TMG TMG-CRS1040 User manual

www.tmgindustrial.com 0/19 TOLL FREE:1-877-761-2819
WARNINGS-SAFE USAGE

www.tmgindustrial.com 1/19 TOLL FREE:1-877-761-2819
MAIN SPECIFICATIONS :
- Assembly size : W3 x L12 x H2 (m) / 9.8 x 39.4 x6.6 (ft)
- Shoulder wall clearance height : 1.2 m /3.9 ft
PRIOR TO ASSEMBLY
Please read the instructions carefully before installation. It is important to follow your local safety regulations and
industry standards during installation. Regulations may include but are not limited to :
- Safety helmets, protective eyewear, and clothing
- Safety harnesses for all elevated workers
- Proper ladder, cage, and safety operation
Check all components and parts before installation. All parts are marked with a part number, please refer to the parts list
to make sure you have all parts.
Choose a day with low or no wind to install, assembly is hard in heavy wind. Do not make any alterations to the structure.
Do not hang any weights on the frame during installation, including parts. We are not responsible for any damages or
injuries caused by inappropriate installation, unauthorized modifications or extreme weather.
This building is not intended for human occupancy.
Read the following item list carefully and count the number of items to ensure that all parts are included prior to setup.
Review the whole structure and choose the proper installation site
Choose a solid flat level ground area to set up the building. Do not install the building on soft ground, wetland, uneven
surfaces, sloped surfaces, or on top of structures that are not rated to hold its weight.
We strongly recommend that you build the structure on a solid foundation such as cement and use anchor bolts on all
baseplates.
Be aware of the surrounding area. Do not set up the building near snowdrifts, open flames or exposed electrical wires. Do
not keep heat sources near the fabric cover. Keep the building surroundings clear at all times.

www.tmgindustrial.com 2/19 TOLL FREE:1-877-761-2819
TMG-CRS1040 PART LIST
PARTS
CODE GRAPHICAL DESCRIPTION LENGTH QTY
1 Peak tube φ32xL1154mm 23
1A Peak tube φ32xL1178mm 6
2
Peak arch tube
(for front and rear truss) L144xW120mm
4
2A
Peak arch tube
( middle trusses ) L198xW144mm
10
3
Shoulder tube
(front and rear truss) L138xW120mm
4
3A
Shoulder tube
(for middle truss) L198xW138mm
10
4 Sidewall tube φ32xL1183mm 14
5 Lower horizontal tube φ32xL2030mm 12
6 Upper horizontal tube φ32xL1922mm 24
7 Front and rear foot tube L166xW52mm 4
8
Front and rear Lower
horizontal tube φ32xL834mm 4
9 Door right pillar φ32xL1937mm 1
9A Door left pillar φ32xL1937mm 1

www.tmgindustrial.com
10
11
12
13
13A
14
15
15A
15B
16
17
18
19
20
21
22
www.tmgindustrial.com
3/19
TOLL FREE:1
Inclined tube φ
32xL1130mm
Door
L805xW548mm
Door frame tube φ
32xL568mm
Pipe clamps φ
32xL70mm
Clip
L93xW40mm
Connector
L55xW34mm
Screw bolt
M8x50mm
Screw bolt
M6x60mm
Tapping screw
#12x25mm
Screw bolt
M6x60mm
Waterproof plug
Barbed wire
L
Plastic cable tie
Tension rope
Roof fabric tarp cover W
5
V-spring buckle
TOLL FREE:1
-877-761-2819
32xL1130mm
8
L805xW548mm
2
32xL568mm
1
32xL70mm 16
L93xW40mm
36
L55xW34mm
4
M8x50mm
14
M6x60mm
18
#12x25mm
18
M6x60mm
20
φ32mm 20
L
43xW2m 1
L200mm 700
L150mm 76
5
.84xL3.62m 1
(φ8) 112

www.tmgindustrial.com 4/19 TOLL FREE:1-877-761-2819
STEP 1 :INSTALL V-SPRING BUCKLE
NO. PART QTY
1 23
4 14
6 24
8 4
22 112

www.tmgindustrial.com 5/19 TOLL FREE:1-877-761-2819
STEP 2: ASSEMBLE FRONT AND REAR TRUSSES.
NO. PART QTY
1 3x2
2 2x2
3 2x2

