Skoda Octavia A7 User manual

SIMPLY CLEVER
OWNER'S MANUAL
OWNER'S MANUAL
Infotainment Swing


5E0012720DG

Preface
This Owner's Manual is provided for the Infotainment Swing (hereinafter re-
ferred to only as a device).
Please read this Owner's Manual carefully, because the operation in accord-
ance with these instructions is a prerequisite for proper use of the unit.

5E0012720DG

Table of Contents
Important information about this Owner's
Manual 3
Explanations and further information 4
Abbreviations
Introductory information
Important notes 6
Unit overview 7
Device operation and settings
Device operation 9
Device settings 10
Radio
Operation 12
Media
Operation 14
Audio sources 16
Telephone
Introductory information 19
Pair and connect 20
Telephone functions 21
Vehicle systems
CAR - vehicle setting 25
Adjustment of the heating and cooling
system 29
Index
2Table of Contents

Important information about this Owner's Manual
This Owner's Manual is valid for the different versions of the Infotainment
Swing (hereinafter referred to only as device). The device may vary in both its
appearance and in the controls arrangement, depending on the vehicle model
in which it is installed.
This Owner's Manual describes all possible device functions without identify-
ing them as special equipment, model variants or market-dependent equip-
ment. Consequently, the device in your vehicle does not need to contain all of
the functions described in this Owner's Manual.
For example, if the vehicle is not factory equipped with the sound system, the
menu points ŠKODA Surround and Virtual Subwoofer are not displayed in the sound
settings menu.
In this Owner´s Manual, only the main menu for the device settings are descri-
bed. A detailed description of all the settings is provided in the on-line Owner
´s Manual» page 6.
The information about the device, e.g. with respect to its compatibility with
external devices or the software update, please refer to the following web-
sites.
http://go.skoda.eu/infotainment
The availability of some features described in this Owner's Manual depends
on the type of external devices (for example, telephone, music player, etc.).
The illustrations in this Owner's Manual are for illustrative purposes only. The
illustrations can differ in minor details from your vehicle; they are only inten-
ded to provide general information.
ŠKODA AUTO pursues a policy of ongoing product and model development
with all vehicles. Changes in terms of supply scope are possible at any time
with regard to design, equipment and technology. The information provided in
this Owner's Manual corresponds to the information available at the time of
publishing.
Therefore, legal claims cannot be made based on the technical data, illustra-
tions and information contained in this Owner's Manual.
We recommend that the web pages that are referred to in this Owner's Man-
ual are displayed using the classic view. If the web pages are displayed using
the mobile view, they may not contain all necessary information.
Screen texts that appear in this Owner´s Manual may differ slightly depending
on the texts show on the device screen.
Declaration of conformity
ŠKODA AUTO hereby declares that the ŠKODA Infotainment systems meet the
basic requirements and additional provisions of the 1999/5/EC Directive with
reference to radio equipment and telecommunications devices.
3
Important information about this Owner's Manual

Explanations and further information
Structure of this Owner´s Manual
The Owner´s Manual is hierarchically divided into the following areas.
■Main chapters (e.g. Introductory information) - the title of the main chapter is
always shown on the lower right side of the page
■Chapter (e.g. Equipment overview)
■Module (for example, Switching the unit on/off)
Information search
When searching for information in the Owner´s Manual, we recommend using
the Index at the end of the manual.
Text notes
- Short press (e.g. a button) within 1 s
- Long press (e.g. a button) for more than 1 s
Text Symbols
® Registered trademark
™ Registered trademark
→Marker to the next operation step
The text symbol used for the right control dial
WARNING
Texts with this symbol draw attention to threats of a serious accident, in-
jury or loss of life.
CAUTION
Texts with this symbol draw attention to the risk of vehicle damage or possible
inoperability of some systems.
Note
Texts with this symbol contain additional information.
“Press”
“Hold”
4Explanations and further information

