Kenwood CS-5135 User manual

4OMHz
DUAL
TRACE
READOUT
OSCILLOSCOPE
40MHz
DUAL
TRACE
OSCILLOSCOPE
|
CS-5135
INSTRUCTION
MANUAL
KENWOOD
CORPORATION
GOO/AN>D|
©PRINTED IN JAPAN B50-7667-20(T)
92/12
1110987654321
91/21110987654321
SUPA

SAFETY
Symbol in This Manual
This symbol indicates where applicable cautionary or
other imformation is to be found.
Power Source
This equipment operates from a power source that does not
apply more than 250 V rms between the supply conductors
or between either supply conductor and ground. A protec-
tive ground connection by way of the grounding conductor
in the power cord is essential for safe operation.
Grounding the Product
This equipment is grounded through the grounding conduc-
tor of the power cord. To avoid electrical shock, plug the
power cord into a properly wired receptacle before connec-
ting to the equipment input or output terminals.
Use the Proper Power Cord
Use only the power cord and connector specified for your
product.
Use the Proper Fuse
To avoid fire hazard, use a fuse of the correct type.
Do not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an ex-
plosive atmosphere.
Do not Remove Cover or Panel
To avoid personal injury, do not remove the cover or panel.
Refer servicing to qualified personnel.
Voltage Conversion
If the power source is not applied to your product, contact
your dealer. To avoid electrical shock, do not perform the
voltage conversion.
CONTENTS
CS) asl Re eee een aren ary mE 2
FEATURES isc) ivintdsptnivsiatcnntiannitiaemngenins 3
SPECIFICATIONS .........c.ccssscssesssseseseeseseseesesees 4
A\PRECAUTIONS.........sesscsssssesseeseeseeseseeseeneeses 7
CONTROLS AND INDICATORS ..........:0:se0ee000 9
FRONT PANEL..:.:..:ccescesvescsteccersccscoasesecnsnansesdasass 9
REAR: PANEL i. iiesecieSutictacssinvsccsitesscostvesdescecdsuvasies 14
DIRECTIONS FOR USE.........sescscesessesesssseeseeees 15
READOUT DISPLAY (CS-5130 Only) ..........ceeeeeeeeee 15
OPERATING INSTRUCTIONS .........ccccccsesseseseees 16
INITIAL STARTING PROCEDURE. ..........scsssssessssesenses 16
[A] OPERATIONS AS A GENERAL-USE OSCILLOSCOPE16
(1) NORMAL SWEEP DISPLAY OPERATION ............ 16
(2) MAGNIFIED SWEEP OPERATION ..........sc.ssssee0 18
(3) ALTERNATE SWEEP OPERATION..............:0:0000 18
(4) X-Y OPERATION .....ccccsssssscsssseesssssscccssseesessesees 19
(5) VIDEO SIGNAL OBSERVATION.............cc0sscces0es 19
(6) SINGLE SWEEP OPERATION...........cscssssesesssseee 20
[B] READOUT OPERATION (CS-5130 Only).......:...0+. 20
APPLICATION 2 21cfecceeeisdvteistalivceacceetacisce 21
PROBE COMPENSATION........:scscesessecsessesseseeeseens 21
TRACE ROTATION COMPENSATION..........0c0c0c0000: 21
1. DC VOLTAGE MEASUREMENTS. ..........00cseeeeeeeees 21
2. MEASUREMENTS OF THE VOLTAGE
BETWEEN TWO POINTS ON A WAVEFORM ..... 22
3. ELIMINATION OF UNDESIRED SIGNAL
COMPONENTS .0...c.cssescssesssesesssesstesesseeseesses 23
4. VOLTAGE RATIO MEASUREMENT
USING CURSORS...0....cccssesscesecseesssessesseesseesees 23
5. TIME MEASUREMENTS ............ccsecsccecccserseecanves 24
6. TIME DIFFERENCE MEASUREMENT .............0-066+ 24
7. PULSE WIDTH MEASUREMENTS ...........0cssseeceeee 25
8. PULSE RISE TIME AND FALL TIME
MEASUREMENT. ...........cccscecceccrecssescenceeenerecs 26
9. PHASE DIFFERENCE MEASUREMENTS ............++ 27
10. TIME RATIO MEASUREMENT USING CURSORS ..28
11. FREQUENCY MEASUREMENTG...........0ccseeeevsers +29
12. RELATIVE MEASUREMENTS .............:ccccseeeceennee 30
13. PULSE JITTER MEASUREMENTS. ..........-ccereeeeeees 31
14, SWEEP MAGNIFICATIONS ...........scsssssssseesseesses 32
15. APPLICATION OF X-Y OPERATION ........c:sesssee0s: 32
A\MAINTENANCE........cscscssceseeeeesceesessesseneeseees 34
ACCESSORIES ........scccscscssssessescesssssssseeseeseaees 35
NOTE: This instruction manual is described for two models
CS-5130 and CS-5135. Refer to item applied to your
product.

FEATURES
.
High
vertical
axis
sensitivity
of
1
mV/div
and
wide
band-
width
that
covers
fully
specified
frequency
response
at
5
mV/div.
.
12-step
vertical
sensitivity
from
1
mV/div
to
5
V/div.
.
Vertical
mode
function
provides
automatic
trigger
sig-
nal
selection
correspondent
to
MODE
selector
setting.
.
Maximum
sweep
time
sweep
at
20
ns/div.
.
Alternate
sweep
function
enables
simultaneous
obser-
vation
of
a
desired
waveform
and
its
magnified
waveform.
. One-touch switchover to X-Y operation.
.
Automatic
fixing
function
eliminates
troublesome
syn-
chronization
operation.
.
Equipped
with
the
CH1
OUT
connector
for
monitoring
channel-1
input
signal.
9.
10.
11.
Five-revolution
DELAY
TIME
POSITION
potentiometer
offers
easy
setting.
The
readout
function
displays,
in
letters,
each
scale
fac-
tor
of
the
vertical
axis
input
sensitivity,
sweep
time,
etc.
on
the
CRT.
(CS-5130
only)
Cursor measurement mode (CS-5130 only)
The
cursor.
measurement
mode
displays,
in
letters,
vol-
tage
difference,
voltage
ratio,
time
difference,
time
ra-
tio,
frequency,
and
phase
difference
corresponding
to
movement
of
two
cursors.
This
display
provides
ac-
curate
waveform
observation
and
facilitates
data
col-
lection
by
photography.

