Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 1
VT-HDT Box
Test device for proportional valves with
integrated electronics (OBE)
Type VT-HDT-1-2X Operating Manual
The test device is suitable for the controlling and functional testing of proportional valves with integrated
electronics (OBE) with an operating voltage of +24V.
Test device VT-HDT-1-2X Test device VT-HDT-1-2X
Features
▶The test device simplify the commissioning and troubleshooting
of hydraulic systems with proportional valves with integrated
electronics
▶Simple and intuitive operation via touchscreen
▶Screens for digital or analog display
▶Automatic valve detection
▶Setpoint generator with interval function
▶Ramp function
▶Potentiometer operation
▶Dead man´s handle
▶2 outputs for switching valves
▶Sockets for external measurements
▶Service case with test device, 24 V power supply, OBE connection
cable and 2 cables for switching valves (see ordering information) Service case VT-HDTSY-1-2X
Notice:
The test device might only be used by persons who are familiar with the device, the valve, and the hydraulic
system. With the corresponding setting, the control signals coming from the system are going to be ignored.
If control-side safety regulations are provided, they are thereby rendered inoperable.
The use of the device on running systems is always at your own risk!
No liability will be accepted for damage caused by incorrect operation!

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 2
Content
Features. ........................................................................................................................................ 1
Ordering code ................................................................................................................................. 2
Test device type VT-HDT-1-2X: ..................................................................................................... 3
▶Operation modes and function ........................................................................................... 4
▶Screens............................................................................................................................... 7
▶Device view......................................................................................................................... 9
▶Connections........................................................................................................................ 9
▶Technical data .................................................................................................................... 10
Service case VT-HDTSY-1-2X ........................................................................................................ 11
Power supply unit VT-HDTNT-5-2X ................................................................................................ 11
OBE-connection cable VT-HDTK-1-2X ........................................................................................... 12
Switching valve cable VT-HDTSK-1-2X .......................................................................................... 12
Environmental protection and disposal ........................................................................................... 13
Read this documentation completely, and in particular the safety and warning instructions, before you
work with the product.
Ordering code:
Pos
.
Designation
Type
Part No.
1
Test device VT-HDT Box
VT-HDT-1-2X
R996037000
2
OBE-Connection cable 6-pol. 3m
VT-HDTK-1-2X
R996037001
3
Power supply unit 120W, 90-264VAC/+24VDC/5A
VT-HDTNT-5-2X
R996025391
4
Switching valve cable 3m
VT-HDTSK-1-2X
R996037002
5
Service case (consisting of: Pos.1, 2, 3)
VT-HDTSY-1-2X/1-1-0-1-0
R996036999
6
Service case compl. incl. 2 switching valve cables
VT-HDTSY-1-2X/1-1-2-1-0
R996043985
Warning
Usage is only granted to qualified personnel!
Only for the intended use!
The correct connection and the correct settings on the device must be ensured!
In particular, the use of the device on running machines poses risks for material
and human, which only the operator has to estimate!
The device must be handled with care, especially soiling, moisture, condensation and me-
chanical loads should be avoided!
Use in potentially explosive environments is prohibited!

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 3
Test device type VT-HDT-1-2X
Approbiate use:
The test device is intended for checking the function
of proportional valves with OnBoardElectronic (OBE)
with an operating voltage of +24V
These can be directional valves, throttles, pressure
limiting, proportional valves, etc.
The power supply is done either by power supply unit
+24V (VT-HDTNT) or valve cable on site.
The operating mode "Simulator mode" may only be
used, when the valve , which is going to get tested, is
removed (from the machine separated) or appropriate
security measures have been implemented.
Touchscreen: Type VT-HDT-1-2X
The brightly lit TFT touchscreen is easy to read and
intuitive to use.
The resistive touchscreen is resistant to dirt.
General conditions:
The valve supply (24V) is applied to terminals A (+) and B (-).
The setpoint is applied to terminals D (+) and E (-).
The actual value is applied to the terminals F (+) and C (-).
Exception: Setting in the screen RANGE: 24V-> C, F: B (E)
With this setting, 24V are switched to terminal C (for example: Enable).
The actual value is measured in this case at the terminals F (+) and B (-).
For valves, which provide the actual value at the terminals F (+) and E (-), please contact the manufacturer.
Warning
The range setting '24V-> C, F: B (E)' causes 24V to reach terminal C.
This can lead to defects at unsuitable valves or cause machinery movement.
The user will be informed by an additional security prompt.

