Zummo Z1 Nature Technical specifications

MAINTENANCE INSTRUCTIONS
Maintenance and
cleaning tips
We advise using protective gloves to handle our juicers.
Cleaning the juice extraction system and front cover at least once a day is advisable.
Do not forget to regularly check the peel containers.
It is not necessary to use specialized products.
All parts can be washed in the dishwasher (it is advisable to clean the front cover by hand).
The front covers of our juicers are
comprised of polycarbonate and ABS
models.For this reason, we advise not
cleaning them in the dishwasher to
prevent scratches or defects
Z1 NATURE

The machines must be cleaned and disinfected as frequently as indicated above. In this
process, first remove all the solid waste, and then clean and disinfect. The following
types of products can be used to disinfect the machines:
Descaling detergents/disinfectants for food use: Used either by immersion (small parts) or
sprayed (large parts and stainless-steel front of machine) in the concentration recommended
by the manufacturer. Each product must be left to act for the time indicated, and then rinsed
well to avoid contact of the juice with the product. These products usually have a very high
pH, which, with time, may degrade the polycarbonate, so it is advisable not to exceed the
product action times on transparent plastic parts.
Chlorinated disinfectant detergents for food use: Same use as the previous products. They
can be used by immersion or sprayed, bearing in mind the time recommendations given by
the manufacturer. Thoroughly rinse the parts treated before they come in contact with the
juice again.
Another option can be solutions with domestic use (4% chlorine) or industrial use (10%
chlorine) bleach. The necessary concentration for it to be eective at room temperature is
100 ppm, which means 2.5 ml of domestic bleach for every litre of water, or 1 ml of industrial
bleach per litre of water.
Juice extraction area:
oJuice extraction tray
oBlade
oCup
oPeel extractor
oFilter tray and filter
oFront cover
oContainer.
oUpper protection
oStainless steel machine front
Clean the following components at least
once a day:
Feeder:
oMachine top
Clean weekly or twice a week when required:
MAINTENANCE INSTRUCTIONS
Z1 NATURE

With the machine stopped press
the o button.
Remove upper protection
Be careful with blade. Remove container. Unscrew the nuts.
Extract blade and cup. Unscrew the nut.
Finally, the drip tray
and grid.
Remove the juice
extraction system
1.
2.
4.
5.
6.
7.
8.
9.
10.
Clean all parts with water and
liquid detergent.
Also suitable for dishwashers
(Except front cover)
1.
2.
DISASSEMBLY AND CLEANING INSTRUCTION
C/ Cádiz, 4 - 46113 Moncada - Valencia (Spain) - ([phone] - [e-mail] - www.zummocorp.com
Z1 NATURE
Extract the front cover.
3.

Fit the drip tray and grid. Mount the juice
extraction system.
Mount the filter tray.
Screw the nut.
Fit upper protection.
Insert the front cover into the
grooves from right to left.
1.
2. 3.
8.
10. 11.
ASSEMBLY INSTRUCTIONS
Z1 NATURE
Screw the nut.
Add the cup.
Add the blade.
4.
5.
7.
C/ Cádiz, 4 - 46113 Moncada - Valencia (Spain) - ([phone] - [e-mail] - www.zummocorp.com
Fit container.
9.
Screw the nut.
6.
D100122/20-1