SPECIFICATIONS
CS-5130 CS-5135
CRT
150 mm rectangular with internal graticule
Acceleration Voltage
~ 12 kV
Display Area
8x10 div (1 div=10 mm)
VERTICAL AXIS (CH1 and CH2)
Sensitivity
1 mV/div to 5 V/div: 1 mV to 2 mV/div +5%, 5 mV/div to 5 V/div +3%
Attenuator
12 steps, 1 mV/div to 5 V/div in 1-2-5 sequence
Vernier control for fully adjustable sensitivity between steps
Input Impedance
1 MQ +2%, approx. 30 pF
Frequency |
Response
DC to 40 MHz, within —3 dB (5 mV/div to 5 V/div)
DC to 15 MHz, within —3 dB (1 mV/div to 2 mV/div)
5 Hz to 40 MHz, within —3 dB (5 mV/div to 5 V/div)
5 Hz to 15 MHz, within —3 dB (1 mV/div to 2 mV/div)
Rise Time
8.7 ns (5 mV/div to 5 V/div)
17.5 ns (1 mV/div & 2 mV/div)
Signal Delay Time
Adequate to identify leading edge
Crosstalk
—40 dB or less (at 1 kHz)
Operating Modes
Single trace
Single trace
Two-waveform display, alternately
Chop Frequency
Channel Polarity
/\ Maximum Input Voltage
HORIZONTAL AXIS Input thru
Operating Modes
Two-waveform display, chopped
CH1+(+CH2) added display
Approx. 300 kHz
Normal or inverted, channel 2 only inverted
500 Vp-p or 250 V (DC +AC peak)
CH2, x10 MAG not included
X-Y operation is selectable with HORIZ MODE switch
CH1: Y axis
CH2 : X axis
Sensitivity
Same as vertical axis (CH2)
Input Impedance
Same as vertical axis (CH2)
Frequency | DC
DC to.1 MHz, within —3 dB
Response | AC
5 Hz to 1 MHz, within —3 dB
X-Y Phase Difference
3° or less at 100 kHz
A Maximum Input Voltage
Same as vertical axis (CH2)
SWEEP
Type A
A sweep
A sweep (intensified for duration of B sweep) and B sweep (delayed sweep) alternating
B
Delayed sweep
x-Y
X-Y oscilloscope operation
Sweep Time A
0.2 ps/div to 0.5 s/div +3%, in 20 ranges, in 1-2-5 sequence
Vernier control for fully adjustable sweep time between steps
B
0.2 ps/div to 50 ms/div +3%, in 17 ranges, in 1-2-5 sequence
Sweep Magnification
X10 (ten times) +5% (+8% in 0.2 ys-to-0.5 ws range)
Linearity
+3% (+5% for x10 magnification)
Holdoff
Continuously variable from NORM to more than ten time (MAX)
Trace Separation
Shifts
B
sweep
trace
continuously
in
vertical
direction
by
4
divisions
or
more
with
respect
to A
sweep
Delayed Sweep
Continuous delay (AFTER DELAY) & triggered delay (B TRIG’ D: triggered by A trigger)
Delay Time
Continuous adjustable from 0.2 us/div to 0.5 s/div

CS-5130
CS-5135
Delay Accuracy
+(3%
of
set
value+
1%
of
full
+4%
of
reading
on
CRT
scale) +(O to 300 ns)
Delayed
Jitter
2
10000
:
1
of
decupled
time
axis
A
set
value
TRIGGERING
;
Modes
AUTO,
NORM,
FIX,
&
SINGLE-RESET
Trigger
VERT
MODE
Triggered
by
input
signal
selected
with
vertical
MODE
selector
Source
CH1
Triggered
by
CH1
vertical
signal
CH2
Triggered
by
CH2
vertical
signal
LINE
.
Triggered
by
line
frequency
EXT
Triggered
by
external
trigger
signal
External
Trigger
Input
Impedance
1MQ+2%,
approx.
25
pF
A\
MAX.
EXT.
Input
Voltage
50
V
(DC+AC
peak)
Coupling
AC, HFrEJ, DC, TV-FRAME, & TV-LINE
Trigger Sensitivity | At NORM po
sition
AC
eee
Trigger frequency range
10 Hz to 20 MHz (INT: 1 div, EXT: 0.15 Vp-p)
‘2 10 Hz to 40 MHz (INT: 1.5 div, EXT: 0.2 Vp-p)
DC
HFREJ
TV
CALIBRATION VOLTAGE
AUTO: Same as above specifications
for above 50 Hz
Trigger frequency range
DC to 20 MHz (INT: 1 div, EXT: 0.15 Vp-p)
DC to 40 MHz (INT: 1.5 div, EXT: 0.2 Vp-p)
Trigger
frequency
range
is
more
than
50
kHz,
and
minimum
amplitude
(voltage)
required
for
sync
is
increased.
FRAME, LINE
INT: 1.0 div, EXT: 0.15 Vp-p
FIX: 50 Hz to 20 MHz (INT: 1.5 div, EXT: 200 mV)
50 Hz to 40 MHz (INT: 2.0 div, EXT: 250 mV)
1
V
p-p+3%,
square
wave,
positive
polarity,
approx.
1
kHz
INTENSITY MODULATION
Sensitivity
+5 V, positive voltage decreases brightness
Input Impedance
Approx. 10 kQ
Usable Frequency Range
DC to 5 MHz
A\ Maximum Input Voltage
50 V (DC +AC peak)
VERTICAL AXIS SIGNAL OUTPUT (CH1 only)
Output voltage
Output Impedance
[ Approx. 50 mVp-p/div (50 @ termination)
Approx. 50 2
Frequency Response
100 Hz to 40 MHz, — 3 dB/50 © termination
(1 mV/div, 2 mV/div: 100 Hz to 15 MHz, — 3 dB)
;
j
:
j
i
3

CS-5130 CS-5135
READOUT
Set Value CH1/CH2 scale factor (with probe detec-
tion); V-UNCAL, ADD, INVERT
A/B sweep scale factor (magnification con-
version): SWEEP-UNCAL, AFTER DELAY,
TRIG’ D, X-Y
Cursor Mode | Voltage difference between AREF and
A mode only Acursors on a CH1 scale factor basis
Voltage difference between AREF and
Acursors on a CH2 scale factor basis
Time difference between AREF and Acur-
sors on the basis of A sweep scale factor
Frequency between AREF and Acursors on
the basis of A sweep scale factor
Ratio: Voltage and time ratio between
AREF and Acursors, supposing
5-division on the CRT as 100%
Phase difference between AREF
and Acursors, supposing 5-divi-
sion on the CRT as 360°
NOTE: The X-Y mode allows AV1 measurement only.
Cursor Resolution 10 bits
Meas-
urement
Measurement +4%
accuracy
Measurable range AV, Ratio: + 3.6 div or more from the CRT
center
AT, 1/AT, Ratio, Phase: + 4.6 div or more
from the CRT center
TRACE ROTATION (Electrical, adjustable from front panel)
POWER REQUIREMENT
Line Voltage © 100 V/120 V/220 V +10%, 216 V—250 V
Line Frequency 50/60 Hz
Power Consumption Approx. 47 W | Approx. 41 W
DIMENSIONS (WxHxD) 319 (341) x 132 (145) x 380 (455) mm >
(__) dimensions include protrusion from basic outline dimensions
WEIGHT 9.0 kg | 8.5 kg
ENVIRONMENTAL
Within Specifications [ 10°C to 35°C, 85% max. relative humidity
zi O°C to 40°C, 85% max. relative humidity
Full Operation
ACCESSORIES SUPPLIED
Probe PC-33 (READOUT compatible probe) x 2 PC-30 x2
| Attenuation 1/10 1/1, 1/10
Input impedance 10 MQ, 25 pF +10% 1 MQ, 200 pF or less
10 MQ, 22 pF +10%
Power supply cable 1
Replacement Fuse 1AxX2,0.5Ax2
Instruction
Manual
1
* Circuit and rating are subject to change without notice due to developments in technology.

