Ballard Designs Tuscan File Hutch User manual

PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 6-13-2019 Page 1 of 6
PRODUCT NAME: Tuscan File Hutch
ITEM NUMBER: MO226
ASSEMBLED DIMENSIONS: 51 3/4” H x 36” W x 15” D
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
IMPORTED

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 6
Ltr.
A 4
B
Shelf Supports
8
Qty. Hardware Included
Ltr.
EGlass Shelf (E)
Glass Shelf (E)
Hardware (A-D)
1
Qty. Components
Ltr.
C 2
D 1
Qty. Hardware Included
Connector Plates
Connector Screws Anti-Tip kit
TOOLS NEEDED:
-Requires a screwdriver
-Power drill suggested
-Two person assembly
suggested
Remove all parts, hardware and
protective packaging from carton
and carefully arrange on a clean,
level, padded surface.
NOTE: To avoid accidentally
discarding small parts or hardware,
retain all carton contents until
assembly and installation are complete.

Page 3 of 6
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
(B)
(A)
(E)
STEP 1: Place Shelf Supports (A) at desired height and gently place Glass Shelf (E) on Shelf Supports.
NOTE: Assemble in intended area for use.
Set and align Hutch on top of Console (sold separately). Attach together by positioning
Connector Plates (C) evenly between the two and securing with Connector Screws (B).
Use a screwdriver to firmly tighten.
STEP 2:
(C)
Console sold separately.

NOTE: Assemble in intended area for use.
Page 4 of 6
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 3: Plug electrical cord into an outlet. Cabinet is equipped with an “Easy Touch” dimmer
control which allows for three levels of brightness. To operate, touch upper right hinge.
Touch Door Hinge
to control light

Cleaning & Care:
DO NOT use alcohol based products or spray polisher as
they can damage the finish. Dust with soft cloth.
Attach a Bracket (H) to the back of the Hutch with the Small Screw (F) through the
smaller hole. Screw the remaining Bracket (H) into a wall stud with the Large Screw (G)
2 inches below the Bracket attached to the furniture. Align the Brackets vertically and
string in the Retention Belt (I). Confirm Strap is securely laced and locked.
Ltr.
F
(G)
(F)
(H)
(H)
(I)
1 Small Screw
Retention Belt
Qty. Hardware Included
ANTI TIP INSTALLATION:
G1 Large Screw
H2 Bracket
I1
NOTE: Assemble in intended area for use.
WALL
STUD
WARNING
Tip-Over Hazard
WALL BRACKET MUST BE ATTACHED TO WALL STUD
Prevent tipping accidents. Anchor your furniture.
Page 5 of 6
Customer Service: 800-367-2810
Online: www.ballarddesigns.com

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 6 of 6
HALOGEN BULB REPLACEMENT:
Insert the new Bulb (A) into the Fixture Body (C) Socket using a tissue or soft cloth (oil from the
skin my damage the bulb). Replace the Lens Cover (B) by twisting it clockwise back into place.
1
Qty.
Halogen JCD G8 120V 25W
Replacement Bulb (A)
NOT INCLUDED
Item needed
Unplug the unit from the wall. Remove the Lens Cover (B) from the Fixture Body (C) by turning it
counter clockwise and pulling it away from the unit. Remove the old Bulb (A) by pulling it straight
out in a horizontal direction.
(B)
(C)
(B)
(C)
(A)
NOTE: Save this page for future bulb replacement.
