Westomatic SIGMA Guide

Part Number: 350101 Issue: 1
PARTS & ELECTRICAL
SCHEMATICS MANUAL

Part Number: 350101 Issue: 1
Page 2 of 75
Published by:
Westomatic Vending Services Ltd.
Shaldon Road
Newton Abbot
Devon
TQ12 4TZ
United Kingdom
www.westomatic.com
Switchboard: [phone]
Sales FAX: [phone]
Part Sales FAX: [phone]
Westomatic Vending Services Ltd. reserves the right to change the product specifications at any
time. While every effort has been mode to ensure that the information in this publication is
accurate, Westomatic Vending Services Ltd disclaims any liability for any direct or indirect losses
howsoever caused arising out of use or reliance on this information.
Information contain herein is correct at time of print:
Revision list:
This manual Draft Issue June 2010
This manual 1st Issue August 2010

Part Number: 350101 Issue: 1
Page 3 of 75
TABLE OF CONTENTS
1. SIGMA DOCUMENTATION AVAILABLE.....................................................................5
1. WIRING DIAGRAMS....................................................................................................6
1.1. DC WIRING..................................................................................................................6
1.2. AC WIRING..................................................................................................................7
2. PROCESSOR BOARD INFORMATION.......................................................................8
3. DIGITAL INPUTS & OUTPUTS....................................................................................9
4. SIGMA ASSEMBLY DRAWINGS...............................................................................13
4.1. SIGMA - CABINET ASSEMBLY 201753....................................................................13
4.2. SIGMA BOILER ASSEMBLY 201595 ........................................................................15
4.3. SIGMA COMMON WHIPPER DECK ASSEMBLY 201791.........................................17
4.4. SIGMA MOVING DISPENSE HEAD ASSY 201723....................................................18
4.5. MDH MECH UNIT ASSY SIGMA V2 201830..............................................................19
4.6. EXTRACTION FAN ASSY SIGMA 201725.................................................................21
4.7. FUSE AND DISTRIBUTION BOX SIGMA 201728......................................................22
4.8. SIGMA INLET VALVE ASSEMBLY 201790..............................................................23
4.9. WHIPPER DECK ASSEMBLY ALL INSTANT S 201738 ...........................................24
4.10. WHIPPER DECK ASSEMBLY 2 BREWER L1 201735..............................................26
4.11. WHIPPER ASSEMBLY ..............................................................................................29
4.12. BTC BREWER SIGMA 201775 ..................................................................................30
4.13. FBT BREWER SIGMA 201777................................................................................... 32
4.14. SIGMA FBC BREWER 201776 ..................................................................................34
4.15. SIGMA FBC BREWER DOUBLE BREW 201727.......................................................35
4.16. MULTIBREWER PLATFORM ASSEMBLY 201527 ...................................................36
4.17. MULTIBREWER PINCHER ASSEMBLY 201528.......................................................37
4.18. MULTI BREWER DRIVE ASSEMBLY 201526........................................................... 38
4.19. SIGMA INSTANT MODULE 201726...........................................................................40
4.20. SIGMA HOT ONLY KIT 912401 ................................................................................. 42
4.21. SIGMA HOT AND COLD KIT 2912402.......................................................................44
4.22. SIGMA HOT COLD CARB KIT 2912403....................................................................46
4.23. MODEL OPTIONS (INSTANT ONLY, CHILLER, CARBONATOR, ETC)...................48
4.24. SIGMA DOOR ASSY 201752.....................................................................................49

Part Number: 350101 Issue: 1
Page 4 of 75
4.25. SIGMA MULTI CHOICE MENU PANEL 201714.........................................................52
4.26. SIGMA FINISHING KIT INSTANT 201792..................................................................54
4.27. SIGMA FINISHING KIT BREWER 201780................................................................. 54
4.28. SIGMA DIRECT CHOICE MENU PANEL ASSEMBLY 201713.................................. 55
4.29. SIGMA FINISHING KIT DC INSTANT 201659 ........................................................... 57
4.30. SIGMA FINISHING KIT DC BREWER 201798...........................................................57
4.31. SIGMA FREE VEND KIT 201762 ...............................................................................58
4.32. SIGMA CASHLESS AREA OPTIONS........................................................................58
4.33. LID DISPENSE KIT 201794.......................................................................................59
4.34. SIGMA NV9 USB BILL ACCEPTOR KIT 201832.......................................................60
4.35. SIGMA COIN HANDLING ASSY 201757 ...................................................................61
4.36. SIGMA CASHLESS BLANKING KIT 201793............................................................. 63
4.37. SIGMA CASH BLANKING KIT 201786......................................................................64
4.38. SIGMA CUP DROPPER 70MM KIT 201763............................................................... 65
4.39. SIGMA CUP DROPPER KIT 73MM 201764...............................................................67
4.40. SIGMA CUP DROPPER 80MM KIT 201766............................................................... 69
4.41. REGION/LANGUAGE KITS .......................................................................................70
4.42. SIGMA CUNO KIT 201772......................................................................................... 71
4.43. PURITY C 150 HEAD & 1 CARTRIDGE 201814........................................................73
4.44. SIGMA LED SERVICE LIGHT KIT 201795.................................................................74
4.45. OPTIONAL ADD-ONS................................................................................................ 75