PRECAUTIONS
SAFETY
Before
connecting
the
instrument
to
the
power
source,
care-
fully
read
the
following
information,
then
verify
that
the
power
cord
and
power
line
fuse
are
ones
for
your
power
line.
The
instrument's
rear
panel
has
a
fuse
holder
on
the
left
of
the
AC
inlet
terminal
(the
fuse
holer
also
serves
as
a
vol-
tage
selector).
The
value
under
the
triangle
V
marked
on
the
holder
indicates
the
line
voltage
set
for
the
instrument.
lf
the
power
cord
is
not
applied
with
the
correct
voltage,
there is a danger from electric shock.
®
When
converting
the
voltage,
refer
to
the
Maintenance
section.
Line voltage
This
instrument
operates
using
ac-power
input
voltages
that
100/120/220/240
V
at
frequencies
from
50
Hz
to
60
Hz.
Power cord
The
ground
wire
of
the
3-wire
ac
power
plug
places
the
chassis
and
housing
of
the
oscilloscope
at
earth
ground.
Do
not
attempt
to
defeat
the
ground
wire
connection
or
float
the
oscilloscope;
to
do
so
may
pose
a
great
safety
hazard.
The
appropriate
power
cord
is
supplied
by
an
option
that
is
specified
when
the
instrument
is
ordered.
:
The
optional
power
cords
are
shown
as
follows
in
Fig.
1.
Line fuse
The
fuse
holder
is
located
on
the
rear
panel
and
contains
the
line
fuse.
Verify
that
the
proper
fuse
is
installed
by
replacing
the
line
fuse.
EQUIPMENT PROTECTION
1.
Never
allow
a
small
spot
of
high
brilliance
to
remain
sta-
tionary
on
the
screen
for
more
than
a
few
seconds.
The
screen
may
become
permanently
burned.
A
spot
will
occur
only
when
the
scope
is
set
up
for
X-Y
operation
and
no
signal
is
applied.
Either
reduce
the
intensity
so
the
spot
is
barely
visible,
switch
back
to
normal
sweep
operation
when
no
signal
is
applied,
or
set
up
the
scope
for
spot
blanking.
2.
Never
cover
the
ventilating
holes
on
the
top
of
the
os-
cilloscope,
as
this
will
increase
the
operating
tempera-
ture
inside
the
case.
3.
Never
apply
more
than
the
maximum
rating
to
the
os-
cilloscope
inputs.
A\
CHI,
CH2
INPUT
jacks:
500
Vp-p
or
250
V
(DC+AC
peak)
EXT
TRIG
INPUT
jack:
50
V
(DC
+AC
peak)
Z
axis
INPUT
jack:
50
V
(DC
+
AC
peak)
Never
apply
external
voltage
to
the
oscilloscope
out-
put
terminals.
4.
10.
Always
connect
a
cable
from
the
earth
ground
(GND)
jack
of
the
oscilloscope
to
the
chassis
of
the
equipment
under
test.
Without
this
caution,
the
entire
current
for
the
equipment
under
test
may
be
drawn
through
the
probe
clip
leads
under
certain
circumstances.
Such
con-
ditions
could
also
pose
a
safety
hazard,
which
the
ground
cable
will
prevent.
.
Always
use
the
probe
ground
clips
for
best
results.
Do
not
use
an
external
ground
wire
in
lieu
of
the
probe
ground
clips,
as
undesired
signals
may
be
introduced.
.
Operation
adjacent
to
equipment
which
produces
strong
ac
magnetic
fields
should
be
avoided
where
possible.
This
includes
such
devices
as
large
power
supplies,
transformers,
electric
motors,
etc.,
that
are
often
found
in
an
industrial
environment.
Strong
magnetic
shields
can
exceed
the
practical
CRT
magnetic
shielding
limits
and
result
interference
and
distortion.
.
Probe
compensation
adjustment
matches
the
probe
to
the
input
of
the
scope.
For
best
results,
compensation
of
probe
should
be
adjusted
initially,
then
the
same
pro-
be
always
used
with
the
input
of
scope.
Probe
compen-
sation
should
be
readjusted
whenever
a
probe
from
a
different
scope
is
used.
(See
page
21)
.
In
X-Y
operation,
do
not
pull
out
the
PULL
x
10
MAG
switch.
If
pulled
out
it,
noise
may
appeare
on
the
waveform.
.
When
turning
on
and
off
the
POWER
switch
repeated-
ly,
keep
an
interval
of
about
5
seconds.
Faster
on
and
off
operation
may
cause
malfunction
to
the
instrument.
Do
not
use
the
provided
PC-33
Probe
with
other
meas-
uring
equipment
because
it
incorporates
4
terminal
for
READOUT
detection
which
might
damage
the
other
equipment.
:

Fig. 1 Power Input Voltage Configuration
[ 2 Factory installed
d and pl H
Plug configuration Power cord and plug type ee cent ace Line cord plug fuse
North American
120 volt/60 Hz 1.0 A, 250 V "
Rated 15 amp Fast blow one
(12 amp max; NEC) 6x30 mm
Universal Europe 0.5 A, 250 V
220 volt/50 Hz T. lag None
Rated 16 amp 5x20 mm
U.K. 0.5 A, 250 V
240 volt/50 Hz Fast blow 0.5 A
Rated 13 amp 6x30 mm Type C
Australian 0.5 A, 250 V
240 volt/50 Hz Fast blow None
Rated 10 amp 6x30 mm
North American
240 volt/60 Hz 0.5 A, 250 V
Rated 15 amp Fast blow None
(12 amp max; NEC) 6x30 mm
Switzerland 0.5 A, 250 V
240 volt/50 Hz Fast blow None
Rated 10 amp 6x30 mm

CONTROLS
AND
INDICATORS
FRONT PANEL
CH1 4POSITION Control
Rotation
adjusts
vertical
position
of
CH1
waveform
on
the
screen.
In
X-Y
operation,
rotation
adjusts
vertical
position
of
display.
CH1 VOLTS/DIV Control
Vertical
attenuator
for
channel
1.
Provides
step
adjust-
ment
of
vertical
sensitivity
in
1-2-5
sequence.
VARI-
ABLE
control
is
turned
to
the
CAL
position,
the
calibrated
vertical
sensitivity
is
obtained.
In
X-Y
opera-
tion,
this
control
serves
as
the
attenuator
for
Y-axis.
CH1 VARIABLE Control
Rotation
provides
fine
controt
of
channel
1
vertical
sen-
sitivity.
In
the
fully
clockwise
(CAL)
position,
the
verti-
cal
attenuator
is
calibrated.
In
X-Y
operation,
this
control
serves
as
the
Y-axis
attenuation
fine
adjustment.
CH1 AC-GND-DC Switch
This switch is the CH1 vertical axis coupling mode
selector,
for
X-Y
operation,
the
Y-axis
coupling
mode
control.
AC:
AC
input
coupling
with
blocking
of
any
DC
sig-
nal component.
Vertical
amplifier
is
disconnected
from
the
in-
put
signal
and
connected
to
ground.
This
mode
is useful in determining the zero reference.
DC:
DC
coupling,
with
both
the
DC
and
AC
com-
ponents
of
the
input
signal
displayed
on
the
CRT.
GND:
CH1 INPUT jack
Vertical input for channel 1 trace in normal sweep oper-
ation. Y-axis input for X-Y operation.
Fig. 2
O® O@®
©
®® © ®
4 CH2 POSITION/PULL INVert Control
% CH2 POSITION:
Rotation
adjusts
vertical
position
of
channel
2
trace.
INV:
Push-pull
switch
selects
channel
2
signal
in-
verted
(PULL
INV)
when
pulled
out.
(Hereafter
PULL
INV
is
described
as
CH2
INV.)
CH2 VOLTS/DIV Control
Vertical
attenuator
for
CH2.
Provides
the
same
func-
tion
as
VOLTS/DIV
Control
@
for
CH1.
In
X-Y
opera-
tion,
the
control
serves
as
the
X-axis
attenuator.
CH2 VARIABLE Control
Rotation
provides
fine
control
of
channel
2
vertical
sen-
sitivity.
Provides
the
same
function
as
VARIABLE
Control
@)
for
CH1.
In
X-Y
operation,
this
control
serves
for
X-axis
at-
tenuation
fine
adjustment.
CH2 AC-GND-DC Switch
Three-position
lever
switch
which
operates
as
follows:
AC:
Blocks
DC
component
of
channel
2
input
signal.
GND:
Opens
signal
path
and
grounds
input
to
vertical
amplifier.
This
provides
a
zero-signal
base
line,
the
position
of
which
can
be
used
as
a
reference
when
performing
DC
measurements.
DC:
Direct
input
of
AC
and
DC
component
of
chan-
nel
2
input
signal.

