Ecco 400 Series Owner's manual

920-0387-00 Rev A. Page 1 of 2
The 400 Series R65 LED Beacon features 12 powerful LED’s arranged to
produce a 360°  ash pattern, with a  ash rate of 125FPM for maximum
visibility. Now with additional features including multiple  ash patterns and
rotate functionality (non ECE R65). This Beacon is suitable for applications
where the UK lighting regulation Chapter 8 is a requirement. Combining the
solid state, maintenance free and long life nature of LED technology with
a proven tough housing design. This ECCO Group Europe, UK produced
beacon is designed to maximise resilience to excessive vibration and
increase the life of the product.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are
essential to ensure the safety of you and those you are seeking to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fi re.
4. Proper placement and installation are vital to the performance of this warning device. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that s/he
can operate the system without losing eye contact with the roadway.
5. Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an
air bag deployment area may reduce the effectiveness of the air bag or become a projectile that could cause serious per-
sonal injury or death. Refer to the vehicle owner’s manual for the air bag deployment area. It is the responsibility of the
user/operator to determine a suitable mounting location ensuring the safety of all passengers inside the vehicle particu-
larly avoiding areas of potential head impact.
6. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use,
the vehicle operator should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open
trunks or compartment doors), people, vehicles or other obstructions.
7. The use of this or any other warning device does not ensure all drivers can or will observe or react to a warning signal.
Never take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an
intersection, driving against traffi c, responding at a high rate of speed, or walking on or around traffi c lanes.
8. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying
all laws regarding warning signal devices. Therefore, the user should check all applicable city, state, and federal laws
and regulations. The manufacturer assumes no liability for any loss resulting from the use of this warning device.
Do not install and/or operate this safety product unless you have read and understand the safety
information contained in this manual.
Failure to install or use this product according to manufacturers recommendations may result in property damage, serious
injury, and/or death to those you are seeking to protect!
!
WARNING!
Installation and Operation Instructions
ED3766 Directional LED
Important! This unit is a safety device and it must be
connected to its own separate, fused power point to assure its
continued operation should any other electrical accessory fail.
Caution: When drilling into any vehicle surface, make sure the
area is free from any electrical wires, fuel lines, vehicle upholstery,
etc. that could be damaged
400 Series R65 LED Beacon

Wire:
920-0387-00 Rev A. Page 2 of 2
RED: = +VE (12-30V DC)
BLACK: = 0V
BLUE: = Connect permanently to GND (Black) for Simulated Rotate
YELLOW: = (Pattern Select and Synchronisation) – Connect to GND to cycle through the ash patterns. The patterns have
Phase A and B. Connect the Yellow with both Phase A and the unit will synchronise up to 4 Beacons. Connect beacons with
Phase A and B and the units will ash asynchronous
Flash Patterns:
Manufacturer Limited Warranty and Limitation of Liability:
Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specications for this product (which
are available from the Manufacturer upon request), and Manufacturer further warrants that this product is free from defects in materi-
als and workmanship. This Limited Warranty extends for thirty-six (36) months from the date of purchase. Other warranties may apply,
call Manufacturer for details. Manufacturer will, at its discretion, repair or replace any product found by the Manufacturer to be defec-
tive and subject to this Limited Warranty.
DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAP-
PROVED MODIFICATIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAIN-
TAINED IN ACCORDANCE WITH THE MAINTENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND
OPERATING INSTRUCTIONS VOIDS THIS LIMITED WARRANTY.
ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT WHICH MAY HAVE BEEN MADE BY SALESPEOPLE,
DEALERS, AGENTS OR OTHER MANUFACTURER’S REPRESENTATIVES DO NOT CONSTITUTE WARRANTIES. THIS LIMITED
WARRANTY MAY NOT BE AMENDED, MODIFIED, OR ENLARGED EXCEPT BY A WRITTEN AGREEMENT SIGNED BY AN AU-
THORIZED OFFICIAL OF MANUFACTURER WHICH EXPRESSLY REFERS TO THIS LIMITED WARRANTY.
Exclusion of Other Warranties: MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED. THE IMPLIED
WARRANTIES FOR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXCLUDED AND SHALL
NOT APPLY TO THE PRODUCT. BUYER’S SOLE AND EXCLUSIVE REMEDY IN CONTRACT, TORT, OR UNDER ANY OTHER
THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE THE REPLACEMENT OR REPAIR
OF THE PRODUCT AS DESCRIBED ABOVE.
Limitation of Liability: IN THE EVENT OF LIABILITY FOR DAMAGES ARISING OUT OF THIS LIMITED WARRANTY OR ANY
OTHER CLAIM RELATED TO THE MANUFACTURER’S PRODUCTS, MANUFACTURER’S LIABILITY FOR DAMAGES SHALL BE
LIMITED TO THE AMOUNT PAID FOR THE PRODUCT AT THE TIME OF THE ORIGINAL PURCHASE. IN NO EVENT SHALL MANU-
FACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY DAMAGE, OR
OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT,
IMPROPER INSTALLATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRE-
SENTATIVE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER
OBLIGATION OR LIABILITY WITH RESPECT TO THE PRODUCT OR ITS SALE, OPERATION AND USE, AND MANUFACTURER
NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH
SUCH PRODUCT.
This Limited Warranty denes specic legal rights. You may have other legal rights, which vary from state to state. Some states do not
allow the exclusion or limitation of incidental or consequential damages.
ECCO Group Europe
Victoria Industrial Park , Victoria Road , Leeds , LS14 2LA
T: [phone]
F: [phone]
www.eccogroup.com
Pattern No. Description Phase Other
0 Steady burn 10% duty cycle (1s sync) N/A
160 FPM Single Flash (400ms on) A
260 FPM Single Flash (400ms on) B
3125 FPM Single Flash (190ms on) AECE R65 Approved
4125 FPM Single Flash (190ms on) BECE R65 Approved
575 FPM Double Flash A
675 FPM Double Flash B
775 FPM Triple Flash A
875 FPM Triple Flash B
975 FPM Quad Flash A
10 75 FPM Quad Flash B
11 125 FPM Fast Double Flash AECE R65 Approved
12 125 FPM Fast Double Flash BECE R65 Approved
13 60 FPM Static Flash (Airport) AMeets the requirement of CAP 168
14 60 FPM Static Flash (Airport) BMeets the requirement of CAP 168
15 Off N/A
