HOW TO USE THIS INSTALL GUIDE
1
2
3
SELECT VEHICLE
PRINT PAGES NEEDED

20192022
SUBARU ASCENT
WITH AMPLIFIER
INSTALL GUIDE
RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE!
+
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.
PRODUCTS REQUIRED
iDatalink Maestro RR2 Radio Replacement Interface
iDatalink Maestro RR-SU3 Installation Harness
iDatalink compatible radio
PROGRAMMED FIRMWARE: SU3-RR2-DS

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITH AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 2
Radar Detectors
ELECTRONICS
Radar Installation Guides
Configuring the RR2’s Programmable
Outputs
Maestro RR2 Programmable
Outputs Guide
Installation, product information, vehicle
specific videos. VIDEO HELP
Last flash information, steering control
configuration, vehicle information. VERIFY FLASH
Software to program module. WEBLINK
WELCOME
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the install guide.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
NEED HELP?
1 866 427-2999
[email protected]
ADDITIONAL INFORMATION AND
ACCESSORIES

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITH AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 3
STEP 1
• Unbox the aftermarket radio and locate its main harness.
• Connect the wires from aftermarket radio main harness to
the SU3 T-harness and match the wire functions.
• Remove the factory radio.
Note: only connect purple/white wire to radio reverse input or
module damage will occur.
STEP 2
• Assemble the SU3 T-harness and connect it to the factory
radio harness.
STEP 3
• Plug the OBDII connector into the OBDII of the vehicle,
under driver dash.
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the RCA connectors to the aftermarket radio.
• Plug the AUX cable to the aftermarket radio.
• Plug the Backup camera cable to the aftermarket radio.
• Plug the Data cable to the data port of the aftermarket
radio.
Note: On Pioneer radio, ensure that there is nothing plugged
into the W/R port.
STEP 5
• Connect all the harnesses to the Maestro RR2 module then
test your installation.
Reverse Automatic Braking (RAB)
When in reverse, RAB and Parking Sensor buttons are
controlled by:
RAB ON/OFF - Tap left side of radio screen or SEEK DOWN
on the steering wheel.
Parking Sensor ON/OFF - Tap right side of radio screen or
SEEK UP on the steering wheel.
Note: On-screen controls require a radio that supports touch
screen control of the camera, but the steering wheel controls
will work regardless of radio.
2
INSTALLATION INSTRUCTIONS P1 /1

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITH AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 4
2
AUXAUX
BACKUP CAMBACKUP CAM
NC
NC
2
3
4
4
4
18
28
6
10
3
10
6
18
5
16
MAESTRO RR2 MODULE
STEP 1
MAIN
HARNESS
SU3 T-HARNESS
GREEN
GREEN/BLACK
PURPLE/BLACK
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
BLUE/WHITE - AMP. TURN ON (+)
PURPLE
STEP 4
STEP 5
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) *
LTGREEN - E-BRAKE (-)
BLUE - POWER ANTENNA
PINK - VEHICLE SPEED
WIRING DIAGRAM
WIRES FROM
VEHICLE
FACTORY RADIO HARNESS
STEP 2
STEP 3 OBDII CONNECTOR
SEE RADIO WIRE
REFERENCE
CHART
FOR RADIO WIRE
COLORS
DATA
CABLE
CONNECT TO
AFTERMARKET RADIO
NOT REQUIRED
STEERING WHEEL
CONTROL CABLE
PIONEER RADIO: ENSURE
THAT NOTHING IS PLUGGED
IN W/R PORT.
AUDIO
CABLE
WHITE
WHITE/BLACK
GRAY
GRAY/BLACK
LF RCA INPUT
RF RCA INPUT
* ONLY CONNECT TO RADIO REVERSE INPUT
OR MODULE DAMAGE WILL OCCUR

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITH AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 5
RADIO WIRE REFERENCE CHART
Wire
Description Polarity Wire Color on Maestro
T-Harness Wire Color on Alpine cable Wire Color on Kenwood/JVC
cable Wire Color on Pioneer cable
Illumination (+) Orange N/A Orange/White Orange/White
Reverse Light (+) Purple/White Orange/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green
VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink
Power Antenna (+) Blue Blue Blue N/A