Abbreviations
Abbreviation Definition
A2DP a Bluetooth® profile for the one-sided audio data transmis-
sion
ACC Adaptive cruise control
AF Alternative frequencies for the current radio station
AM Identification of the radio-frequency range
TCS Traction Control of the drive wheels
AVRCP a Bluetooth® profile for the operation associated with the
transmission of audio data multimedia functions
BT Bluetooth ® - wireless communication for reception and
transmission of voice and data information
CNG Compressed natural gas
DAB Digital radio reception
DRM a system for monitoring or restricting the use of digital me-
dia content
ESC Electronic Stability Control
FM Identification of the radio-frequency range
ID3 tag an additional feature of a music file, which allows for the dis-
play of artist, title, album name, etc.
mp3 compressed audio format
PIN personal identification number
PTY Type of broadcast program
RDS a system for the transmission of additional information for
FM radio reception
SIM card a card for the identification of the mobile network operator
TP Identification of a traffic information station
USB MSC a software profile for transferring files between two devices
(sometimes referred to as EMS)
VBR variable bit rate with files that have data compression
VIN Vehicle identification number
wma compressed audio format
5
Abbreviations

Introductory information
Important notes
Introduction to the subject
WARNING
■Concentrate fully at all times on your driving! As the driver you are fully
responsible for the operation of your vehicle.
■Use the device only so that you have the vehicle fully under control in any
traffic situation, for example, the telephone does not couple or connect,
does not work with the contact list, etc. - risk of accident!
WARNING
■Adjust the volume to ensure that acoustic signals from outside the vehi-
cle, e.g. sirens from emergency vehicles, can be heard at all times.
■High volumes can cause hearing damage.
WARNING
■Never leave a communication device, e.g. mobile phone, audio sources, in
the deployment area of an airbag, on a seat, on the dashboard or any an-
other area, from which it can be thrown during a sudden braking manoeu-
vre, an accident or a collision - risk of injury!
■Never connect or disconnect an external device while driving - risk of ac-
cident!
■Always route the connection cable of the external device such that is
does not restrict you when driving.
CAUTION
In some countries, some unit features can no longer be selected when the ve-
hicle is running faster than a certain speed. This is not a malfunction, but com-
plies with the national legal regulations.
Online Owner´s Manual
Fig. 1 QR code with reference to the ŠKODA websites
Read in the QR code » Fig. 1 using the respective application on your external
device (e.g. phone, tablet) or enter the following address in the web browser
to open the website with a model overview of the ŠKODA brand.
http://go.skoda.eu/owners-manuals
▶Select the desired model - a menu with the Owner´s Manual is displayed.
▶Select the construction period as well as the language.
▶Select the corresponding on-line Owner´s Manual.
It is possible to print out information from the on-lineOwner's Manual.
External devices and applications
The availability of some of the functions described in this Owner´s Manual
depends on the type of device to be connected and the applications installed
in it.
Mobile phones
On the following pages, check to see if the device is compatible with the selec-
ted mobile phones.
http://go.skoda.eu/compatibility
Due to the large number of mobile phones as well as the ongoing develop-
ment of these devices, ŠKODA AUTO cannot always ensure compatibility with
the device unconditionally. It is always recommended to physically check the
function on the associated vehicle, including the ŠKODA Partners, beforehand. 
6Introductory information

Only those versions of the selected phones will be tested and supported which
originate from the official distribution network. The same also applies to their
firmware and software.
The functions of the mobile phone to be tested may differ from the same type
of mobile phone depending on the specification for the respective country or
the specific service.
Mobile phones with the operating system and in the version available at the
time of these tests will be tested. In this regard, it could be the case that the
functions of a mobile phone may differ with a different operating system ver-
sion compared to the one used with the tested phone.
ŠKODA AUTO can accept no responsibility for the continuous changes made by
the mobile phone manufacturers and application vendors.
The function of some mobile applications may be affected by the quality of the
Internet connection at the respective location.
ŠKODA AUTO does not accept any liability for any damage to the device or ve-
hicle due to the use of incorrect or illegal applications or the improper or unau-
thorized use of mobile phones.
Unit overview
Description of the device
The device may differ depending on the vehicle model, in which it is installed
in both its appearance and in the arrangement of the controls.
Fig. 2 Illustrative device overview
Left control dial for switching the device on and off; volume adjustment
Control dial for calls and confirmations
 - Radio menu » page 12
 - Media menu » page 14
Depending on equipment fitted:
▶ - Muting
▶ - Telephone menu » page 19
 - Unit settings » page 10
 - Sound settings 


