Festo MPA-S User manual

Valve terminals MPA-S

Subject to change – 2017/12
2èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features
Innovative Versatile Reliable Easy to mount
Slim high-performance valves in
sturdy metal housing
MPA1 flow rates up to 360 l/min
MPA2 flow rates up to 700 l/min
From the individual valve to the
valve terminal with multi-pin plug,
AS-interface, CPI and fieldbus
connections and control block
Dream team: fieldbus valve
terminal suitable for electrical
peripherals CPX. This means:
– Forward-looking internal com
munication system for actuation
of the valves and CPX modules
– Diagnostics down to the
individual valve
– Valves can be actuated with
or without (standard) isolated
electrical circuits
Modular system offering a range of
configuration options
Expandable up to 128 solenoid
coils
Conversion and expansion possible
at a later date
Further manifold blocks can be
assembled using just three screws
and sturdy separating seals on
metal separator plates
Integration of innovative function
modules possible
Manual regulators, rotatable
pressure gauges
Proportional pressure regulators
Additional air supply via additional
pressure zones using supply plates
Wide range of pressures
–0.9 … 10 bar
Wide range of valve functions
Sturdy and durable metal
components
– Valves
– Manifold blocks
– Seals
Fast troubleshooting thanks to LEDs
on the valves and diagnostics via
fieldbus
Extensive operating voltage range
25%
Ease of servicing through
replaceable valves and electronics
modules
Manual override either non-detent
ing, detenting or secured against
unauthorised activation (covered)
Durable, thanks to tried and tested
piston spool valves
Large and durable labelling system,
suitable for barcodes
Ready-to-install unit, already
assembled and tested
Lower selection, ordering, installa
tion and commissioning costs
Secure mounting on wall or H-rail
mounting

2017/12 – Subject to change 3 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features
Reduced downtimes:
Two-colour LED diagnostics on site
Reliable operation:
Manual override non-detenting/detenting or with cover
Width 10 mm and 20 mm
Safe:
Operating voltage connection 25%, outputs
and valves can be disconnected separately
Compact:
Slim valves and flat plate silencers
Flexible:
– 64 valve positions/128 solenoid coils (FB)
– 24 valve positions/24 solenoid coils (MP)
Functional:
Sturdy metal thread or pre-assembled QS
fittings
Wide range of valve functions
Practical:
Large inscription labels
Quick mounting:
Directly using screws or on a H-rail,
automatic earthing
CPX diagnostic interface for hand
held devices (channel-oriented diag
nostics down to the individual valve)
Pneumatic interface to CPX
Straightforward electrical onnections
– Multi-pin plug connection
– Fieldbus connection
– Control block
– AS-interface
–CPI
Modular:
Supply plates facilitate the creation of
multiple pressure zones as well as numer
ous additional exhaust and supply ports
Equipment options
Valve functions
5/2-way valve, single solenoid
5/2-way valve, double solenoid
2x 3/2-way valve,
normally open
2x 3/2-way valve,
normally closed
2x 3/2-way valve,
1x normally open,
1x normally closed
5/3-way valve,
mid-position pressurised
5/3-way valve,
mid-position closed
5/3-way valve,
mid-position exhausted
2x 2/2-way valve,
1x normally closed,
1x normally closed, reversible
2x 2/2-way valve,
normally closed
1x 3/2-way valve,
normally closed,
external compressed air supply
1x 3/2-way valve,
normally open,
external compressed air supply
Manual pressure regulators
Proportional pressure regulators
Pressure sensor
All valves have the same compact
dimensions with an overall length of
107 mm and a width of 10.5 mm or
21 mm. A height of 55 mm makes
them a perfect match for the electrical
peripherals CPX.
Special features
Multi-pin terminal
Max. 24 valve positions/
max. 24 solenoid coils
Parallel modular valve linking via
circuit boards
Electronics module with integrated
holding current reduction
Any compressed air supply
Creation of pressure zones
Fieldbus terminal/control block
Max. 64 valve positions/
max. 128 solenoid coils
Internal CPX bus system for valve
actuation
Module for electrical valve actua
tion, via separate voltage supply or
without electrical isolation
Any compressed air supply
Creation of pressure zones
Individual valve
Electrical M8 connection, 4-pin
with screw connection
Detachable electronics module with
integrated holding current
reduction
AS-interface
2 to 8 valves, freely configurable
(max. 8 solenoid coils) with input
feedback
CPI interface
Max. 32 valve positions/
max. 32 solenoid coils
Combinable
MPA1 flow rates up to 360 l/min
MPA2 flow rates up to 700 l/min
MPA1 and MPA2 can be combined
on one valve terminal
Electrical supply plate
Increases the maximum number of
valve positions possible to 64, with
max. 128 solenoid coils
Creation of isolated, individually
disconnectable electrical circuits
(voltage zones)
Greater economy thanks to the
higher number of valves/solenoid
coils per valve terminal
Greater safety through individual
disconnection of valve groups, for
example for EMERGENCY-STOP
functions
-H- Note
The electrical supply plate is
available with either an M18 or
7/8” connection.

