Axis B/U Series User manual

USER MANUAL
B/U Series
File: 2011-06 R-BU-128 B-50_4 GB

2 USER MANUAL
_____________________________________________________________________________________________________________________
Index:
1. General description. ................................................................................................... 4
2. Completeness ............................................................................................................. 4
3. Technical data ............................................................................................................. 5
4. Keys and indicators ................................................................................................... 6
5. Sec rity r les .............................................................................................................. 7
6. Environment protection .............................................................................................. 7
7. Preparation to work .................................................................................................... 8
8. Start- p ........................................................................................................................ 9
9. General r les ............................................................................................................. 10
10. Balance checking .................................................................................................. 11
11. Scale adj stment ................................................................................................... 11
12. Connecting to a comp ter or a printer (optional) ............................................... 11
13. Basic f nction........................................................................................................ 15
13.1 Normal weighing .................................................................................................. 15
13.2 Weighing with tare ................................................................................................ 16
13.3 Increased readability ............................................................................................ 16
14. Special f nctions describtion .............................................................................. 17
14.1 Men c stomization f nction (ACtIV and dEFAUL) ........................................... 18
14.2 A tozeroing f nction (A toZE) .......................................................................... 19
14.3 Pieces co nting (PCS) ........................................................................................ 20
14.4 Printer cooperation settings (PrInt) ................................................................... 21
14.5 Serial port parameters setting (Port) .................................................................. 22
14.6 Constant tare (tArE) .............................................................................................. 23
14.7 Average calc lation f nction (AVErAG) ............................................................. 25
14.8 Recipe weighing f nction (RECIPE) ................................................................... 26
14.9 Percentage weighing f nction (PErC)................................................................. 27
14.10 Anti-dist rbance filter f nction (FILtEr) .......................................................... 28
14.11 F nction for maxim m val e indication (UP) .................................................. 29
14.12 Force meas ring f nction (nEWto) ................................................................. 30
14.13 F nction for weighing large animals (LOC) ..................................................... 31
14.14 Checkweighing f nction (thr) ........................................................................... 32

USER MANUAL 3
_____________________________________________________________________________________________________________________
14.15 Total weight f nction (totAL) ............................................................................. 35
14.16 F nction for setting date and time (dAtE) ........................................................ 37
14.17 F nction for selecting label n mber (LAbEL) .................................................. 38
14.18 External calibration (CALIb) .............................................................................. 39
14.19 Setting time of stabilization f nction (Stb) ....................................................... 40
14.20 Entering reference zero f nction (Zero) ........................................................... 41
14.21 A tomatic switching off the scale f nction (A toOF) ..................................... 42
14.22 Density determining f nction (dEnSIt) ............................................................. 43
14.23 Statistical calc lations f nction (StAt) ............................................................. 45
15. Maintenance and repairs of small defects........................................................ 47
Declaration of Conformity ................................................................................................ 48
Appendix A ........................................................................................................................ 49

4 USER MANUAL
_____________________________________________________________________________________________________________________
1. General description.
B/U series platform scales are destined for general use.
B series scales are made in two main versions: with LE display (basic) and with
LC display (option).
ouble-range option is described In Appendix A
All scales are metrological tested - calibration or legal verification on demand.
Scales have following verification features:
- a seal protecting scale casing against opening,
- notified body stamps and green metrological marking placed on the balance
name plate.
Legal verification is valid for 3 years unless the seal is broken.
NACE classification: 29.24.23.
Certificates:
EC Type
Approval Certificate
No. PL 04 022
Health Quality
Certificate
No. HŻ/06458/01
AXIS management System
Certificate
IN EN ISO 9001:2000
No. 78 100 6386
2. Completeness
Standard set consist of:
1. Scale
2. User manual
3. Guarantee card
4. Feeder ZN12V/850mA

