the barcode printer in a

short time.

Please read this manual carefully to make full use of the

functions of MB200i/MB201i.

Notes

1. Reproduction of all or part of this manual is prohibited

without permission of the copyright owner.

2. The information in this manual is subject to change

without notice.

3. If you find any ambiguous or erroneous information in

this manual, please contact your nearest dealer or

service center.

1st Edition Dec. 2004

4th Edition Dec. 2013 Q01147003

Table of Contents

1. Safety Precautions ....................................... 4

Markings and Symbols ............................ 4

Precautions in Use ................................ 13

2. Unpacking .................................................. 15

3. Parts Name ................................................ 16

Name and Function of Controls ................. 18

4. Before Starting ........................................... 19

Charging the Battery Pack .................... 19

Installing and removing the Battery Pack .

Using AC Adapter .................................. 25

Setting Labels ........................................ 26

• Continuous mode ............................ 26

5. Test Printing ............................................... 28

6. Reference .................................................. 29

Options .................................................. 29

DIP Switch ............................................. 30

Basic Specifications of MB200i/MB201i .

Preparation

Operation

Reference

Safety Precautions

Warning

1. Safety Precautions

In this section, safety precautions about printer operation

are explained to ensure proper care and usage. Make sure

to read these carefully before using your printer.

Markings and Symbols

The following symbols or markings are used in this manual

and on the printer so that you can properly use the printer,

and to prevent any damage to property, harm or injury to

yourself and others. Make sure to read their explanations

carefully to familiarize yourself with their meanings.

This symbol indicates information

that, if ignored or applied incorrectly,

creates the danger of death or

serious personal injury.

This symbol indicates information

that, if ignored or applied incorrectly,

creates the possibility of personal

injury or property damage.

Caution

Safety Precautions

Symbol examples

The triangle ( ) indicates something you should

take absolute care with. The cautions are indicated

concretely within the symbol. The symbol on the left

indicates a risk of electric shock.

A circle with a diagonal line ( ) indicates something

you should not do. The symbol on the left indicates

that you should not try to take the unit apart.

A black circle with a picture inside ( )indicates

something you need to do. The symbol on the left

indicates that you should unplug the unit from the

wall outlet.

Safety Precautions

Warning

Liquid

Do not place any container with water or chemicals,

such as flower vase or cup, as well as small metallic

objects, near the printer. If any of these should fall

into the printer, immediately turn off the power and

contact your nearest dealer or service center.

Continued use creates a damage of fire or electric

shock.

Foreign Matter

Do not drop or insert metallic or flammable objects

into the openings on the printer (such as outlets for

cables). If any of these should fall into the printer,

immediately turn off the power and contact your

nearest dealer or service center. Continued use

creates a danger of fire or electric shock.

Dropping and Damage

Should the printer ever fall or otherwise become

damaged, immediately turn off the power and contact

your nearest dealer or service center. Continued use

creates a danger of fire or electric shock.

Safety Precautions

Abnormal Conditions

Continued use of the printer while it is emitting smoke

or strange odors creates the danger of fire or electric

shock. Immediately turn off the power and contact

your nearest dealer or service center. Do not try to

service the printer by yourself.

Disassembly

Never try to take the unit apart or modify it in any

way. Doing so creates the danger of fire or electric

shock. Contact your nearest dealer or service center

for repair.

Battery Pack

• Never try to take apart the battery pack or modify it

in any way such as with a solder iron.

•Never expose the battery to direct flame, throw it

into fire, or take any actions that may lead to

shorting.

•When charging the battery pack, make sure to use

the printer or the specified battery charger.

Warning

Safety Precautions

AC Adapter/Battery Charger (Option)

•Use only the specified voltage. Using a different

voltage may create the danger of fire or electric

shock.

•Use only the specified battery charger. Using a

different battery charger may create the danger of

fire or electric shock.

• Never use the battery charger with any other

battery pack except for the specified one. Doing so

can rupture the battery, cause leakage, fire or

electric shock.

•Never cut, damage or modify the power cord. Also,

never place heavy objects on the power cord or

heat or pull the power cord. Doing so may damage

the cord and create the danger or fire or electric

shock.

•Should the power cord ever become seriously

damaged (internal wiring exposed or shorted),

contact your nearest dealer or service center for

repair. Continued use of such a cord creates the

danger of fire or electric shock.

•Never modify, excessively bend, twist, or pull the

power cord. Doing so creates the danger of fire or

electric shock.