Subject to change – 2017/12
4èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features
Valve terminal configurator Online via: èwww.festo.com
Selecting an MPA valve terminal using
the online catalogue is quick and easy
thanks to the convenient valve
terminal configurator provided. This
makes it much easier to find the right
product.
The valve terminals are fully
assembled according to your order
specifications and are individually
tested. This reduces the assembly and
installation time to a minimum.
The valve terminal MPA is ordered
using the order code.
Ordering system for MPA
èInternet: mpa
Ordering system for CPX
èInternet: cpx
2D/3D CAD data Online via: èwww.festo.com
You can request the CAD data for a
valve terminal you have configured. To
do so, perform the product search as
described above. Go to the shopping
basket and click on the CAD icon
(compass). On the next page you can
generate a 3D preview or request
another data format of your choice by
e-mail.

2017/12 – Subject to change 5 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features
Individual connection
Valves can also be used on individual
sub-bases for actuators further away
from the valve terminal.
The electrical connection is estab
lished using a standard 4-pin M8 plug
(EN 60947-5-2).
Further information
èVMPA1
Multi-pin plug connection
The signal flow from the controller to
the valve terminal takes place via a
pre-assembled or self-assembled
multi-wire cable to the multi-pin plug
connection, which substantially
reduces installation time.
The valve terminal can be equipped
with max. 24 solenoid coils. This
corresponds to 4 to 24 MPA1 or 2 to
24 MPA2 valves, or a combination of
both.
Versions
Sub-D connection
Pre-assembled multi-pin cable
Multi-pin cable for self-assembly
AS-interface connection
A special feature of the AS-interface is
its ability to simultaneously transmit
data and supply power via a two-wire
cable. The encoded cable profile
prevents connection with incorrect
polarity.
The valve terminal with AS-interface is
available in the following versions:
With two to eight modular valve
positions (max. 8 solenoid coils).
This corresponds to 2 to 8 MPA1 or
2 to 8 MPA2 valves, or a
combination of both.
With all available valve functions.
The connection technology used for
the inputs can be selected as with
CPX: M8, M12, Harax, Sub-D,
Cage Clamp® (terminals to IP20).
Further information
èInternet: as-interface
CPI installation system
Valve terminal for CPI installation
system:
Valve terminals with CP connection
are intended for connection to higher-
order bus nodes or to control blocks.
A bus node or control block also en
ables the connection of decentralised
input/output units. The following bus
protocols are supported:
PROFIBUS DP
INTERBUS
DeviceNet
CANopen
CC-Link
EtherNet/IP
PROFINET
POWERLINK
EtherCAT
Sercos III
Four strings with up to 32 inputs and
outputs can be connected to a bus
node or control block. The connecting
cables transmit the power supply for
the input modules and the load volt
age for the valves as well as control
signals.
Further information
èInternet: ctec

