Victory 4x4 V4R-PET Configuration guide

5TH GEN 4RUNNER
PET DIVIDER
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-459-8447!
INSTALL INSTRUCTIONS
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.

INCLUDED HARDWARE
1/4”-20
Serr. Flange Nut
22x
1/4”-20 3/4”
Button Head
22x

INCLUDED PARTS
2x
1x
2x

1. Start by connecting the provided bracket to the molle panel, as shown and
oriented below. Using (2) of the provided 1/4”-20 button heads and flange
nuts to secure. Repeat this process for the other side.
INSTALLATION
2. Next, assemble your (3) provided panel pieces together, as shown and
oriented below. You will need to use (12) provided 1/4”-20 button heads
and flange nuts to secure.

INSTALLATION
3. Once your (3) panel pieces are assembled and hardware tight, secure the
pet divider to the brackets on molle panel with (3) provided 1/4”-20 button
heads and flange nuts. Secure as shown in the orientation below on each
side.