Part Number: 350101 Issue: 1
Page 5 of 75
1. Sigma Documentation Available
The following technical documentation is available for the Sigma vending machine.
Part number 350100 - Sigma Technical Manual
Part number 350101 - This Manual
Part number 350103 - Installation/Operator Guide
350104 - Installation/Operator Guide (GERMAN)

Part Number: 350101 Issue: 1
Page 6 of 75
1. Wiring Diagrams
1.1. DC Wiring

Part Number: 350101 Issue: 1
Page 7 of 75
1.2. AC Wiring

Part Number: 350101 Issue: 1
Page 8 of 75
2. Processor Board Information

Part Number: 350101 Issue: 1
Page 9 of 75
3. Digital Inputs & Outputs
NOTE: Water valves, ingredient & whipper motors are number from left to right looking at the
front of the machine.
A A – J1 – LCD (LCD)
Connector Function Wire Colour Type Destination
A1 Display 5v Red 7/0.2mm LCD – 1
A2 D3 Blue 7/0.2mm LCD – 5
A3 D2 Green 7/0.2mm LCD – 4
A4 D1 Yellow 7/0.2mm LCD – 3
A5 D0 White 7/0.2mm LCD – 2
A6 LE Brown 7/0.2mm LCD – 6
A7 R-S Violet 7/0.2mm LCD – 7
A8 0V Black 7/0.2mm LCD – 8
C C – J3 – Inputs 1-8
Connector Function Wire Colour Type Destination
C1 0v – Flush Buttons Black C1 7/0.2mm FLUSH – 4
C2 0v – Free vend by key Black C2 7/0.2mm KEY – 1 ,COLD – 1
C3 IN[01] - Door Switch White C3 7/0.2mm C21
C4 IN[02] – Cold Water Flush White C4 7/0.2mm FLUSH – 3
C5 IN[03] – Syrup Flush White C5 7/0.2mm FLUSH – 2
C6 IN[04] - Free vend key switch White C6 7/0.2mm KEY – 2
C7 IN[05] – Hot Water Flush White C7 7/0.2mm FLUSH – 1
C8 IN[06] - Multi Brewer Home 1 White C8 7/0.2mm BAY 1 - 7
C9 IN[07] - Multi Brewer Home 2 White C9 7/0.2mm BAY 2 - 7
C10 IN[08] - Cup sold out White C10 7/0.2mm TUR - 8
D D – J4 – Inputs 9-16
Connector Function Wire Colour Type Destination
D1 0v Black D1 7/0.2mm C22
D2 IN[09] – Cup peeler home White D2 7/0.2mm TUR – 12
D3 IN[10] – Spare - -
D4 IN[11] – Spare - -
D5 IN[12] – MDH Home White D5 7/0.2mm MDH – 2
D6 IN[13] – MDH Dispense White D6 7/0.2mm MDH – 1
D7 IN[14] - Spare - - -
D8 IN[15] – Spare - - -
D9 IN[16] – Spare - - -
E E – J5 – Inputs 17-24
Connector Function Wire Colour Type Destination
E1 12v cup sensor Red E1 7/0.2mm SEN – 1, And link to
SEN – 2
E2 0v cup sensor Black E2 7/0.2mm SEN – 4
E3 IN[17] – Spare - - -
E4 IN[18] – Spare - - -
E5 IN[19] – Cold Shot White E5 7/0.2mm COLD – 3
E6 IN[20] - Cup sensor 1 White E6 7/0.2mm SEN – 3
E7 IN[21] - Cup sensor 2 - - -
E8 IN[22] – FB/BTC Waste 1 - - -
E9 IN[23] - FB/BTC Waste 2 - - -
E10 IN[24] - - - -