www.tmgindustrial.com 6/19 TOLL FREE:1-877-761-2819
STEP 3 : ASSEMBLE MIDDLE TRUSSES.
NO. PART QTY
1 3x5
2A 2x5
3A 2x5

www.tmgindustrial.com 7/19 TOLL FREE:1-877-761-2819
STEP 4 : CONNECT THE FRONT TRUSS AND THE 2ND TRUSS THROUGH PART (#6).
NO. PART QTY
6 4

www.tmgindustrial.com 8/19 TOLL FREE:1-877-761-2819
STEP 5 : CONNECT THE 3ST TRUSS AND THE REAR TRUSS THROUGH PART (#6).
NO. PART QTY
1A 6
6 20
13A 24
15A 12
15B 12

www.tmgindustrial.com 9/19 TOLL FREE:1-877-761-2819
STEP 6 : ASSEMBLE PART (#4).
NO. PART QTY
4 14

www.tmgindustrial.com 10/19 TOLL FREE:1-877-761-2819
STEP 7 : FOUNDATION INSTALLATION.
NO. PART QTY NO. PART QTY
1 2 14 4
5 12 15 14
7 4 16 4
8 4

www.tmgindustrial.com 11/19 TOLL FREE:1-877-761-2819
STEP 8 : INSTALL THE DOOR FRAME (#9) AND (#9A).
NO. PART QTY NO. PART QTY
9 1 13A 12
9A 1 15A 6
12 1 15B 6

www.tmgindustrial.com 12/19 TOLL FREE:1-877-761-2819
STEP 9 : INSTALL THE DIAGONAL BRACING BARS (#10).
NO. PART QTY
10 8
13 16
16 16

www.tmgindustrial.com 13/19 TOLL FREE:1-877-761-2819
STEP 10 : INSTALL THE DOOR (#11).
NO. PART QTY
11 2
17 20

www.tmgindustrial.com 14/19 TOLL FREE:1-877-761-2819
STEP 11 : INSTALL THE TOP HEXAGONAL WIRE MESH.
NO. PART QTY
18 1
19 100

www.tmgindustrial.com 15/19 TOLL FREE:1-877-761-2819
STEP 12 : INSTALL THE TOP HEXAGONAL WIRE MESH.
NO. PART QTY
18 1
19 400

www.tmgindustrial.com 16/19 TOLL FREE:1-877-761-2819
STEP 13 : INSTALL THE FRONT DOOR HEXAGONAL WIRE MESH .
NO. PART QTY
18 1
19 140
Note : When installing the hexagonal mesh
(#18) of the front truss, cover the net on the
front truss, and then wrap the rope (#19)
through the mesh hole to the truss to ensure
that the hexagonal mesh is stretched and
flat, and the surplus parts at the top left and
right corners are

www.tmgindustrial.com 17/19 TOLL FREE:1-877-761-2819
STEP 14 : INSTALL THE REAR DOOR HEXAGONAL WIRE MESH.
NO. PART QTY
18 1
19 60

www.tmgindustrial.com 18/19 TOLL FREE:1-877-761-2819
STEP 15 : INSTALL THE TOP COVER (#21).
NO. PART QTY
20 76
21 1

www.tmgindustrial.com 19/19 TOLL FREE:1-877-761-2819
AFTER THE INSTALLATION
Walk around and inspect the building periodically to make sure all components are still firmly secured and the whole
building is well supported. Check all bolts and nuts as well as all connection points to make sure they are all in good
position. Check the base plates, adjust the ropes and tie downs if required and clean the cover regularly.
Snow accumulating on the fabric cover must be removed as soon as possible. If snow becomes solid ice on the cover,
it will increase the weight on the roof and collapses the building or reduce the life span eventually.
Keep the building on a dry ground most of the time. Do not keep the fabric dirt skirt under water all the time, otherwise
the fabric will deteriorate.
We strongly recommend you remove any snow from the roof immediately. Do not leave any snow load on the roof
overnight. Keep 3 feet of clearance on all sides at all times. Do not allow snow to accumulate and pile up on the sides
of the building. Otherwise the push from the sides toward inside will make the building collapsed at some point.
