JSI SWISH Overhead Supports User manual

Installation Instructions
Overhead Supports
Recommended Tools
Hardware Used
Step 1
Attach Supports To Overhead
• #14 x 3/4”Pan Head Wood Screw,
8 per leg support
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546 Form No. INST-10003
• #14 x 3/4”Pan Head Wood Screw, 8 per leg
• #8 x 5/8”Pan Head Wood Screw, when applicable
Page 1 of 2
With Grommet No Grommet
#3 Phillips Head
#2 Phillips Head
Step 2
Determine Support Foot Needed
For Grommet or No Grommet
• Support legs are shipped with no
grommet foot. Foot can be switched by
removing two screws.
• When no grommet feet are used on either
support leg, the support legs will need to
be fastened to the bench top. (See Step 3).
Insert supports between metal trim

Installation Instructions
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546 Form No. INST-10003
Page 2 of 2
Overhead Supports
(continued)
Step 3
Insert Supports Onto Worksurface
• Insert Supports into worksurface grommet holes.
Insert Supports into
Grommet Holes
Leg Cover Removal Leg Cover Intall
Leg cover can
be removed
for electrical
routing.
Insert one side
of cover into leg,
rotate and snap
fit other side into
place.
Important: When overheads are applied
to worksurfaces without grommet holes,
the overhead must be fastened to
worksurface using #8 x 5/8”
wood screws, one
per support.