10
Fig. 3
CH2 INPUT Jack
Vertical input for channel 2 trace in normal sweep oper-
ation. X-axis input in X-Y operation.
MODE Switch
Selects the basic operating modes of the oscilloscope.
CH1: Only the input signal to channel 1 is displayed
as a single trace.
CH2: Only the input signal to channel 2 is displayed
as a single trace.
ALT: Alternate sweep is selected regardless of sweep
time.
CHOP: Chop sweep is selected regardless of sweep
time at approximately 300 kHz.
ADD: The waveforms from channel 1 and channel 2
inputs are added and the sum is displayed as a
single trace. When the CH2 INV ©) button is en-
gaged, the waveform from channel 2 is sub-
tracted from the channel 1 waveform and the
difference is displayed as a single trace.
GND terminal/binding post.
Earth and chassis ground.
CAL Terminal
Provides 1 kHz, 1 V peak-to-peak square wave signal.
This is useful for probe compensation adjustment.
EXT TRIG INPUT Jack
Input terminal for external sync signal.
When SOURCE switch is selected in EXT position, the
input signal at the EXT TRIG INPUT jack becomes the
trigger.
QS © ® &8&®&
POWER Switch
A press of this switch turns the power ON.
POWER Indicator
Lights when the POWER switch is pressed.
INTEN (REAL) Control
Controller for adjusting brightness of the real-time
waveform.
INTEN (READOUT) Control (CS-5130 only}
Controller for adjusting brightness of the READOUT
value.
* By turning the controller clockwise up to the very
end, the READOUT value becomes brightest; turn-
ing counterclockwise turns readout function OFF and
makes the value disappear.
FOCUS/PULL ASTIG Control
FOCUS: Focus adjustment
ASTIG: Used to bring the waveform into the best
condition with the FOCUS adjustment by ad-
justing trace and spot aberration. Pull the
knob to make a spot circular.

SCALE
ILLUM/PULL
TRACE
ROTA
Control
SCALE
ILLUM:
Brightness
adjustment
of
the
scale
of
the
CRT.
For
photographing,
rotate
the
knob
to
adjust
brightness
to
prevent
halation
caused
by
too
bright
illumi-
nation.
Tilt
adjustment
of
the
horizontal
bright
line
in
the
case
where
geomagnetism
influences
the
bright
line
to
tilt.
TRACE ROTA:
A SWEEP TIME/DIV Control
Range
select
dial
of
19
ranges
from
0.2
ps/div
to
0.5
s/div.
To
calibrate
the
set
value,
rotate
the
SWEEP
VARIA-
BLE
controller
@)
clockwise
up
to
the
CAL
position.
B SWEEP TIME/DIV Control
Range
select
dial
of
17
ranges
from
50
ms/div
to
0.2
ysidiv.
Set
this
dial
to
a
value
same
as
the
A
SWEEP
TIME/DIV
@D
or
higher
than
it.
A SWEEP VARIABLE Control
Fine
sweep
time
adjustment.
In
the
fully
clockwise
(CAL)
position,
the
sweep
time
is
calibrated.
<4 > POSITION/PULL x 10 MAG Control
Horizontal
position
controller,
which
provides
horizon-
tal
shift
of
waveform.
By
pulling
the
knob,
the
sweep
time is quickened ten times.
In
the
X-Y
operation,
rotation
adjusts
horizontal
posi-
tion of display.
NOTE:
In
X-Y
operation,
keep
this
knob
pressed
(nor-
mal
sweep
mode).
LEVEL/PULL SLOPE (—)} Control
LEVEL:
Trigger
level
adjustment
determines
point
on
triggering
waveform
where
A
sweep
triggered.
PULL SLOPE (—) Switch:
Two-position
push-pull
switch.
Pulled
out
posi-
tion
selects
negative
going
(—)
slope
and
pushed
in
position
selects
positivegoing
(+)
slope
as
triggering
point
for
A
sweep.
HOLDOFF/PULL B TRIG’D Control
HOLD OFF:
Adjusts
holdoff
(trigger
inhibit
period
beyond
sweep
duration).
Clockwise
rotation
from
the
NORM
position
increases
holdoff
time,
up
to
10
times
at
the
MAX.
po-
sition
(fully
clockwise).
PULL B TRIG’D:
Pulling
out
the
knob
activates
B
TRIG’D
function.
B
sweep
starts
from
the
sweep
start
point
at
the
trigger
level
after
delay
time
set
with
the
A
SWEEP
TIME/DIV
and
AREF/DELAY
TIME
POSITION
@)
(DELAY
TIME
PO-
SITION
only
on
the
CS-5135)
has
passed.
The
trigger
signal
for
A
sweep
is
used
as
the
trigger
signal
for
B
sweep.
With
this
knob
depressed,
B
sweep
starts
af-
ter
delay
time
set
with
the
A
SWEEP
TIME/DIV
and
AREF/DELAY
TIME
POSITION
has
passed.
@ TRACE SEPARATION Control
Adjusts
vertical
separation
between
A
sweep
and
B
sweep
(control
has
effect
only
in
the
ALT
of
HORIZ.
MODE).
Clockwise
rotation
increases
separation;
B
sweep
moves
down
with
respect
to
A
sweep
up
to
4
divisions.
COUPLING Switch
Selects
coupling
for
sync
trigger
signal.
AC:
Trigger
is
AC
coupled.
Blocks
DC
component
of
input
signal;
most
commonly
used
position.
Sync
signal
is
DC
coupled
through
a
low-pass
filter
to
eliminate
high
frequency
components
for
stable
triggering
of
low
frequency
signals.
oc:
The
sync
signal
is
DC
coupled
for
sync
which
includes
the
effects
of
DC
components.
TV FRAME:
Vertical
sync
pulses
of
a
composite
video
sig-
nal are selected for triggering.
TV
LINE:
Horizontal
sync
pulses
of
a
composite
video
signal
are
selected
for
triggering.
HFrey:
SOURCE Switch
Sweep trigger source select switch.
VERT
MODE:
(Hereinafter
referred
to
as
V.MODE).
The
sweep
trigger
source
is
selected
with
the
MODE
selector
for
the
vertical
operation
(Y-
axis).
When
the
vertical
MODE
selector
is
set
to
CH1,
the
channel-1
signal
is
used
as
a
trig-
ger
source.
When
it
is
set
to
CH2,
the
channel-2
signal
is
used
as
a
trigger
source.
When
set
to
ALT,
both
the
channel-1
and
channel-2
signals
are
used
alternately.
When
set
to
CHOP
or
ADD,
the
channel-1
signal
is
used
as
a
trigger
source.
Channel
1
signal
is
used
as
a
trigger
source.
Channel
2
signal
is
used
as
a
trigger
source.
Sweep
is
triggered
by
line
voltage
(50/60
Hz).
NOTE:
When
the
COUPLING
switch
is.
set
to
other
than
AC
position,
the
syn-
chronization
cannot
be
carried
out.
Be
sure
to
set
the
COUPLING
switch
to
AC
position.
Sweep
is
triggered
by
signal
applied
to
EXT
TRIG
input jack @.
CH1:
CH2:
LINE:
EXT:
TRIGGERING
MODE
(Trig
MODE)
Control
Selects triggering mode.
AUTO:
Triggered
sweep
operation
when
trigger
sig-
nal
is
present,
automatically
generates
sweep
(free
runs)
in
absence
of
trigger
signal.
Normal
triggered
sweep
operation.
No
trace
is
presented
when
a
proper
trigger
signal
is
not
applied.
X-Y
operation.
Channel
1
input
signal
pro-
duces
vertical
deflection
(Y-axis).
Chan
nel
2
input
signal
produces
horizontal
defile
ction
(X-axis).
This
operates
regardless
vertical
MIODE
selection.
NORM:
11