Part Number: 350101 Issue: 1
Page 10 of 75
XXX - Wires ( White F2 ) and ( Black F3 ) are Twisted Pairs throughout machine.
F F – CAN BUS
Connector Function Wire Colour Type Destination
F1 Can 0v White F1 7/0.2mm PAD-3
DGB-9
GPRS- 4
F2 Can Lo White F2 7/0.2mm XXX PAD-4
DGB-10
GPRS- 6
F3 Can Hi Black F3 7/0.2mm XXX PAD-5
DGB-11
GPRS- 5
F4 Can 12v White F4 7/0.2mm PAD-6
DGB-12
G G – J7 – Waste tray (WST)
Connector Function Wire Colour Type Destination
G1 Waste tray full White G1 7/0.2mm C43
G2 0v White G2 7/0.2mm C44
H H – J8 – Boiler Probes
Connector Function Wire Colour Type Destination
H1 Boiler Probe Common White H1 7/0.2mm T-PROBE – 1
H2 Overflow Probe White H2 7/0.2mm T-PROBE – 2
H3 Under fill Probe White H3 7/0.2mm T-PROBE – 3
H4 Full Probe White H4 7/0.2mm T-PROBE – 4
H5 NTC Thermocouple White H5 7/0.2mm T-PROBE – 5
H6 NTC Thermocouple White H6 7/0.2mm T-PROBE – 6
I I – J9 – Boiler Interface Board (BIB)
Connector Function Wire Colour Type Destination
I1 Boiler Heat White I1 7/0.2mm FD1-5
I2 Boiler Monitor White I2 7/0.2mm FD1-1
I3 24v - - -
I4 0v - - -
L L – J12 – MDB (MDB)
L - 4 core Screened 7/0.2mm 1A cable, Black sheath PVC insulated Typically RS 482-5459
Wire from L to MDB1 & MDB3 , Braided wire link non screened from MDB2 to MDB3
Connector Function Wire Colour Type Destination
L1 24v Red 7/0.2mm MDB1 – 1
MDB2 – 1
MDB3 – 1
L2 0v Green 7/0.2mm MDB1 – 2
MDB2 – 2
MDB3 – 2
L3 MDB Rx Yellow 7/0.2mm MDB1 – 4
MDB2 – 4
MDB3 – 4
L4 MDB Tx Blue 7/0.2mm MDB1 – 5
MDB2 – 5
MDB3 – 5
L5 0v Screen Screen MDB1 – 6
MDB2 – 6
MDB3 – 6

