JSI Flux User manual

Installation Instructions
Assembly of Modular Components
Recommended Tools
Page 1 of 2
g
Flux
Hardware Used
Step 1 Preparing the Modular Components
• Unpack the modular and place in the proper order for
installation, matching up the correct credenza top width.
• Remove drawers or doors to access the top fastening strip
inside the modular units as needed.
note: keep drawers in the correct order, each drawer has
been fitted to a particular location in the modular unit.
• Level in place the modular base cabinet to each of the
other cabinets.
Level
#8 x 5/8”
Pan Head
Wood Screws
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL017
3/25/18
Phillips Head BitScrew Gun
Screw Driver
multi file lateral file
file file
modular credenza top
Modular Components
Step 2 Assembling the Modular Components
• Use the bar clamp to secure and ensure the units are tight.
Fasten the unit together with #8 x 11/4”screws.
diagram 1
• Repeat above step as needed until all units are attached
side to side.
• Align the credenza top on to the units. Some tolerance has
been built into top width. Even out the tolerance from side to
side. Clamp the top into place.
diagram 2
• Fasten the top using #8 x 11/2” Pan Head Wood Screws.
• Re-install the drawer and doors into the units. Check to
make sure the unit is level.
diagram 1
diagram 3
diagram 2
box file wing end
two door pedestal
Bar Clamp (minimum qty of 2)
Style A
Modular Credenza with Side by Side Units
#8 x 11/2”
Pan Head
Wood Screws
#8 x 11/4”
Pan Head
Wood Screws

Installation Instructions
Assembly of Modular Components into Credenza Shell (continued)
Page 2 of 2
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL017
3/25/18
diagram 4
diagram 5
diagram 6
Step 1 Preparing the Modular Components
• Unpack the modular and place in the proper order for
installation,matching up the correct credenza top width.
• Remove drawers or doors to access the top fastening strip
inside the modular units as needed.
note: keep drawers in the correct order, each drawer has
been fitted to a particular location in the modular unit.
diagram 4
Step 2 Assembling the Modular Components
• Level in place the modular base cabinet to each of the
other cabinets, if applicable. Use the bar clamp to secure
and ensure the units are tight. Fasten the units together with
#8 x 11/4” screws.
diagram 1 in style A
• Align the credenza top on to the unit(s) and to the wing end.
Even out the top from side to side to the proper width. Clamp
the top into place.
diagram 5
• Fasten the top using #8 x 11/2” Pan Head Wood Screws
through the top fastening rails on the pedestal(s).
• Fasten the top using #8 x 5/8” Pan Head Wood Screws
screws through the brackets on the wing end.
• Re-install the drawer and doors into the units. Check to
make sure the unit is level.
Style B
Modular Credenza with Wing End
