JSI Flux User manual

Installation Instructions
Assembling and Attaching
Run-off Desk with End Leg/Post Frame to a Support Credenza
Types of Credenzas
Page 1 of 2
Flux
Hardware Used
Level
#8 x 7/8”Wood Screws
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL011
1-22-18
Installers: Two set of brackets are included with the run-off
desk, flat brackets and stepped brackets. Credenza are offered
with aprons or no aprons.
Product Layout Plan
Phillips Head BitScrew Gun
Screw Driver
flush to top - use flat bracket
apron rail top - use stepped bracket
Recommended Tools
Pencil
Tape Measure
Drill Bit
Flat Bracket
Step Bracket
four (4) flat brackets
included
Step 1 End Frame Assembly / Post
Frame Assembly Installation
• Unpack the end leg assembly/post frame assembly
along with hardware.
• Align the top support rail perpendicular to the end leg
assembly/post frame assembly using the two
¼-20 pan head bolts to secure the top.
• Flip worksurface top upside down and lay on a flat
clean debris free pad.
• Place leg or post assembly onto the bottom side of
the worksurface top.
• Align the leg or post assembly with the pre-bored
holes on the top for the assembly.
(tabs on Top Support Rail are not pre-bored)
• Fasten assembly to the bottom side using #8 x 7/8 ”
pan head screws.
1/4 -20 x 3/4”Pan Head Screws
four (4) step brackets
included

Installation Instructions
Page 2 of 2
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL011
1/22/11
Step 2 FLAT - Attaching Brackets
• Determine the location (from the plan)of the of the
run-off desk. Make sure credenza is
level and placed correct as per layout location.
• Evenly space out bracket locations provided with
run-off desk. The flat bracket should be centered
half way between the bracket length.
recommended all brackets be used.
• Fasten the flat bracket to the credenza using the
provided screws, #8 x 7/8 ”.
Assembling and Attaching Run-off Desk with End Leg/Post Frame continued
diagram show placement for a 28” wide run-off desk top.
Step 2 STEP - Attaching Brackets
• Determine the location (from the plan) of the of the
run-off desk. Make sure credenza is level and placed
correct as per layout location.
• Evenly space out bracket locations provided with
run-off desk. To avoid interference with the run-off
desk support rail do not place any brackets
in the center. The step bracket should be up tight
against the apron rail as shown in the diagram.
recommended all brackets be used.
• Fasten the step bracket to the credenza using the
provided screws, #8 x 7/8 ”.
note: make sure the brackets are level
diagram show placement for a 28” wide run-off desk top.
Step 3 Attaching Run-off Desk
(Flat or Step Styles)
• Lift the run-off desk in to place, using the bracket on
the credenza as support.
• Measure the location and level the run-off
desk.
• Lift the run-off desk in to place, align the holes and
fasten the bracket to underside of the run-off desk
with the provided screws, #8 x 7/8 ”. as shown in the
diagram.