Part Number: 350101 Issue: 1
Page 11 of 75
N N – J16 – Outputs 23-32
Connector Function Wire Colour Type Destination
N1 Brew 2 Air pump White N1 7/0.2mm BAY 2 – 5
N2 Brew 1 Air pump White N2 7/0.2mm BAY 1 – 5
N3 Brewer 1 pinch valve White N3 7/0.2mm BAY 1 – 3
N4 Brewer 2 pinch valve White N4 7/0.2mm BAY 2 – 3
N5 MDH Motor White N5 7/0.2mm MDH - 6
N6 Cup Transfer motor White N6 7/0.2mm TUR - 13
N7 Cup Peeler motor White N7 7/0.2mm TUR – 15
N8 Whipper motor 6 White N8 7/0.2mm BAY 1 – 2
N9 Whipper motor 5 White N9 7/0.2mm WHIP-5
N10 Whipper motor 4 White N10 7/0.2mm WHIP-4
PTFE Cable Type A 19/0.2mm changed to 7/0.2mm PVC
O O – J17 – Outputs 11-22
Connector Function Wire Colour Type Destination
O1 Whipper 3 White O1 7/0.2mm WHIP-3
O2 Whipper 2 White O2 7/0.2mm WHIP-2
O3 Whipper 1 White O3 7/0.2mm WHIP-1
O4 Ingredient motor 7 White O4 7/0.2mm BAY 2 – 4
O5 Ingredient motor 6 White O5 7/0.2mm BAY 1 – 4
O6 Ingredient motor 5 White O6 7/0.2mm WHIP-11
O7 Ingredient motor 4 White O7 7/0.2mm WHIP-10
O8 Ingredient motor 3 White O8 7/0.2mm WHIP-09
O9 Ingredient motor 2 White O9 7/0.2mm WHIP-08
O10 Ingredient motor 1 White O10 7/0.2mm WHIP-07
O11 Water Station 7 White O11 7/0.2mm VALVE-7
O12 Water Station 6 White O12 7/0.2mm VALVE-6
P P – J18 – Outputs 1-10
Connector Function Wire Colour Type Destination
P1 Water Station 5 White P1 7/0.2mm VALVE-5
P2 Water Station 4 White P2 7/0.2mm VALVE-4
P3 Water Station 3 White P3 7/0.2mm VALVE-3
P4 Water Station 2 White P4 7/0.2mm VALVE-2
P5 Water Station 1 White P5 7/0.2mm VALVE-1
P6 Brewer 2 Air Pinch White P6 7/0.2mm BAY 2 – 6
P7 Brewer 1 Air Pinch White P7 7/0.2mm BAY 1 – 6
P8 Cold water inlet White P8 7/0.2mm C41
P9 Hot water inlet White P9 7/0.2mm C39
P10 Master water inlet White P10 7/0.2mm C37 , C35
Q Q – J-- – Outputs 41-48
Connector Function Wire Colour Type Destination
Q1 Spare - - -
Q2 Spare - - -
Q3 Spare - - -
Q4 Spare - - -
Q5 Spare - - -
Q6 Spare - - -
Q7 Internal LED light White Q7 7/0.2mm LED5 - 2
Q8 Triple Brew : ingredient 8 White Q8 7/0.2mm TB - 1
R Q – J-- – Outputs 41-48
Connector Function Wire Colour Type Destination
R1 Carbonated Water White R1 7/0.2mm DGB – 6
R2 Still Water White R2 7/0.2mm DGB - 5
R3 Syrup 3 White R3 7/0.2mm DGB - 8
R4 Syrup 2 White R4 7/0.2mm DGB - 4
R5 Syrup 1 White R5 7/0.2mm DGB - 3
R6 UV Lamp White R6 7/0.2mm FD2 - 8
R7 Whipper motor 7 White R7 7/0.2mm BAY2 - 2
R8 Water Station 8 White R8 7/0.2mm VALVE-8
PTFE Cable Type A 19/0.2mm ( 11A ). Single PVC 7/0.2mm ( 1.4A ). Single PVC 16/0.2mm ( 3A ). Single PVC 30/0.25mm (
21A ). Single PVC 24/0.2mm ( 4.5A ).

Part Number: 350101 Issue: 1
Page 12 of 75
Connectors in ( Brackets ) can be daisy chained if required.
FD1 FD1 – Fuse and Distribution Board
Connector Function Wire Colour Type Destination
FD1 -1 Boiler Monitor White I2 7/0.2mm I2
FD1 -2 CPU Switched 24v Red FD1-2 16/0.2mm C46
FD1 -3 Bay 2 24v Red PTFE
FD1-3 19/0.2mm BAY 2 – 1
FD1 -4 Bay 1 and Bay 2 0v Black FD1-4 7/0.2mm BAY 1 – 8
BAY 2 – 8
FD1 -5 Boiler Drive White I1 7/0.2mm I1
FD1 -6 Cup Dropper 24v Red FD1-6 16/0.2mm TUR – 14
FD1 -7 Cup Dropper 0v Black FD1-7 16/0.2mm TUR – 11
TUR – 01
FD1 -8 Water inlet and MDH 24v Red FD1-8 16/0.2mm MDH – 5
C42 , ( C40 , C38 ,
C36 )
FD1 -9 Bay 1 24v Red PTFE
FD1-9 19/0.2mm BAY 1 – 1 TB – 2
Connectors in ( Brackets ) can be daisy chained if required.
FD2 FD2 – Fuse and Distribution Board
Connector Function Wire Colour Type Destination
FD2 –1 Led Lighting 0v Black FD2-1 16/0.2mm PAD – 2
GPRS - 2
( LED1 – 2
LED2 – 2 )
( LED3 – 2
LED4 – 2 )
FD2 –2 Chiller 24v Red FD2 – 2 16/0.2mm DGB – 2
FD2 –3 Led Lighting 24v Red FD2 – 3 16/0.2mm PAD – 1
( LED1 – 1
LED2 – 1 )
( LED3 – 1
LED4 – 1
LED5 -1 )
FD2 –4 Chiller 0v Black FD2 – 4 16/0.2mm DGB – 7
FD2 –5 Not Connected - - -
FD2 –6 Ingredient Motor 24v Red FD2 – 6 16/0.2mm WHIP - 12
FD2 –7 MDH 0v Black FD2 – 7 16/0.2mm MDH – 3
FD2 –8 UV Tube Drive - - -
FD2 –9 Water Valves 24v Red FD2 – 9 16/0.2mm VALVE - 10
FD2 -10 CPU 0v Black FD2 – 10 1.5mm2C47 , C48
FD2 –11 CPU 24v Red FD2 – 11 16/0.2mm C45
GPRS - 1
FD2 –12 Whipper Motors 24v Red FD2 – 12 24/0.2mm WHIP – 6
Links
Connector Function Wire Colour Type Destination
TUR-7 Cup dropper switch White 7/0.2mm TUR-2
Earth Links
Connector Function Wire Colour Type Destination
FLUSH – 8 Earth Green / Yellow 1.5mm2E05
WHIP-14 Earth Green / Yellow 1.5mm2E07
E06 Earth Green / Yellow 1.5mm2E08

