VENETA Cordloop Instruction sheet

Required Tools measuring
tape
drill with
2mm bit
phillips bit or
screwdriver
pencil knife
How to install your
#65101-40156
Cordloop
(Roller Blinds with No top treatment) Difficulty:
19mm Round Head
Screw
Blind Bracket
(on Clutch end
for Inside Mount)
Blind Bracket
(on End Plug end
for Inside Mount)
Blind Bracket
Cover
Traditional Hold
Down Bracket
(Optional)
Included Hardware
The hardware can be found in
the small hardware box included
with your blind.
1Blind Bracket Installation
①
②
③
Installing inside the window frame…
When installing the blind bracket, the distance from the bracket’s front mounting hole to the
front edge of the window frame should be at least 19mm.
Make sure both blind brackets line up with each other horizontally.
First fit the blind bracket cover over the blind bracket, and then screw brackets into wall.
Each blind bracket will require two 32mm round head screws for the installation.
①
②
③
④
Installing outside the window frame…
Blind Brackets Installation Tips…
When installing the blind bracket, the distance from the bracket’s front mounting hole to the
front edge of the window frame should be at least 19mm.
Make sure both blind brackets line up with each other horizontally.
Each blind bracket will require two 32mm round head screws for the installation.
Fit the blind bracket cover over the blind bracket.
①
②
The top & bottom of left & right blind brackets should be at the same horizontal line.
The front & back of left & right blind brackets should be at the same horizontal line.
32mm Round
Head Screw
(for Blind Bracket)
1
④
≥19mm
≥19mm

①
Installation of the Blind…
First, insert the clutch end into the tongue of clutch
bracket.
②Second, press the end plug and insert the end plug
end into the hole of bracket of the other side.
③
①
②
③
2Blind Installation and Removal
Installation
continued…
Blind Installation Tips…
After blind is installed into blind brackets, use a level to check if
the fabrics roll is horizontal; if not, please adjust the position of
blind brackets to keep the fabrics roll level.
3Install Safety Tension Device
Use two 19mm round head screws to install the safety device.
The chain should be fully extended upon installation of the device.
The blind needs to be level.
The gap on end plug end needs
to be about 4.5mm.
4.5mm
How to install your
#65101-40156
Cordloop
(Roller Blinds with No top treatment) Difficulty:
2
①
②
The lock pin in the blind bracket
must be slide downward into the
end plug to prevent the blind
from falling.
Align clutch end
of the blind with
the tongue of the
clutch bracket.
① ② ③
Removal of the Blind…
Use a tool to push the lock pin on end plug bracket upward.
Use tool to draw back the end plug from bracket.
Finally remove blind from mounting bracket.
To avoid creating a possible
strangulation hazard for children,
the corded or chained internal
window covering must be installed
in such a way that a loose cord or
chain cannot form a loop 220 mm
or longer at a height of less than
1600 mm above floor level.
A cord/chain guide may be
installed lower than 1600mm
above floor level if the
cord/chain is sufficiently
secured or tensioned to
prevent a loop 220 mm or
longer from being formed.
If a cord/chain guide is
installed lower than 1600 mm
above floor level, it must be
designed to prevent a child
from being able to remove the
cord/chain.
If a cleat is used to secure the
cord, it must be at least 1600 mm
above floor level because a
child is capable of unwinding a
cord from a cleat.
www.venetablinds.com.au/child-safety
WARNING
ALL WINDOW COVERINGS
WITH CORD OR CHAIN
Finally slide the lock pin in the blind bracket downward into the end plug to prevent the
blind from falling.

Great Job… Enjoy your new Veneta Blinds!
Installation
continued…
4Hold Down Brackets Installation (optional)
Use 19mm round head screw to secure each bracket.
5Blinds Operation
To raise the blind,
pull downward on
the side of the
bead chain that is
furthest away from
the blind fabric.
To “release” the
bead chain or
lower the blind,
pull downward
on the side of
the bead chain
that is closest to
the blind fabric.
Cordloop…
1Dusting
Dust can be removed using a feather duster or vacuum with brush attachment on low suction.
2Spot Cleaning
Use a warm damp cloth or a mild detergent for tougher stains.
Dab the affected area, but do not rub the fabric. Finish with just a warm damp cloth.
Allow the fabric to dry in the lowered position.
Need HELP?
Call our
Customer Service team
for assistance
1300 836 382
Maintaining your
Blind
How to install, operate and maintain your
#65101-40156
Cordloop
(Roller Blinds with No top treatment) Difficulty:
3
Please write a review on our
website at…
www.venetablinds.com.au
Feedback?
We would love to know how you
went with your installation…