1
2
3
4
5
7
Introductory information

Depending on equipment fitted:
▶ - Setting the vehicle systems » page 25 (not applicable for Yeti)
▶ - Activating/deactivating the Traffic Monitoring » page 14 (applies
to Yeti)
Touchscreen » page 9
SD card slot » page 16
Touch screen
The device is equipped with a touch screen that can be operated by light fin-
ger pressure on the screen surface.
The brightness of the screen can be set  → Screen → Brightness: .
CAUTION
■The screen can only be operated by a slight touch of a finger. If there is too
much pressure there is a risk of damage to the screen!
■To protect the screen, you can use a suitable screen protector for touch pads
that does not affect its functionality.
■Dirt can be removed from the screen by using a soft cloth and, if necessary,
methylated spirits.
Software update
Current information on the compatibility of external devices can be found on
the following ŠKODAInternet pages.
http://go.skoda.eu/infotainment
▶To display the software information, press the  button, then tap on the
System information function surface.
▶To start the software update, tap on the
Update software function surface in
the displayed menu.
Turn device on/off
›To power on/off the device, press  .
Automatic Power On of the device
If the device was not switched off using the controller prior to switching off
the  Ignition, this automatically switches on after the ignition is switched on.
6
7
8
Automatic Power Off of the device
If the vehicle key is pulled out of the ignition lock while the unit is switched on,
the device will switch off automatically.
If the vehicle is fitted with the starter button, the device will switch off auto-
matically after the engine is switched off and the door is opened.
With the ignition off, the device will automatically turn off after about 30 mi-
nutes.
The device turns off automatically under certain circumstances. The device in-
forms of this via a text message on the device display.
Adjusting the volume
Every change in volume is displayed on the screen.
›To increase the volume, turn the controller  clockwise.
›To reduce volume, turn the controller  anticlockwise.
›To mute, turn the controller  to the left to 0.
›or: press the  button.
The following symbol appears in the display when the sound is muted .
If, at the time of muting, sound is played from the source in the media menu,
then the playback is interrupted (pause)1).
CAUTION
■High volumes can cause sound resonance in the vehicle.
■When changing or connecting an audio source, this may cause sudden
changes in volume. Reduce the volume before changing or connecting an au-
dio source.
1) Does not apply for AUX.
8Introductory information

Device operation and settings
Device operation
Operating principles
Fig. 3 Screen area / screen display
Description of the display » Fig. 3
Status line with time and outdoor temperature information and other in-
formation
Information and the operation of the current menu
Function surfaces of the current menu
Identification of the current menu
Return to the higher-level menu
 Open a sub menu of the menu item with the “pop-up window”
Menu item with “Checkbox”
▶ - Function is switched on
▶ - Function is switched off
Scroll symbol - positioning and moving in the menu is possible by moving
fingers on the scroll symbol up or down
▶Finger touch above the scroll symbol - changes to the next screen im-
age up
▶Finger touch below the scroll symbol - changes to the next screen down
A
B
C
D
E
F
G
H
Function surfaces
The screen areas which confirm a function or a menu are called “function sur-
faces”.
▶White text - the surface is active and thus selectable
▶Grey text - the surface is inactive and thus not selectable
▶Green frame - currently selected surface
Selecting menu/menu item/function
▶By tapping on the function surface  or .
▶Turning the knob .
Confirming menu/menu item/function
▶By tapping on the function surface.
▶Press the wheel .
Returning to higher-level menu
▶By tapping on the function surface .
▶By tapping on the screen outside of the “pop-up window”.
▶By pressing the corresponding button next to the screen (e.g. in the menu
Media, by pressing the  button).
Select the menu item / function value
▶ - Selected menu item / function value
▶ - Deselected menu item / function value
Set value
▶By pressing the function surface with one of the following symbols , , , ,
, .
▶By touching or moving your finger over the scale.
▶Turning the knob .
Note
Depending on the equipment, the device can be operated with the operating
lever or via the buttons on the multifunction steering wheel. Additional infor-
mation » Vehicle Owner´s Manual.
9
Device operation and settings