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITH AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 6
MODULE DIAGNOSTICS
LED 2
LED 1
PROGRAMMING BUTTON
LED 1
Module/Firmware
status
LED 2 (RR2)
Bluetooth activity
LED STATUS DIAGNOSTIC
• or •RED or GREEN
flashing
LED flashes 1 or more times, either red or green, when a steering wheel
button is pressed : normal operation.
•1 RED flash Module has no firmware.
Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE.
•2 RED flashes Problem detected. Consult troubleshooting table.
•1 GREEN flash After radio boots up : Normal operation.
•3 GREEN flashes Bluetooth is activated.
Turns off after one minute: Normal operation.
• • OFF Normal operation (inactive).

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITH AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 7
TROUBLESHOOTING TABLE
PROBLEM SOLUTION
Gauges do not work, radio shows OBD2 Error 1 or Error 2. Ensure OBDII connector is securely attached to the OBDII connector of the
vehicle.
If you hardwired connections at the OBDII, check connections at the OBDII
connector. Make sure the RED/BROWN wire is on PIN 6 and the YELLOW/
BROWN wire is connected to PIN 14 of the OBDII connector. Do not use
T-Taps. Soldering or military splicing methods are recommended.
If anything else is connected to the OBD2 or CAN wires of vehicle
(programmer, throttle controller, insurance tracker, etc.) try unplugging it to
see if gauges work. If gauges work without it installed, call tech support for
options.
Reset the RR.
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and
that it is plugged into the black port on the Maestro RR. The red and blue
ports on the RR should be empty.
Make sure the correct radio model and serial number were entered during
the flash. Verify the radio’s serial number entered during the flash matches
what is listed on the radio screen. This can be found in the settings of the
radio, listed as Device Id, Device Number, or Serial Number.
The light on the Maestro is blinking RED TWICE but the radio is NOT turning
on.
If installing a modular radio and it is not turning on, ensure the screen is
secured and any trim pieces on the radio have been installed fully. Not
installing these fully will prevent radio from powering up and show a 2x red
error as well.
Test red and yellow wires for DC voltage at radio using a multimeter. Contact
support if no voltage on red or yellow.
The light on the Maestro is flashing RED ONCE. There is no firmware on the module; flash the RR module.
The Harman Kardon system has no sound. (if applicable) Ensure the BLUE/WHITE amp turn-on wire is connected. Ensure the 6-pin
connector (the plug with blue, green, green/black, purple, and purple/black
wires) on the T-harness is not connected to the car.
MAESTRO RR2 RESET PROCEDURE:
Turn the key to the OFF position, then disconnect all connectors from the module.
Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will flash RED rapidly (this may
take up to 10 seconds).
Release the programming button. Wait, the LED will turn solid GREEN for 2 seconds to show the reset was successful.
TECHNICAL ASSISTANCE
Phone: [phone]
Email: maestr[email protected]
IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest firmware from the manufacturer. Please visit the radio
manufacturer’s website and look for any updates pertaining to your radio.

20192022
SUBARU ASCENT
WITHOUT AMPLIFIER
INSTALL GUIDE
RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE!
+
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.
PRODUCTS REQUIRED
iDatalink Maestro RR2 Radio Replacement Interface
iDatalink Maestro RR-SU3 Installation Harness
iDatalink compatible radio
PROGRAMMED FIRMWARE: SU3-RR2-DS

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITHOUT AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 2
Radar Detectors
ELECTRONICS
Radar Installation Guides
Configuring the RR2’s Programmable
Outputs
Maestro RR2 Programmable
Outputs Guide
Installation, product information, vehicle
specific videos. VIDEO HELP
Last flash information, steering control
configuration, vehicle information. VERIFY FLASH
Software to program module. WEBLINK
WELCOME
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the install guide.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
NEED HELP?
1 866 427-2999
[email protected]
ADDITIONAL INFORMATION AND
ACCESSORIES