USER MANUAL 5
_____________________________________________________________________________________________________________________
3. Technical data
Scale type
B0.3U
B0.6U
B1.5U
B3U
B6U
B15U
Maximum l ading
(Max)
300g
600g
1500g
3000g
6000g
15kg
Read unit
(d)
0,1g
0,05g*
0,2g
0,1g*
0,5g
0,1g*
1g
0,1g*
2g
1g*
5g
1g*
Verific
ati n unit
(e)
0,2g
0,2g
0,5g
1g
2g
5g
Minimum l ading
(Min)
2g
4g
10g
20g
40g
20g
Tare range
-
300g
-
600g
-
1500g
-
3000g
-
6000g
-
15kg
Accuracy class
III
W rking temperature
-
10÷40°C
Weighing time
<3s
Pan dimensi n
[mm]
100x150
x70
150x200
x70
20
0x20
x80
250x260
x110
250x260
x110
Cable length
3m
P wer supply
~230V, 50Hz, 8VA / 12V 500mA
Scale weight
2,5kg
2,8kg
3,5kg
EC Verificati n
  
* increased readability for non-EC verification applications
Value Max, d i e f r d uble-range scales are place in Appendix A.

6 USER MANUAL
_____________________________________________________________________________________________________________________
4. Keys and indicators
key
I /
- switch-on / switch-off (standby),
key
→
T
←
- tare (subtract package weight from weighed mass),
key B/G - gross,
key
→
0
←
- zeroing (when the platform is empty),
key MENU - special function menu,
key - result printout,
key HR - high resolution,
indicator
→
0
←
- zero indicator,
indicator - result stabilization indicator,
indicator NET - net weight indicator (indication with subtracted tare)
indicator - gross mass (after use of B/G key),
indicator - indicator of pieces counting (indications in pieces)
LCD version:
indicator MODE - special function setting,
bar
indicator
- total load indicator (graduated 0-100%)
indicator OFF - standby,
indicator B/G - gross mass (key B/G),
indicator pcs - pieces counting

USER MANUAL 7
_____________________________________________________________________________________________________________________
5. Sec rity r les
To avoid electrical shock or damage of the scale or
connected peripheral devices, it is necessary to follow
the security rules below
.
• All repairs and necessary regulations can be made by authorised personnel
only.
• To avoid fire risk use a feeder of an appropriate type (supplied with the
scale). Pay attention that supply voltage is compatible with specified
technical data.
• o not use the scale when its cover is opened.
• o not use the scale in explosive conditions.
• o not use the scale in high humidity.
• If the scale seems not to operate properly, unplug it from the mains and do
not use until checked by authorised service.
6. Environment protection
According to legal regulations it if forbidden to dispose
wasted electronic equipment in waste containers.
• Please return wasted scale to the point of purchase or other company
specialised in recycling of wasted electronic components.

8 USER MANUAL
_____________________________________________________________________________________________________________________
7. Preparation to work
1. Take the scale out of the package
removing protective foils.
2. Take a pan off and remove protective
elements from below the pan.
3. Place the scale on a stable ground not
affected by mechanical vibrations and
airflows.
4. Level the scale with the rotating rear legs
so that the air bubble in the water-level at
the back of the scale is in the middle. Lock
the legs with the nut.
Correct Wrong
5. Put on the pan.
6. Plug the feeder connector to the power
socket at the back of the scale and plug the
feeder to the mains. After self-tests and
result stabilisation, the scale displays zero
indication.

USER MANUAL 9
_____________________________________________________________________________________________________________________
8. Start- p
Leave the pan empty, plug the feeder to the mains (~230V/50Hz) and plug the
feeder connector to the 12V power socket at the back of the scale.
The scale proceeds with following start-up actions:
isplay test.
Basic electronic components tests: C1,
C-2, C-6 .
Program version.
The scale is now ready to work.
Note:
In scales with power feeder please plug in feeder to wall socket first, and
connect feeder plug to scale next.