Subject to change – 2017/12
6èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features
Fieldbus connection via the CPX system
An integrated fieldbus node manages
communication with a higher-order
PLC. This enables a space-saving
pneumatic and electronic solution.
Valve terminals with fieldbus inter
faces can be configured with up to
16 manifold blocks. In conjunction
with MPA1 and 8 solenoid coils per
manifold block, up to 128 solenoid
coils can thus be actuated. An MPA2
with 4 solenoid coils per manifold
block can actuate 64 solenoid coils.
Versions
PROFIBUS DP
INTERBUS
DeviceNet
CANopen
CC-Link
EtherNet/IP
PROFINET
POWERLINK
EtherCAT
Sercos III
Front End Controller Remote
Front End Controller
Remote I/O
Modbus/TCP
CPX terminal
èInternet: cpx
Control block connection via the CPX system
Controllers integrated in the Festo
valve terminals enable the construc
tion of stand-alone control units to
IP65, without control cabinets.
Using the slave operation mode, these
valve terminals can be used for intelli
gent pre-processing and are therefore
ideal modules for designing decentra
lised intelligence.
In the master operation mode,
terminal groups can be designed with
many options and functions which
can autonomously control a medium-
sized machine/system.
CPX terminal
èInternet: cpx
-H- Note
Note possible restrictions for the IP
protection class
èATEX conformity declaration

2017/12 – Subject to change 7 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Modular pneumatic components
The modular design of the MPA
facilitates maximum flexibility right
from the planning stage and offers
maximum ease of service in
operation.
The system consists of manifold
blocks and valves.
The manifold blocks are screwed
together and thus form the support
system for the valves.
They contain the connection ducts for
supplying compressed air to and vent
ing from the valve terminal as well as
the working lines for the pneumatic
drives for each valve.
Each manifold block is connected to
the next using three screws.
Individual terminal sections can be
isolated and further manifold blocks
inserted by loosening these screws.
This ensures that the valve terminal
can be rapidly and reliably extended.
Modular electrical peripherals
The manner in which the valves are
actuated differs according to whether
you are using a multi-pin terminal,
fieldbus terminal or individual valve.
The MPA with CPX interface is based
on the internal bus system of the CPX
and uses this serial communication
system for all solenoid coils and a
range of electrical input and output
functions.
Serial linking facilitates the following:
Transmission of switching
information
High valve density
Compact design
Position-based diagnostics
Separate voltage supply for valves
Flexible conversion without address
shifting
Transmission of status, parameter
and diagnostic data
èInternet: cpx
Option of CP interface
CPX-CEC as stand-alone controller
with access via Ethernet and web
server
MPA with electrical peripherals CPX Modularity with electrical peripherals CPX

Subject to change – 2017/12
8èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Individual sub-base
Ordering:
Using individual part numbers
Individual sub-bases can be equipped
with any valve (VMPA…of the
corresponding width).
The electrical connection is estab
lished using a standard 4-pin M8 plug
(EN 60947-5-2).
3
2
1
46
aJ
5
7
89
Description Brief description èPage/Internet
1Solenoid valve Width 10 mm, 14 mm, 20 mm VMPA1
2Manual override (MO) Non-detenting/turning with detent, per solenoid coil VMPA1
3Coded cover cap Manual override with non-detenting operation only once cover cap fitted VMPA1
4Covered cover cap Manual override blocked once cover cap fitted VMPA1
5Cover cap, manual override detenting Manual override detenting and operable without tools once cover cap fitted VMPA1
6Inscription label holder Can be pushed onto manual override VMPA1
7Sub-base For individual valve VMPA…VMPA1
8Fittings and/or silencers For working ports (2, 4) and air supply/exhaust ports (1, 3, 5) VMPA1
9Fittings, silencers or blanking plugs For pilot air supply/pilot exhaust air (12/14, 82/84) and pressure compensation VMPA1
aJ Electrical connection M8 4-pin VMPA1