12
SINGLE: Single-sweep mode
NOTE: Dual-trace single-sweep observation is
not possible if the vertical operation
MODE is set to ALT. Be sure to set the
MODE to CHOP.
RESET: Reset mode of single-sweep operation. When
reset, the switch returns to the SINGLE posi-
tion, with the READY LED @) lighting until com-
pletion of sweep.
READY Indicator
When reset in single-sweep operation, this lamp lights
and remains lit until the sweep operation is completed.
HORIZ MODE (HORIZONTAL MODE) Switch
Used to select the horizontal display mode.
A: Only A sweep is operative, with the B sweep
dormant.
ALT: A-sweep alternates with the B sweep. For this
mode of operation, the B sweep appears as an
intensified section on the A sweep.
B: Only delayed B sweep is operative.
X-Y: Channel 1 becomes the Y-axis and channel 2
becomes the X-axis for X-Y operation. The set-
ting of the vertical MODE and TRIG MODE
switches have no effect.
CURSORS Switch (CS-5130 only)
Cursor measurement mode select switch.
NOTE: Cursor measurement is impossible if the HO-
RIZ MODE selector @ is set to- ALT or B.
Fig. 4
OFF:
AV 1:
Cursor measurement is not performed. The
cursor, and cursour measurement mode and
cursor measurement value are not displayed
on the CRT.
Two horizontal cursor lines are displayed on
the CRT, and voitage difference and voltage
ratio between them are displayed in the upper
right on the CRT posterior to the cursor
measurement mode display.
Setting the CH1 VARIABLE controller @) to the
CAL position causes voltage difference meas-
urement, and a value calculated in accordance
with setting of the CH1 VOLTS/DIV control @)
is displayed posterior to AV1.
Setting the CH1 VARIABLE controller @ to the
UNCAL position causes voltage ratio me asure-
ment, and a value calculated assuming that
5-division as 100% is displayed posterior to
the RATIO.
When the A cursor is below the 4 REF cursor,
a negative value is displayed.
NOTE: Setting of the MODE select switch @)
to the CH2 position causes 4 V2 mode
cursor measurement.

AV2:
AT:
1/AT:
Two
horizontal
cursor
lines
are
displayed
on
the
CRT,
and
voltage
difference
and
voltage
ratio
between
them
are
displayed
in
the
upper
right
on
the
CRT
posterior
to
the
cursor
measurement
mode
display.
Setting
the
CH2
VARIABLE
controller
(8)
to
the
CAL
position
causes
voltage
difference
mea-
surement,
and
a
value
calculated
in
accordance
with
setting
of
the
CH2
VOLTS/DIV
control
®
is
displayed
posterior
to
AV2.
Setting
the
CH2
VARIABLE
controller
@)
to
the
UNCAL
position
causes
voltage
ratio
measure-
ment,
and
a
value
calculated
on
the
basis
of
5-division
as
100%
is
displayed
posterior
to
the
RATIO.
When
the
A
cursor
is
below
the
AREF
cursor,
a minus value is displayed.
NOTE:
Setting
of
the
MODE
select
switch
@
to
the
CH1
position causes
AV1
mode
cur-
sor
measurement.
Setting of the HORIZ MODE select
switch @ to the X-Y position disables
AV2 mode measurement.
Two
vertical
cursor
lines
are
displayed
on
the
CRT,
and
time
difference
and
time
ratio
between
them
are
displayed
in
the
upper
right
on
the
CRT
posterior
to
the
cursor
measurement
mode
display.
Setting
the
SWEEP
VARIABLE
controller
@
to
the
CAL
position
causes
time
difference
meas-
urement,
and
a
value
calculated
in
accordance
with
setting
of
the
A
SWEEP
TIME/DIV
control
@) is displayed posterior to AT.
Setting
the
SWEEP
VARIABLE
controller
@
to
the
UNCAL
position
causes
time
ratio
measure-
ment,
and
a
value
calculated
assuming
that
5-division
as
100%
is
displayed
posterior
to
the
RATIO.
When
the
A
cursor
is
on
the
left
of
the
4
REF
cursor, a minus value is displayed.
NOTE:
Setting
of
the
HORIZ
MODE
select
switch
@
to
the
X-Y
position
disables
AT
mode
measurement.
Two
vertical
cursor
lines
are
displayed
on
the
CRT,
and
frequency
and
phase
difference
bet-
ween
them
are
displayed
in
the
upper
right
on
the
CRT
posterior
to
the
cursor
measurement
mode
display.
Setting
the
SWEEP
VARIABLE
controller
@®
to
the
CAL
position
causes
frequency
measure-
ment,
and
a
value
calculated
in
accordance
with
setting
of
the
A
SWEEP
TIME/DIV
control
@
is
displayed
posterior
to
1/AT.
Setting
the
SWEEP
VARIABLE
controller
@
to
the
UNCAL
position
causes
phase
difference
measurement,
and
a
value
calculated
assuming
that
5-division
as
360°
is
displayed
posterior
to
the
PHASE.
When
the
A
cursor
is
on
the
left
of
the
4
REF
cursor,
a
minus
value
is
displayed.
However,
fre-
quency
is
displayed
in
an
absolute
value.
NOTE:
Setting
of
the
HORIZ
MODE
select
switch
@
to
the
X-Y
position
disables
1/AT
mode
measurement.
@ A Control (CS-5130 only)
Controller
for
shifting
the
measuring
cursor
(rough
dot-
ted
line)
out
of
two
cursor
lines
displayed
on
the
CRT
in
the
cursor
measurement.
By
rotating
the
controller
clockwise,
the
cursor
line
moves
upward
or
rightward:
by
rotating
counterclockwise,
it
moves
downward
or
leftward.
4 REF/DELAY TIME POSITION Control
(DELAY
TIME
POSITION
only
on
the
CS-5135)
Controller
for
shifting
the
reference
cursor
(small-dotted
line)
out
of
two
cursor
lines
displayed
on
the
CRT
in
the
cursor
measurement.
By
rotating
the
controller
clock-
wise,
the
cursor
line
moves
upward
or
rightward:
by
rotating
counterclockwise,
it
moves
downward
or
leftward.
This
controller
is
also
used
to
set
delay
time
of
the
B
sweep
start
point
from
the
A
sweep
start
point,
if
the
HORIZ
MODE
selector
is
set
to
ALT
or
B
position.
(DE-
LAY
TIME
POSITION)
It
controls
delay
time
continuously
between
0.2
and
10
times
of
a
set
value
with
the
A
SWEEP
TIME/DIV
con-
troller.
13

CONTROLS AND INDICATORS
REAR PANEL
14
Z AXIS INPUT Jack
External intensity modulation input; TTL compatible.
Positive voltage increases brightness, negative voltage
decreases brightness.
CH1 OUTPUT Jack
CH1 vertical output signal connector.
AC coupled output connector. Do not connect CH1
OUTPUT to channel 2 input as cascaded operation.
Fuse Holder, Line Voltage Selector
Contains the line fuse. Verify that the proper fuse is in-
stalled when replacing the line fuse.
100 V, 120 Vi... eececeeseecsctseserenecenersseeesenaenaran ers 1A
220 V, 240 V...cceceecceceteeeseeeeeneereeeenecenenseoen O.5A
After pulling the power cord plug from the power out-
let, adjust this selector to your line voltage.
Power Input Connector
Input terminals of power supply. Connect the AC cord
provided.

