UNIS Coconut Bash User manual

www.universal-space.com
Operation Manual
IMPORTANT
NOTE: Some portions of assembly may require additional assistance.

Coconut Bash
09/21/2018
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]

Coconut Bash
2
12/14/2018
CONTENT
IMPORTANT SAFETY INSTRUCTIONS......................................................................2
1. SPECIFICATIONS................................................................................................... 5
2. CONTENTS OF THE ACCESSORY KIT................................................................... 8
3. PART NAME......................................................................................................... 12
4. SET UP & INSTALLATION....................................................................................13
5. HOW TO PLAY......................................................................................................31
6. IO SETTING.......................................................................................................... 32
7. TROUBLE SHOOTINGS........................................................................................ 39
8. MAINTENANCE & INSPECTION..........................................................................40
9. OVERALL CONSTRUCTION................................................................................. 44
10. WIRING DIAGRAM...........................................................................................68

Coconut Bash
12/14/2018
3
Thank you for purchasing Coconut Bash. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technica
l
personne
l
s
houl
d
under no circumstance attempt to
s
ervice the machine.Contactyourdistributoror
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended ma
y
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated b
y
signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE,andWARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part ma
y
be hot or can cause electric shock.
Do not touch.

Coconut Bash
4
12/14/2018
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE
T
O ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Coconut Bash
12/14/2018
5
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz
Min. Power consumption: 200W
Max. Power consumption: 320W
Single ver. dimension: W44.5×D122.2×H105.2(in) W1132×D3105×H2672 (mm)
Twin ver. dimension: W89.1×D122.2×H112.3(in) W2264×D3105×H2854 (mm)
Single ver. weight：Approximately 970 lb
Part No: C146
Model No: A-414
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Single ver. dimension:

Coconut Bash
6
12/14/2018
Twin ver. dimension:
Note: Game specifications are subject to change without notice.

Coconut Bash
12/14/2018
7
This machine will be divided into two parts during transportation.
Front part: W43.6×D55×H84.5 (in) W1107×D1399×H2146 (mm)
Back part: W43.4×D38.7×H84.4 (in) W1102×D983×H2145(mm)
Note: Game specifications are subject to change without notice.

Coconut Bash
8
12/14/2018
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included：
1. Following accessories:
No. Part No. Code Name Picture Qty Note
1 C146-244-001 20611702022A Ball 20 /
2 C146-245-000 25300171002 Key 2/
3 C146-246-000 25300172002 Key 1/
4 C146-243-000 41440000251A Manual 1/
5 C146-409-000 21901000013 Fuse 11 /
6 C146-485-000 23301000001 Power cord 1/
7 C146-247-000 20101040066
Hexagon
socket
button head
screws
2
To connect the
track back
cover
8 C146-248-000 20101040171
Hexagon
socket
button head
screws
4To install the
front marquee
9 C146-249-000 20101020041
Cross
recessed pan
head screw
set
8
To install the
middle top
cover plate

Coconut Bash
12/14/2018
9
No. Part No. Code Name Picture Qty Note
10 C146-250-000 20101000116
Cross
recessed pan
head screw
32 To install L&R
windows
11 C146-251-000 20101040011
Hexagon
socket
button head
screws
8To install the
ball track
12 C146-252-000 20101100020
Cross
recessed pan
head screw
16
To install
middle L/R part
13 C146-253-000 20101000117
Cross
recessed pan
head screw
12 To install L/R
side bar
14 C146-254-000 20104020002
Cross
recessed
hexagon
screw kit
6
To install send
ball assy. and
back bottom
plate
15 C146-255-000 20104020004
Cross
recessed
hexagon
screw kit
16
To install
middle bottom
part and Large
marquee
16 C146-256-000 20101108005
Hexagon
socket
button head
screws
2To install the
front marquee
17 C146-257-000 20102020030 Hexagon
flange nut 4To install L/R baffle
18 C146-740-002 20511702026B Steps label / 1 /

Coconut Bash
10
12/14/2018
2. Component & hardware for installation：
No. Part No. Code Name Picture Qty
1/ / Middlebottompart 1
2 / / Send ball assy. 1
3
C146-174-000 20211702033 L baffle 2 1
C146-176-000 20211702035 R baffle 2 1
4 C146-109-001 20311702044 Middle top cover plate 1
5 / / Middle L part 1
6 / / Ball track assy. 1
7 C146-232-000 20211702074 Ball track back cover 1

Coconut Bash
12/14/2018
11
NOTE: Part models are subject to change without notice.
No. Part No. Code Name Picture Qty
8/ / MiddleRpart 1
9/ / Rsidebar 1
10 / / Lsidebar 1
11 / / L&R window assy. 2
12 / / Front marquee assy. 1
13 / / Large marquee assy. 1
14 C146-241-000 20211702123 Back bottom plate 1

Coconut Bash
12
12/14/2018
3. PART NAME
Key Components
Ball exit
Wheel stop
button
Coconut
rebound assy.
Ball out assy.
Wheel assy.
L/R
windows
Front marquee
assy.
Ticket
dispenser
assy.
Coin mech
assy.

Coconut Bash
12/14/2018
13
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid
Place the unit on a dry level surface
Ventilation openings in the back of the unit must not be obstructed by objects or b
y
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this game on a flat surface. If the game is installed on an unsuitable floor, it could
cause game malfunction.
To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it
touches the floor, lifting the casters off the ground b
y
0.2 in. Repeat the same for all
levelers.
NOTICE
Make sure the machine is level.
We do not recommend using power tools as they may cause damage.
NOTICE
leveler

Coconut Bash
14
12/14/2018
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 11.8 in
Play area
Service area
Y
our unit must be leveled to operate properly.
NOTICE

Coconut Bash
12/14/2018
15
4.4Machine Installation
Before processing with assembly assure you have the following tools.
No. Name Picture Use for
1Phillips screwdriver
For Marquee
Installation&Connect
Lane Assembly
2Wrench
3Allen hexagon wrenches Connect Lane Assembly
& Display Assembly

Coconut Bash
16
12/14/2018
4.4.1
No. Part No. Code Name Picture Qty
1 C146-255-000 20104020004 Cross recessed hexagon screw kit 14
2/ / Middle bottom part 1
No. 15
SPEC. M6X25
Qty. 14
Middle bottom part

Coconut Bash
12/14/2018
17
4.4.2
No. Part No. Code Name Picture Qty
1 C146-254-000 20104020002 Cross recessed hexagon
screw kit 2
2/ / Send ball assy. 1
No. 14
SPEC. M6X16
Qty. 2
Send ball assy.

Coconut Bash
18
12/14/2018
4.4.3
No. Part No. Code Name Picture Qty
1 C146-257-000 20102020030 Hexagon flange nut 4
2 C146-174-000 20211702033 L baffle 2 1
3 C146-176-000 20211702035 R baffle 2 1
No. 17
SPEC. M5
Qty. 4
L/R baffle 2

Coconut Bash
12/14/2018
19
4.4.4
No. Part No. Code Name Picture Qty
1 C146-249-000 20101020041 Cross recessed pan head screw
set 8
2 C146-109-001 20311702044 Middle top cover plate 1
No. 9
SPEC. M5X12
Qty. 8
Middle top cover plate