Warning

Safety Precautions

Location

Do not locate the printer in the area subjected to high

humidity or dew. If dew forms inside the printer,

immediately turn off the printer and do not use it until

it has been dried up. Continued use creates the

danger of electric shock or the printer damage.

Power

Do not use wet hands to operate the power switch,

replace the battery pack or unplug the AC adapter or

battery charger. Doing so creates the danger of

electric shock.

Thermal Head and Stepping Motor

• The thermal head gets very hot after printing. Take

care when replacing paper or cleaning the printer

just after printing to avoid burn.

•Touching the end of the thermal head with bare

hands may cause injury. Take care when replacing

paper or cleaning the printer to avoid injury.

•Do not try to replace the thermal head by yourself.

Doing so creates the danger of injury, burn, or

electric shock.

Easy Cutter

This part contains a blade. Take care to avoid cutting

your hands.

Caution

Safety Precautions

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired operation.

FCC Caution:

Changes or modifications not expressly approved by the manufacturer

for compliance could void the user's authority to operate the equipment.

NOTE : This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates and can radiate radio frequency energy and, if not installed

and used in accordance with instructions, may cause harmful

interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

- Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

Warning

Safety Precautions

This manual show that both the specification of Bluetooth and wireless

LAN. Please refer to the corresponding section which shows

specification of Bluetooth or wireless LAN.

Wireless LAN specification.

The available scientific evidence does not show that any health

problems are associated with using low power wireless devices. There is

no proof, however, that these low power wireless devices are absolutely

safe. Low power Wireless devices emit low levels of radio frequency

energy (RF) in the microwave range while being used.

Whereas high levels of RF can produce health effects (by heating

tissue), exposure to low level RF that does not produce heating effects

causes no known adverse health effects. Many studies of low level RF

exposures have not found any biological effects. Some studies have

suggested that same biological effects might occur, but such findings

have not been confirmed by additional research.

The (Wireless LAN Module (WM-B-AG-02)) has been tested and found

to comply with the Federal Communications Commission (FCC)

guidelines on radio frequency energy (RF) exposures. The maximum

SAR levels tested for the (Wireless LAN Module (WM-B-AG-02))has

been shown to be (0.449)W/kg at (Body). This device should not be co-

located or operated with any other antenna transmitter.

Warning

Safety Precautions

Replacing the Battery Pack

• Use only the specified battery pack.

•When replacing the battery pack, make sure to

install the pack with the correct direction. Incorrectly

replacing the battery create the danger of injury or

damage to surrounding areas.

•Replacing a small-size rechargeable battery

(Lithium ion battery) Apply insulation treatment for

the old battery pack by sealing the contact with tape

or the like and ask our sales representative or

service center for the measure to be taken for

effective use of scarce resource. Do not place the

battery pack together with other batteries such as

dry batteries.

Leaving the printer unused for a long time

If you have no plan to use the print for a long time,

remove the battery pack from the printer and unplug

the AC adapter from the wall outlet.

Maintenance and Cleaning

For safe maintenance or cleaning of the printer, make

sure to remove the battery pack and the AC adapter

from the printer.

Caution

Safety Precautions

Precautions in Use

Do not place the printer in a hot or cold place.

The operation temperature range is -15 to 50°C (Wireless

LAN model: 0 to 50°C). Do not place the printer in an area

with high humidity or at the temperature outside the

specified range.

Do not drop or give shock to the printer.

The printer is given a protection against vibration possibly

caused during normal transportation. However, do not apply

extreme vibration or shock by dropping to the printer.

Do not disassemble or modify the printer.

The printer has high-precision components inside requiring

fine adjustment. Do not disassemble the printer.

Connect the specified cables to the external

input terminals.

Special cables are required to connect to the external

equipment through the external input terminals. Contact

your nearest dealer or service center if necessary.

Use a specified option.

Do not use a device not specified as option. Otherwise a

fault may occur.

Use the specified paper.

Use the specified paper. Otherwise, broken head or faulty

printing may occur.

Safety Precautions

Wireless LAN & Bluetooth specification.

IC (Industry Canada) Caution:

"The installer of this radio equipment must ensure that the

antenna is located or pointed such that it does not emit

RF field in excess of Health Canada limits for the general

population; consult Safety Code 6, obtainable from Health

Canada's website www.hc-sc.gc.ca/rpb"

CE Caution:

Hereby, SATO CORPORATION declares that this WM-B-

AG-02 is in compliance with the essential requirements

and other relevant provisions of Directive 1999/5/EC.

