Uplus Lighting MINI740 User manual

User manual
MINI 740
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions………………………………………………………………………………3-4
Technical Specifications……………………………………………………………………………4
Control Menu …………………………………………………………………………………………5
DMX Channels ……………………………………………………………………………………6-8
Dimension ……………………………………………………………………………………………9
Trouble Shooting……………………………………………………………………………………0
Fixture Cleaning………………………………………………………… …………………………10
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:

4
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also
always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Voltage: AC100V～240V 50-60HZ
Rated Power: 350W
LED Source: 7*40W RGBW 4-in-1 LED
Zoom angle: 4.5°-45°
Strobe: 0-25Hz
Control: DMX512/Auto Run/Master-Slave/Music
DMX Channels: 17/21/21/29channel
Dimmer: 0-100% linear dimmer
Pan: 540°+16 bit fine
Tilt: 270°+16 bit fine
Display: LCD colorful display
IP: IP20
Dimension:340*273*170mm ; NW:5.75 kgs

5
3.Control Menu
Menu Operation
Main Menu
Second
Third
Fourth
Dmx Address
000 - 512
Fixture
Dmx Mode
BAS1 7 CH/ BAS2 1 CH/ EXT2 1 CH/ EXT2 9 CH
Run Mode
DMX / Host / Sound
Pan Invert
Close / Open
Tilt Invert
Close / Open
No Dmx Signal
Clear / Hold
Sound Control
0 -- 99
Manual
Pan
000 - 255
Pan Fine
000 - 255
Tilt
000 - 255
Tilt Fine
000 - 255
⁞
⁞
Information
Time
Current Time
xxxH
Total Time
xxxH
Sensor
Pan
FALSE / TURE
Tilt
FALSE / TURE
Zoom
FALSE / TURE
Te m p
FALSE / TURE
Fan
FALSE / TURE
Te m p e r a t u r e
Head Temp
xxxC
Software Version
Panel
Vx . xx
Vx . xx
Vx . xx
Factory
Password
000 - 255
Pan
000 - 255
Tilt
000 - 255
Zoom
000 - 255
Red
000 - 255
Green
000 - 255
Blue
000 - 255
White
000 - 255
Fixture Reset
Motor Reset
Cance / Run
Factory
Cance / Run
Display
Language
CH / EN
Display Flip
Normal / Reverse
Display Mode
6 0 s / Show

6
4.DMX Channels
17 CH Mode
Channel
Features
value
Function
CH1
Red
0--255
Red 0- 100% dimmer, from dark to bright
CH2
Green
0--255
Green 0- 100% dimmer, from dark to bright
CH3
Blue
0--255
Blue 0- 100% dimmer, from dark to bright
CH4
White
0--255
White 0- 100% dimmer, from dark to bright
CH5
CTO
0--255
8500K-2800K CT linear contro
CH6
Macro color
0--255
Macro color change
CH7
Strobe
0--3
Close
4--103
Regular Strobe, Slow To Fast
104--107
Open
108--207
Pulse, Slow To Fast
208--212
Open
213--225
Random Slow Strobe
226--238
Random Middle Speed Strobe
239--251
Random Fast Strobe
252--255
Open
CH8
Dimmer
0- 100% linear dimmer
CH9
Dimmer fine
Dimmer fine
CH10
Pan
0--255
Pan movement control
CH11
Pan Fine
0--255
Pan fine control
CH12
Tilt
0--255
Tilt movement control
CH13
Tilt Fine
0--255
Tilt fine control
CH14
Zoom
0--255
zoom
CH15
Color cross fade
0--255
multiple color cross fade
CH16
Function
0--255
CH17
Reset
0--250
No function
251--255
Wait 5 seconds to auto reset
21 CH Mode (basic)
Channel
Features
value
Function
CH1
Red
0--255
Red 0- 100% dimmer, from dark to bright
CH2
Red fine
0--255
Red fine
CH3
Green
0--255
Green 0- 100% dimmer, from dark to bright
CH4
Green fine
0--255
Green fine
CH5
Blue
0--255
Blue 0- 100% dimmer, from dark to bright
CH6
Blue fine
0--255
Blue fine
CH7
White
0--255
White 0- 100% dimmer, from dark to bright
CH8
White fine
0--255
White fine
CH9
CTO
0--255
8500K-2800K CT linear contro
CH10
Macro color
0--255
Macro color change
0--3
Close
4--103
Regular Strobe, Slow To Fast

