Uplus Lighting 360 BEAM User manual

User manual
360 BEAM
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3-4
Technical Specifications…………………………………………………………………………4-5
Control Menu ……………………………………………………………………………………5-7
DMX Channels ……………………………………………………………………………………8-10
Dimension …………………………………………………………………………………………11
LUX Date ……………………………………………………………………………………………11
Trouble Shooting…………………………………………………………………………………12
Fixture Cleaning………………………………………………………… ………………………12
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

4
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also
always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Input voltage range: 90-240V~ 50/60Hz
Machine power: 365 W
Input power: 550W
Light source: PHILIPS MSD Silver 300 LL (3000 hours)
Diameter of light-emitting lens: 145mm
Color temperature: 7800K
When the beam angle is 2°, the illuminance at 10 meters can reach 400,000 lux
Fixed gobo: 1 fixed gobo, 16 gobos plus 1 white circle
Color wheel: 1 color wheel, 14 fixed colors plus white, two-way rainbow effect
Equipped with 1 8 prism, and 8+16+24 honeycomb prism, the two prisms can be stacked and
rotated in both directions
Beam angle: 2°
Control mode: DMX512, self-propelled, master-slave, RDM
Channel: 18CH
With fog and colorful effects
Electric focusing system
Outstanding strobe effect with variable speed
0-100% smooth dimming
Control panel: LCD display, touch panel
X-axis rotation angle: 540°
Y-axis rotation angle: 270°

5
XY axis magnetic coding positioning is more accurate
Power Outlet: Power Connector Input/Output
Signal input/output: three-pin XLR head socket
Overheating self-energy protection bulbs, extending lamp life
Lamp size: 338x256x512mm
Net weight: 14KG
3.Control Menu
1—Displays the current DMX address in large font
2—Logo display area
3—DMX signal frame rate (FPS)
4—Current channel mode, the displayed number indicates the current channel number
5—Fan speed display (select whether to display according to the lighting conditions)
6—Current Mode (Master, Slave)
7—Current running mode (DMX512, Auto, User)
8—Error message. If a red band "x" is displayed, the self-test found an error. (Press down to view
specific error message)
9 - temperature display or other content (depending on lamp configuration)
10 —SN term display
menu operation:
1. DMX address: set the DMX address
2. Channel mode: Set the channel mode, the number of the menu option indicates the number of
channels.

6
3. Reset operation: reset the motor
Motor power off：
Select "On", all motors are powered off; select "Off", all motors are powered on
and reset. Using this menu, it is possible to plug and unplug the motor and power-on reset without
turning off the main switch.
XY Axis: Reset Pan and Tilt Motors
.......
4.Run: Set the run mode
The description of each menu option is as follows (Note: "Automatic" mode options may
vary according to different product models):
DMX: controlled and run by DMX512 console.
Self-propelled (factory test): run the program set by the manufacturer, this program is mainly
used for factory test.
User program: run user self-programming program. The editing scene can be set in the [Run
Settings] - [Self-Programming] menu.
5.lamp：Switch the light bulb. After changing the value, it takes about 3 seconds to work, you can
switch the value back within 3 seconds to cancel the operation. After turning off the light
bulb, you must wait 1~2 minutes before turning it on again. If you operate the menu to turn
on the light bulb within two minutes, the light bulb will not be lit. After the waiting time is up,
it will light up by itself.
If this menu item is "on", the system will first try to light the bulb when powered on, and wait
for the light board to return.
6.Manual: Manually set the value of the channel
7.Operation settings: Operation parameter settings.
XY axis general settings:
X-axis reverse: Select "Yes" to reverse the rotation direction of the Pan motor, select "No",
and follow the rotation direction at the factory.
Y-axis reverse: select "Yes" to reverse the rotation direction of the Pan motor, select "No",
and follow the rotation direction at the factory.
DMX512
When no signal: select the operation mode if no DMX512 signal is detected
When powering on: Only when powering on, if no DMX signal is detected,
the above operation mode will be executed,
Otherwise, the last DMX action will be held
Centered: Except for Pan and Tilt, all other channels are cleared to zero.
Self-propelled (factory test/pattern/color): Run the program set by the factory.
User program: run user self-programming program.
Runtime: At any time, as long as the DMX signal is lost, the action performed
Hold: Hold the DMX value of the last frame.
Shut off: close the shutter
Turn on the light bulb: Select "No", the light will not light after the power-on reset is
completed, select "Yes", the light bulb will be automatically turned on after the power-on reset is
completed.
8. Advanced settings:
Fine-tuning: Factory debugging function, which requires password authentication to enter.
Display: Menu screen flip setting
Language: Set the system language

