JSI CAAV User manual

INSTALLATION INSTRUCTIONS
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Recommended tools
CAAV
SIDE MOUNT POWER INSTALL
STEP 1:
•Before attaching the attachment bracket locate
where the wood frame and the set foam meet
(see red line) you will be able to feel this
transition. The top of the attachment bracket
will need to align with the top of the frame
•The bracket can be moved forward or
backwards to suit the needs of the user, but
once the screws are installed there will be
permanent holes in the fabric.
•Screw the bracket down using the provided
screws. This can be done with the hand screw
driver –JSI doesn’t recommend the use of a
drill or power driver in the application. This
will help avoid pulling threads or foam when
installing.
Components for EC47 Power Unit shown
Attachment Bracket shown in different
color to be easily identified.
#8 x ½ pan head screws –4 per
Hardware enclosed

INSTALLATION INSTRUCTIONS
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Recommended tools
CAAV
STEP 2:
•Align tabs on cover with tabs on attachment plate
•Slide upwards until bottom tabs are touching
STEP 3:
•Feed cord thru top of cover plate
•Insert electrical unit into cover plate
•Threaded stud will exit thru both tabs
•Install thumb nut to lock in place
•Installation complete
SIDE MOUNT POWER INSTALL
#8 x ½ pan head screws –4 per
Hardware enclosed