DIRECTIONS
FOR
USE
READOUT
DISPLAY
(CS-5130
Only)
(1)
POSITIONS
OF
THE
DISPLAY
Displays
the
scale
factors,
cursor
measure-
ment
data,
etc.
at
the
following
positions
on
the CRT.
1 Cursor mode
3.CH1 scale factor 5 ADD
2
Cursor
measurement
value
7 A sweep scale factor
6CH2 invert 4CH2 scale factor 8 B sweep scale factor
(2)
DISPLAY
CONTENTS
1
Cursor
Mode
The
current
setting
cursor
mode,
which
depends
on
the
combination
of
the
operation
controls,
is
displayed.
AV1,
AV2,
AT,
1/AT,
RATIO,
PHASE
2 Cursor Measuring Data
The
result
measured
by
the
two
cursors
is
displayed.
In
the
1/AT
mode,
when
the
two
cursors
approach
each
other
and
the
measurement
nears
its
limit,
a
‘’?’’
will
be
displayed
in
front
of
the
measured
data.
This
shows
that
the
measured
data
is
not
available.
3 CH1 Scale Factor
Displays
the
CH1
vertical
axis
sensitivity
to
one
division.
When
not
in
CAL
mode.
a
‘’>”’
is
displayed
posterior
to
CH1.
NOTE:
This
is
not
displayed
when
the
MODE
switch
(@)
is set to CH2.
4 CH2 Scale Factor
Displays
the
CH2
vertical
axis
sensitivity
to
one
division.
When
not
in
CAL
mode.
a’
>”’
is
displayed
posterior
to
CH2.
NOTE:
This
is
not
displayed
when
the
MODE
switch
(i)
is set to CH1.
5 ADD
‘+
4."
ig
displayed
when
the
MODE
switch
@)
is
set
to
ADD.
Fig. 6
6 CH2 INVERT
The
inverted
polarity
of
CH2
‘’!”
is
displayed
by
con-
trolling
the
¥
POSITION/PULL
INV
©.
A Sweep Scale Factor
Displays
a
sweep
range
selected
with
the
A
SWEEP
TIME/DIV
@).
When
the
SWEEP
VARIABLE
is
not set
to
CAL
mode,
a
“">"’
is
displayed
posterior
to
A.
B Sweep Scale Factor
Displays
a
sweep
range
selected
with
the
B
SWEEP
TIME/DIV
if
the
HORIZ
MODE
@
is
set
to
ALT
or
B.
By
pulling
the
<>
POSITION/PULL
x
10
MAG
@,
1/10
scale
factors
of
the
A
SWEEP
TIME/DIV
@
and
B
SWEEP
TIME/DIV
@
are
displayed.
If
the
HORIZ
MODE
@
is
set
to
X-Y
position,
‘“’X-Y"’
is
displayed instead
of
Aand
B
sweep
ranges.
Delay Time
The
cursor
mode
and
cursor
measuring
data
are
not
dis-
played
if
the
HORIZ
MODE
@
is
set
to
ALT
or
B,
‘‘DE-
LAY’”’
is
displayed
in
place
of
the
cursor
mode,
and
a
delay
time
is
displayed
in
place
of
the
cursor
measuring
data.
If
the
triggered
delay
(B
TRIG’D)
is
selected,
“2
%ES
dis-
played
posterior
to
DELAY.
:
15

OPERATING INSTRUCTIONS
refer to the item ‘’Front Panel’’. In the case of using a pro-
be, refer to the Operation Manual attached to the probe as
INITIAL STARTING PROCEDURE
Prior to turning the power ON, set the switches as in the
drawing below in advance. For details of switch setting,
POWER OFF
Rotate counter
clockwise up to
the very end
Three o'clock
position
Center push
Rotate counter
clockwise up to
the very end
[A] OPERATION AS A GENERAL-USE OSCIL-
LOSCOPE
(1) Normal sweep display operation
1. Press the POWER switch (5 to supply power, and the
POWER LED (6 lights.
2. A bright line appears in the CRT center. If it is not in the
center, adjust its position to the center with the ¥ POSI-
TION controller @). Then, adjust the brightness with the
INTENSITY controller (2), and the focus, with the FOCUS
controller as required for easy observation.
3. Supply input signal into the CH1 INPUT jack ©). Rotate
the VOLTS/DIV control @ to adjust waveform to ap-
propriate dimensions.
Set the MODE select switch (1) to CH2. Then, supply in-
put signal into the CH2 INPUT connector (2. Its wave-
form is displayed on the CRT in the same procedures with
channel 1.
When the MODE select switch is set to ADD, the com-
posite waveforms of CH1 and CH2 (the algebraic sum
of CH1 + CH2) is displayed on the CRT. In this status,
if CH2 INV is engaged by pulling out the CH2 ¥ POSI-
TION, the algebraic difference between CH1 and CH2
(CH1 - CH2) will be displayed.
The sensitivity of the ADDed waveform becomes the
same as the value indicated by VOLTS/DIV provided that
the same VOLTS/DIV value has been set for the wave-
forms of the two channels.
When the MODE select switch (i) is set to ALT, the
channel-1 and channel-2 waveforms are displayed alter-
nately in every sweep. Waveform of each channel is trig-
gered independently. If the MODE select switch @ is set
to CHOP, channel-1 and channel-2 waveforms through
chopped triggering are displayed. If the SOURCE select
switch @ is set to V. MODE, the channel-1 signal only
16
well as the application example ‘‘Probe Compensation’.
Center push AC V.MODE
AUTO
1 ms/DIV {A)
1 ms/DIV (B)
CAL
Center Push
5 V/DIV CH1 | CAL Center AC
AC Center CAL 5 V/DIV Push
is triggered. To make the channel-2 signal triggered, set
the SOURCE select switch @ to CH2.
. The display on the screen will probably be unsynchroniz-
ed. Refer to TRIGGERING procedure below for adjusting
synchronization and sweep speed to obtain a stable dis-
play showing the desired number of waveform.
TRIGGERING
The input signal must be properly triggered for stable
waveform observation, TRIGGERING is possible the in-
put signal INTernally to create a trigger or with an EX-
Ternally provided signal of timing relationship to the
observed signal, applying such a signal to the EXT. TRIG
INPUT jack @.
(1) The selection of a signal that serves as the trigger
signal is made using the SOURCE switch @.
* Internal Sync
When the SOURCE selector is set to V.MODE,
CH1, CH2 or LINE, the input signal is connected to
the internal trigger circuit. In this position, a part of
the input signal fed to the INPUT jack (©) or @ is ap-
plied from the vertical amplifier to the trigger circuit
to cause the trigger signal synchronously with the
input signal to drive the sweep circuit. If the SOURCE
select switch is set to V.MODE, the trigger signal
is selected in compliance with the vertical MODE
selector setting. (Refer to the section “CONTROLS
AND INDICATORS”’.) Setting the vertical MODE
selector to ALT causes independent trigger to the
channel-1 and channel-2 signals respectively, ena-
bling two signals with no time relationship to be ob-
served.
If the SOURCE select switch is set to CH1 or CH2,
triggering is made by the channel-1 and channe!-2
signals respectively, regardless of MODE @ setting.
Setting the SOURCE select switch to LINE causes
synchronization with commercial power frequency.