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITHOUT AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 3
STEP 1
• Unbox the aftermarket radio and locate its main harness.
• Cut the WHITE and GRAY RCA tips.
• Connect the wires from aftermarket radio main harness to
the SU3 T-harness and match the wire functions.
• Remove the factory radio.
Note: only connect purple/white wire to radio reverse input or
module damage will occur.
STEP 2
• Assemble the SU3 T-harness and connect it to the factory
radio harness.
STEP 3
• Plug the OBDII connector into the OBDII of the vehicle,
under driver dash.
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the AUX cable to the aftermarket radio.
• Plug the Backup camera cable to the aftermarket radio.
• Plug the Data cable to the data port of the aftermarket
radio.
Note: On Pioneer radio, ensure that there is nothing plugged
into the W/R port.
STEP 5
• Connect all the harnesses to the Maestro RR2 module then
test your installation.
Reverse Automatic Braking (RAB)
When in reverse, RAB and Parking Sensor buttons are
controlled by:
RAB ON/OFF - Tap left side of radio screen or SEEK DOWN
on the steering wheel.
Parking Sensor ON/OFF - Tap right side of radio screen or
SEEK UP on the steering wheel.
Note: On-screen controls require a radio that supports touch
screen control of the camera, but the steering wheel controls
will work regardless of radio.
1
INSTALLATION INSTRUCTIONS P1 /1

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITHOUT AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 4
1
AUXAUX
BACKUP CAMBACKUP CAM
2
3
4
4
4
18
28
6
10
3
10
6
18
5
16
MAESTRO RR2 MODULE
CUT AND REMOVE THE SPEAKER
WIRE JUNCTION CONNECTORS
STEP 1
MAIN
HARNESS
SU3 T-HARNESS
WHITE - LF SPEAKER (+)
WHITE/BLACK - LF SPEAKER (-)
GRAY - RF SPEAKER (+)
GRAY/BLACK - RF SPEAKER (-)
GREEN - LR SPEAKER (+)
GREEN/BLACK - LR SPEAKER (-)
PURPLE/BLACK - RR SPEAKER (-)
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
BLUE/WHITE - AMP. TURN ON (+)
PURPLE - RR SPEAKER (+)
STEP 4
STEP 5
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) *
LTGREEN - E-BRAKE (-)
BLUE - POWER ANTENNA
PINK - VEHICLE SPEED
WIRING DIAGRAM
WIRES FROM
VEHICLE
FACTORY RADIO HARNESS
STEP 2
STEP 3 OBDII CONNECTOR
SEE RADIO WIRE
REFERENCE
CHART
FOR RADIO WIRE
COLORS
DATA
CABLE
CONNECT TO
AFTERMARKET RADIO
NOT REQUIRED
STEERING WHEEL
CONTROL CABLE
PIONEER RADIO: ENSURE
THAT NOTHING IS PLUGGED
IN W/R PORT.
AUDIO
CABLE
* ONLY CONNECT TO RADIO REVERSE INPUT
OR MODULE DAMAGE WILL OCCUR

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITHOUT AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 5
RADIO WIRE REFERENCE CHART
Wire
Description Polarity Wire Color on Maestro
T-Harness Wire Color on Alpine cable Wire Color on Kenwood/JVC
cable Wire Color on Pioneer cable
Illumination (+) Orange N/A Orange/White Orange/White
Reverse Light (+) Purple/White Orange/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green
VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink
Power Antenna (+) Blue Blue Blue N/A

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITHOUT AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 6
MODULE DIAGNOSTICS
LED 2
LED 1
PROGRAMMING BUTTON
LED 1
Module/Firmware
status
LED 2 (RR2)
Bluetooth activity
LED STATUS DIAGNOSTIC
• or •RED or GREEN
flashing
LED flashes 1 or more times, either red or green, when a steering wheel
button is pressed : normal operation.
•1 RED flash Module has no firmware.
Flash module using Weblink Desktop and log in. Do NOT use DEMO MODE.
•2 RED flashes Problem detected. Consult troubleshooting table.
•1 GREEN flash After radio boots up : Normal operation.
•3 GREEN flashes Bluetooth is activated.
Turns off after one minute: Normal operation.
• • OFF Normal operation (inactive).