7
CH11
Strobe
104--107
Open
108--207
Pulse, Slow To Fast
208--212
Open
213--225
Random Slow Strobe
226--238
Random Middle Speed Strobe
239--251
Random Fast Strobe
252--255
Open
CH12
Dimmer
0- 100% linear dimmer
CH13
Dimmer fine
Dimmer fine
CH14
Pan
0--255
Pan movement control
CH15
Pan Fine
0--255
Pan fine control
CH16
Tilt
0--255
Tilt movement control
CH17
Tilt Fine
0--255
Tilt fine control
CH18
Zoom
0--255
zoom
CH19
Color cross fade
0--255
multiple color cross fade
CH20
Function
0--255
CH21
Reset
0--250
No function
251--255
Wait 5 seconds to auto reset
21 CH Mode (extender)
Channel
Features
value
Function
CH1
Red Circle
0--255
Red Circle 0- 100% dimmer, from dark to bright
CH2
Green Circle
0--255
Green Circle 0- 100% dimmer, from dark to bright
CH3
Blue Circle
0--255
Blue Circle 0- 100% dimmer, from dark to bright
CH4
White Circle
0--255
White Circle 0- 100% dimmer, from dark to bright
CH5
Red Centre
0--255
Red Centre 0- 100% dimmer, from dark to bright
CH6
Green Centre
0--255
Green Centre 0- 100% dimmer, from dark to bright
CH7
Blue Centre
0--255
Blue Centre 0- 100% dimmer, from dark to bright
CH8
White Centre
0--255
White Centre 0- 100% dimmer, from dark to bright
CH9
CTO
0--255
8500K-2800K CT linear contro
CH10
Macro color
0--255
Macro color change
CH11
Strobe
0--3
Close
4--103
Regular Strobe, Slow To Fast
104--107
Open
108--207
Pulse, Slow To Fast
208--212
Open
213--225
Random Slow Strobe
226--238
Random Middle Speed Strobe
239--251
Random Fast Strobe
252--255
Open
CH12
Dimmer
0- 100% linear dimmer
CH13
Dimmer fine
Dimmer fine
CH14
Pan
0--255
Pan movement control
CH15
Pan Fine
0--255
Pan fine control
CH16
Tilt
0--255
Tilt movement control
CH17
Tilt Fine
0--255
Tilt fine control

8
CH18
Zoom
0--255
zoom
CH19
Color cross fade
0--255
multiple color cross fade
CH20
Function
0--255
CH21
Reset
0--250
No function
251--255
Wait 5 seconds to auto reset
29 CH Mode (extender)
Channel
Features
value
Function
CH1
Red Circle
0--255
Red Circle 0- 100% dimmer, from dark to bright
CH2
Red Circle fine
0--255
Red Circle fine
CH3
Green Circle
0--255
Green Circle 0- 100% dimmer, from dark to bright
CH4
Green Circle fine
0--255
Green Circle fine
CH5
Blue Circle
0--255
Blue Circle 0- 100% dimmer, from dark to bright
CH6
Blue Circle fine
0--255
Blue Circle fine
CH7
White Circle
0--255
White Circle 0- 100% dimmer, from dark to bright
CH8
White Circle fine
0--255
White Circle fine
CH9
Red Centre
0--255
Red Centre 0- 100% dimmer, from dark to bright
CH10
Red Centre fine
0--255
Red Centre fine
CH11
Green Centre
0--255
Green Centre 0- 100% dimmer, from dark to bright
CH12
Green Centre fine
0--255
Green Centre fine
CH13
Blue Centre
0--255
Blue Centre 0- 100% dimmer, from dark to bright
CH14
Blue Centre fine
0--255
Blue Centre fine
CH15
White Centre
0--255
White Centre 0- 100% dimmer, from dark to bright
CH16
White Centre fine
0--255
White Centre fine
CH17
CTO
0--255
8500K-2800K CT linear contro
CH18
Macro color
0--255
Macro color change
CH19
Strobe
0--3
Close
4--103
Regular Strobe, Slow To Fast
104--107
Open
108--207
Pulse, Slow To Fast
208--212
Open
213--225
Random Slow Strobe
226--238
Random Middle Speed Strobe
239--251
Random Fast Strobe
252--255
Open
CH20
Dimmer
0- 100% linear dimmer
CH21
Dimmer fine
Dimmer fine
CH22
Pan
0--255
Pan movement control
CH23
Pan Fine
0--255
Pan fine control
CH24
Tilt
0--255
Tilt movement control
CH25
Tilt Fine
0--255
Tilt fine control
CH26
Zoom
0--255
zoom
CH27
Color cross fade
0--255
multiple color cross fade
CH28
Function
0--255
CH29
Reset
0--250
No function
251--255
Wait 5 seconds to auto reset

9
5.Dimension

10
6.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
7.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
