JSI Reef User manual

Installation Instructions
Wall Dependent Panel Table
Recommended Tools
Page 1 of 3Reef
Package Contents
Step 1
Attach Stretcher Rail to End Panels
• Stand End Panels upright and attach Stretcher Rail
using 1/4 ”bolts. Tighten bolts firmly.
Hardware Used
1/4 x 1”Machine Bolts
#8 x 5/8 ”Flat Head Wood Screws
Top
End Panels
Stretcher Rail
Note: Two people are recommended for assembly.
#8 x 5/8 ”Pan Head Wood Screws
#2 Phillips Head Bit
#2 Phillips Screw Driver
Screw Gun
Level
Socket
Wrench
7/16 ”
Socket
3/16 ”
Hex Wrench
1/4 - 20 x 3/4 ” Socket Head Cap Screws
(Used with Foot Rail option)
1/4 x 1”Bolts
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-RE005
5/1/16

Installation Instructions
Page 2 of 3
Wall Dependent Panel Table
(continued)
Reef
Step 2
Attach Worksurface to Frame
• Place worksurface onto frame. Align edges accordingly.
• Fasten top to frame using all under surface brackets.
Use #8 x 5/8 ”flat head screws on triangle brackets
and #8 x 5/8 ”pan head screws on L-brackets.
Step 3
Level Table
• Position table against wall in desired location.
Level front-to-back and side-to-side by rotating
adjustable glides.
#8 x 5/8 ”
Flat Head Screws
#8 x 5/8 ”
Pan Head Screws
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-RE005
5/1/16

Installation Instructions
Table Options
Page 3 of 3Reef
Coat Hook
Attach Coat Hooks to End Panels
• Pilot holes have been factory pre-drilled for the two
coat hook locations. Use these holes and #8 x 5/8 ”
flat head screws to attach hooks to end panels.
Coat Hook
Foot Rail
#8 x 5/8 ”
Flat Head
Wood Screws
Wall Dependent Panel Table
(Options)
Coat Hook
Foot Rail
Foot Rail
Attach Foot Rail to End Panels
• Locate holes with threaded inserts towards bottom of end panels.
• Carefully slide Foot Rail into place between end panels.
Note: Bottom of End Panels may need to pulled out slightly as
not to scratch/mar inside surfaces.
• Fasten using 1/4 - 20 x 3/4 ” Socket Head Cap Screws.
Pilot Holes
#8 x 5/8 ”
Flat Head Screws
Threaded
Metal Inserts
Flange points down & inward
towards center of table
Slightly pull bottom of end panels outward
in order to slide Foot Rail into place
without marring surfaces
Coat Hooks
1/4 - 20 x 3/4 ”
Socket Head
Cap Screws
3/16 ”
Hex Wrench
1/4 - 20 x 3/4 ”
Socket Head
Cap Screw
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-RE005
5/1/16
