Wren Kitchens BASE UNIT 1000 User manual

BASE UNIT
800 - 1000 Adjustable Corner Assembly Guide
For Internal Use: FI.WR.INS.023_WKIN00105_BASE_AdjCnr_800 -1000_Rev12.indd
1000
inc. 600 Door
800-1000 Magic
Corner
800-1000
inc. 400 OR 500 Door
1000 Carousel

Page 1
BASE UNIT
800 - 1000 Adjustable Corner Assembly Guide
(F) x12
Wooden
Dowel
(G) x8
Cam Dowel
(Expanding)
(H) x8
Cam Lock
(K) x18
30mm
Screw
(P) x4
45mm
Screw Black
(L) x37
15mm
Screw
(N) x1
Door Buer
(Z) x5
Shelf Peg Plastic
(M) x4
Cover Cap
Panel B
x2 End Panel
2nd Back Panel
x1
Panel E
x2 Rail
Panel C
x1 Base Panel
Panel D
x1 Muntin
Shelf
x1
Legs
x5
Frontal
(Packed separately) x1
Panel A
x1 Back Panel
REQUIRED TOOLS
NOT to be
used with
CAM DOWEL &
CAM LOCK
L Bracket LGE
x4
Hinge Mounting Plate
x4 Inc Screws
Hinge
x2 Inc Screws
Space Plug
x2
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED

Page 2
For Internal Use: FI.WR.INS.023_WKIN00105_BASE_AdjCnr_800 -1000_Rev12.indd
Step 1.
Seat dowel (F)
into holes in
both end panels (B)
as shown.
NB. All Cam Locks (H) are to be positioned facing the
outside of the unit carcase, for ease of tightening.
Do not use power tools with
cam dowel (G) or cam lock (H)
Dowel (F)
& Cam Dowel (G)
location detail
View from underside View from underside
H
H
G
G
GGG
G
G
G
G
G
FFFF
F
F
F
F
F
F
F
F
B
B
B
B
C
E
E
B B
Step 2.
Seat cam dowel (G) into
holes in both end panels (B)
as shown.
Seat (G)
cam dowel
into hole as
shown.
Step 3.
Attach panels (C) to panels (B),
using cam dowel (G) (in blue), and
also using dowels (F) (in orange)
in positions as shown.
Step 4.
Insert cam lock (H).
Do NOT tighten until Step 6.

Page 3
BASE UNIT
800 - 1000 Adjustable Corner Assembly Guide
Step 5.
Slide back panel (A) into
groove of end panels (B).
Once back panel (A) is in position, ensure
the panel is ush & square with bottom of
end panels (B).
Step 7.
Secure back panel (A) with 4 x 30mm screws (K)
equally spaced at the bottom of back panel (A) into
base panel (C), as shown.
Ensure you screw into the centre of base panel (C)
(9mm from the edge).
B
B
C
E
E
A
A
K
9mm
C
View from underside
H
H
B
Step 6.
Hand tighten all cam locks (H), this will
expand cam dowels (G) and tighten the
unit together.

Page 4
For Internal Use: FI.WR.INS.023_WKIN00105_BASE_AdjCnr_800 -1000_Rev12.indd
Step 8.
Option 2
• 1000 Unit
600 Door Option
To secure muntin panel (D) in place, measure 100mm from the
pre-drilled pilot holes directed away from the door opening.
Then re-drill pilot holes as shown and secure muntin (D), base
(C) & rail (E) using 4 x 45mm screws (P) as shown.
Please refer to Customer Specic Kitchen Plan for left or
right hand orientation.
600 Drilling For Muntin
Position diagram
100mm
C
Front
C
D
13mm
32mm
B
B
C
D
E
P
P
P
P
P
P
B
E
C
P
P
B
D
Step 8.
Option 1
• 1000 Unit
500 Door Option
• 800 Unit
400 Door Option
To secure muntin panel (D) in place, use pre-drilled
pilot holes to align muntin as shown. Secure muntin
(D), base (C) & rail (E) using 4 x 45mm screws (P) as
shown.
Please refer to Customer Specic Kitchen Plan
for left or right hand orientation.