Alphanumeric with keyboard
Fig. 4
Example of the keyboard display
The alphanumeric keypad is used to enter characters.
Description of the alphanumeric keyboard » Fig. 4
Input line
Context-dependent:
▶ - Switch to capital letters
▶ - Switch to special characters
▶ - Switch to numbers
Context-dependent:
▶ - Switch to numbers
▶ - Switch to Latin letters
▶ - Switch to Cyrillic letters
Context-dependent:
▶ - Confirmation of the entered character
▶ - Display of searched entries (the number of searched entries is dis-
played in the function surface)
Return to the higher-level menu
Erase the entered characters
By holding the variants of each type are displayed.
Exchange between the more keyboard languages
Enters a blank
Move the cursor within the input line to the left
Move the cursor within the input line to the right
Search
While entering characters, a search is made for corresponding entries.
The entry such as a telephone contact to be searched for must be entered
along with the special characters (diacritics).
A
B
C
D







By tapping on the function surface  a list of matching entries opens. If fewer
than 4 entries are found, a list of the found entries opens automatically.
Device settings
Configuration wizard
Fig. 5
Configuration wizard
The Configuration wizard is automatically displayed if there are at least two
non-selected menu items after turning on the device, or if a new user account
in personalisation is selected.
Disable the automatic display of the Configuration wizard by tapping the func-
tion surface Don´t show again .
›For manual display, press the  button, then tap the function surface
Con-
figuration wizard .
The Configuration wizard allows you to set the following menu items in se-
quence.
Renaming the user account of personalisation » Vehicle - Owner´s Man-
ual
Time setting (not applicable for Yeti)
Date setting (not applicable for Yeti)
Storing the radio stations with the currently strongest reception signal
in the first memory group of each individual broadcast area
Pairing and connecting a phone to the device
The selected menu item is provided with the  symbol.
Menu items which are not set can be set by tapping on the respective function
surface in the A » Fig. 5 area.





10 Device operation and settings

System settings of the device
›Press the  button.
■
Sound - sound settings
■
Screen - setting the screen displays
■
Time and date - time and date settings (not applicable for Yeti)
■
Language - set the device language
■
Additional keyboard languages - set the additional keyboard languages
■
Units - set the units (not applicable for Yeti)
■
Configuration wizard - display of the Configuration wizard
■
Remove SD card safely - safe removal of the SD card
■
Remove USB device safely - safe removal of USB device
■
Factory settings - reset to factory settings
■
Bluetooth - Bluetooth® settings
■
System information - system information and software update » page 8
■
Copyright - license information of the device
11
Device operation and settings

Radio
Operation
Introduction to the subject
The device allows analogue radio reception of FM and AM frequency ranges as
well as DAB digital radio reception.
CAUTION
■For vehicles with window antennas do not stick foil or metal coated stickers
to the window as this can lead to interference.
■Car parks, tunnels, tall buildings or mountains can interfere with the radio
signal even causing it to fail completely.
Main menu
Fig. 6
Main menu
›To display the main menu, press the  button.
Main menu » Fig. 6
The selected radio station (description or frequency)
Radio Text (AM, FM) / Description of the group (DAB)
Preset station buttons for favourite channels
Choice of radio range (FM / AM / DAB)
Choice of storage groups of the preferred station in the selected broad-
casting ranges (e.g. FM1, FM2 or FM3)
Changing the station
Manual / semi-automatic station search
Radio Text display
Radio main menu settings
A
B
C
D

 



