Belson Outdoors WALK-THROUGH HEXAGON PICNIC TABLE User manual

111 North River Road
North Aurora, IL 60542
Phone: [phone]
Fax: [phone]
[email protected]
Model # HT-100 Instructions Sheet
www.belson.com
WALK-THROUGH HEXAGON PICNIC TABLE

www.belson.com
BEFORE ASSEMBLY, PLEASE MAKE SURE ALL COMPONENTS ARE INCLUDED.
FP - FASTENER PACK
( 1 ) - ONE FASTENER PACK
J - TABLE TOP
( 1 ) - ONE TABLE TOP W/SMALL SPOKE ASSEMBLY
N - SEAT
( 6 ) - SIX SEATS
C - LARGE SPOKE
( 3 ) - THREE LARGE SPOKES
R - CENTER PROPELLER
( 1 ) - ONE CENTER PROPELLER
H - LEG
( 3 ) - THREE LEGS
A - LEG SUPPORT
( 3 ) - THREE LEG SUPPORTS
Q - SEAT SUPPORT
( 6 ) - SIX SEAT SUPPORTS

www.belson.com
1 - #3 PHILLIPS DRIVE BIT
2 - 9/16" SOCKET WRENCH
ALSO NEEDED FOR THIS ASSEMBLY WILL BE THE FOLLOWING MATERIALS:
18 - 3/8" X 5" HEX HEAD BOLT
BEFORE ASSEMBLY, PLEASE MAKE SURE ALL FASTENERS ARE INCLUDED.
36 - 3/8" FLAT WASHER
18 - 3/8" NYLON LOCK NUT
30 - #12 X 3" FLAT HEAD PHILLIPS SCREW
12 - #12 X 2-1/2" FLAT HEAD PHILLIPS SCREW

www.belson.com
STEP #1:
FASTEN ( 2 ) TWO SEAT SUPPORTS ONTO EACH END OF ( 1 ) ONE LEG SUPPORT. BE SURE THAT
EACH SEAT SUPPORT, WHEN FASTENED, ARE POINTING IN THE SAME DIRECTION AS SHOWN ABOVE.
USE ( 1 ) ONE #12 X 2-1/2” FLAT HEAD PHILLIPS SCREW PER HOLE TO SECURE.
STEP #2:
FASTEN THE SEAT SUPPORT ASSEMBLY TO THE LEG AS SHOWN ABOVE. USE ( 1 ) ONE #12 X 3”
FLAT HEAD PHILLIPS SCREW PER HOLE TO SECURE.
#12 X 2-1/2” FLAT HEAD
PHILLIPS SCREW
#12 X 3” FLAT HEAD
PHILLIPS SCREW

www.belson.com
STEP #3:
SLIDE THE LARGE SPOKE ASSEMBLY UP TO MATCH THE HOLES TO THE LEGS. SECURE THE LARGE
SPOKE ASSEMBLY TO THE LEGS AS SHOWN BELOW. USE ( 1 ) ONE 3/8” X 5” HEX HEAD BOLT AND
( 1 ) ONE 3/8” FLAT WASHER ALONG WITH ( 1 ) ONE 3/8” FLAT WASHER AND ( 1 ) ONE 3/8” NYLON
LOCK NUT PER HOLE TO SECURE.
STEP #4:
FASTEN THE SEATS TO THE LARGE SPOKE ASSEMBLY USING THE PROVIDED PILOT HOLES AND SEAT
SUPPORT ASSEMBLIES, AS SHOWN ABOVE. BE SURE WHEN INSTALLING THE SET OF SEATS THAT
THE INNER EDGES ARE FLUSH AND TIGHT WITH EACH OTHER. USE ( 1 ) ONE #12 X 3” FLAT HEAD
PHILLIPS SCREW PER HOLE TO SECURE.
STEP #5: REPEAT STEPS 1 THROUGH 4, TWO TIMES.
3/8” X 5” HEX
HEAD BOLT 3/8” FLAT WASHER

www.belson.com
STEP #6:
ASSEMBLE THE LEG/SEAT ASSE,BLIES TO THE CENTER PROPELLER AS SHOWN ABOVE. USE ( 1 )
ONE 3/8” X 5” HEX HEAD BOLT AND ( 1 ) ONE 3/8” FLAT WASHER ALONG WITH ( 1 ) ONE 3/8” FLAT
WASHER AND ( 1 ) ONE 3/8” NYLON LOCK NUT PER HOLE TO SECURE.
DO NOT TIGHTEN BOLTS COMPLETELY. THIS WILL BE DONE IN A LATER STEP.
3/8” FLAT WASHER
3/8” NYLON LOCK NUT
3/8” X 5” HEX
HEAD BOLT
3/8” FLAT WASHER

www.belson.com
STEP #7:
PLACE THE TABLE TOP ASSEMBLY ONTO THE LEG/SEAT ASSEMBLES AS SHOWN ABOVE. SLIDE ( 1 )
ONE LEG BETWEEN THE PROPELLERS OF EACH SPOKE ASSEMBLY. SECURE THE LEGS TO THE SMALL
SPOKE ASSEMBLY. USE ( 1 ) ONE 3/8” X 5” HEX HEAD BOLT AND ( 1 ) ONE 3/8” FLAT WASHER ALONG
WITH ( 1 ) ONE 3/8” FLAT WASHER AND ( 1 ) ONE 3/8” NYLON LOCK NUT PER HOLE TO SECURE.
BE SURE TO TIGHTEN ALL LOOSE BOLTS AFTER COMPLETING THIS STEP.
3/8” X 5” HEX
HEAD BOLT
3/8” FLAT WASHER
3/8” NYLON LOCK NUT
3/8” FLAT WASHER
