JSI CAAV User manual

INSTALLATION INSTRUCTIONS
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Recommended tools
Hardware enclosed
CAAV
RUN-OFF TABLE AND MEDIA
PANEL ASSEMBLY
UNIT WILL BE MADE FROM 2 MODELS:
•(1) Run-off Table
•(1) Media Panel
STEP 1:
•Grab access media panel access door by the hand
hold
•Firmly pull straight out to disengage the clips
•Set access panel to the side during install
Run-off table leg pre-assembled. See
run-off table leg install instructions.
5/16 Flat Washer –4 per
5/16 Split Lock Washer –4 per
5/16-18 x 2-1/4 Hex Head Bolt –4 per

INSTALLATION INSTRUCTIONS
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Recommended tools
Hardware enclosed
CAAV
RUN-OFF TABLE AND MEDIA
PANEL ASSEMBLY
5/16 Flat Washer –4 per
5/16 Split Lock Washer –4 per
5/16-18 x 2-1/4 Hex Head Bolt –4 per
STEP 2:
•Insert the bolts thru the washers as shown
•Insert bolts/washers thru attachment holes
in the medial panel sub-top as shown
•Align bolts with the inserts in the bottom
of the run-off top
•Start all 4 bolts –once all are started firmly
tighten bolts
STEP 3:
•Align clips on access door to clips in chassis
and firmly snap panel back in place.
•Properly level media panel
•Neoprene pads on run-off table are self-
leveling
•Install complete
