JSI CAAV User manual

INSTALLATION INSTRUCTIONS
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Recommended tools
CAAV
GANGING INSTRUCTIONS
STEP 1:
•The modular/sectional unit will come with
ganging brackets pre-installed. One side will be
a “hook” and the other a “receiver”
•Align units as shown and slide close together
STEP 2:
•While pushing units together lift the side with
the “hook” so it can drop into the “receiver” as
shown
•Make sure “hook” is securely engaged in the
“receiver”
Receiver
Hook

INSTALLATION INSTRUCTIONS
NOTE: all screws provided must be
installed for proper installation and
compliance with product warranty.
Recommended tools
CAAV
STEP 3:
•Units are ganged and ready for the next unit to link
•In the instance the chair will be the last unit in the
setting you may want to remove the unused
ganging bracket.
•Lay unit over and remove the two screws attaching
the bracket
STEP 4:
•Link units together (same as steps 1 & 2)
•Properly level the units using the leveling glides
•Installation complete
GANGING INSTRUCTIONS
