Frama Fs 3 Series User manual

Fs Series 3
Quick Installation Guide
For more help with your installation, please visit:
www.frama.co.uk/Fs3
Remove tabs from
print heads before
inserting into unit!
2
Insert meter (b).
3
1
2
4
3
Plug in LAN cable (c), weigh platform cable (d -place weigh platform in position) and power cable (e).
Power the machine on.
4
1
Unpack box, remove packaging.
Press OK to start the installation.
5
Follow the step by step instructions.
OK
Installation Process
1 LAN
6
OK
Installation Process
Welcome to your mailing system. Press “OK”
to start the installation.
7
Your machine is now ready
to use. Please turn over
for your Quick User Guide.
Box contents includes:
3
Machine base
Postage Meter
(PSD)
LAN cable Power cable
Weighing platform
Ink Cartridge

Fs Series 3 Quick User Guide
Getting to know your Franking Machine Quick steps to franking your mail
£000.00
Mem: None
Acct:00000
1st Inl. Lett
No service
13.03.20 0g
Screen Information
2aTo weigh an item...
Put the mail on the platform:
1. Check that the A3 icon is
2. Otherwise press and select
the option: Standard weighing
A1 Rate and services (to change: B2)
A2 Date printed
A3 Weighing type (to change: B3)
A4 Messagenotication
A5 Postage and weight
A6 Memorized job (can contain rate, stamp settings and account)
A7 Current account
A5
A6
A7
A1
A2
A3
A4
Shortcut keys
B1 Sleep/On/Off-mode(amber/green/ashingamber)
B2 Rate and postal services selection
B3 Weighing modes
B4 Memorized jobs (rate, stamp settings and account)
B5 Credit management
B1
B4
B2
B5
B3
1To reset the machine...
Press:
to clear the information
on screen.
to wake the machine
up with default settings.
to return to the home screen.
2bor, if you know the weight...
Key the weight in manually:
1. Press and then select the
option: Manual weight entry
4When all steps are completed...
Print the stamp:
1. Insert the mail into the machine, the
stamp will print on the upper right hand
side.
2. Push the item to the back and right of the
machine. Hold in position until printing has
nished,thenremove.
2. Enter the weight and press
Adding credit
Press choose ‘Credit’ and follow the
instructions on screen.
Note: in order to add credit to the machine
there must be funds available
in your postage account.
Changing the ink cartridge
1. Open the machine by pulling the left
hand side front panel towards you.
2. On the keypad, press
and select Cartridge > Headset
Replacement. The cartridge
moves to a replacement position and
a waiting message is displayed on the
screen.
3. Pull the blue lever to free the empty
cartridge. Remove the cartridge.
4. On the new ink cartridge, remove the
protective strip from the printing head.
5. Insert the new ink cartridge in the
carriage, and then lock it by pushing the
blue lever back in place.
6. Close the front panel and
press on the control panel.
7. Follow the steps on screen.
3When the weight is displayed...
Select a rate (and services):
2. Use the keypad to choose a rate or
service option, or use the wizard for
access to more rates.
Currently selected rate and services
are indicated at the
top of the screen.
£000.47
1st Inl. Lett
No service
13.03.20 00015g
Change/add services:
1. Press
The Rate selection screen
is displayed.
£000.0
1st Inl. Lett
No service
26.07.16 0g
11st Class 22nd Class
4Inland 5Intl
8Wizard
3. When done, press
toconrmyourselectionandreturn
to the home screen.
To order consumables for your machine please call: [phone]
or visit www.framashop.co.uk
Formorespecicinformationonyourfranking
machine, please visit www.frama.co.uk/Fs3
A0127546/A - 29/10/2019