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU ASCENT WITHOUT AMPLIFIER 20192022
Automotive Data Solutions Inc. © 2023 7
TROUBLESHOOTING TABLE
PROBLEM SOLUTION
Gauges do not work, radio shows OBD2 Error 1 or Error 2. Ensure OBDII connector is securely attached to the OBDII connector of the
vehicle.
If you hardwired connections at the OBDII, check connections at the OBDII
connector. Make sure the RED/BROWN wire is on PIN 6 and the YELLOW/
BROWN wire is connected to PIN 14 of the OBDII connector. Do not use
T-Taps. Soldering or military splicing methods are recommended.
If anything else is connected to the OBD2 or CAN wires of vehicle
(programmer, throttle controller, insurance tracker, etc.) try unplugging it to
see if gauges work. If gauges work without it installed, call tech support for
options.
Reset the RR.
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and
that it is plugged into the black port on the Maestro RR. The red and blue
ports on the RR should be empty.
Make sure the correct radio model and serial number were entered during
the flash. Verify the radio’s serial number entered during the flash matches
what is listed on the radio screen. This can be found in the settings of the
radio, listed as Device Id, Device Number, or Serial Number.
The light on the Maestro is blinking RED TWICE but the radio is NOT turning
on.
If installing a modular radio and it is not turning on, ensure the screen is
secured and any trim pieces on the radio have been installed fully. Not
installing these fully will prevent radio from powering up and show a 2x red
error as well.
Test red and yellow wires for DC voltage at radio using a multimeter. Contact
support if no voltage on red or yellow.
The light on the Maestro is flashing RED ONCE. There is no firmware on the module; flash the RR module.
The Harman Kardon system has no sound. (if applicable) Ensure the BLUE/WHITE amp turn-on wire is connected. Ensure the 6-pin
connector (the plug with blue, green, green/black, purple, and purple/black
wires) on the T-harness is not connected to the car.
MAESTRO RR2 RESET PROCEDURE:
Turn the key to the OFF position, then disconnect all connectors from the module.
Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will flash RED rapidly (this may
take up to 10 seconds).
Release the programming button. Wait, the LED will turn solid GREEN for 2 seconds to show the reset was successful.
TECHNICAL ASSISTANCE
Phone: [phone]
Email: maestr[email protected]
IMPORTANT: To ensure proper operation, the aftermarket radio needs to have the latest firmware from the manufacturer. Please visit the radio
manufacturer’s website and look for any updates pertaining to your radio.

20182022
SUBARU CROSSTREK
WITH AMPLIFIER
INSTALL GUIDE
RETAINS STEERING WHEEL CONTROLS, FACTORY AMPLIFIER, AND MORE!
+
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here
in are the properties of their respective owners.
PRODUCTS REQUIRED
iDatalink Maestro RR2 Radio Replacement Interface
iDatalink Maestro RR-SU3 Installation Harness
iDatalink compatible radio
PROGRAMMED FIRMWARE: SU3-RR2-DS

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU CROSSTREK WITH AMPLIFIER 20182022
Automotive Data Solutions Inc. © 2023 2
Radar Detectors
ELECTRONICS
Radar Installation Guides
Configuring the RR2’s Programmable
Outputs
Maestro RR2 Programmable
Outputs Guide
Installation, product information, vehicle
specific videos. VIDEO HELP
Last flash information, steering control
configuration, vehicle information. VERIFY FLASH
Software to program module. WEBLINK
WELCOME
Congratulations on the purchase
of your iDatalink Maestro RR Radio
replacement solution. You are
now a few simple steps away from
enjoying your new car radio with
enhanced features.
Before starting your installation,
please ensure that your iDatalink
Maestro module is programmed
with the correct firmware for your
vehicle and that you carefully review
the install guide.
Please note that Maestro RR will
only retain functionalities that
were originally available in the
vehicle.
NEED HELP?
1 866 427-2999
[email protected]
ADDITIONAL INFORMATION AND
ACCESSORIES

