Uplus Lighting 400 IP BLINDER User manual

User manual
400 IP BLINDER
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3-4
2.Technical Specifications…………………………………………………………………………4
3.Control Menu ………………………………………………………………………………………5
4.DMX Channels ………………………………………………………………………………………6
5.Trouble Shooting……………………………………………………………………………………7
6.Fixture Cleaning………………………………………………………… …………………………7
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure
that they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is

4
firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to
which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s
weight. Also always use a safety cable that can hold 12 times of the weight of the unit when
installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Input Voltage:AC90-240V,50/60Hz
Power Consumption:400W
Light Source:4X100W COB LED,
Each LED can be controlled individual
Lamp life:50000hrs
Color temperature:3200K/6500K
Beam Angle: 40゜
Display :Digital display
Control Mode:DMX512,Master/Slave,Auto,Sound Active
DMX Channel:4/8 DMX Channels
Dimmer:0-100% smooth linear adjustment
Strobe:High speed strobe effect with 1-25 flashes per second
Cooling mode: Fan cooling(Temperature control)
IP Rate:IP65
Strobe: 0-30Hz

5
3.Control Menu
Display:
The operating instructions:according to the function keys A will cycle out eight different function effect,
digital tube top two number represents the current in the function(see table)function.After two number
represents the function in the address or speed,parameters.According to B or C key can change the
parameters,press D key confirmation.
2.LED Display Window Function CRT(All of the selected press again according to the function D key
confirmation)
Number
display
Function Explain
NO.1
A001
eight channels address(001-512)B.C add minus address
NO.2
D001
eight channels address(001-512)B.C add minus address
NO.3
CC00
Seven channels address(01-99)B.C modify jump to change
speed
NO.4
CP00
Seven color gradient(01-99)B.C gradient to change speed
NO.5
DE00
Seven color combination change
NO.6
BEBE
Seven color sonic change
NO.7
R220
Choosing colors red,B.C modify choice
NO.8
G220
Choosing colors green,B.C modify choice
NO.9
B220
Choosing colors blue,B.C modify choice
NO.10
W220
Choosing colors white,B.C modify choice
NO.11
-ON- / -OFF
Display -ON- / -OFF

6
4.DMX Channels
DMX Channels(8 channels)
Channels
Function
Explain
NO.1
Total dimming
RGBW total dimming,from dark to bright
NO.2
W1 Dimming
W1 Dimming,from dark to bright
NO.3
W2 Dimming
W2 Dimming,from dark to bright
NO.4
W3 Dimming
W3 Dimming,from dark to bright
NO.5
W4 Dimming
W4 Dimming,from dark to bright
NO.6
Total strobe
RGBW total strobe,from slow to fast
NO.7
Function choose
0—50：DMX8channels controller；51－100：jump；101—
150：gradient；151—200：pulse change；201—255：sound
controll
NO.8
Function speed
Function speed,from slow to fast
DMX Channels (4 Channels)
channelsnumber
Function
Explain
NO.1
W1 Dimming
W1 Dimming,from dark to bright
NO.2
W2 Dimming
W2 Dimming,from dark to bright
NO.3
W3 Dimming
W3 Dimming,from dark to bright
NO.4
W4 Dimming
W4 Dimming,from dark to bright

7
5.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X
p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
6.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
