TMG PRO Series User manual

►www.tmgindustrial.com 0/41 TOLL FREE:1-877-761-2819

►www.tmgindustrial.com 1/41 TOLL FREE:1-877-761-2819
MAIN SPECIFICATIONS :
Assembly size : W15.24 x L31.2 x H7.0 (m) / 50 x 100 x 23 (ft)
Outside width : 15.24 m / 50ft, inside width : 14.4 m / 47.4 ft, length : 31.2 m / 100 ft
Ridge peak height : 7.0 m / 23 ft
Peak clearance height : 6.4 m / 21 ft
Roll up door : 4.6 x 4.7 (m) / 15 x 15.4 (ft) (The front and rear doors are the same size).
Shoulder wall clearance height : 2.8 m / 9 ft
PRIOR TO ASSEMBLY
Please go through the whole instruction manual completely. It is very important to follow your local safety
regulations and industry standards during installation. Regulations may include but are not limited to:
- Safety helmets, protective eyewear, and clothing
- Safety harnesses for all elevated workers
- Proper ladder, cage, and safety operation
Check all components and parts before installation. All parts are marked with a part
number, please refer to the parts list to ensure you have all parts.
Choose a day with low or no wind to install, it is hard to assemble with heavy wind. Do not make any alterations to
the structure. Do not hang any weight on the frame during installation, including parts. We are not responsible for
any damages or injuries caused by inappropriate installation, unauthorized modifications or extreme weather.
This building is not intended for human occupancy.
It is recommended to use heavy duty duct tapes to tape the tube connection joint spots to protect the cover from
damage and worn. It will help to extend the cover life span.
Check the parts list below to make sure all parts are received prior to assembly.

►www.tmgindustrial.com 2/41 TOLL FREE:1-877-761-2819
FRAME STRUCTURE DIAGRAM.

►www.tmgindustrial.com 3/41 TOLL FREE:1-877-761-2819
TMG-DT50100-PRO PART LIST
PARTS
CODE
GRAPHICAL
DESCRIPTION
LENGTH
QTY
BOX
1A
Peak arch tube
(for front and rear truss)
L2646mm
2
A
1
Peak arch tube
(for 6 middle trusses )
L2646mm
12
A
2A
Upper rafter tube
(for front and rear truss)
L2855mm
4
C
2
Upper rafter tube
(for middle truss)
L2855mm
24
B/C
3A
Lower rafter tube
(for front and rear truss)
L2855mm
4
C
3
Lower rafter tube
(for middle truss)
L2855mm
24
C
4A
Shoulder tube
(front and rear truss)
L2613mm
4
B
4
Shoulder tube
(for middle truss)
L2613mm
24
D/E
5A
Sidewall tube
(front and rear truss)
L1895mm
4
D
5
Sidewall tube
(for middle truss)
L1895mm
24
E
5B
Roof purl in
(horizontal tube)
φ58xL2440mm
143
B
5C
Front and rear span tube
φ58xL2890mm
16
A
5L
Base plate for front and rear
truss left corners
W260xL320mm
2
A

►www.tmgindustrial.com 4/41 TOLL FREE:1-877-761-2819
5R
Base plate for front and rear
truss right corners
W260xL320mm
2
A
6
Base plates for middle truss
W260xL280mm
22
A
6A
Ratchets
3T
106
A
6M
Base plates for middle truss
(group 8 truss)
W280xL570mm
2
A
6C
Clip
6
A
7L
Left base plate of front and
rear door frame
W150xL350mm
2
A
7R
Right base plate of front and
rear door frame
W150xL350mm
2
A
7A
Front and rear door left and
right column base plate
W150xL200mm
4
A
8
Side door right tube
W200xL2070mm
2
A
8A
Side door left tube
W200xL2070mm
2
A
8B
Side door
L2005xW925mm
2
D
8C
Pressing plate
W20xL1000mm
2
A
8D
Pressing plate
W20xL2000mm
12
A
9B
Front and rear vertical door
rail connection plate
W69xL240mm
8
A

