Victory 4x4 OFF-GRID DRAWER SYSTEM User manual

OFF-GRID DRAWER
SYSTEM
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-459-8447!
INSTALLATION INSTRUCTIONS
Please read the mounting instructions below carefully before attempting to install.
Check out the install video on the product page for more detailed information.

INCLUDED HARDWARE
16x
46x
16x
1/4” ID Black
Washer
1/4"-20
Serr. Flange Nut
1/4"-20 X 1/2"
Button Head
30x 1/4"-20 X 3/8"
Button Head
34x
1/4" Flat
Nuts
1x Loctite Packet

INCLUDED PARTS
1x
1x
1x
1x
1x
1x
1x 1x
2x
1L/1R
1L/1R

Start by taking the (2) provided slides and bolt one to each side of the
inside of the slide assembly with the red handles pointing out, as shown in
the orientation below. Making sure to use (4) each per side of the provided
shorter 1/4” button heads, washers and flat nuts and apply the provided
blue loctitie to the bolts before tightening. You will need to extend the
slide to access some of the mounting holes on the inside.
ASSEMBLY
1.

ASSEMBLY
2. Next, take the back piece of the cabinet assembly with the “X” cutout
and bolt that piece to the main U shaped slide piece using (6) each of the
provided longer 1/4” button heads, washers and flange nuts as shown in
the orientation below.

ASSEMBLY
4. Once you have all of that assembled, you can now bolt the cabinet
assembly to your floor through the (4) bottom mounting holes on
each side using the provided 1/4” button heads, washers to secure into
nutstrips. For more details on our vehicle specific floor systems, be sure to
check out our product page on our website and watch our install video.
3. Next, mount the (2) provided L shaped brackets in the upper inside corners
of the slide assembly with the provided 1/4” button heads, washers and
flange nuts as shown in the orientation below. Make sure to do this on
each side.

ASSEMBLY
5. You are now ready to assemble the drawer, start with the flat rectangle
piece and mount it to the back side of “U” shaped drawer. Look for the
arrow pointing forward to identify which direction the drawer should be
facing. Then tighten the piece into place with the provided 1/4” button
heads, washers and flange nuts, as shown in the orientation below.

ASSEMBLY
6. Once the back piece to the drawer is attatched, you can now slide in the
provided divider piece from the top into whichever slot in the drawer to
your liking, as shown below.

ASSEMBLY
7. You can now start to fasten the front drawer piece onto the drawer
assembly. To do so use (2) of the provided 1/4” button heads, washers
and flange nuts, as shown below. Edge trim will be provided to be cut and
trimmed to nest inside the cutouts of this panel.

ASSEMBLY
8. With the front piece in place, you now need to attatch the drawer
assembly to your slide system using (4) of the provided shorter 1/4” button
heads, washers and flat nuts per side, as shown in the orientation below.
Be sure that the button heads are installed from the inside of the drawer
facing out. You will need to adjust the length of the slide to access some of
the bolt holes.

ASSEMBLY
9. With your drawer attached to your slides, you can now assemble the
handle system around the red latches on the slides. To do so, use (4) of the
provided button heads and secure them through the “PRESS” bracket into
the pem nut bracket and sandwhich them around the red grab handles so
they are grabbing them, as shown in the orientation below.

ASSEMBLY
10. The final step is to secure the handle cover bracket to the front of the
drawer to complete your install. Take (4) of the provided 1/4” button heads,
washers and flange nuts and use them to secure the bracket to the panel,
as shown in the orientation below. *If you’ve purchased our label kit, you
will install them here befre securing the handle cover.

ASSEMBLY
11. You are now finished with the install, enjoy your new drawer system! For
placement and specific instruction of your new drawer, refer to your vehicle
floor product page on our website for more detail.
This installation guide shows how to assemble one O-Grid Drawer
assembly, but the possibilities are endless! Check out the product page for
inspiration on how to maximize your space by using a combination of O-
Grid Drawers and our O-Grid Fridge Slide!