Information symbol in the status line
Symbol Meaning
 Traffic information station
  Traffic information signals are not available or the selected sta-
tion is not a traffic information station
Signal is not available (DAB)
  RDS function is switched off (FM)
  AF Alternative frequency is switched off (FM)
If the displayed station name continuously changes (dynamic text), then it is
possible to fix the current text by holding your finger on the device screen in
the station name area. The station name is shown in full by holding your finger
in the area of the station name again (FM).
Search for station and select frequency
Station search
›Tap on the Radio function surface  in the main  menu.
Depending on the setting  → Arrow buttons: will set an available station from
the Stations list or a station of the current broadcast range on the Stations
buttons.
Select frequency
›Tap on the Radio function  surface. It current frequency range appears in
the scale.
›To set the desired frequency value, tap the function surface  or  at the
bottom of the screen or rotate the controller  or use your finger to move
the scale.
The frequency selection is terminated by pressing  the controller.
Scan through the stations one after the other (scan)
The function scans through all the available stations in the current frequency
range in succession, for a few seconds each.
›To start/finish the automatic play of the available stations, press the control-
ler in the Radio main  menu.
12 Radio

List of available stations
Fig. 7 Example of a list of available FM/DAB stations (hierarchical sorting)
›To display the list of available stations of the currently selected broadcasting
area, rotate the controller in the Radio main  menu.
›To play, tap on the function surface of the desired station.
›To filter the stations according to programme type (e.g. culture, music, sport
etc.) in the FM 1) and DAB2) station list, tap on the function surface  » Fig. 7 -
.
Information symbols
Station is stored under one of the preset station buttons
Currently played stations
 Traffic information station
 (e.g.) Type of programme being broadcast (FM and DAB)
 (e.g.) Type the regional broadcast (FM)
Signal reception is not available (DAB)
Signal reception is not safe (DAB)
Update the list of stations
In the FM area, the station list is updated automatically.
In the AM and DAB area, a manual update is carried out by tapping on the
function surface  » Fig. 7 - .
Sort the stations in the station list
The FM station list can be sorted depending on the settings of the menu item
 →
Advanced settings → Sort stations: .
The AM station list is sorted according to the frequency of the received sta-
tion.
The DAB station list can be sorted depending on the settings of the menu item
 →
Kind of stat. list: .
Station buttons for your favourite stations
Each radio range includes 12 station buttons for saving preferred stations.
These are each divided into three groups.
A station can be stored in the device memory in one of the following ways.
›To save a station on the main menu Radio, hold down the desired function
surface C » Fig. 6 on page 12 until an acoustic signal sounds.
›To save a station in the station list, keep the function surface of the desired
station held down, select the memory group, and then tap the desired sta-
tion button.
If a station is saved on an already assigned station button, this station button
will be overwritten.
Station logos
The station key of a preferred station can contain the name and the station
logo.
Assign a station logo
›Tap on the Radio function surface  →
Station logos .
›Tap on an occupied station button and select the data carrier (SD card, USB).
›Search for and select the desired station logo on the respective data carrier.
Remove station logo
›Tap on the Radio function surface  →
Station logos .
›Tap on the station button from which you want to remove a logo.
›Or:: tap on the function surface 
All to delete the logos of all the station
buttons simultaneously.
›Confirm / cancel the removal. 
1) Applies with activated RDS function.
2) Applies to selected global sorting of the station list.
13
Radio

