TMG TMG-DT40FW8 User manual

►www.tmgindustrial.com 0/13 TOLL FREE:1-877-761-2819

►www.tmgindustrial.com 1/13 TOLL FREE:1-877-761-2819
MAIN SPECIFICATIONS :
Overall assembled size : W12 x H7.1 (m) / W39.37x H23.29 (ft)
Width : 12m / 39.37ft
Height : 7.1 m / 23.29ft
Front door:4.6x4.2(m)/15.09x13.78(ft)
PRIOR TO ASSEMBLY
Please read the instructions carefully before installation. It is very important to follow your local safety regulations and
industry standards during installation. Regulations may include but are not limited to:
- Safety helmets, protective eyewear, and clothing
- Safety harnesses for all elevated workers
- Proper ladder, cage, and safety operation
Check all components and parts before installation. All parts are marked with a part number, please refer to the parts
list to make sure you have all parts.
Choose a day with low or no wind to install, assembly is hard in heavy wind. Do not make any alterations to the structure.
Do not hang any weights on the frame during installation, including parts. We are not responsible for any damages or
injuries caused by inappropriate installation, unauthorized modifications or extreme weather.
This building is not intended for human occupancy.
It is recommended to tape or add foam/rubber on the frame where joints connect and where it touches the cover. This
will help extend the life span of the cover.

►www.tmgindustrial.com 2/13 TOLL FREE:1-877-761-2819
TMG-DT40FW8 PART LIST
PARTS
CODE
DESCRIPTION
LENGTH
QTY
7A
Baseplate
W150xL200mm
1
7B
Baseplate
W150xL200mm
3
7D
Baseplate of front door frame
W150xL200mm
2
9
Side vertical tube
L2620mm
1
9A
Side door left tube
L2027mm
1
9B
Side door right tube
L2027mm
1
9C
Side door
W925xL2005mm
1
9D
Side vertical tube
L2620mm
1
10A
Lower vertical tube
L2640mm
1
10B
Lower vertical tube
L2640mm
1
10L
Front vertical door rail
(left side lower part)
L2625mm
1
10R
Front vertical door rail
(right side lower part)
L2625mm
1
11L
Front vertical door rail
(left side upper part)
L2065mm
1
11R
Front vertical door rail
(right side upper part)
L2065mm
1
11A
Middle vertical tube
L2014mm
2
12
Upper vertical tube
L1616mm
2

►www.tmgindustrial.com 3/13 TOLL FREE:1-877-761-2819
13
Upper vertical tube
L2146mm
1
14A
Bottom tension bar
L1590mm
3
14B
Front door hand winch crossing tube
L1635mm
1
15A
Transverse tube
L1781mm
2
15B
Side door upper tube
L1642mm
1
16A
Middle transverse tube
L1635mm
2
17
Upper transverse tube
L2500mm
1
18
Upper transverse tube
L2920mm
2
18A
Front roll up door dropping tubes (to
connect #18B)
L2356mm
7
18B
Front roll up door dropping tubes (to
connect #18A)
L2359mm
7
19
Upper transverse tube
L2666mm
1
20
Support tube
L2985mm
3
21
Expansion bolts
φ16x150mm
16
23A
Wire rope for front door hand winch
15m
1
23B
Right pulley system for front door
L150mm
1
23C
Left pulley system for front door
L150mm
1
23D
Roll up door hand winch
(1200 lb)
1

►www.tmgindustrial.com 4/13 TOLL FREE:1-877-761-2819
24C
Front vertical door rail connection plate
L240mm
2
24D
Front vertical door rail end plate (floatable
to keep door rail straight)
L220mm
2
25
Tube clamps
φ58
19
25A
Tapping screw
#12x25mm
68
25B
Pressing plate
L2000mm
6
25C
Pressing plate
L1000mm
1
27
Hex bolt and nuts
M10x50mm
19
29
Hex bolt and nuts
M8x90mm
29
29A
Hex bolt and nuts
M10x70mm
26
30
Tube end water plug
φ32
6
33
Braided rope
100m
1
34
Front truss fabric cover panel
W12.1xL7.3m
1
34A
Front roll up door cover panel
W4560xL4870mm
1
38
Front fabric tarp secure pin
L200m
1

►www.tmgindustrial.com 5/13 TOLL FREE:1-877-761-2819
STEP 1 : REVIEW THE WHOLE STRUCTURE AND CHOOSE THE PROPER INSTALLATION SITE.
Place the containers making sure they are parallel and the correct width apart the diagonal X and Y must be
equal. Baseplates must be bolted firmly with expansion bolts, It is concrete expansion bolt.
Installation diagram of expansion bolt.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
7A
1
7D
2
7B
3
21
12

►www.tmgindustrial.com 6/13 TOLL FREE:1-877-761-2819
STEP 2 : FRONT TRUSS TO COMPLETE.