10 USER MANUAL
_____________________________________________________________________________________________________________________
9. General r les
1. Before each measurement make sure that zero indicator is displayed. If zero
indicator does not displayed or “----“ communicate appears, press →0← key
and wait until zero indication and zero indicator appears
2. The scale is equipped with a tare equal to its range. To tare the scale press
→T← key (left or right). Storing a tare value does not extend measuring range,
but only subtracts it from a load placed on a pan. To make weight control easier
and to avoid range overdrawing, the scale is equipped with a load indicator
(graduated in percentages).
3. Weighing result should be read when the indicator " " lights, which signalises
stabilisation of a result.
4. When the scale is not used but it is necessary to be ready to work immediately, it
can be switched off by pressing I/ key. The scale reading system is then
switched off to "standby" mode (signalled by the indicator "OFF" in version
with the LC display). To switch the scale on press I/ key. The scale is
immediately ready to operate maximum accuracy (after self tests).
5. Weighed sample should be placed in the centre of the pan.
6. Protect the scale against dust, aggressive dusts and liquids. To clean the scale
wash it with water with soap and dry it afterwards.
Place the scale on a platform to avoid dropping weighed objects
on the pan.
.
Do not overload the scale more then 20% of maximum load (Max .

USER MANUAL 11
_____________________________________________________________________________________________________________________
10. Balance checking
It is advised to check scale indication accuracy before and after series of
measurement using any load with known weight.
To check the scale with legal verification use a calibration weight with valid
calibration certificate. In case permissible error is exceeded it is advised to contact
the nearest service to calibrate the scale
11. Scale adj stment
To adjust a balance it is necessary to break protective marks, therefore
to calibrate the scale please contact the nearest service
.
12. Connecting to a comp ter, printer or label printer
The scale is equipped with RS232C or
RS485 (optional), which can be used to
connect external devices such as a computer
or a printer. etailed way of communication
data is defined by one of protocol:
- LonG – protocol to printer and computer
- ELtron – protocol to label printer
When cooperating with a printer data is send
automatically after result stabilisation, but
next transmission is possible after removing
previously weighted sample.
When protocol Long is chosen scale sends
result of weighting under the influence of
initializing signal from computer, or after
pressing a key.
When automatic transmission mode is
chosen (function PrInt), a printer data is send
automatically after result stabilisation, but
next transmission is possible after removing
previously weighted sample. The scale sends
following information: successive number of
weighing, date and time (if clock module is
installed )and weighing result.
uring transmission communicate Print is displayed. It is also possible by scale to
display text message sent from computer confirming received information.
RS485 (option)
RxD (receiver)
TxD (transmitter)
GND
Case
1
2
3
4
5
6
7
8
9
A
In ut
Out ut
A
B
B
Case
1
2
3
4
5
6
7
8
9
}
}
RS
-
232C

12 USER MANUAL
_____________________________________________________________________________________________________________________
Scale with Eltron protocol sending record of data after pressed key.
The scale sends following information: number of label, date and time (if clock
module is installed ) and weighing result. uring transmission communicate Label
is displayed.
In special features scale can be equipped in second RS232 interface for additional
functions, ex. continuous transmitting of indications to second display.
Computer must have a special program for cooperation with data from a scale.
Programs offer is available on www.axis.pl/en internet site.
Detailed protocol description
LonG protocol
Communication parameters: 8 bits, 1 stop bit, no parity, baud rate 4800bps,
 Readout of scale indication ( corresponds to pressing key
Computer→Scale: S I CR LF (53h 49h 0 h 0Ah),
Scale→Computer: scale response according to description below (16 bytes):
Byte 1 - sign „-” or space
Byte 2 - space
Byte
3
÷
4 -
digit or space
Byte 5÷9 - digit, decimal point or space
Byte 10 - digit
Byte 11 - space
Byte 12 - k, l, c, p or space
Byte 13 - g, b, t, c or %
Byte 14 - space
Byte 15 - CR
Byte 16 - LF
Attention:
Network number different than zero (F..-rS / nr function) changes scale working
mode: communication with a computer is possible after logging the scale in with
02h scale number command. To log the scale out use 03h command.
For example: Using a program to test RS232 interface ( program is available on
www.axis.pl in computer programs section) for scale number 1 please write: $0201
to log in, then SI, and write: $03 to close communication