Note
■The following image formats are supported: jpg, gif, png, bmp (we recom-
mend using the png format).
■Maximum resolution 400x240 pixels.
TP Traffic programme
›To switch on/off the traffic monitoring in the main menu Radio, tap on the
function surface  → Traffic program (TP) .
During a traffic announcement, it is possible to cancel the current announce-
ment if necessary by deactivating the traffic monitoring.
Note
■Should this station not transmit traffic reports or the signal is not available,
then the device automatically searches in the background for another TP sta-
tion.
■During playback in Media main menu or a station in the AM radio range, traf-
fic news is received from the previously selected station in the FM radio range.
Settings
The basic setting for the Radio main menu functions is the same for all radio
ranges.
›Tap on the Radio main menu function  surface.
■
Scan - auto-play all available stations in the current frequency band for
around five seconds each
■
Arrow buttons: - setting the function of the station change (function surfaces 
)
■
Traffic program (TP) - switches on/off the traffic program
■
Radio text - switches on/off the radio text display (FM and DAB)
■
Kind of stat. list: - sort types of radio stations in the station list (DAB)
■
Station logos - manual management of station logos
■
Delete presets - delete the stations stored on the station buttons
■
Advanced settings - further settings that are different depending on the selec-
ted radio range(FM and DAB) » page 6, Online Owner´s Manual
Media
Operation
Main menu
Fig. 8
Main menu
›To display the main menu, press the  button.
Main menu » Fig. 8
Information on playing track
Playback timeline with a slider
Select the audio source
Depending on the audio source type:
▶Folder / Title list
▶Multimedia database
Settings of the main menu Media
Note
■Information concerning the given title appears on the screen, if they are stor-
ed as so-called ID3 Tag on the audio source. If no ID3 tag is available, only the
title name is displayed.
■The remaining playback time indicated does not correspond to the actual re-
maining playback time for titles with variable bitrates.
A
B
C


14 Media

Select audio source
Fig. 9 Select the audio source
›In the Media main menu, tap on the function surface A» Fig. 9 and select
the desired audio source.
›or: in the folder/track list and in the multimedia database hold down the
function surface  B and select the desired audio source.
By selecting an audio source, playback of titles available starts (not for AUX).
Use play
The unit will play the contents of the connected audio source according to the
alphabetically sequenced directory and file name.
Operation Action
Play / Pause Tap 
Play the previous title Tap  (within 3 seconds after the
start of the track playback)
Plays the current track from the start Tap  (after about 3 seconds after
the start of the track playback)
Fast-reverse within the title Press and hold 
Fast-forward within the title Press and hold 
Play the next title Tap 
Switch on/off the random playback
from the current album or folder Tap 
Operation Action
Switch on/off the repeat playback
from the current album or folder Tap 
Switch on/off repeat playback of spe-
cific track Tap 
The movement within the track is possible by finger touching the timeline B
» Fig. 8 on page 14.
Folder / track list
Fig. 10
Folder / Title list
›To display the folder / track list on the Media main menu, tap on the function
 surface.
The content of an audio source is displayed in alphabetical order in the fold-
er/track list.
Folder/Title list » Fig. 10
Selected audio source / audio source folder (movement within the folder is
carried out by pressing the function surface for the folder)
Select the audio source
Folder
Playlist
Currently playing title / track playback stopped
The title cannot be played (tapping on the function surface shows the
cause). 
A



  

15
Media

Note
■With more than 1,000 tracks in the folder only the first 1,000 tracks with the
oldest creation date are displayed.
■The scanning speed of the folder / track list depends on the connection
speed and volume of data.
Multimedia database
Fig. 11 Multimedia database
For some Apple devices connected via USB, the multimedia database is dis-
played instead of the folders and title lists.
In the multimedia database, the tracks are sorted according to individual cate-
gories B » Fig. 11.
›To display the multimedia database, in the Media main menu tap on the
function  surface.
›To playback, select the category and then the title.
Multimedia database » Fig. 11
Selected audio source / Selected category / folder of the audio source
Tap - selection of the parent folder / Hold - selection of the audio source
Sorting categories
Audio sources
Introduction to the subject
›To play, first connect the desired audio source or insert it into the device and
then select the audio source from the list » page 15. Playback starts auto-
matically (does not apply to AUX).
A

