Wren Kitchens Adjustable Corner Base Unit Assembly instructions

FITTING GUIDE
Adjustable Corner
Base Unit
HEIGHT: 34 1/2”
WIDTH: 36”-42”
DEPTH 24”-25”
For Internal Use: CON.INS.001.001_50-WKIN0006_BASE_AdjCnr_Rev5.indd
(H) x16 1 1/4” Screws (B) x30 5/8” Screws (K) x4 L Bracket - Large
Sample cabinet shown
Step 1.
Secure each leg into place with 2
x 5/8”screws (B). Ensure legs are
rotated as shown so that part is
supporting the end panel.
Step 2.
Use 2 x 5/8”screws (B) to secure each
of the L brackets (K) to the cabinet at
either side.
Step 3.
Place the longer packer ush with the
front edge of the cabinet and screw
through using 2 x 1 1/4”screws (H) to
secure it in place.
Step 4.
Place the shorter packer inside the
cabinet ush with the front edge and
screw through the top and bottom of the
cabinet using 2 x 1 1/4”screws (H) at each
location.
B
Screws for attaching to walls and worktop are not provided as these vary depending
on materials, thickness and construction. Ensure appropriate xings for wall and
worktop construction are used. Please refer to the specialist worktop supplier if
these are required for solid surface worktops.
REQUIRED TOOLS
B
B
H
H
H
K
Page 1

FITTING GUIDE
Adjustable Corner
Base Unit
HEIGHT: 34 1/2”
WIDTH: 36”-42”
DEPTH 24”-25”
For Internal Use: CON.INS.001.001_50-WKIN0006_BASE_AdjCnr_Rev5.indd
W
X
Sample cabinet shown
Step 6.
To create your corner post attach
panel (W) and panel (X) as shown.
screw through panel (W) into panel
(X) at 4 locations using
4 x 1 1/4” (H) screws.
Corner post size can be adjusted by
positioning panel (X) along panel (W).
Step 7.
Place your assembled corner post
into position then screw through
packers using 3 x 1 1/4” (H) screws
into each panel.
H
H
H
H
H
H
H
H
H
H
Page 2
Step 5.
Cut panel (X) to size according to
Kitchen Plan.