7
Ignore errors: Some error reports may not affect the final use effect, or for the general
purpose of the product, you can choose to turn off some meaningless error reports
Trim Recovery: After replacing the display board, use this menu to restore the trim data
saved by the motor board to the display board.
9. Information:
DMX value: Display the current received DMX signal value
Channel: Displays the DMX value of the selected channel that needs to be observed
Error: Display error message (if any item in this menu is wrong, an exclamation mark will be
displayed in the upper right corner of the menu cover)
Storage: Indicates whether the storage is functioning normally. If the memory is
abnormal, the menu information cannot be recorded or read, and the lamp time record and
self-programming data may also be lost.
RAM Error: Chip memory allocation failed, if this error occurs, please contact the
manufacturer.
Bus communication: If there is an error, the motors of various functions will not
operate normally. If this error occurs, please check whether the communication cables between the
boards are in poor contact.
Bulb: The communication between the bulb and the lighting board. If the
communication is wrong, the main control chip cannot correctly judge whether the light bulb is
normally turned off or on, which may cause some functions to not work properly.
Lighting board: Communication with the light bulb lighting board.
X-axis reset: X-axis reset failed, check whether the magnetic code or motor is normal.
Y-axis reset: Y-axis reset failed, check whether the magnetic coding or motor is normal.
Color reset: Color wheel reset failed
Fixed pattern reset: Fixed pattern disk reset failed
Fan stop: The blower stops rotating, and the light bulb will be automatically turned off
after a certain time.
Bulb: Displays the usage time of the bulb
Usage time: Displays the total time the lamp has been on since the lamp time was reset
to zero
Time reset: The total time the bulb is on is reset to 0.
Test Mode: For product testing and temporary use only.
Product Code: The internal code of the product is only for reference in product production and
maintenance.

8
4.DMX Channels
Model - CH18
Channel
DMX Value
Description
1
0-255
Pan
2
0-255
Pan fine
3
0-255
Tilt
4
0-255
Tilt fine
5
Pan/Tilt speed
0
Maximum speed
in speed mode
1-255
speed from fast to slow
in time mode
1-255
Time from 0.1s to 25.5s
6
0-255
dimmer
7
strobe
0-3
closure
4-103
Strobe from slow to fast
104-107
Open
108-207
Fast off and slow on, from fast to slow
208-212
Open
213-251
Random strobe, from slow to fast
252-255
Open
8
color wheel
0-4
Color 1 (white light)
5-8
color 1+color 2
9-12
color 2
13-17
color 2+color 3
18-21
color 3
22-25
color 3+color 4
26-29
color 4
30-34
color 4+color 5
35-38
color 5
39-42
color 5+color 6
43-46
color 6
47-51
color 6+color 7
52-55
color 7
56-59
color 7+color 8
60-63
color 8
64-68
color 8+color 9
69-72
color 9
73-76
color 9+color 10
77-81
color 10
82-85
Color 10 + Color 11

9
8
86-89
color 11
90-93
Color 11+Color 12
94-98
color 12
99-102
Color 12+Color 13
103-106
color 13
107-110
Color 13+Color 14
111-115
color 14
116-119
Color 14+Color 15
120-123
color 15
124-127
Color 15+Color 1
128-190
Rainbow effect from fast to slow
191-192
rainbow effect stopped
193-255
Rainbow effect from slow to fast
9
Gobo
0-3
Open (white light hole)
4-6
Gobo 1
7-9
Gobo 2
10-12
Gobo 3
13-15
Gobo 4
16-18
Gobo 5
19-21
Gobo 6
22-24
Gobo 7
25-27
Gobo 8
28-30
Gobo 9
31-33
Gobo 10
34-36
Gobo 11
37-39
Gobo 12
40-42
Gobo 13
43-45
Gobo 14
46-48
Gobo 15
49-54
Gobo 16
55-62
Pattern 1 shaking from slow to fast
63-70
Pattern 2 shaking from slow to fast
71-78
Pattern 3 shaking from slow to fast
79-86
Pattern 4 shaking from slow to fast
87-94
Pattern 5shaking from slow to fast
95-102
Pattern 6shaking from slow to fast
103-110
Pattern 7shaking from slow to fast
111-118
Pattern 8 shaking from slow to fast
119-126
Pattern 9shaking from slow to fast
137-134
Pattern 10 shaking from slow to fast
135-142
Pattern 11 shaking from slow to fast
143-150
Pattern 12 shaking from slow to fast
151-159
Pattern 13 shaking from slow to fast
159-166
Pattern 14 shaking from slow to fast
167-174
Pattern 15 shaking from slow to fast

10
9
175-190
Pattern 16 shaking from slow to fast
191-201
Open
202-227
The gobo is scrolling forward, from fast to slow
228-229
stop scrolling
230-255
gobo scrolls in reverse, from slow to fast
10
Atomization and colorful
0-19
null
20-137
atomization
138-255
colorful
11
Prism1
0-127
no prism
128-255
Prism 1 Insert
12
Prism 1 Positioning and Rotation
0-127
Prism 1 Positioning and Rotation
128-190
Prism 1 rotates in reverse, from fast to slow
191-192
Prism 1 stops rotating
193-255
Prism 1 rotates forward, from slow to fast
13
Prism2
0-127
no prism
128-255
Prism 2 Insert
14
0-255
focus
15
no function
16
no function
17
reset
To achieve the following effects, push the DMX value to the corresponding
position and stand still for at least 4 seconds
0-25
null
26-76
effect reset
77-127
Pan/Tilt reset
128-255
reset all
18
reset
Lamp
To achieve the following effects, push the DMX value to the corresponding
position and stand still for at least 4 seconds
0-25
no effect
26-100
Lamp Off
101-255
Lamp ON

11
5.Dimension
6.LUX Date

12
7.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
8.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