2017/12 – Subject to change 9 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Pneumatic components of the valve terminal – Multi-pin plug, AS-interface
The manifold blocks are either
prepared for:
2 or 4 single solenoid valves
2 or 4 double solenoid valves
depending on the size.
Double solenoid valve positions
can be equipped with any valve or a
blanking plate.
Single solenoid valve positions can
only be equipped with single
solenoid valves.
aJ
aC
aA
89
aHbD bC
1
2
3
4
5
6
7aB
aD
aF
aG
aE
aH
aI
bJ
bB
bA

Subject to change – 2017/12
10 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Pneumatic components of the valve terminal – Multi-pin plug, AS-interface
Designation Brief description èPage/Internet
1Electronics module For connecting MPA1 or MPA2 valves 79
2Solenoid valve Width 10 mm 73
3Coded cover cap Manual override with non-detenting operation only once cover cap fitted 80
4Cover cap Manual override blocked once cover cap fitted 80
5Cover cap, manual override detenting Manual override detenting and operable without tools once cover cap fitted 80
6Inscription label holder Can be pushed onto manual override 83
7Blanking plate For unused valve position (vacant position), width 10 mm 80
8Mounting Optional for valve terminal mounting (on supply plate) 83
9Flat plate silencer – –
aJ Exhaust plate For ducted exhaust air 80
aA Regulator plate Vertical stacking (pressure regulator plate, vertical pressure shut-off plate, vertical supply
plate)
74
aB Solenoid valve Width 20 mm 73
aC Blanking plate For unused valve position (vacant position), width 20 mm 80
aD H-rail mounting – 83
aE Right-hand end plate – 78
aF Separating seal For manifold block 80
aG Fittings For working lines 82
aH Inscription label – 83
aI Manifold block For two valve locations, width 20 mm 77
bJ Fittings For pneumatic supply plate 82
bA Supply plate – 80
bB Electrical manifold module For multi-pin plug connection, for AS-interface 79
bC Manifold block For four valve locations, width 10 mm 77
bD Electrical interlinking module For multi-pin plug connection, for AS-Interface, for a sub-base with pneumatic supply plate
(on the left next to the sub-base)
79

2017/12 – Subject to change 11 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Pneumatic components of the valve terminal – CPI connection, fieldbus
The manifold blocks are either
prepared for:
2 or 4 single solenoid valves
2 or 4 double solenoid valves
depending on the size.
Double solenoid valve positions
can be equipped with any valve or a
blanking plate.
Single solenoid valve positions can
only be equipped with single
solenoid valves.
1
aB aE aF
bD
bF
aD
bE
aJ aC
bG
2
3
4
bA
bI bH
5
6
7 8 9 aA aG
aH
aI
bJ
bA
bB
bC

Subject to change – 2017/12
12 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Pneumatic components of the valve terminal – CPI connection, fieldbus
Designation Brief description èPage/Internet
1Electronics module – 79
2Solenoid valve Width 10 mm 73
3Coded cover cap Manual override with non-detenting operation only once cover cap fitted 80
4Cover cap Manual override blocked once cover cap fitted 80
5Cover cap, manual override detenting Manual override detenting and operable without tools once cover cap fitted 80
6Inscription label holder Can be pushed onto manual override 83
7Blanking plate For unused valve position (vacant position), width 10 mm 80
8Electrical manifold module For fieldbus connection, for proportional pressure regulator 79
9Mounting Optional for valve terminal mounting (on supply plate) 83
aJ Flat plate silencer – –
aA Exhaust plate For ducted exhaust air 80
aB Mounting Optional for valve terminal mounting
(on the manifold block of the proportional pressure regulator)
83
aC Electrical module For proportional pressure regulator 79
aD Proportional pressure regulator – 77
aE Regulator plate Vertical stacking (pressure regulator plate, vertical pressure shut-off plate, vertical supply
plate)
74
aF Solenoid valve Width 20 mm 73
aG Blanking plate For unused valve position (vacant position), width 20 mm 80
aH H-rail mounting – 83
aI Right-hand end plate – 78
bJ Separating seal For manifold block 80
bA Fittings For working lines 82
bB Manifold block For two valve locations, width 20 mm 77
bC Manifold block For proportional pressure regulator 77
bD Pressure sensor – 80
bE Fittings For pneumatic supply plate 82
bF Supply plate – 80
bG Electrical supply plate For auxiliary voltage supply for large valve terminals 79
bH Inscription label – 83
bI Manifold block For four valve locations, width 10 mm 77