(2)
* External Sync
When
the
SOURCE
selection
is
in
EXT,
the
input
sig-
nalat
the
EXT
TRIG
INPUT
(4
jack
becomes
the
trig-
ger.
This
signal
must
have
a
time
or
frequency
relationship
to
the
signal
being
observed
to
syn-
chronize
the
display.
External
sync
is
prefered
for
waveform
observation
in
many
applications.
For
ex-
ample,
Fig.
8
shows
that
the
sweep
circuit
is
driven
by
the
gate
signal
when
the
gate
signal
in
the
burst
signal
is
applied
to
the
EXT.
TRIG
INPUT
jack.
Shows
the
input/output
signals,
where
the
burst
sig-
nal
generated
from
the
signal
is
applied
to
the
in-
strument
under
test.
Thus,
accurate
triggering
can
be
achieved
without
regard
to
the
input
signal
fed
to
the
INPUT
©)
or
(0
jack
so
that
no
further
trigger-
ing
is
required
even
when
the
input
signal
is
varied.
| | EXT. TRIG
Trigger signal
(Gate signal)
|
'
t
,
Input
signal
to
f amplifier, etc.
1
{
|
{
1
Output signal from
amplifier, etc.
Fig. 8
After
the
SOURCE
has
been
set,
the
trigger
point
can
be
set
by
rotating
LEVEL/SLOPE
control
@).
AC:
The
trigger
signal
is
capacitively
coupled,
so
its
DC
component
is
cut,
giving
a
stable
trigger
which
is
not
affected
by
the
DC
component.
With
this
advantage,
this
position
of
the
coupling
switch
is
conveniently
selected
for
ordinary
applications.
However,
if
the
trigger
signal
is
lower
than
10
Hz,
the
trigger
signal
level
becomes
attenuated,
resulting
in
difficulty
in
triggering.
HF Rev:
The
trigger
signal
is
supplied
through
a
low-pass
filter
to
eliminate
the
high-frequency
component
(higher
than
10
kHz),
giving
a
stable
triggering
with low-
frequency
component.
When
high-frequency
noise
is
superimposed
over
the
trigger
signal
as
shown
in
Fig.
9,
the
high-frequency
noise
is
cut
to
provide
a
stable
trigger.
Waveform with high frequency noise
Trigger signa! by HF rejection
Fig. 9
(3)
DC:
Permits
triggering
from
dc
to
over
60
MHz.
Couples
dc
component
of
sync
trigger
signal.
Useful
for
trig-
gering
from
very
low
frequency
signals
(below
10
Hz)
or
ramp
waveforms
with
slow
repeating
dc.
Setting of coupling switch @.
* Triggering Level
Trigger
point
on
waveform
is
adjusted
by
the
LEVEL/PULL
@)
control.
Fig.
10
shows
the
relation-
ship
between
the
SLOPE
and
LEVEL
of
the
trigger
point.
Triggering
level
can
be
adjusted
as
necessary.
SLOPE ‘’—'’ RANGE
SLOPE ‘+’ RANGE +
I\ T\ jm
Fig. 10
* Auto Trigger
When
the
TRIG
MODE
@9
selection
is
in
AUTO,
the
sweep
circuit
becomes
free-running
as
long
as
there
is
no
trigger
signal,
permitting
a
check
of
GND
lev-
el.
When
a
trigger
signal
is
present,
the
trigger
point
can
be
determined
by
the
LEVEL
control
for
obser-
vation
as
in
the
normal
trigger
signal.
When
the
trig-
ger
level
exceeds
the
trigger
signal,
the
trigger
circuit
also
becomes
free-running
where
the
waveform
starts
running.
When
the
TRIG
MODE
is
set
to
NORM
and/or,
when
the
trigger
signal
is
absent
or
the
trig-
gering
level
exceeds
the
signal
there
is
no
sweep.
* Fix
When
the
TRIG
MODE
@)
is
set
to
FIX,
triggering
is
always
effected
in
the
center
of
the
waveform,
eliminating
the
need
for
adjusting
the
triggering
lev-
el.
As
shown
in
Fig.
11-(a)
or
(b),
when
the
TRIG
MODE
is
set
to
NORM
and
the
triggering
level
is
ad-
justed
to
either
side
of
the
signal,
the
trigger
point
is
deviated
as
the
input
signal
becomes
small
which,
in
turn,
stops
the
sweep
operation.
By
setting
the
TRIG
MODE
to
FIX,
the
triggering
level
is
automati-
cally
adjusted
to
the
approximate
center
of
the
wave-
form
and
the
signal
is
synchronized
regardless
of
the
position
of
LEVEL
control
as
shown
in
Fig.
11-(c).
When
the
input
signal
is
suddenly
changed
from
a
square
waveform
to
a
pulse
waveform,
the
trigger
point
is
shifted
extremely
toward
the
‘’—"'
side
of
the
waveform
unless
the
triggering
level
is
readjusted
as
shown
in
Fig.
12-(a).
See
Fig
12-(a)-(2).
Also,
if
the
trigger
point
has
been
set
to
the
‘’—’’
of
squarewave
(Fig
12-(b)-(1))
and
the
input
signal
is
changed
to
a
pluse
signal,
the
trig-
ger
point
is
deviated
and
the
sweep
stops.
When
this
happens,
set
the
TRIG
MODE
to
FIX
and
the
trigger-
ing
is
effected
in
the
approximate
center
of
the
wave-
form,
making
it
possible
to
observe
a
stabilized
waveform.
(Fig
12-(c))
17