Part Number: 350101 Issue: 1
Page 13 of 75
4. Sigma Assembly Drawings
4.1. SIGMA - CABINET ASSEMBLY 201753

Part Number: 350101 Issue: 1
Page 14 of 75
SIGMA - CABINET ASSEMBLY 201753 (cont’)
ITEM No. QTY. PART No. DESCRIPTION
1 1 194022 SIGMA CABINET ASSEMBLY
2 1 201723 SIGMA MOVING DISPENSE HEAD ASSEMBLY
3 1 194023 SIGMA BACK PLATE
4 1 190050 PLINTH SOLO ENCORE
5 1 201725 EXTRACTION FAN ASSY SIGMA
6 1 201728 FUSE AND DISTRIBUTION BOX SIGMA
7 1 201595 PRELUDE - BOILER ASSEMBLY
8 1 190044 DOOR HINGE SOLO ENCORE
9 1 100035339 NYLON HOLE PLUG - 9.5mm
10 3 100086024 NN M6
11 1 134097 15mm BLIND GROMMET
12 0.81m 100046069 TUBING - WHITE SILICONE 4mm I.D x 2mm WALL THK (CUT
LENGTH 810mm)
13 1 100085028 SCREW - No.6 x 3/8" PAN REC SELF TAP AB
14 1 100091083 WEIGHT PRESSURE SWITCH
15 2 135913 BUNG 50 x 20 mm
16 22 186093 NUT M4 SERRATED FLANGED
17 1 113166 SWITCH PRESSURE 65/18
18 3 134106 MUSHROOM BUMPER
19 1 100034090 BUSH - STRAIN RELIEF RDD LOCKIT
20 1 100034069 P CLIP - BLACK NX2A
21 4 100095021 FOOT-ADJUSTABLE 70MM
22 1 194135 WASTE BIN PLATFORM
23 1 190055 BRACKET CENTRE WASTE ENCORE
24 1 201791 SIGMA COMMON WHIPPER DECK ASSEMBLY
25 1 188118 CLIP SPRING 1.5"
26 2 100085004 SCREW - M4 x 10mm REC PAN
27 3 100085122 SCREW - M4 x 10mm PAN REC ST - STEEL
28 1 201790 SIGMA INLET VALVE ASSEMBLY
29 1 100034049 P CLIP - BLACK NX4
30 2 100034005 P CLIP - BLACK NX8
31 4 100087007 WASHER - M5 INTERNAL SHAKE STEEL
32 1 100085132 Hex Head Set Screw M5 x 25 BRASS
33 3 100086034 Hex Nut Plain M5 BRASS
34 1 246512 SIGMA DC LOOM (NOT SHOWN)
35 1 246506 SIGMA FD3 AC LOOM (NOT SHOWN)
36 1 246511 SIGMA BOILER VALVES LOOM (NOT SHOWN)
37 1.04m 100046015 TUBING-VACUFLEX 1.5 inch BLACK (CUT LENGTH 1.04m)
38 2 148050 TEE PIECE 38MM
39 1 194075 SIGMA BOILER INSULATION - FRONT
40 1 100036243 LABEL-EARTH WARNING (NOT SHOWN)
41 1 100038190 LABEL - CE MARK (NOT SHOWN)
N.B. 111201 - CABLE - MAINS 13A PLUG ANGLED 16A (for UK use only).