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU CROSSTREK WITH AMPLIFIER 20182022
Automotive Data Solutions Inc. © 2023 3
STEP 1
• Unbox the aftermarket radio and locate its main harness.
• Connect the wires from aftermarket radio main harness to
the SU3 T-harness and match the wire functions.
• Remove the factory radio.
Note: only connect purple/white wire to radio reverse input or
module damage will occur.
STEP 2
• Assemble the SU3 T-harness and connect it to the factory
radio harness.
STEP 3
• Plug the OBDII connector into the OBDII of the vehicle,
under driver dash.
STEP 4
• Plug the aftermarket radio harnesses into the aftermarket
radio.
• Plug the RCA connectors to the aftermarket radio.
• Plug the AUX cable to the aftermarket radio.
• Plug the Backup camera cable to the aftermarket radio.
• Plug the Data cable to the data port of the aftermarket
radio.
Note: On Pioneer radio, ensure that there is nothing plugged
into the W/R port.
STEP 5
• Connect all the harnesses to the Maestro RR2 module then
test your installation.
Reverse Automatic Braking (RAB)
When in reverse, RAB and Parking Sensor buttons are
controlled by:
RAB ON/OFF - Tap left side of radio screen or SEEK DOWN
on the steering wheel.
Parking Sensor ON/OFF - Tap right side of radio screen or
SEEK UP on the steering wheel.
Note: On-screen controls require a radio that supports touch
screen control of the camera, but the steering wheel controls
will work regardless of radio.
2
INSTALLATION INSTRUCTIONS P1 /1

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU CROSSTREK WITH AMPLIFIER 20182022
Automotive Data Solutions Inc. © 2023 4
2
AUXAUX
BACKUP CAMBACKUP CAM
NC
NC
2
3
4
4
4
18
28
6
10
3
10
6
18
5
16
MAESTRO RR2 MODULE
STEP 1
MAIN
HARNESS
SU3 T-HARNESS
GREEN
GREEN/BLACK
PURPLE/BLACK
YELLOW - 12V (+)
BLACK - GROUND
RED - ACCESSORY (+)
BLUE/WHITE - AMP. TURN ON (+)
PURPLE
STEP 4
STEP 5
ORANGE - ILLUMINATION (+)
PURPLE/WHITE - REVERSE LIGHT (+) *
LTGREEN - E-BRAKE (-)
BLUE - POWER ANTENNA
PINK - VEHICLE SPEED
WIRING DIAGRAM
WIRES FROM
VEHICLE
FACTORY RADIO HARNESS
STEP 2
STEP 3 OBDII CONNECTOR
SEE RADIO WIRE
REFERENCE
CHART
FOR RADIO WIRE
COLORS
DATA
CABLE
CONNECT TO
AFTERMARKET RADIO
NOT REQUIRED
STEERING WHEEL
CONTROL CABLE
PIONEER RADIO: ENSURE
THAT NOTHING IS PLUGGED
IN W/R PORT.
AUDIO
CABLE
WHITE
WHITE/BLACK
GRAY
GRAY/BLACK
LF RCA INPUT
RF RCA INPUT
* ONLY CONNECT TO RADIO REVERSE INPUT
OR MODULE DAMAGE WILL OCCUR

SU3-RR2-DS-(RR-SU3)-EN maestro.idatalink.com
SUBARU CROSSTREK WITH AMPLIFIER 20182022
Automotive Data Solutions Inc. © 2023 5
RADIO WIRE REFERENCE CHART
Wire
Description Polarity Wire Color on Maestro
T-Harness Wire Color on Alpine cable Wire Color on Kenwood/JVC
cable Wire Color on Pioneer cable
Illumination (+) Orange N/A Orange/White Orange/White
Reverse Light (+) Purple/White Orange/White Purple/White Purple/White
E-Brake (-) Lt Green Yellow/Blue Lt Green Lt Green
VSS (vehicle speed sensor) (DATA) Pink Green/White Pink Pink
Power Antenna (+) Blue Blue Blue N/A