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 4
Operating modes and functions:
External mode:
The signals from the valve input connector are looped through to the valve output connector. The signals
are measured internally and displayed. A setpoint specification is not possible.
Simulator mode:
The setpoint is generated internally and output to the valve output connector.
Depending on the preselection, setpoint can be set via potentiometer or touch screen.
The output setpoint and the actual value from the valve are measured and displayed.
Burden resistance at mA ranges:
In external mode, the current for actual value flows over the burden resistance of the ext. control.
In simulator mode over the internal burden resistance of the test device.
Warning
Dead man´s handle:Deadman activ
When working on systems, this operating mode is required.
A setpoint specification is only possible, when the button is pressed.
If the button released, the setpoint goes to 0%; The switching valves are not switched off, when the button is
released.
When the button is pressed again, the setpoint remains at 0%; A setpoint must be specified again.
The status of the dead man´s handle is displayed at the 'Range bar' (red / green)
Warning
External mode is activ
Simulator mode activ
Only use the operating mode "simulator mode" if the valve, which is going to get tested, has
been removed (disconnected from the machine) or if appropriate safety measures have been
implemented by the operator!
The dead man´s handle is not a safety device in sense of machine safety rules!

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 5
Operation with potentiometer: Potentiometer activ
The valve setpoint is changeable with a potentiometer. The touch functions are not active.
The center position of the potentiometer always equals 0% (no movement)
i.e.: Middle position corresponds to 12mA at range 4 .. (12) .. 20mA
Center position corresponds to 0V at range (0) .. +10V (left side of adjustmant range not active)
When potentiometer operation is activated, the output setpoint is 0%, independent of the current position.
Only after the potentiometer has been turned to 'zero position' once, the potentiometer is active.
('Range bar' changes from 'Orange' to 'Green')
This applies:
- when power up the test device
- when selecting the operation with potentiometer
- when working with dead man´s handle
Sockets for external measurements:Measuring sockets activ
The setpoint and the actual value of the valve can be recorded (external measuring devices, data loggers).
The measured values are only available at the sockets if this setting is activated.
The sockets are wired internally, according to the range selected (V or mA - no jumper is needed at the meas-
uring sockets).
The measuring sockets can also be used:
- for device calibration
- for controlling a frequency converter or other devices
(in the V range without special adapter cable)
Attention
Analog curves:4 curves activ
It can be selected whether only the setpoint and the actual value are shown in screen 'ANALOG' or
additionally 'Uv' and 'Iv'.
Only devices with potential-free measuring inputs may be connected!

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 6
Automatic valve detection:Valve detection activ
The plugging and unplugging of a valve is detected and in these cases the screen 'Range' is displayed.
When a valve is plugged in, it is further detected whether it is a valve with V- or mA range and only the corre-
sponding ranges are displayed for selection.
Warning
Ramp function:Ramp activ 20
If this setting is activated, the setpoint is not output directly, but by a ramp function.
Value input via selection and '+/-' keys:
Volt - range: ramp value 20 -> 10V/s, ramp value 40 -> 20V/s
mA - range: Ramp value 35 -> 20mA/s, ramp value 70 -> 40mA/s
High value -> steep ramp, low value -> flat ramp.
Warning
Function interval: Interval activ 15
This enables automatic setpoint output with adjustable profile.
Setting value in 1/10 s; Value input via selection and '+/-' keys.
e.g. Ramp 20, interval 15, 'MI' + 5V, 'MII' -1V:
- Setpoint moves to 'MI' value for 1.5 sec. with selected ramp.
- Following moves to 'MII' value for 1.5 sec. with selected ramp, and so on
The function is deactivated by unselection or when a setpoint entry is done via the touchscreen.
Internal mA Resistance:Resistance on
When in 'External mode' (and mA Range) the loop current for 'Actual value' usually flows through the burden
resistance of the external control (PLC).
If this burden does not exist, a resistance in the test device can be switched on, to enable readout of 'Actual
value'.
If this setting is activated, a setpoint of 900 mV is output for 25 ms (when a valve is
connected).
This must be taken into account during operation with systems!
The valve detection only works with a valve current consumption > 30 mA!
ATTENTION: Ramp remains active, even when operated with dead man´s handle!