B
If AUX is selected as the audio source, the playback must be started on the
connected device.
CAUTION
■Do not save any important data or that which has not been backed up on the
connected audio sources. ŠKODA assumes no responsibility for lost or dam-
aged files or connected audio sources.
■When changing or connecting an audio source, this may cause sudden
changes in volume. Reduce the volume before changing or connecting an au-
dio source.
SD-card
Fig. 12
Insert the SD card
›Insert the SD card in the slot in the direction of arrow (with the cut end fac-
ing right), until this “locks” » Fig. 12.
›To remove the SD card, tap on the Media main menu function surface  →
Remove SD card safely . Please wait... → SD can now be removed. appears on the screen.
›Press on the inserted SD memory card. The SD card “jumps” into the eject
position.
CAUTION
■Do not use an SD card with a broken write protection slide - there is a risk of
damage to the SD card reader!
■When using an SD card with an adapter, vehicle vibrations might cause the
card to fall out of the adapter.
USB input
The USB input (shown with the symbol ) is located in the front centre con-
sole. The exact location of the input » Vehicle - Owner´s Manual.
The USB input audio source can be connected directly or via a connecting ca-
ble. 
16 Media

›To connect, insert the USB audio source into the appropriate input.
›To disconnect the USB audio source, tap on the Media main menu function
surface  → Remove USB safely . Please wait... → USB device can be removed. appears
on the screen.
›Disconnect the audio source from the corresponding USB input.
Charge USB audio source
With the ignition on after connecting the USB audio source, the charging proc-
ess is automatically started (applies for audio sources where charging via the
USB connector is possible).
The charging efficiency can differ compared to the charging from the usual
mains power supply.
Some connected audio sources may not be recognised and cannot be charged.
CAUTION
USB extension cords, or reducers may impair the function of the connected au-
dio source.
Note
We recommend that you use extension cords from ŠKODA Original Accesso-
ries.
Bluetooth®player
The unit allows audio files of a connected Bluetooth® player to play using the
A2DP and AVRCP audio profile.
›To connect the Bluetooth® player with the device - follow the same instruc-
tions as for pairing the device with a telephone» page 20.
›To disconnect the Bluetooth®player, end the connection in the list of paired
devices » page 21.
Apple device
If an Apple device is connected as a Bluetooth® player, and this is connected to
the USB input, then the Bluetooth ® connection is not dropped. If playback is
cancelled, playback must be started again. Only if USB is selected as the audio
source will the Apple device disconnect as a Bluetooth® player. In this regard,
an appropriate warning message appears on the device screen.
If an Apple device is connected to the USB input and playback is switched on,
this device cannot be connected as a Bluetooth® player. In this regard, an ap-
propriate warning message appears on the device screen.
AUX - input
The AUX input (marked with the  lettering) is located in the front centre
console. The exact location of the input » Vehicle - Owner´s Manual.
›To connect, insert the plug of the AUX audio source into the appropriate con-
nector.
›To disconnect, pull the plug out of the AUX audio source.
CAUTION
■The AUX input must only be used for audio devices!
■If an external audio source is connected to the AUX input, which is equipped
with an adapter for external power supply, the sound may be impaired.
Note
■The 3.5 mm stereo jack plug is used for the AUX input.
■We recommend that you use extension cords from ŠKODA Original Accesso-
ries.
Supported audio sources and file formats
Supported audio sources
Source Interface Type Specification File system
SD card SD reader Standard
size SD, SDHC, SDXC
FAT16
VFAT
FAT32
exFAT
USB-
devices
USB 1.x; 2.x
and 3.x or
higher with
support of
USB 2.x
MSC
USB stick;
HDD (without any spe-
cial software);
The MSC mode sup-
ports USB devices
MTP
Devices with the An-
droid operating system
or Windows mobile
(mobile phone, tablet)
Apple
Devices with the iOS
operating system
(iPhone, iPod, iPad)
Bluetooth®
Player - -
Bluetooth proto-
colsA2DPand AVRCP
(1.0 - 1.4)
-
17
Media

Supported audio file formats
Codec type
(File formats) File suffix Max bit rate
Maximum
sampling
rate
Playlists
Windows Media
Audio 9 and 10 wma 384 kbit / s 96 kHz m3u
pls
wpl
asx
MPEG-1; 2 and 2.5
(Layer-3) mp3 320 kbit / s 48 kHz
Note
■The GPT standards (GUID partition table) method structured audio sources
are not supported by the device.
■Files that are protected by Digital Rights Management (DRM) technology
cannot be played back by the device.
18 Media