USER MANUAL 13
_____________________________________________________________________________________________________________________
 Asking for scale presence in system (testing scale connection with computer):
Computer→Scale: S J CR LF (53h 4Ah 0 h 0Ah),
Scale→Computer: M J CR LF (4 h 4Ah 0 h 0Ah),
 isplaying a sign on scale display (text message from computer):
Computer→Scale: S N n n X X X X X X CR LF (53h 4Eh 0 h 0Ah),
nn-displaying time in seconds; XXXXXX- signs to display
Scale→Computer: M N CR LF (4 h 4Eh 0 h 0Ah),
 Scale tarring (calling → T ← key press) :
Computer→Scale: S T CR LF (53h 54h 0 h 0Ah),
Scale→Computer: without response,
 Scale zeroing (calling → 0 ← key press):
Computer→ Scale: S Z CR LF (53h 5Ah 0 h 0Ah),
Scale →Computer: without response,
 Scale turning on / off (calling I/ key press):
Computer→ Scale: S S CR LF (53h 53h 0 h 0Ah),
Scale →Computer: without response,
 Entering to special function menu (calling MENU key press):
Computer→ Scale: S F CR LF (53h 46h 0 h 0Ah),
Scale →Computer: without response,
 Setting low threshold value (option):
Computer→ Scale: S L D1 DN CR LF (53h 4Ch D1 DN 0 h 0Ah)
D1 DN – threshold value, maximum 8 characters („-” – negative value, digits,
dot – decimal separator), number of digits after dot should be the same as on
scale display,
Scale →Computer: without response,
 Example:
⋅ in order to set low threshold 1000g in scale B1.5 (d=0.5g) the following order
should be sent:
S L 1 0 0 0 . 0 CR LF (53h 4Ch 31h 30h 30h 30h 2Eh 30h 0 h 0Ah),
⋅ in order to set low threshold 100kg in scale B150 (d=50g) the following order
should be sent:
S L 1 0 0 . 0 0 CR LF (53h 4Ch 31h 30h 30h 2Eh 30h 30h 0 h 0Ah),),
 Setting high threshold value (option):
Computer→ Scale: S H D1 DN CR LF (53h 48h D1 DN 0 h 0Ah),
D1 DN – threshold value (see )
Scale →Computer: without response.

14 USER MANUAL
_____________________________________________________________________________________________________________________
Connecting cable WK-1 (scale – computer / 9-pin interface):
Protocol ELTRON description
Communication parameters: 8bits, 1stop, no parity, 9600bps,
 After use key scale send:
Scale→Label printer : EPL-2 language instruction to initialize print of label:
US - control instruction
FR"0001" - number of labels
? - starting instruction
hh:mm - 5 signs: hours:minutes
yyyy.mm.dd - 10 signs: year.month.day
mass + unit - 10 signs: scale indicate + mass unit
P1 - ending instruction
Attention:
1. It is possible to place a constant signs (company name, product name).
2. The default number of label’s is 0001 (label number 1). ifferent numbers of
label are possible by using a LAbEL function
3. Label formula must be saved in printer – label forma must be designed in
computer (by Zebra esigner program) and saved in printer.
4. Parameters and protocol of transmission must be compatible with printer label

USER MANUAL 15
_____________________________________________________________________________________________________________________
13. Basic f nction
To make clear how to manage with each function, in further part of instruction
descriptions are replaced with pictures.
- put a load on the pan
- remove the load from the pan
- press the key when indication is
displayed
- forced change
- automatic change
13.1 Normal weighing
Press →0← key ( → T ← key in non-
legalized scales), which zeros the
scale, operates only when the pan is
empty .
Weighing result should be read when
the indicator " " lights.
0.00
2.30
0
2.30
T

16 USER MANUAL
_____________________________________________________________________________________________________________________
13.2 Weighing with tare
The scale is equipped with tare equal
to its range.
Joint value tare and mass net can not
cross a maximum of scale.
To display gross weight press B/G
key.
Note:
Press B/G key to return to net weight
indication.
13.3 Increased readability
Press HR key to display the weighing
result (for 5s.) with the highest
readability possible. This function is
especially helpful in scales with legal
verification with d=e.
The weighing result with increased
readability can be used for
informational purposes only and
cannot be printed or sent to a
computer with key.
2.30
0.00
40.01
42.31
T
NET
NET
2.30
2.29
2.30