2017/12 – Subject to change 13 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Valve terminal with multi-pin plug connection
Order code:
32P-… for the pneumatic
components
32E-… for the electrical
components
MPA valve terminals with multi-pin
plug connection can be expanded by
up to 24 solenoid coils.
The multi-pin plug connection is
designed as a removable 25-pin
Sub-D connection to IP65.
The cable can be selected when
ordering:
2.5 m
5 m
10 m
Each can be used for max. 8 or
24 valves.
1
23
4
5
67
Designation Brief description èPage/Internet
1Inscription labels Large, for multi-pin plug connection –
2Flat plate silencer For pneumatic interface –
3Exhaust plate For ducted exhaust air 80
4Multi-pin plug connection For self-assembly 81
5Multi-pin plug connection With multi-pin cable 81
6H-rail mounting – 83
7Electrical interface For multi-pin plug 78

Subject to change – 2017/12
14 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Valve terminal with AS-interface connection
Order code:
32P-… for the pneumatic
components
52E-… for the electrical
components
MPA valve terminals with AS-interface
connection can be expanded by up to
8 solenoid coils.
4
2
3
1
5
Designation Brief description èPage/Internet
1Manifold block – 78
2Flat plate silencer For pneumatic interface –
3Exhaust plate For ducted exhaust air 80
4Cover – –
5Electrical interface – 78

2017/12 – Subject to change 15 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Valve terminal with CPI connection
Order code:
32P-… for the pneumatic
components
56E-… for the electrical
components
MPA valve terminals with CPI
connection can be expanded by up to
32 solenoid coils.
3
1
2
4
Designation Brief description èPage/Internet
1Flat plate silencer For pneumatic interface –
2Exhaust plate For ducted exhaust air 80
3Electrical interface – 78
4Inscription label Large for CPI electrical interface –

Subject to change – 2017/12
16 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Peripherals overview
Valve terminal with fieldbus connection, control block (electrical peripherals CPX)
Order code:
32P-… for the pneumatic
components
50E-… for the electrical
components
Valve terminals with fieldbus inter
faces can be configured with up to
16 manifold blocks. In conjunction
with MPA1 and 8 solenoid coils per
manifold block, up to 128 solenoid
coils can thus be equipped. An MPA2
with 4 solenoid coils per manifold
block can actuate 64 solenoid coils.
Each valve position can be equipped
with any valve or a blanking plate. The
rules for CPX apply to the equipment
that can be used in combination with
the electrical peripherals CPX.
In general:
Digital inputs/outputs
Analogue inputs/outputs
Parameterisation of inputs and
outputs
Integrated multi-featured
diagnostic system
Preventive maintenance concepts
3
1
2
4
6
5
Designation Brief description èPage/Internet
1Flat plate silencer For pneumatic interface –
2Exhaust plate For ducted exhaust air 80
3CPX modules – –
4Pneumatic interface For CPX modules 78
5Inscription label Large, for pneumatic interface CPX –
6H-rail mounting – 83