Part Number: 350101 Issue: 1
Page 15 of 75
4.2. SIGMA BOILER ASSEMBLY 201595

Part Number: 350101 Issue: 1
Page 16 of 75
SIGMA - BOILER ASSEMBLY 201595 (cont’)
ITEM No. QTY. PART No. DESCRIPTION
1 1 201663 SIGMA - BOILER M/ETALWORK KIT
2 1 117231 2.2 kW BOILER ELEMENT
3 1 198550 PRELUDE BOILER LID GASKET V2
4 2 194076 SIGMA BOILER INSULATION - SIDES
5 1 119090 THERMISTOR PROBE SET
6 1 01Z190006 PROBE SET GASKET
7 6 100087002 M3 INTERNAL SHAKEPROOF
8 6 100086001 NUT - M3 HEX FULL STEEL
9 2 110200 TERMINAL ADAPTER
10 2 100086047 FULL NUT M4 BRASS
11 1 147148 DRAIN HOSE PIPE CLAMP
12 1 100046009 17mm ID SILLICONE PIPE
13 1 100046003 7.8mm ID SILLICONE PIPE
14 7 116075 VALVE 8mm BODY LOW SCALE 24VDC
15 8 147123 DELIVERY SEAL VALVE
16 1 198523 PRELUDE THERMISTOR PROBE RETAINING PLATE
17 1 198529 SPACER PLATE - TEMPERATURE LIMITER
18 1 114153 TEMPERATURE LIMITER
19 1 246511 SIGMA BOILER VALVES LOOM

Part Number: 350101 Issue: 1
Page 17 of 75
4.3. SIGMA COMMON WHIPPER DECK ASSEMBLY 201791
ITEM No. QTY. PART No. DESCRIPTION
1 1 194031 SIGMA WHIPPER DECK ASSY WELDMENT
2 8 185334 SCREW – 3.5 x 10 PLASTECH REC PAN
3 1 100087076 WASHER – M4 EXTERNAL SHAKEPROOF
4 2 186093 NUT M4 SERRATED FLANGED
5 1 100034048 P-CLIP NXP2
6 3 161440 MOTOR 90RPM 24VDC – 263.4090A
7 4 291051 44mm Pinion 101.8102T
8 1 161441 MOTOR 130RPM 24VDC – 263.4130A
9 1 246510-D SIGMA WHIPPER DECK LOOM
10 1 100036243 LABEL-EARTH WARNING

Part Number: 350101 Issue: 1
Page 18 of 75
4.4. SIGMA MOVING DISPENSE HEAD ASSY 201723
ITEM No. QTY. PART No. DESCRIPTION
1 1 194016 SIGMA MDH DRAWER
2 1 201830 MDH MECH UNIT ASSY SIGMA V2
3 4 100085004 SCREW - M4 x 10mm REC PAN
4 2 100085088 Selftap Phillips Pan Head AB No.8 x 1\2
5 1 100095053 LOCKING PIN
6 1 194122 SIGMA MDH STRAP
7 1 187099 WASHER-M6 STEEL FORM B ST STEEL
8 1 194018 SIGMA DISPENSE HEAD
9 2 100034049 P CLIP - BLACK NX4

Part Number: 350101 Issue: 1
Page 19 of 75
4.5. MDH MECH UNIT ASSY SIGMA V2 201830
ITEM No. QTY. PART No. DESCRIPTION
1 1 194109 MOTOR 24VDC - PLANETARY GEARBOX
2 1 188180 LINEAR SLIDE FINN 300 SINGLE EXTENSION
3 1 194104 SPACER - NYLON 66 - 8.2ID x 12OD x 7.5LG
4 1 100041013 BEARING 6x17x6mm BM026-B
5 1 194214 MDH DRIVE PLATE 8MM SHAFT V2
6 1 100087055 WASHER-M6 STEEL FORM B
7 1 100085205 Machine Screw Phillips Pan Head M6 x 20
8 1 194213 MDH BEARING GUIDE
9 4 185244 SCREW - M4 x 6 LG CSK POZI
10 1 194210 SIGMA MDH BRACKET V2

Part Number: 350101 Issue: 1
Page 20 of 75
11 1 194212 MDH SLIDE ARM
12 1 194215 MDH SLIDE SPIGOT
13 8 100087002 M3 INTERNAL SHAKEPROOF
14 4 100085018 Machine Screw Phillips Pan Head M3 x 10
15 1 194205 SIGMA MDH HOUSING GASKET
16 1 100085137 HB M4 x 12
17 3 100086002 NUT M4 HEX FULL STEEL
18 2 100013090 SWITCH GPL SHORT LEVER
19 4 100086001 NUT - M3 HEX FULL STEEL
20 1 100086085 Nyloc Nut M8
21 1 194211 MDH DRAWER COVER SIGMA V2
22 4 186093 NUT M4 SERRATED FLANGED
23 2 134097 15mm BLIND GROMMET
24 1 246508 SIGMA MDH MODULE LOOM