(a) \
Trigger point
“NORM”
(b)
Trigger
point
OBIXe
Trigger
point
Fig. 11
LEVEL control
H
(1) | \ [_\ [~ O
ce)
-
+
Trigger
point
Ad ©.
Input signal changed
into a pulse waveform. re ~\
Readjust level
(a) When the trigger level is set
around the center of the waveform.
~
My
(1)
F Trigger point
'
t
\
a ‘
'
bot cceceeen af teat Chat
Sweep stops with no trigger.
(2)
Same level as (1)
(3)
\
Z)
+
Highest level
(b) When the trigger level is set to
the ‘’—’" side of the waveform
(Mode switch set to ‘“NORM‘’)
(4) Triggering without
setting level
(c) Mode switch set to ‘‘FIX’’.
Fig. 12
18
5. Adjust the A SWEEP/TIME DIV control @ to obtain an
appropriate display. Now a normal sweep display is ob-
tained.
(2) MAGNIFIED SWEEP OPERATION
Since merely shortening the sweep time to magnify a por-
tion of an observed waveform can result in the desired por-
tion disappearing off the screen, such magnified display
should be performed using the MAGNIFIED SWEEP.
Using the <® POSITION @ control, adjust the desired por-
tion of waveform to the CRT. Pull the PULL x 10 MAG
control to magnify the display 10 times. For this type of dis-
play the sweep time is the SWEEP TIME/DIV setting divid-
ed by 10.
(3) ALTERNATE SWEEP OPERATION
A sweep and B delayed sweep are usable in an alternating
fashion making it possible to observe both the normal and
magnified waveform simultaneously.
Procedure:
1. Set the HORIZ MODE to A and adjust for a normal wave-
form display.
2. Depress the HOLD OFF control @6) (AFTER DELAY) and
set the HORIZ MODE to ALT. Adjust TRACE SEPATA-
TION @ for easy observation of both the A and B traces.
The upper trace is the non-magnified portion of the wave-
form with the magnified portion super-imposed as an
intensified section. The lower waveform is the intensi-
fied portion displayed magnified.
3. The AREF/DELAY TIME POSITION @) control can be used
to continuously slide the magnified portion of the wave-
form across the A sweep period to allow magnification
of precisely the desired portion of waveform.
4. Set the HORIZ MODE to B to display the INT intensified
portion as a magnified B sweep. (Fig. 14)
5. For Starts AFTER DELAY operation, apparent jitter in-
creases as magnification increases. To obtain a jitter free
display pull the HOLD OFF control out. In this ‘‘Trigger-
able After Delay’’ mode the A trigger signal selected by
the SOURCE switch @) becomes the B trigger source.

r i 1
Magnified
view
of
intensified.
ast
Fig.
14
Magnified
view
of
intensified
zone
above
Note
that
for
this
type
of
operation
both
the
DELAY
TIME
POSITION
and
TRIG
LEVEL
affect
the
start
of
the
B
sweep
so
that
the
delay
time
is
used
as
a
reference
point.
(Fig.
15)
T T T
A Sweep
{_
: 1 r =
Intensified zone to be magnified.
(4)
X-Y
OPERATION
For
some
measurements,
an
external
horizontal
deflection
signal
is
required.
This
is
also
referred
to
as
an
X-Y
meas-
urement,
where
the
Y
input
provides
vertical
deflection
and
X
input
provides
horizontal
deflection.
X-Y
operation
permits
the
oscilloscope
to
perform
many
types
of
measurements
not
possible
with
conventional
sweep
operation.
The
CRT
display
becomes
an
electronic
graph
of
two
instantaneous
voltages.
The
display
may
be
a
direct
comparison
of
two
voltages
such
as
during
phase
measurement,
or
frequency
measurement
with
Lissajous
waveforms.
To
use
an
external
horizontal
input,
use
the
following
pro-
cedure;
1.
Set
the
HORIZ
MODE
switch
to
X-Y
the
position.
2.
Use
the
channel
1
probe
for
the
vertical
input
and
the
channel
2
probe
for
the
horizontal
input.
3.
Adjust
the
amount
of
horizontal
deflection
with
the
CH2
VOLTS/DIV
and
VARIABLE
controls.
4.
The
CH2
(vertical)
POSITION
©
control
now
serves
as
the
horizontal
position
control,
and
the
<>
POSITION
control
is
disabled.
5.
All
sync
controls
are
disconnected
and
have
no
effect.
(5)
VIDEO
SIGNAL
OBSERVATION
The
TV
FRAME/LINE
switch
permits
selection
of
vertical
or
horizontal
sync
pulse
for
sweep
triggering
when
viewing
composite
video
waveforms.
In
the
LINE
position,
horizon-
tal
sync
pulses
are
selected
as
triggers
to
permit
viewing
of
horizontal
line
of
video.
In
the
FRAME
position,
vertical
sync
pulses
are
selected
as
triggers
to
permit
viewing
of
ver-
tical
fields
and
frames
of
video.
When
observing
the
video
waveforms,
stable
display
is
obtained
on
the
screen
regard-
less
the
TRIG
LEVEL
@
control
if
the
TRIG
MODE
switch
to
FIX.
At
most
points
of
measurement,
a
composite
video
signal
is
of
the
(—)
polarity,
that
is,
the
sync
pulses
are
negative
and
the
video
is
positive.
In
this
case,
use
‘’—"’
SLOPE.
If
the
waveform
is
taken
at
a
circuit
point
where
the
video
waveform
is
inverted,
the
sync
pulses
are
positive
and
the
video
is
negative.
In
this
case,
use
“+”
SLOPE.
19

(6) SINGLE SWEEP OPERATION
This mode of display is useful for fooking at non-
synchronous or one time events.
Procedure:
1.
r-- NOTE:
Set the TRIG MODE @0 to either AUTO or NORM. Apply
a signal of approximately the same amplitude and fre-
quency as the signal that is to be observed as the trig-
ger signal and set the trigger level.
. Set TRIG MODE to RESET — observe that the READY
indicator LED lights to indicate the reset condition. This
LED goes out when the sweep period is completed.
. After the above set-up is completed the scope is ready
to operate in the SINGLE sweep mode of operation after
resetting the instrument using the RESET switch. Input
of the trigger signal results in one and only one sweep
and READY indicator LED goes out.
With the HORIZ MODE set to ALT the simultaneous
observation of the A sweep and B sweep waveforms
at SINGLE sweep mode is not possible. Also for ALT
(vertical MODE) mode operation simultaneous obser-
vation is not possible. Set the unit to the CHOP mode
in this case.
[B] READOUT OPERATION (CS-5130 only)
1
CRT surface readout
By rotating the INTEN (READOUT) controller clock-
wise upto the very end, characters are displayed on the
CRT. Adjust the brightness as necessity requires. The
CH1 and CH2 scale factors are displayed in the lower
part of the CRT in accordance with setting of the MODE
select switch @. The sweep scale factor is displayed in
the lower right part. By pulling the < » POSITION/
PULL x 10 MAG switch @9, a tenth scale factor of the A
and B SWEEP TIME/DIV control @ @ is displayed.
NOTE: When the readout values are displayed, brilliance
modulation may influence the real-time waveform
in some cases. In such a case, rotate the INTEN
(READOUT) control fully counterclockwise.
The readout function will be turned OFF, and the
brilliance modulation on the real-time waveform
will disappear.
Cursor measurement
AV1: Set the MODE select switch @ to ALT and the
CURSORS select switch @} to AV1, and two
horizontal cursor lines are displayed on the CRT
and voltage difference between cursor lines cal-
culated in accordance with setting of the CH1
VOLTS/DIV control @ is displayed in the upper
right on the CRT. By setting the CH1 VARIABLE
controller @) to the UNCAL position, voltage ra-
tio is displayed.
Move the cursors to the positions to be measured
with the AREF controller @) and A controller @.
20
AV2:
AT:
1/AT:
Set the CURSORS select switch @ to AV2, vol-
tage difference in accordance with the CH2 range
setting is displayed in the upper right on the CRT
similarly with the above AV 1.
Set the CURSORS select switch @ to AT, and
two vertical cursor lines are displayed on the CRT
and time difference between the cursor lines cal-
culated based on the A sweep scale factor dis-
played in the lower right is displayed in the upper
right. By setting the SWEEP VARIABLE controller
@) to the UNCAL position, time ratio is displayed.
Set the CURSORS select switch @3 to 1/AT, and
two vertical cursor lines are displayed on the CRT
and frequency between the cursor lines calculat-
ed based on the A sweep scale factor displayed
in the lower right is displayed in the upper right.
By setting the SWEEP VARIABLE controller @) to
the UNCAL position, phase difference is dis-
played.