►www.tmgindustrial.com 7/13 TOLL FREE:1-877-761-2819
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
9
1
15B
1
9A
1
16A
2
9B
1
17
1
9C
1
18
2
9D
1
19
1
10A
1
21
4
10B
1
23B
1
10L
1
23C
1
10R
1
24C
2
11L
1
24D
2
11R
1
25
13
11A
2
25A
10
12
2
27
13
13
1
29
29
14A
3
29A
24
14B
1
30
6
15A
2

►www.tmgindustrial.com 8/13 TOLL FREE:1-877-761-2819
STEP 3 : INSTALL THE TOP SUPPORT TUBE.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
20
3
25A
6
25
6
27
6

►www.tmgindustrial.com 9/13 TOLL FREE:1-877-761-2819
STEP 4 : INSTALL FRONT COVER PANEL.
Lift up (#34) cover panel, starting from the center point of the frame (highest ridge point) use ropes (#33)
through the grommets to tie the panel to the truss firmly. All grommets need to be tied to the frame as shown.
PARTS
CODE
PART
QTY
ROPE SHEAR SIZE
34
1
33
Qty
A
13m
2
B
16m
1
C
8m
2
D
4m
5
E
3m
1

►www.tmgindustrial.com 10/13 TOLL FREE:1-877-761-2819
Install the front door metal strip.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
25A
52
25C
1
25B
6

►www.tmgindustrial.com 11/13 TOLL FREE:1-877-761-2819
STEP 5 : INSTALL MECHANICAL ROLL UP DOORS.
Door curtain installation.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
18A
7
34A
1
18B
7

►www.tmgindustrial.com 12/13 TOLL FREE:1-877-761-2819
Front door installation, please look at the door from inside.
The hand winch (#23D) comes with a shorter cable, we call it cable (#B).
PARTS
CODE
PART
QTY
ROPE SHEAR SIZE
23A
1
33
Qty
23D
1
F
7m
1
29A
2
38
1

►www.tmgindustrial.com 13/13 TOLL FREE:1-877-761-2819
AFTER THE INSTALLATION
Walk around and inspect the shelter periodically to make sure all components are still firmly secured and the whole
shelter is well supported. Check all bolts and nuts as well as all connection points to make sure they are all in good
position. Check the base plates, adjust the ropes and tie downs if required and clean the cover regularly.
Snow accumulating on the fabric cover must be removed as soon as possible. If snow becomes solid ice on the cover, it
will increase the weight on the roof and may collapse the shelter or reduce the life span.
Keep the shelter on a dry ground most of the time. Do not keep the fabric dirt skirt under water all the time, otherwise
the fabric will deteriorate.
We strongly recommend you remove any snow from the roof immediately. Do not leave any snow load on the roof
overnight. Keep 3 feet of clearance on all sides at all times. Do not allow snow to accumulate and pile up on the sides of
the building. Otherwise the pressure from the sides will push inwards and could lead to a collapse.

►www.tmgindustrial.com 0/8 TOLL FREE:1-877-761-2819

►www.tmgindustrial.com 1/8 TOLL FREE:1-877-761-2819
MAIN SPECIFICATIONS :
Overall assembled size : W12 x H7.1 (m) / W39.37x H23.29 (ft)
Width : 12 m / 39.37ft
Height : 7.1 m / 23.29ft
PRIOR TO ASSEMBLY
Please read the instructions carefully before installation. It is very important to follow your local safety regulations and
industry standards during installation. Regulations may include but are not limited to:
- Safety helmets, protective eyewear, and clothing
- Safety harnesses for all elevated workers
- Proper ladder, cage, and safety operation
Check all components and parts before installation. All parts are marked with a part number, please refer to the parts
list to make sure you have all parts.
Choose a day with low or no wind to install, assembly is hard in heavy wind. Do not make any alterations to the structure.
Do not hang any weights on the frame during installation, including parts. We are not responsible for any damages or
injuries caused by inappropriate installation, unauthorized modifications or extreme weather.
This building is not intended for human occupancy.
It is recommended to tape or add foam/rubber on the frame where joints connect and where it touches the cover. This
will help extend the life span of the cover.

►www.tmgindustrial.com 2/8 TOLL FREE:1-877-761-2819
TMG-DT40BW8 PART LIST
PARTS
CODE
DESCRIPTION
LENGTH
QTY
7A
Baseplate
W150xL200mm
3
7B
Baseplate of front door frame
W150xL200mm
2
7C
Baseplate for bottom tension bar
W80xL200mm
4
9
Side vertical tube
L2620mm
2
10
Lower vertical tube
L2640mm
3
11
Middle vertical tube
L2034mm
3
12
Upper vertical tube
L1616mm
2
13
Upper vertical tube
L2146mm
1
14
Bottom tension bar
L2740mm
4
15
Transverse tube
L2929mm
2
16
Middle transverse tube
L2784mm
2
17
Upper transverse tube
L2500mm
1
18
Upper transverse tube
L2920mm
2
19
Upper transverse tube
L2666mm
1
20
Support tube
L2985mm
3
21
Expansion bolts
φ16x150mm
18

►www.tmgindustrial.com 3/8 TOLL FREE:1-877-761-2819
25
Tube clamps
φ58
15
25A
Tapping screw
#12x25mm
6
27
Hex bolt and nuts
M10x50mm
15
29
Hex bolt and nuts
M8x90mm
28
30
Tube end water plug
φ32
8
33
Braided rope
100m
1
35
Rear truss fabric cover panel
W12.1xL7.3m
1

►www.tmgindustrial.com 4/8 TOLL FREE:1-877-761-2819
STEP 1 : REVIEW THE WHOLE STRUCTURE AND CHOOSE THE PROPER INSTALLATION SITE.
Place the containers making sure they are parallel and the correct width apart the diagonal X and Y must be
equal. Baseplates must be bolted firmly with expansion bolts, It is concrete expansion bolt.
Installation diagram of expansion bolt.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
7A
3
7C
4
7B
2
21
18

►www.tmgindustrial.com 5/8 TOLL FREE:1-877-761-2819
STEP 2 : REAR TRUSS TO COMPLETE.
PARTS
CODE
PART
QTY
PARTS
CODE
PART
QTY
9
2
17
1
10
3
18
2
11
3
19
1
12
2
25
9
13
1
27
9
14
4
29
28
15
2
30
8
16
2