2017/12 – Subject to change 17 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features – Pneumatic components
Sub-base valve
MPA offers a comprehensive range of
valve functions. All valves are
equipped with patented sealing
system which facilitates efficient
sealing, a broad pressure range and
long service life. To increase power
they have a pneumatic pilot control
supplied by pilot air.
Sub-base valves can be quickly
replaced since the tubing connectors
remain on the manifold block.
This design is also particularly flat.
Irrespective of the valve function there
are sub-base valves with one solenoid
coil (single solenoid) or with two
solenoid coils (double solenoid or two
single solenoid valves in one
housing).
Constructional design
Valve replacement Extension
The valves are attached to the metal
manifold block using two screws,
which means that they can be easily
replaced. The mechanical sturdiness
of the manifold block guarantees
excellent long-term sealing.
Blanking plates can be replaced by
valves at a later date. The dimensions,
mounting points and existing pneu
matic installations remain unchanged
during this process.
The valve code (M, MS, MU, J, N, NS,
NU, K, KS, KU, H, HS, HU, B, G, E, X, W,
D, DS, I) is located on the front of the
valve beneath the manual override.
5/2-way valve
Code Circuit symbol Width Description
[mm]
M 10,
20
Single solenoid
Pneumatic spring return
Reverse operation
Operating pressure –0.9 … +10 bar
MS 10,
20
Single solenoid
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +8 bar
MU 10 Single solenoid
Polymer poppet valve
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +10 bar
J 10,
20
Double solenoid
Reverse operation
Operating pressure –0.9 … +10 bar

Subject to change – 2017/12
18 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features – Pneumatic components
2x 3/2-way valve
Code Circuit symbol Width Description
[mm]
N 10,
20
Single solenoid
Normally open
Pneumatic spring return
Operating pressure 3 … 10 bar
NS 10,
20
Single solenoid
Normally open
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +8 bar
NU 10 Single solenoid
Polymer poppet valve
Normally open
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +10 bar
K 10,
20
Single solenoid
Normally closed
Pneumatic spring return
Operating pressure 3 … 10 bar
KS 10,
20
Single solenoid
Normally closed
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +8 bar
KU 10 Single solenoid
Polymer poppet valve
Normally closed
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +10 bar
H 10,
20
Single solenoid
Normal position
– 1x closed
– 1x open
Pneumatic spring return
Operating pressure 3 … 10 bar
HS 10,
20
Single solenoid
Normal position
– 1x closed
– 1x open
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +8 bar
HU 10 Single solenoid
Polymer poppet valve
Normal position
– 1x closed
– 1x open
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +10 bar

2017/12 – Subject to change 19 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features – Pneumatic components
5/3-way valve
Code Circuit symbol Width Description
[mm]
B 10,
20
Mid-position pressurised1)
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +10 bar
G 10,
20
Mid-position closed1)
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +10 bar
E 10,
20
Mid-position exhausted1)
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +10 bar
1) If neither solenoid coil is energised, the valve moves to its mid-position by means of spring force.
If both coils are energised at the same time, the valve remains in the previously assumed switching position.
3/2-way valve
Code Circuit symbol Width Description
[mm]
W 10,
20
Single solenoid
Normally open
External compressed air supply
Pneumatic spring return
Reverse operation
Operating pressure –0.9 … +10 bar
Compressed air (–0.9 … +10 bar) supplied at working port 2
can be switched with both internal and external pilot air supply.
X 10,
20
Single solenoid
Normally closed
External compressed air supply
Pneumatic spring return
Reverse operation
Operating pressure –0.9 … +10 bar
Compressed air (–0.9 … +10 bar) supplied at working port 4
can be switched with both internal and external pilot air supply.

Subject to change – 2017/12
20 èInternet: www.festo.com/catalogue/...
Valve terminals MPA-S
Key features – Pneumatic components
2x 2/2-way valve
Code Circuit symbol Width Description
[mm]
D 10,
20
Single solenoid
Normally closed
Pneumatic spring return
Operating pressure 3 … 10 bar
DS 10,
20
Single solenoid
Normally closed
Mechanical spring return
Reverse operation
Operating pressure –0.9 … +8 bar
I 10,
20
Single solenoid
1x normally closed
1x normally closed, reverse operation
Pneumatic spring return
Operating pressure 3 … 10 bar
Vacuum at port 3/5 only
-H- Note
A filter must be installed upstream of valves operated in
vacuum mode. This prevents any foreign matter in the intake air
getting into the valve (e.g. when operating a suction cup).