►www.tmgindustrial.com 5/41 TOLL FREE:1-877-761-2819
9C
Front and rear vertical door
rail end plate (floatable to
keep door rail straight)
W60xL218mm
4
A
9L
Front and rear vertical door
rail
(left side upper part)
W250xL2376mm
2
A
9R
Front and rear vertical door
rail
(right side upper part)
W250xL2376mm
2
A
10L
Front and rear vertical door
rail
(left side lower part)
W250xL2660mm
2
A
10R
Front and rear vertical door
rail
(right side lower part)
W250xL2660mm
2
A
10A
Right lower vertical tubes for
front and rear trusses
φ58xL2198mm
2
A
10B
Left and right upper vertical
tubes for front and rear
trusses
φ58xL1867mm
4
A
10
Left lower vertical tubes for
front and rear trusses
φ58xL2198mm
2
A
11
Side door upper tube
(front and rear)
W140xL2061mm
2
A
12
Front and rear door cross
tubes
(left and right)
W140xL2756mm
8
A
12A
Front and rear door cross
tubes
(left and right)
W140xL2062mm
2
A
13
Front and rear door cross
beam (left)
W140xL2304mm
2
A
13A
Front and rear door cross
beam (right)
W140xL2284mm
2
A
13B
Front and rear door center
vertical supporting rod for
cross beam
W140xL1280mm
2
A
14
Front and rear door hand
winch crossing tube
W140xL2761mm
2
A
15
Front and rear fabric panel
tension tubes
φ32xL2700mm
4
A
15A
Front and rear fabric panel
tension tubes
φ32xL2200mm
2
A

►www.tmgindustrial.com 6/41 TOLL FREE:1-877-761-2819
15B
Front and rear fabric panel
tension tubes
φ32xL750mm
2
A
15C
Front and rear fabric panel
tension tubes
φ32xL470mm
2
A
16
Front and rear roll up door
dropping tubes
(to connect #16A)
φ32xL2346mm
14
A
16A
Front and rear roll up door
dropping tubes
(to connect #16)
φ32xL2342mm
14
A
16B
Middle truss crossing steel
tension cables
φ6xL5900mm
16
A
16C
Sidewall frame steel tension
cables
φ6xL4700mm
30
A
17
Tarp cover tension tubes on
both sides
φ32xL1993mm
30
C
17A
Tarp cover tension tubes on
both sides
φ32xL1450mm
2
C
17B
Tarp cover tension tubes on
both sides
φ32xL970mm
2
C
18
Pipe clamps for front and rear
vertical tubes to connect to
truss frame
φ58mm
28
A
19
Tension tube end water plug
φ32mm
26
A
20
Roll up door hand winch
1200LB
2
A
21
Wire rope for front and rear
door hand winch
φ4xL16m
2
A
22
Tie down straps
(for #6A and front and rear
arches)
W38x800mm
106
A
23
Scratch resistant tape
L10m
5
A
24
Roof fabric tarp cover
1
E

►www.tmgindustrial.com 7/41 TOLL FREE:1-877-761-2819
24A
Roof fabric tarp cover
1
E
25
Front and rear truss fabric tarp
panel
2
A
25A
Front and rear roll up door
fabric tarp panel
2
A
26
Plastic hose
(in grooves at both ends of
#24)
φ25xL4000m
24
D
26A
Connector
(for connection #26)
φ25
20
A
27
Tension ropes
(tie to front and back doors)
φ32xL300m
1
A
28
Self locking bolt and nuts
M10x80mm
154
A
29
Self locking bolt and nuts
M8x70mm
16
A
30
Hex bolt and nuts
M12x30mm
560
A
31
Hex bolt and nuts
M10x90mm
92
A
31A
Hex bolt and nuts
M10x100mm
8
A
32
Hex bolt and nuts
M10x50mm
34
A
33
Front and rear fabric tarp
secure pin
φ6x200mm
4
A
34
Expansion bolts φ16
φ16x150mm
136
A
35
Cable connection plate
L91mm
18
A
36
Hex bolt and nuts
M10x60mm
12
A
37
Tapping screw
#12x25mm
104
A