Page 5
BASE UNIT
800 - 1000 Adjustable Corner Assembly Guide
Step 11.
Place packer (Z1) ush with the front edge of
the unit and up tight to the centre muntin. Screw
through from the unit using 2 x 30mm screws (K)
in the top and 2 x 30mm screws (K) in the bottom,
locations shown.
Please refer to Customer
Specic Kitchen Plan for left
or right hand orientation.
Step 12.
Place panel (Y) together with the remaining packer (Z2) ush as shown and screw
together using 3x 30mm screws (K) equally spaced as shown.
Please refer to Customer Specic Kitchen Plan for left or right hand orientation.
Adjustable Corner Post Pack
Panel X
x1
Panel Y
x1
Packer Z
x2
K
K
Z1
Z1 Z2
X
Y
K
K
K
K
Step 10.
To create your corner post
attach panel (X) and panel (Y)
as shown. Screw through panel
(X) into panel (Y) at 4 locations
using 4 x 30 mm (K) screws.
Corner post size can be adjusted
by positioning panel (Y) along
panel (X).
Step 9.
Cut panels (X) & (Y) to size
according to Customer
Specic Kitchen Plan.

Page 6
For Internal Use: FI.WR.INS.023_WKIN00105_BASE_AdjCnr_800 -1000_Rev12.indd
K
K
K
K
Step 15.
Secure blanking panel with 9 x 15mm screws (L),
evenly spaced, as shown. Ensure you screw 9mm from
edge of the blanking panel to ensure to screw into
the centre of the end panel, top rail and bottom fixed
shelf.
Step 14.
Corner Blanking Panel. Measure and cut blanking
panel to required width.
LL
L
L
L
L
L
L
L
9mm
Step 13.
Place panels (Y) & (X) together with packer (Z) ush as
shown and screw together using 4 x 30mm (K) screws
equally spaced as shown.
Please refer to Customer Specic Kitchen Plan for
left or right hand orientation.
XY
Z

Page 7
BASE UNIT
800 - 1000 Adjustable Corner Assembly Guide
B
B
Leg position diagram
C
FrontFront
Step 17.
Secure each of the legs into place with
4 x 15mm screws (L) per leg.
Step 16.
Position legs as shown. Ensure legs
are rotated to also provide support
to the end panels (B).
L
LL
L
C
B
C
Step 18.
Push leg rmly down into leg base.
Adjust legs to 155mm before turning unit
upright. Once in situ level accordingly.
B

Page 8
For Internal Use: FI.WR.INS.023_WKIN00105_BASE_AdjCnr_800 -1000_Rev12.indd
Corner Carousel
Please refer to separate instructions included with your carousel tray.
The middle shelf should be discarded when using the carousel tray.
Carousel

Page 9
BASE UNIT
800 - 1000 Adjustable Corner Assembly Guide
Magic Corner
Please refer to separate instructions included with your magic corner.
The middle shelf and hinges should be discarded when using the magic corner.
800-1000 Magic Corner

Page 10
For Internal Use: FI.WR.INS.023_WKIN00105_BASE_AdjCnr_800 -1000_Rev12.indd
D B
126mm
126mm
94mm
from base
from top
Attach hinge plates onto panel (D) in locations shown
using 4 x 15mm screws (L).
(Ignore this step when tting Magic Corner)
94mm
Securing to Adjacent Units
Screw into any side units using the 30mm screws (K) provided to secure to unit.
Screw just to the rear of the hinge plate at the top and bottom of both sides of the
unit, place a cover cap (M) on the heads to conceal it.
Worktop
Screw up through the front rail into your worktop to secure it in place.
LL
Secure unit to wall using space plugs. Drill 2 pilot holes through the back rail into the
wall and insert Space-Plugs. Then unwind space plug until it contacts both surfaces.
Finally, tighten the screws.
L Brackets
Use 2 x 15mm screws (L) to secure each of the L brackets
to the unit at either side. Then screw up through into the
worktop as shown.
Hinge Plates
K
Screws for attaching to walls and worktop are not provided as these vary
depending on materials, thickness and construction. Ensure appropriate xings
for wall and worktop construction are used. Please refer to the specialist worktop
supplier if these are required for solid surface worktops.

Page 11
BASE UNIT
800 - 1000 Adjustable Corner Assembly Guide
Step 17.
Insert hinge in top & bottom
holes as shown below.
Step 18.
Secure hinges by tightening
2 x screws with hinge dowels
attached. These are already
positioned within the hinges.
Step 19.
Attach the door to unit
where required.
To attach door, clip hinge
onto hinge plate and click
to secure.
Hinge Cover Caps
Step 21.
Fit cover caps to hinge.
Adjust Soft close to suit.
Step 20.
Adjust hinge to suit. As shown below.
To adjust hinge using
a screw driver, tighten
or loosen as required at
points 1 & 2.
Point 1- In - Out
Point 2- Left - Right
12
FRONTAL
HINGE
ADJUSTMENT
Hinge Plates
View from inside of Unit
To release door,
pull catch as shown,
to release hinge from
the hinge plate.
The top and bottom
hinges MUST be
adjusted to the SAME
STRENGTH.
To Move the
hinge up/down,
loosen screws
A + B,
Manoeuvre
the door, then
re-tighten the
screws
A
