Victory 4x4 200 Series Configuration guide

200 SERIES & LX 570
MONITOR DELETE PANEL
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-459-8447!
INSTALL INSTRUCTIONS
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.

INCLUDED HARDWARE
4x
1/4”-20 x 3/4” Long
Stainless Steel Button
Head Screws

INCLUDED PARTS
2x
2x

1. Start by removing the plastic cover panel behind the monitor, use a plastic
pry tool or a flat head screw driver to pop the small bottom piece o, as
shown below.
INSTALLATION
2. Once the plastic piece is popped o, you need to disconnect the (2) wire
harnesses that are now exposed. Both should just be thumb tabs that you
pinch to pop o. See below for the harness locations.

3. Now that you have disonnected the wiring, you will need a 10mm socket
to remove the (3) factory nuts holding the monitor in place. Be sure to
support the monitor when removing the last nut as it is going to want to
fall. Once the nuts are removed, you can then pull straight back.
INSTALLATION
4. Take the provided mounting bracket and slide it on to the (3) mounting
studs with the flange pointed up, making sure the bracket is behind the
wiring. Once the bracket it in place, take the (3) factory nuts and tighten
them down with a 10mm socket, make sure to reinstall the factory
ground to the middle stud. Once the bracket is in place, make sure the (2)
connectors are out of the way with one on each side of the middle flange,
as shown below.

INSTALLATION
5. Once the bracket is secure and the wires are out of the way, take the
provided button head bolts and use them to secure the face bracket to the
mounting bracket, as shown in the orientation below, to complete your
install. Repeat this same process for the opposite side.