►www.tmgindustrial.com 8/41 TOLL FREE:1-877-761-2819
STEP 1 : BASEPLATE POSITIONING AND INSTALLATION.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
5L
2
7L
2
5R
2
7R
2
6
22
7A
4
6M
2
34
128

►www.tmgindustrial.com 9/41 TOLL FREE:1-877-761-2819
STEP 2 : INSTALLATION OF FRONT AND REAR 2 GROUP TRUSSES.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
1A
1x2
5A
2x2
2A
2x2
30
32x2
3A
2x2
4A
2x2

►www.tmgindustrial.com 10/41 TOLL FREE:1-877-761-2819
STEP 3 : INSTALLATION OF MIDDLE 12 GROUP TRUSS.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
1
1x12
5
2x12
2
2x12
30
32x12
3
2x12
4
2x12

►www.tmgindustrial.com 11/41 TOLL FREE:1-877-761-2819
STEP 4 : WRAP (#23) AROUND THE SHARP POINTS OF THE JOINT TO AVOID FRICTION BETWEEN THE FABRIC AND THE
INTERFACE.
PARTS
CODE
PART
QTY
23
5

►www.tmgindustrial.com 12/41 TOLL FREE:1-877-761-2819
STEP 5 : PUT UP THE FRONT TRUSS (IT IS SUGGESTED TO USE CRANE FOR HOISTING).
PARTS
CODE
PART
QTY
30
8

►www.tmgindustrial.com 13/41 TOLL FREE:1-877-761-2819
STEP 6 : PUT UP THE 2ND TRUSS, AND CONNECT ALL PURLINS (#5B) BETWEEN 1ST AND 2ND.
PARTS
CODE
PART
QTY
5B
11
30
8
28
22

►www.tmgindustrial.com 14/41 TOLL FREE:1-877-761-2819
STEP 7 : REPEAT ABOVE STEP TO PUT UP ALL OTHER TRUSSES, AND CONNECT ALL PURLINS.
PARTS
CODE
PART
QTY
5B
132
30
96
28
132

►www.tmgindustrial.com 15/41 TOLL FREE:1-877-761-2819
STEP 8 : INSTALLATION OF DIAGONAL PURLINS (THE FRONT AND REAR MOUNTING METHODS ARE THE SAME).
PARTS
CODE
PART
QTY
5C
16
18
20
32
20

►www.tmgindustrial.com 16/41 TOLL FREE:1-877-761-2819
STEP 9 : TENSION CABLE INSTALLATION, ALL CABLES ARE DIAGONALLY INSTALLED ON EACH.
PARTS
CODE
PART
QTY
16B
12
16C
30
35
18

►www.tmgindustrial.com 17/41 TOLL FREE:1-877-761-2819
STEP 10 : DOOR COLUMN INSTALLATION (THE FRONT AND REAR MOUNTING METHODS ARE THE SAME).
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
9L
1
10R
1
31
26
9R
1
13
1
32
3
9B
`
4
13A
1
36
4
9C
2
13B
1
10L
1
18
2

►www.tmgindustrial.com 18/41 TOLL FREE:1-877-761-2819
STEP 11 :
1. DOOR SUPPORT PIPE INSTALLATION (THE FRONT AND REAR MOUNTING METHODS ARE THE SAME).
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
10
1
15
1
31
6
10B
1
16B
1
31A
2
11
1
18
1
32
2
12
2
29
4

►www.tmgindustrial.com 19/41 TOLL FREE:1-877-761-2819
STEP 11 :
2. DOOR SUPPORT PIPE INSTALLATION (THE FRONT AND REAR MOUNTING METHODS ARE THE SAME).
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
10A
1
14
1
18
1
10B
1
15
1
29
4
12
2
15A
1
31
10
12A
1
16B
1
31A
2
32
2
