JSI Flux Series User manual

Installation Instructions
Mounting of Peninsula Desks w/End Leg/Post Frame to Support Credenza
Recommended Tools
s
Page 1 of 3
Flux
Hardware Used
Step 1 Attaching Top Support
Rail
• Unpack the end leg assembly/post frame
assembly along with the hardware.
• Align the top support rail perpindicular to
the end leg assembly/post frame
assembly using the two ¼-20 pan
head bolts to secure the top.
Level
#8 x 7/8”Wood Screws
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL006
11/21/17
Installers: To properly install the Flux Peninsula Desk product you will
need a floor plan to assure proper installation. Peninsula Desk require
a secondary height credenza with factory installed mounting.
Product Layout Plan
Socket Wrench
Phillips Head BitScrew Gun
Screw Driver
1/4 -20 x 3/4”Pan Head Screws
5/16”-11/2”Hex Head Bolts
with Washer
(included with credenza)

Installation Instructions
Mounting of Peninsula Desks with End Leg/Post Frame continued
Page 2 of 3
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL006
11/21/17
Step 2 End Frame Assembly / Post Frame Assembly Installation
• Flip worksurface top upside down an lay on a flat clean debris free pad.
• Place leg or post assembly onto the bottom side of the worksurface top.
• Align the leg or post assembly with the prebore holes on the top.
(tabs on Top Support Rail are not pre-bored)
• Fasten assembly to the bottom side of the top using #8 x 7/8 ” pan head screws.
Step 3 Review the Layout
• The product offers two different locations to mount the peninsula desk to the secondary height credenza. The layout plan
should indicate the correct mounting location. Guide lines in this step will explain the flush mount location or the offset mount
location.
Flush Mount Location
back panel of top support flush
with back panel of credenza
Offset Mount Location
back panel of top support inset
5” from back panel of credenza
A
A
B

Installation Instructions
Mounting Peninsula Desks with End Leg/Post Frame continued
Page 3 of 3
Flux
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-FL006
11/21/17
Step 3 continued Review the Layout for Mounting Location
Step 4
Mounting the Peninsula Desk
• Align the correct mounting holes on the “double” T support with the
holes on the credenza top
• Layout with an overhead cabinet requires the offset mounting location. If using the wall panels the offset location mounting location is
also recommended.
5”
layouts with overhead
cabinets require offset mount
location
layouts with wall mount
items, recommend using
offset mount location
offset mount locations increases overall layout footprint by
approximately 5”
Step 4 Mounting the Peninsula Desk (Note: Prior to peforming Step 4 check for options see next page for Option A and or B)
A
A
B
position = flush mount location
position = offset mount location
A
A
B
• Fasten peninsula desk from inside the cabinet using 5/16” x 11/2” hex head
bolts with washer into the the bottom of the “double” T support.
• Finish by leveling the produc using the adjustable glides located on the end
leg assembly or the post frame assembly.
A
A
B