Bluetooth Specification

Wireless LAN specification.

If you want to get a copy of the original Declaration of

Conformity of our products which relates the R&TTE, please

contact to web address: www.barcodesato.com

Unpacking

2. Unpacking

After unpacking, make sure that all the printer components

are present. If any component or part is missing, contact

your nearest dealer or service center.

Quick guide

Printer

Battery pack

*Belt holder has already installed on the printer when shipping.

Shape of cushioning material (protecting bad, etc. for supporting printer)

may partly differ by the lot.

Shoulder belt

Parts Name

3. Parts Name

Open cover

Cover open/close lever

Dispenser unit

Belt clip

Easy cutter

Battery cover

Cover for DC input jack

RS-232C

cover

Label guide adjust

dial cover

Label ejection

Parts Name

234

*1Operation panel with LCD is built in the wireless LAN interface model

only (for manufacture option). For other option information, see

"Reference" on page 29.

*2Operation panel with LCD for the wireless LAN interface model has

CHARGE LED (for manufacture option) .

Label guide

Label width scale

DIP switch

Label guide

adjust dial

DC input jack

Platen

Battery indicator (LED) *2

IrDA filter

PRINT key

FEED key

POWER key

STATUS (LED)

LCD *1

RS-232C

connector

Parts Name

Name and Function of Controls

RS-232C Interface: Connects to

PC or handy terminal. Used for

connecting to a computer.

Signal:Low level -6.6 to +6.6 V

High level -6.6 to +6.6 V

RS-232C cover: Cover for RS-

232C connector.

Open cover: Opened for setting

labels.

Cover Open/Close lever: Used to

open or close the cover.

Easy cutter: Cuts printed labels.

IrDA filter: Contains IrDA sensor

and emitter.

DIP switch: Sets the operation

mode of the printer. (See page

30.)

Dispenser unit: Moved to select

Dispense mode.

POWER key: Turns on/off the

printer.

Battery cover: Cover for special

battery pack.

Battery indicator (LED): Indicates

the remaining amount of

battery of the printer.

Belt clip: Used when hanging the

printer on your belt.

*Do not hang the printer on to

anything but a belt.

Label guide: Set to meet the size

of the label used.

Label guide adjust dial: Adjusts

the label guide to the width of

the label used.

Label guide adjust dial cover:

Cover for label guide adjust

dial.

Label ejection: Ejects the printed

label.

Label width scale: Indicates the

width of label used.

DC input jack: Connects to AC

adapter.

Cover for DC input jack: Cover

for DC input terminal and DIP

switch.

FEED key: Press to feed label.

PRINT key: Sets the printer online

or offline.

STATUS (LED): Indicates the

status of the printer.

Before Starting

4. Before Starting

Charging the Battery Pack

IMPORTANT SAFETY INSTRUCTIONS –

SAVE THESE INSTRUCTIONS.

DANGER –

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

CAREFULLY FOLLOW THESE INSTRUCTIONS.

•For connection to a supply not in the U.S.A, use an

attachment plug adapter of the proper configuration for

the power outlet.

•Using the battery charger (option) to charge the

battery pack

Follow the steps below to charge the battery pack using the

battery charger.

•This power unit is intended to be correctly orientated in a

vertical or floor mount position.

•Use Battery pack Model No. PT/MB200-BAT

•Use Battery charger (Battery pack Model No. PT/MB200-

BAT only)

1Single-socket type: Model No. PT/MB200-CHG

2Five-socket type: Model No. PT/MB200-CHG5

Before Starting

1Plug one end of the

power cord to the

battery charger and the

other to the wall outlet.

(POWER lamp lights red.)

2Put the battery pack on

the battery charger and

then slide it in the

direction of the arrow.

Charging starts and the

CHARGE lamp lights

orange. When charging is

completed (fully charged),

the CHARGE lamp goes off.

In case of five-socket

charger, charging starts and

the CHARGE lamp lights

orange. When charging is

completed (fully charged),

the CHARGE lamp lights

green.

3After charging, remove

the battery pack from

the charger.

Slide the battery pack in the

opposite direction of step (2)

to remove the battery back.

CHARGE

POWER

Other manuals for MB 200i

This manual suits for next models

Table of contents

SATO MB 200i User manual

Popular Barcode Reader manuals by other brands
