Victory 4x4 UNDER SEAT MOLLE Configuration guide

TOYOTA TUNDRA 2022+
UNDER SEAT MOLLE
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-459-8447!
INSTALL INSTRUCTIONS
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.

INCLUDED HARDWARE
4x
4x
1/4”-20 Button
Head
3/4” OD - 1-1/4” Long
3/8” Screw Size
Aluminium Spacer
4x
4x
5/16”-18 Serr
Flange Nut
5/16”-18 Thread
2” Long Stainless
Steel Button Head

INCLUDED PARTS
1x
1x

1. Start by folding your back seat up and remove any floor mats that you may
have in the way in the back seat.
INSTALLATION
2. Once the seats and floor mats are out of the way, you’re going to want to
remove the (6) factory clips that hold the front plastic cover of the under
seat together. To do so, press down on the center until they pop and then
use a pry tool or a flat head screw driver and pull stright up to remove
them.

3. With the clips removed, you can now pop out the plastic piece by pulling
straight out. There will be (2) clips still holding it down that you won’t be
able to see, so you’re going to have to use a good amount of force.
INSTALLATION
4. Take the samller provided bracket and line up the (6) mounting holes on
the top flange up with the holes where the clips use to be on the plastic
and re-use the factory clips to secure the new bracket. Make sure to reset
the clips before re-using them, to do so hold the top and push up on the
bottom to pop the center cap back out, as shown below. Pull out on the
center cap to extend it fully once it has popped up. Then simply push down
on the center of the clip to to secure it once in the hole.

5. With the bracket now in place and secure with the clips, you will need to
remove the plastic cover for the fuse and relay on the passenger side, and
the battery cover on the driver side. You can do so by using a plastic pry
tool or a flat screw driver.
INSTALLATION

6. Take the supplied molle panel and (4) of the supplied 5/16”-2” long button
heads and nuts and (4) of the aluminum spacers and assemble them loose
for now in the orientation shown below. Be sure to line the bolts up with
the factory holes and make sure the nuts are behind the seat plastic. With
the panels now removed from the previous step, you can now reach inside
the seat to thread the nut onto the back of the bolts, as shown below.
INSTALLATION

7. Now that the molle panel is in place, take (4) of the supplied 1/4” button
heads and thread them into the pre-existing nut holes on the mounting
bracket through the slots on the molle panel, as shown below. Once you
have all (4) bolts started you can tighten them down with 5/32” hex.
INSTALLATION
7. Go back and fully tighten the (4) longer 2” bolts with the spacers using
a 3/16” hex. Now that you have all your hardware tight, reinstall the (2)
plastic covers for the battery and fuse and relay box. Also reinstall any floor
mats you may have had and flip the seats back down to complete your
install.
