Saxby Lighting 73721 Manual

Instruction leaflet
Sirio Suspension Kit
73721
www.saxbylighting.com Saxby Lighting Ltd. BH23 3PE

Thank you for purchasing this accessory. Please read the instructions carefully before use to ensure safe and satisfactory
operation of this product. Please retain these instructions for future reference.
This surface mount kit is designed only for use with
Sirio fittings - 71708, 71710, 73986. Please refer to the
installation instructions supplied with the fitting for wiring
and connection details.
• Checkyouhaveallnecessaryparts:
- 6 x plastic plugs
- 6 x screws
- 2 x ceiling discs
- 2 x cable boss sets with clips
- 2 x cables
• Using the metal ceiling discs as a template, mark the
fixing holes with the two discs 480mm apart. Once
marked, drill fixing holes and fit supplied fixings.
Plastic plugs are suitable for masonry only.
• See Figure 1. Pull the cable through the top of the
metal ceiling discs. Attach discs to the ceiling with
the supplied fixings.
• SeeFigure2.Removefoursetsoftwoscrewsfrom
corners located on the back of panel. Place fixing
bracketsoverremovedscrewholesandtightenfixing
bracketsinplaceusingremovedscrews.
• See Figure 3. Depress metal button on boss
and feed cable through until secure. This can be
re-adjusted later
Installation
For your safety, always switch off the supply before cleaning.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
Commissioning
Iss.1 13042017
Fig 6.
Fig 5.
Fig 4.
• See Figures 4 & 5. Attach clips on wire to fixing
brackets.
• See Figure 6. Should you wish to adjust the height
of the fitting, pull the wire through boss on both
endsofproductuntildesiredlengthisachieved.
Fig 1.
Fig 3.Fig 2.
