Victory 4x4 UNI-UPRS Configuration guide

5TH GEN 4RUNNER
UPPER SHELF......................................2
GX 460
UPPER SHELF......................................8
TABLE OF CONTENTS

5TH GEN 4RUNNER
UPPER SHELF
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-459-8447!
INSTALL INSTRUCTIONS
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.

INCLUDED HARDWARE
13x
1/4”-20 X 3/4”
Button Head
13x 1/4”-20
Serr. Flange Nut
1/4”
Washer
13x

INCLUDED PARTS
1x 1x
2x

1Start by installing the mounts onto the Rear Window MOLLE Panels. Do
this using three 1/4”-20 X 3/4” button head bolts and three 1/4”-20 serr.
flange nuts per mount. Mount them to the top row of holes on the panels,
using all holes except for the one closest to the hatch of the vehicle.
INSTALLATION

INSTALLATION
2Next, attach the front panel to the basket using three 1/4”-20 X 3/4”
button head bolts, 1/4” washers and 1/4”-20 serr. flange nuts.

INSTALLATION
3Finally, raise the basket up between the two mounts and attach them
together using two 1/4”-20 X 3/4” button head bolts, 1/4” washers and
1/4”-20 serr. flange nuts per side.

GX 460
UPPER SHELF
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-459-8447!
INSTALL INSTRUCTIONS
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.

INCLUDED HARDWARE
7x
1/4”-20 X 3/4”
Button Head
7x 1/4”-20
Serr. Flange Nut
1/4”
Washer
7x 4x
35 mm M6
Button Head

INCLUDED PARTS
1x 1x
2x

1Start by installing the mounts onto the handles on the ceiling of the
cargo area. To do so you will need to first take them o. To do this, find
the seams on either side of each handle and pop the outer covers o. It
may be helpful to use something like a plastic pry tool but can be done by
hand. Then simply take out the factory bolts. Then, pop the handles into
the square cutouts in the mounting brackets and reinstall them using the
provided 35 mm M6 button head bolts.
INSTALLATION

INSTALLATION
2Next, attach the front panel to the basket using three 1/4”-20 X 3/4”
button head bolts, 1/4” washers and 1/4”-20 serr. flange nuts.

INSTALLATION
3Finally, set the basket on the lip of the two mounts and attach them
together using two 1/4”-20 X 3/4” button head bolts, 1/4” washers and
1/4”-20 serr. flange nuts per side.