USER MANUAL 17
_____________________________________________________________________________________________________________________
14. Special f nctions describtion
List of available functions:
 menu customization function (ACtIV),
 removal of all function from menu (dEFAUL).
 autozeroing function (AutoZE),
 pieces counting function (PCS),
 function for setting serial port working (PrInt)
 function for setting serial port (Port)
 entering tare function (tArE)
 recipe weighing function (rECIPE),
 weighing large animals function (LOC)
 force measuring function (nEWto)
 maximum value indication function (UP)
 anti-disturbance filter function (FILtEr)
 average calculating function (AVErA)
 percentage weighing function (PErC),
 extended calibration function (CALIb)
 setting time of stabilisation function (Stb)
 selecting label number function (LabEL)
 automatic switching off scale function (AutoOF)
 entering reference zero (Zero)
 determining solids and liquids density function (dEnSIt)
 calculator for good packaging control (tP) - option*
 statistical calculations (StAt)- option*
 paperweight calculation function (PAP) - option*
function with additional equipment require:
 options with the clock:
- setting current date and time function (dAtE)
- total weight function (totAL)
 options with the transoptors connectors:
- checkweighing function (thr)
* Functions offered with special version of scale software (with limited possibility
of using other special functions).
User create own menu by choosing function in ACtIV function (described in
chapter 14.1).

18 USER MANUAL
_____________________________________________________________________________________________________________________
14.1 Men c stomization f nction (ACtIV and dEFAUL)
Among available user functions it is
possible to select these, which should be
displayed after pressing MENU key. It
allows avoiding displaying whole list of
available functions, which makes
operation time longer.
Operation sequence shown in the
pictures on the left causes adding
function for setting serial interface
RS232C parameters (Port) to function
menu.
After switching on ACTIV function a
dot is displayed on the right side (to
distinguish from regular menu). Chosen
functions are displayed with a dot on
the left side.
In every moment, it is possible to
restore primary (manufacture) settings
choosing dEFAULt special function.
In order to remove function from menu
in the last operation in place of selecting
Port -1 choose Port -0
0.00
ACtIV
Port -1
Port -0
PCS .
.
. Port
T
T
T

USER MANUAL 19
_____________________________________________________________________________________________________________________
14.2 A tozeroing f nction (A toZE)
When F -Aut function is activated,
the scale automatically ensures stable
zero indication if the pan is empty or
if zero indication was acquired by
pressing → T ← key.
To leave the function press MENU
key, then with → T ← key chose
AutoZE and Aut-0.
Note:
Autozeroing function is activated
automatically for 10 min after
switching-on
0.01
AutoZE
Aut-1
Aut-0
0.00
T
T

20 USER MANUAL
_____________________________________________________________________________________________________________________
14.3 Pieces co nting (PCS)
This function enables to count
identical pieces, e.g. turnbuckles or
buttons.
A measurement is performed in two
phases:
- first phase - single piece weight
calculation on the basis of defined
pieces amount (5, 10, 20, 50, 100,
200 or 500 pieces),
- second phase – pieces counting.
It is advised that single piece weight
is not less than one reading unit and
sample weight used in first phase is
bigger than 100 reading units.
To leave function press MENU key
and then with →Τ← key chose
PCS and PCS-0.
Note:
1 Err-3 communicate signalises that
a sample was not put on the pan
The same communicate appears
if single piece weight is less than one
reading unit (it is possible to count
pieces but measuring error is
bigger)
2 To chose previously used pieces
amount select " _ _ " in first phase
(in case no value was chosen, error
communicate appears
3 During pieces counting → T ← key
function does not change
4 In scales equipped with LCD
display, weighing unit is visible and
"  " sign is replaced with "pcs "
0
0.00
23.40
PCS
PCS -0
PCS-1
PCS - --
5
5
12
12
T
T
T
T