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 7
Screens:
Screen 'Range':
Is displayed: -at power up
-after connecting or disconnecting a valve, if 'valve detection active' is enabled
-by 'Click' on 'Range bar' in screen 'DISPLAY VALUES'
Screen 'Display Values (Digital)':

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 8
Screen 'Display Values (Analog)':
Screen 'Settings':

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 9
Device view:
Connections:

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 10
Technical data:
Mechanically:
Dimensions
with plugs and potentiometer knob
155 x 73 x 47
mm
Weight
250
g
Protection
IP40
Temperature range
0…+40
°C
Humidity
no condensation
Electrical:
Supply voltage
24 (20…30)
V DC
Current consumption
for test device 24V
ca. 50
mA
for OBE-valve + 2 switching valves
max. 5
A
Reverse polarity protection
for test device
YES
Overvoltage protection
suppresor diode 30V
YES
Device fuse
OBE-valve, PTC self-resetting
3
A
switching valves, PTC self-resetting
1,8
A
Max. output voltage
setpoint out
±15
V
short circuit protected
YES
Burden resistance
internal current measurements
56
Ω
internal burden resistance (mA ranges)
100
Ω
external max.
500
Ω
Accuracy
±2
%
CE-conformity
Low Voltage Directive LVD 2014/35/EU
YES
EMC-Directive 2014/30/EU
YES
RoHS-Directive 2011/65/EU YES
Connections:
Valve input
connector plug flange
CM02E14S-61P
matching cable socket
CM06EA14S-61S
Valve output
connector socket flange
MS3102A-14S-6S
matching cable plug
MS3106A-14S-6P
Switching valve
connector socket flange
0202015
matching cable socket
0202001
Measuring sockets
standard
4
mm

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 11
Service case VT-HDTSY-1-2X
The service case contains the test device VT-HDT-1-2X, the
24 V power supply unit and the OBE-connection cable.
Depending on the order variant (see ordering code, page 2),
2 pieces of switching valve cables are included in the case.
Typ VT-HDTSY-1-2X
Technical data:
Design
Aluminum frame case with 2 locks, 3 hinges
Dimensions (B x H x D) mm
450 x 100 x 350
Weight kg
4,5
Power supply unit VT-HDTNT-5-2X
Table power supply unit 90-264 VAC →24 VDC; 5 A
The power connector of the power supply unit fits sockets
in Germany and many other European countries.
In some countries, a country-specific adapter needs to be
used. This is not included in the scope of delivery.
Type VT-HDTNT-5-2X (actual product may differ)
Technical data:
Operating voltage U VAC
90…264; 47…63 Hz
Current consumption Imax A
1,2
Fuse
electronic overload protection
Output voltage U VDC
24 ± 1 V; 5 A
Length of the power cable l m
approx. 1,5
Length of the cable to the test device l m
approx 1,5
Dimensions (B x H x D) mm
139 x 61 x 36
Weight m kg
0,46

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 12
OBE-Connection cable VT-HDTK-1-2X
Connection cable between test device VT-HDT-1-2X and
proportional valves with integrated electronics (valves with
ordering code K9 and K31 for the electrical connection)
Type VT-HDTK-1-2X (actual product may differ)
Technical data:
Connection for valve
Mating connector according to DIN EN 175201-804
Connection for test device
Connector Amphenol MS3106A 14S 6P
Length of connection cable l m
3
Weight m kg
0,3
Cable for switching valve VT-HDTSK-1-2X
Connection cable between test device VT-HDT-1-2X and
switching valves with electrical connection K4.
Type VT-HDTSK-1-2X (actual product may differ)
Technical data:
Connection for valve
Connector acc. DIN EN 175301-803, 2-po. + PE
Connection for test device
Connector BKL 0202001
Length of connection cable l m
3
Weight m kg
0,2
Notices:
When operating valves with electrical connection
K31, the ground conductor is interrupted.

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 13
Environmental protection and disposal:
Environmental protection:
Our products don´t contain no hazardous substances that they can release under normal conditions of use.
Normally, therefore, no negative effects on the environment are to be feared.
Disposal:
The products manufactured by us can be returned to us for disposal free of charge.
The prerequisite is, however, that no disturbing attachments such as oils, fats or other impurities are
included.
Furthermore, inappropriate foreign substances or components must not be included in the return.
The products are free to deliver to the address indicated on the back.
The packaging materials are made of cardboard, wood and polystyrene. They can be used easily everywhere.
For ecological reasons, the return transport should be avoided.

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 14
Notes:

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 15
Notes:

Bosch Rexroth GmbH Austria V1.08 / 2019-01 Page 16
Notes:
Bosch Rexroth GmbH
Industriepark 18
4061 Pasching
Österreich
Phone: [phone]
Fax: [phone]
E-Mail: [e-mail]
https://www.boschrexroth.at
© This document, as well as the data, specifications and other information
set forth in it, are the exclusive property of Bosch Rexroth AG. It may not
be reproduced or given to third parties without consent of Bosch Rexroth
AG. The data specified above only serve to describe the product. No
statements concerning a certain condition or suitability for a certain appli-
cation can be derived from our information. The information given does
not release the user from the obligation of own judgment and verification.
It must be remembered that our products are subject to a natural process
of wear and aging.
